BETCO crewman dc2000 E83018-00 User manual

E83018-00
CREWMAN

DC2000
%URZQ$YHQXH7ROHGR2KLR-0127
´'XVW&RQWURO
Electric Burnisher
2SHUDWRU¶V 0DQXDO
Parts Schematic
Customer Service: 888-GO-%(7&2)D[-445-7HFKQLFDO6HUYLFH-856-ZZZEHWFRFRP
1

General Instructions for the CREWMAN

DC2000
Operating Instructions
Check machine for damage to cord or plug.
8VHRQO\+L6SHHG%XUQLVKLQJSDGV´RU´GLDmeter.
To install or change the pad:
1. Unplug the machine.
2. Tip the machine back on the wheels.
3. Remove the center-lock.
4. Center the pad on the pad driver.
5. Replace the center-lock and tighten securely.
To operate the machine:
1. Plug into a grounded outlet.
2. Release the handle and lower it.
3. The handle can be locked into a comfortable position
for the operator or used free floating.
4. Press the safety lever and squeeze the trigger to start
the machine.
5. Do not operate in one place as damage to the floor or
finish could result.
6. The machine should be operated in the green area
of the meter on the handle. Turn the knob on the
back to increase or decrease the pad pressure.
7. Do not operate the machine with the handle in the
upright position.
8. Remove the pad after every use.
9. Use only new or clean pads and reverse them
as needed.
Specifications:
Length - 30 in.
Width - 22 in.
Height - 50 in.
Weight - 69 Lbs.
Pad Speed - 2000 RPM
Pad Diameter - 20 in.
Drive motor - 1.5 HP, 120v, 15 A, 50/60 HZ
Cord - 14-3 ST, 75 ft.
Safety
Read and understand the manual before operating
this machine.
'RQRWRSHUDWHLQH[SORVLYHDUHDVRUXVHQHDU
flammable liquids or gases.
$WWDFKRQO\WRSURSHUO\JURXQGHGRXWOHW
'R not expose to rain, store indoors.
'RQRWRSHUDWHWKHPDFKLQHZLWKDGDPDJHG
cord or plug.
'RQRWEORFNRUGLVFRQQHFWWKHVDIHW\OHYHU
Do not leave the machine plugged in
while unattended.
8QSOXJWKHPDFKLQHEHIRUHVHUYLFLQJ
'RQRWSXWILQJHUVXQGHUWKHSDGRUSDGKROGHU
Unplug the machine before installing or
removing the pad.
2 8VHRQO\ZLWK+L6SHHG%XUQLVKLQJSDGV
Maintenance
To maintain appearance - wipe the machine with a damp cloth
after use.
Warning - Unplug the machine before servicing
The operator should check the following at 250 hour intervals:
1. Check the motor brushes for wear or
excessive arcing.
2. Check the cord and electrical system.
3. Check the safety lockout on the trigger.
4. Check wheels and bearings.
5. Check the Dust shroud and brush seal.
6. Check the Dust bag before each use.
BETCO US WARRANTY POLICY
10 Year Coverage
Subject to the conditions stated below, Betco warrants parts and labor on ro-
tationally molded polyethylene tanks/housings and injection molded vacuum
head assemblies to be free from defects in materials and workmanship for a
period of ten years to the original purchaser.
3 Year Coverage
Subject to the conditions stated below, Betco warrants parts and labor on all
other Betco components to be free from defects in materials and workman-
ship for a period of three years to the original purchaser.
1 Year Coverage
Subject to the conditions stated below, Betco offers a limited warranty on
parts and labor on the following equipment, parts and accessories to be free
from defects in material and workmanship for a period of one year to the
original purchaser. DM Series Vacuums: #85506-00, #85507-00 Bac Pac Lite
Vacuum: #85903-00 FiberPRO®Floor Dryer: #85507-00 WORKMANSeries
Vacuums: #85024-00, #85025-00, #85026-00, #85027-00 CV100T Vacuum:
#85023-00. All Tools and Accessories/All Battery Chargers/All Batteries are
pro-rated for 1 year.
Allowable Travel Time Warranty Reimbursement
Eligible equipment: All battery and propane powered equipment products.
Warranty period: 90 days from date of sale to the original purchaser. A maxi-
mum 60 mile round trip at 44 cents per mile will be allowed for warranty
consideration.
Propane Machine Warranty:
Honda engines are warranted by Honda for a period of 2 years against manu-
facturer defect. Kawasaki engines are warranted by Kawasaki for a period
of 2 years against manufacturer defect. All other components (except wear
items)* are warranted by Betco for a period of 3 years.
*Wear items exempt from warranty consideration include but may not be
limited to: power cords, transport wheels, vacuum bags, belts, squeegee
blades, pad drivers, clutch plates, handle grips, filters, screens, throttle
cables, brushes and carbon brushes.
Subject to the conditions and excep-
tions stated in this warranty, Betco warrants the Betco products to be free
from defects in material and workmanship, under normal use and service,
for the periods listed under the warranty policy to the original purchaser. At
any time during the warranty period, Betco will furnish replacement parts for
the Betco products to the original purchaser. Such parts will be furnished and
charged including transportation costs, to the original owner through any
Betco authorized Service Distributor. If the original part is returned within the
warranty policy period from date of delivery for inspection by Betco and is
found to be defective, the owner will be credited for the cost of replacement
parts plus shipping and handling. Replacement parts that have become de-
fective through wear or abuse are not included in this warranty.This warranty
does not apply to damage or defect caused by accident, misuse, negligence,
fire or to any Betco product which has been serviced or repaired by other
than an authorized Betco Service Distributor or Betco factory personnel.
This warranty is void if products are used for any purpose other than that
which was intended. There are no other warranties expressed or implied. In
no event shall Betco be liable for incidental or consequential damages or any
damage to person or property. (Please note some states do not allow the
exclusion or limitations for incidental and consequential damages.)

BURNISHER MODEL CREWMAN

DC2000
ref# part# NU# description
1 E81117 310190 Base, Steel
2
E81174 310191 Plate, Motor Mount
3
E81173 310192 Bracket, Dust Control Burnisher
4
E81172 310193 Bracket, Spring Adjustment
5
E81089 110122 Bolt, 5/16 - ;´
6
E81063 110148 1XW´1\ORN
7
E81085 110275 Bolt, Shoulder 1/2 x 3/8
8
E83145 110103 :DVKHU´1\ORQ
9
E81076 110276 Nut, 3/8 Nylok Thin
10
E83651 310116 $[OH[´
11
E81124 310114F :KHHO´
12
E83143 110144 &DS$[OH´
13
E81126 310199 :KHHO&DVWHU´
14
E81082 110274 Bolt, 1/4 - 20 X 3/8 with patch
15
E81713 110142 :DVKHU)ODW´
16
E81132 110273 6SULQJ´
17
E81393 110278 5RG7KUHDGHGVSULQJDGMXVWPHQW´
18
E81079 110293 1XW´-13 Jam
19
E281109 210146 Motor, 1.5 HP 115v 2000 RPM
Not Shown, Carbon Brush, Motor E85053, Rectifier E85042
20
E81062 110119 :DVKHU)ODW´866
21
E81066 110124 :DVKHU/RFN´6SOLW
22
E81080 110125 Bolt 3/8 - [´*U
23
E81144 310195 Shroud, Dust
24
E83657 310202 Brush, Extrusion, Skirt DC Burnisher
25
E83425 110150 Screw, 1/4 - ;´3K7U+G
26
E81173 110142 :DVKHU)ODW´
27
E81078 110143 :DVKHU/RFN´6SOLW
28
E81071 110205 3OXJ3ODVWLFUDWFKHW´
29
E81149 310200 Pad Driver, DC Burnisher
30
E81072 110152 %ROW;´
31
E81062 110119 :DVKHU)ODW866´
32
E81067 110120 :DVKHU/RFN´6SOLW
33
E81142 310196 Cover, DC Burnisher
34
E81143 310203 Cover, Dust Bag DC Burnisher
35
E81074 110290 Screw, 10-24 X 1/2 Truss Head Zn
36
E83788 310204 Bag, Dust, Cloth
37
E83720 110291 Decal, Brush Pressure DC Burnisher
38
E81523 110227 Screw, 8-32 x 3/8 Ph Tr Hd
39
E81141 310152 Cover, Motor
40
E81229 110279 Knob, black, DC Burnisher
41
E83269 110168 Washer, Spring 1/2 in.
42
E81150 310108 Pad Holder, for replacement only
43
E81088 110277 Nut, 1/2 x 13 thin nylock
44
E81604 110338 *DVNHWV[[´´
3

BURNISHER MODEL CREWMAN

DC2000 PARTS
ref# part# NU# description
1 E83523 110146 Nylon Cable Tie
2
E83132 210105 Cord, Handle, 14-3
3
E83789 110299 1XW(OHFWULFDO&RQGXLW´
4
E83790 210121 Cord, 50 Feet, 14-3ST
5
E83496 210104 Strain Relief for Replacement
6
E81064 110178 Bolt, Hex. 1/4-20 x 3/4
7
E83520 110115 Nut, Nylock, 1/4-20
8
E83127 310118 Grip
9
E83651 110116 Screw, Phillips, No. 6x1
10
E83426 110140 Screw, Phillips, 1/4-[´
11
E83130 110149 Spring
12
E83270 110163 Clip, Spring
13
E85032 210102A Switch
14
E83129 310119 Safety Lock
15
E82752 310120 Trigger, Switch
16
E83325 310121 Cover, Switch Box
17
E82750 310122B Switch Box, Handle, Dual Speed
18
E81105 310153 Plate, Switch
19
E83451 310124 Handle Tube, 7/8 x 16
20
E81065 110318 Bolt, Hex. 1/4-[´Grade 5
21
E81070 110319 Nut, Nylock, 1/4-20
22
E83519 210106 *URPPHW´,'
23
E83137 310128 Cord Hook
24
E83135 110112 Oval Washer
25
E83133 310189 Handle, Cam Lock Assembly
26
E81379 110169 Washer, Spring, 3/8
27
E81063 110148 Nut, Nylock, 5/16-18
28
E83145 110103 Washer, Nylon
29
E81077 110154 Bolt, Shoulder, 3/8 x 1
30
E83269 110168 Washer, Spring, 1/2
W
31 E83143 110144 Caps, Axle, 0.5
METER MOTOR
B B
32
G
33
E83136 310130 Bracket, Flat Handle
W B G
34 E83711 310127A Handle Tube
120 V ELECTRICAL SCHEMATIC
35 E81394 110287 $[OH[´
36
E81216 210153 Meter, 15 Amp.
%URZQ$YHQXH7ROHGR2KLR-0127
4
Customer Service: 888-GO-%(7&2)D[-445-7HFKQLFDO6HUYLFH-856-Zww.betco.com
E83018-00 Feb09U
E82717 310126A Handle attachment, Welded
Cam Lock Assembly not shown EP50064
