BETAFPV LiteRadio 3 User manual

LiteRadio 3 Radio Transmitter
BETAFPV Congurator Suppoed

01
The front side of the radio transmitter.
● Nano module bay for external RF TX module.
● Suppo BETAFPV Congurator for updating, conguring and tuning.
● 8 channels in total.
LiteRadio 3 is a remote control radio transmitter designed primarily for RC models,
including multicopters, airplanes. It gives you more than you ever thought possible
from an ent level 8-channel radio.
● USB Joystick suppo for most practice simulator.
● New designed joystick gimbal for longer usage life.
● Provide ExpressLRS 2.4G protocol version and Frsky protocol version for option.
● Built-in 2000mAh batte and USB charge supported.
LED Ring
Power Button
Throttle Joystick Direction Joystick
Switch A
Switch BSwitch C
Switch D

02
1.Button Functions
● Power Button: Turn the radio transmitter o/on.
● SETUP Button: Enter joystick calibration mode after radio transmitter is powered
on.
● BIND Button: Enter binding mode after radio transmitter is powered on.
There are three buttons on LiteRadio 3 radio transmitter.
2.Power On/O
POWER ON: Long press the power button on the radio transmitter for 3 seconds
until it beeps three times (do re mi) then release. The radio transmitter LED ring will
ash red quickly, then remain blue.
POWER OFF: A long press of the power button on the radio transmitter will turn it
o after three beeps (mi re do).
3.LED Indicator and Buzzer
The LED ring indicates the working status of the radio transmitter.
The back side of the radio transmitter.
SETUP BIND
Audio Po Type-C Po
NANO Bay
NC
VCC
GND
CRSF.po

03
4.Binding the Receiver
There are the steps to make the LiteRadio 3 enter binding status.
1. Power on the radio transmitter󲞚and wait for its system to load completely. LED
ring will be solid blue if done correctly.
2. Press the bind button on the back of the radio transmitter to enter binding stutas.
The LED ring will be red and ash quickly.
3. The LED ring will change to solid blue 5 seconds later when radio transmitter exits
binding status. If not bind successfully, repeat the󲞚process󲞚above.
5.Switching Protocol
Note: Switching internal protocol is only available for Frsky version radio transmitter.
ExpressLRS version can only switch to the external TX module.
The Frsky version could suppo 4 dierent internal protocols, including Frsky D16
FCC, Frsky D16 LBT, Frsky D8 and Futaba S-FHSS, it also suppos. The protocol is
indicated by the ashing times of the LED when power on, before the buzzer
alarms.
Reason Solution
Red light solid on The throttle joystick or
switches are not in the lowest
Lower throttle and switches
to the lowest position.
Turn to blue then.
Red light ashing quickly
Blue light ashing slowly
Red light breathes slowly
Green light breathes slowly
The radio transmitter
is binding
Batte reaches the low
voltage limit
On charging
Charge complete
Charge the transmitter
Wait for completing binding
State of the LED Ring
The buzzer will alarm three times, which indicates a low batte and needs to be re-
charged.

04
LiteRadio 3 radio transmitter has a built-in 2000mAh batte. It indicates low batte
and needs to be re-charged if blue light ashes slowly and buzzer beeps
continuously. Below charging method for reference:
● The LED ring breathes in red means charging, while in green means fully charged.
● Turn o the radio transmitter.
● Plug in radio transmitter with adapter by USB cable (5V output adapter is
allowed).
6.Charging
Note: LiteRadio 3 Frsky version only work with D16 ACCST 1.X Frsky protocol. So if you use a Frsky
receiver with D16 ACCST 2.X version or ACCESS version, binding will fail.
3. Then the ash color and times of the LED before buzzer alarms will change,
according to the tables above.
1. Power the radio transmitter o;
2. Press and hold the BIND button while power the radio transmitter back on;
To change protocols and TX module, here are the steps:
Red Flash once Internal Frsky D16 FCC (ACCST 1.X Version)
LED Status Protocol Version
Red Flash twice Internal Frsky D16 LBT (ACCST 1.X Version)
Red Flash Three Times Internal Frsky D8
Red Flash Four Times Internal Futaba S-FHSS
Purple Flash Three Times Quickly Internal TX Module O and Run External TX Module
Frsky Version
Red Flash once Internal ELRS
LED Status Protocol Version
Purple Flash Three Times Quickly Internal TX Module O and Run External TX Module
ExpressLRS Version

05
7.HID Joystick
It is the safest and quickest method to get staed by using model practice simulator
for staers. LiteRadio 3 radio transmitter suppos most of simulators on market
with comprehensive conguration.
The continue working time for full charged batte is about 15 hours.
Output 5V
Type-C Data Cable
Type-C Data Cable

06
8.Joystick Calibration
The joystick data may oset after it has used for a period of time (if joysticks is hit
by physical). User need to re-calibrate joysticks based on following steps.
● After powering on, press SETUP button on the back of remote control radio
transmitter, it hears two "Bee Bee" sounds, and red LED ash quickly (two ashes
each time), which means remote control radio transmitter entered calibration mode.
● Move throttle joystick and direction joystick to middle position, press SETUP
button again, wait until the buzzer beep three "Bee Bee Bee" sounds, red LED light
ashes quickly (two ashes each time), which indicates joystick data has been
acquired and enter into the bounda value calibration mode.
● Slowly rotate the throttle and direction joystick twice around the bounda of the
● Connect the transmitter to computer via USB data cable. Wait for the LED ring
breathes in red or green.
● Turn o radio transmitter.
● Install driver from PC automatically, prompt box pops up after successful
installation. Then, radio transmitter works as joystick human inteace device (AKA
HID device) normally.
Operation steps below:
User needs to manually install driver if PC doesn't install automatically or installed
incorrectly.
DO NOT power on the transmitter rst and connect it to the PC. The USB po is invalid in this
situation.
Other devices
Bluetooth & other devices
BETAFPV JoyStick
Setting up a device
We're setting up 'BETAFPV JoyStick'.

07
9.BETAFPV Congurator
BETAFPV Congurator is utility designed to simplify updating, conguring and
tuning the radio transmitter.
Download address: https://github.com/BETAFPV/BETAFPV_Congurator/releases
Remove the cover on the back of the transmitter and there is a label, comes with "BETAFPV
Congurator Suppoed".
How to recognise if your radio transmitter suppos the BETAFPV Congurator?
DO NOT power on the transmitter rst and connect it to the PC. The USB po is invalid in this
situation.
How to enter the radio transmitter conguration page:
● Turn o the radio transmitter.
● Click the "Connect Radio Controller" button on the top right of the page.
● Open the BETAFPV Congurator program in your computer and switch to the
congurator page for radio transmitter.
● Connect the transmitter to computer via USB data cable. Wait for the LED ring
breathes in red or green.
joysticks(counterclockwise/clockwise), then press SETUP button again, it hears a
long ''Bee''sound about 3 seconds. And the red LED light stops ashing, indicating
that joystick calibration is complete successfully.

08
● 内置2000mAh电池，支持USB充电。
● 提供ExpressLRS 2.4G协议版本，Frsky协议版本供客户选择；
LiteRadio 3作为该系列中新的成员，将带来更多更新的功能。
● 支持8通道；
LiteRadio 3遥控器是一款模型进阶需求的遥控器。BETAFPV LiteRadio系列遥控器从
2020年发布以来，成为深受广大模型爱好者喜欢的手柄遥控器之一。
● USB Joystick模式支持绝大部分模型模拟器；
● 使用新版本高寿命的电位器摇杆；
● 支持外接Nano高频头扩展；
● 支持BETAFPV Congurator上位机调参和升级；
LiteRadio 3遥控器正面如下图所示。
油门摇杆 方向摇杆
电源键 指示灯
拨杆SB
拨杆SA
拨杆SC
拨杆SD

09
1.按键功能介绍
● 开机键：长按开机/关机。
● SETUP键：遥控器开机状态，短按后遥控器进入摇杆校准模式。
遥控器上有3个按键，其功能如下：
● BIND键：遥控器开机状态，短按后遥控器进入对频模式。
2.开机/关机
● 开机状态下，长按遥控器电源键3秒，直到听到蜂鸣器发出三声响（mi re do），同时
红色LED灯快速闪烁，遥控器关机成功。
● 关机状态下，长按遥控器电源键3秒，直至听到蜂鸣器发出三声响（do re mi），同时
红色LED灯亮起，然后变成蓝色常亮，遥控器开机成功。
3.LED提示灯和提示音
遥控器开关按键下有一颗RGB LED提示灯，用于提示遥控器的常见状态。
LiteRadio3遥控器背面如下图所示。
SETUP按键 BIND按键
音频接口 Type-C接口
NANO高频头接口
NC
VCC
GND
CRSF.po

10
4.遥控器绑定接收机
3. 接收机进入对频状态，与遥控器对频；
在开机状态下，按下遥控器底部的BIND按键，遥控器将进入绑定状态，该过程为持续
5秒的红灯闪烁，待停止闪烁后，绑定过程结束。
1. 遥控器开机，确保LED灯环处于蓝色常亮；
2. 按一下遥控器底部的BIND按键，遥控器正面的电源按键灯会呈现红色闪烁，此时遥控
器进入时间为5秒的对频状态；
4. 5秒之后遥控器自动退出对频状态，检查遥控器是否对上接收机；如果没有，请重复
上面第二步操作。
5.遥控器协议查看与切换
关机状态下，按电源键开机，在BB响发出声音之前，可以看到LED闪烁，闪烁颜色及次
数代表当前发射模块及协议版本，具体如下：
注意：内置协议切换只适用于Frsky协议遥控器。ExpressLRS协议遥控器，内置协议不
可以切换。
指示灯状态 状态说明 解决办法
红色常亮 开机时油门杆不在最低位 将油门杆拨到最低位
红灯快闪
红灯渐变闪烁
处于对频过程中
充电中
等待对频完成
蓝色慢闪
绿灯渐变闪烁
电池电压过低
充电完成
给遥控器充电
遥控器内置了一个蜂鸣器，当它连续重复报警三次时，说明电量过低，需要给遥控器充
电。

11
6.低电量警报及充电
● 关闭遥控器；
● 红灯渐变闪烁，表示正在充电中；绿灯渐变闪烁，表示充电结束。
● 使用USB线连接遥控器和适配器（5V输出的适配器即可，例如手机充电器）；
遥控器已经内置了2000mAh的电池，无需再外接电池。蓝灯慢闪烁，蜂鸣器连续响起，
表示遥控器电池电量较低，需要重新充电。充电方式如下：
如何切换协议：
在关机状态下，先按住遥控器底部的BIND按键，同时按电源键开机，此时LED灯颜色和
闪烁次数将发生变化，LED灯闪烁完毕协议即切换成功，其闪烁次数表示下次开机的协
议版本。
注意：LiteRadio 3 Frsky版本只能够支持D16 ACCST 1.X版本的协议。如果使用Frsky官方接收机，且
该接收机为D16 ACCST 2.X或者ACCESS协议，则无法对频连接使用。
灯光颜色及闪烁次数 发射模块及协议版本
ExpressLRS协议遥控器
红灯闪烁一次 内置 ELRS
紫灯快速闪烁三次 内置发射模块关闭，外置发射模块开启
灯光颜色及闪烁次数 发射模块及协议版本
Frsky协议遥控器
红灯闪烁一次 内置 Frsky D16 FCC（ACCST 1.X 版本）
红灯闪烁两次 内置 Frsky D16 LBT（ACCST 1.X 版本）
红灯闪烁三次 内置 Frsky D8
红灯闪烁四次 内置 Futaba S-FHSS
紫灯快速闪烁三次 内置发射模块关闭，外置发射模块开启

12
7.HID Joystick模式使用
在连接个人电脑后， LiteRadio 3遥控器可作为USB游戏手柄使用，可以用来练习模型模
拟器。具体步骤如下：
电池充满，关机放置，可以保证 30天电池电量仍保持在80%左右。
电池充满，可以连续使用 15小时左右；
输出5伏
Type-C数据线
Type-C数据线
● 遥控器关机；
● 使用一根USB数据线连接遥控器和PC电脑，遥控器LED变为红色或者绿色渐变闪烁；

13
8.摇杆校准
遥控器在使用一段时间之后，例如摇杆受到较重的物理撞击，可能会出现摇杆值发生偏
移的情况。这个时候可以通过校准摇杆值，确保其摇杆值处于中位。
● 将两边的摇杆都移动至中间位置，再次按一下SETUP按键，待蜂鸣器持续发出滴滴滴
声（3声），同时红色LED灯快速闪烁（每次闪烁两下），表示摇杆中值已经校准完毕，
并进入边界值校准。
● 拨到摇杆，使其环绕摇杆边界缓慢转动两圈（逆时针/顺时针都可以），接着再次按一
下SETUP按键，再听到蜂鸣器发出一声长时间滴声（大概3秒），且红色LED灯停止闪
烁，表示摇杆校准完毕。
● 在开机状态下，按一下遥控器背面的SETUP按键，待听到蜂鸣器持续的发出滴滴声
（2声），同时红色LED快速闪烁（每次闪烁两下），表示进入校准模式。
● PC会自动安装驱动，驱动安装成功后弹出提示框，说明电脑已经成功识别到此遥控器
并可以正常使用。
若无法正常识别出遥控器，则可能是电脑没有自动安装驱动，或者识别了错误的驱动程
序，需要重新安装驱动。
注意：遥控器开机状态下连接到电脑，USB口无信号输出，无法使用Joystick功能。

14
9.BETAFPV Congurator基本使用
BETAFPV Congurator可以用来对飞控或者遥控器进行参数配置，固件升级。
注意：遥控器开机状态下连接到电脑，USB口无信号输出，无法使用BETAFPV Congurator。
如何判断手里的遥控器是否支持BETAFPV Congurator上位机调参？
● 取下遥控器的Micro接口后盖，可以看到有一张铭牌，上面写着BETAFPV Congurator Suppoed。
注意：老版本遥控器无法使用BETAFPV Congurator上位机调参。
下载地址：https://github.com/BETAFPV/BETAFPV_Congurator/releases
● 遥控器关机；
● 用USB数据线将遥控器连接到电脑，LED灯红色或者绿色渐变闪烁，遥控器被识别为
HID设备；
● 打开BETAFPV Congurator，切换到遥控器配置程序页面；
● 点击右上角“连接遥控器”按钮，进入遥控器参数设置页面。
如何进入遥控器参数配置页面：
可以进行的配置内容包括：
● 各通道的混控，微调等切换。
● 切换摇杆模式（即日本手、美国手）；
● ExpressLRS系统参数配置（射频模块为ExpressLRS系统时有效）；
● 射频模块的配置（开启关闭内置、外置射频模块）；
