BETCO Stealth ASD26BT Product manual

1
E87026-00
E88064-00
STEALTH
STEALTH™
ASD26BT
ASD26BT
26” Automatic Scrubber
with Traction Drive
1001 Brown Avenue • Toledo, Ohio 43607-0127
Customer Service: 888-GO-BETCO • Fax: [phone] • Technical Service: 877-856-5954 • www.betco.com
Operator and Parts
Manual

RECEIVING THE MACHINE
Immediately check, when receiving the machine, that all the
materials indicated on delivery documents have been
received and also that the machine has not been damaged
in transit. If it has been damaged, this damage must be
immediately reported to the shipper and also to our
customer’s service department. Only acting promptly in this
manner will make it possible to receive missing material and
to be compensated for damage.
SERIAL # PLATE
INTRODUCTION
This is an automatic scrubber which, via the mechanical
action of the rotating brush and the chemical action of a
water/detergent solution, can clean any type of flooring. As it
advances, it also collects the dirt removed and the detergent
solution not absorbed by the floor.
The machine must be used only for this purpose. Even
the best machines will only work well if used correctly and
kept in good working order. We therefore suggest you read
this instruction booklet carefully and re-read it whenever
difficulties arise while using the machine. If necessary,
remember that our assistance and customer service
(organized in collaboration with our dealers) is always
available for advice or direct intervention.

TECHNICAL DESCRIPTION UM
Rated power HP (W) 1.7 (1260)
Working width In (mm) 26.0 (660)
Rear squeegee width In (mm) 37.3 (948)
Work capacity ft
2
/h (m
2
/h) 31,970 (2970)
Water consumption g/ft
2
Brush & Pad (diameter)
∅
in
(
mm
)
14.0 (355)
Brush RPM RPM 225
Brush pressure lb (Kg) 99.2 (45)
Brush motor V / HP (V / W) 24 / 0.75 (24 / 560)
Drive Type Automatic
Traction motor V / HP (V / W) 24 / 0.20 (24 / 150)
Forward movement speed mph (km/h) 0-1.9 (0-3)
Maximum grade 10%
Vacuum motor V / HP (V / W) 36 / 0.74 (36 / 550)
Vacuum motor suction inches of water (mbar) 22.1 (55)
Solution tank capacity Gal (l) 14.5 (55)
Recovery tank capacity Gal (l) 15.9 (60)
Weight of machine (excluding batteries) lb (Kg) 253.5 (115)
Batteries V / Ah 12 / 155 (2)
Charger V / A 24 / 12
Battery compartment dimensions
(Length / Height / Width) in x in x in
(mm/mm/mm) 13.8 x 12.0 x 14.2
(350 / 305 / 360)
Machine dimensions
(Length / Height / Width) in x in x in
(mm/mm/mm) 54.3 x 41.5 x 26.8
(1380 / 1053 / 680)
Noise level dBA 58
Vibration level ft/s
2
(m/s
2
)5.9 (1.79)

SYMBOLS USED ON THE MACHINE
Solution valve symbol
Used to indicate the water regulation switch
Battery charge gauge
Battery symbol
Open book symbol
Used to tell the operator to read the manual before using the machine
Maximum solution temperature
Located near the solution tank inlet

GENERAL SAFETY REGULATIONS
The regulations below must be carefully followed in order to avoid harm to the operator and damage to the machine.
Read all labels on the machine carefully. Do not cover them for any reason and replace them immediately if they become damaged.
The machine must be used exclusively by authorized and trained personnel.
When operating the machine be careful of other people and of children in particular.
The machine is not suitable for cleaning carpets.
The power cable outlet must be provided with a proper ground.
Avoid damaging the power cable or the battery charger by crushing, bending or stressing it.
Whenever the power cable of the battery charger is damaged, immediately contact a BETCO service center.
Do not mix different types of detergent as this may produce harmful gases.
Do not set containers of liquid on the machine.
Machine storage temperature is between -10°F and 130°F, never store outside under humid conditions.
Operating conditions: room temperature between 32°F and 100°F with relative humidity between 30% to 95%.
Only use the machine in closed areas and do not expose it directly to rain.
Never use the machine in an explosive environment.
Do not use the machine as a means of transport.
Never use acid chemicals which could damage the machine.
Avoid running the brushes with the machine stopped: this could damage the floor.
Never vacuum up flammable liquids.
Never use the machine to gather dangerous powders.
Use a powder fire extinguisher in case of fire. Do not use water.
Do not hit against shelving or scaffolding when there is a chance of falling objects. The operator must always be equipped with the appropriate
safety device (gloves, shoes, helmet, glasses, etc.)
Do not use the machine on surfaces with an inclination greater than the one shown on the plate.
The machine is designed to wash and dry floors simultaneously. Different operations should only be carried out in areas where passage of
unauthorised people is prohibited. Signal the presence of wet floors with suitable signs.
If the machine does not work properly, check this is not caused by failure to carry out routine maintenance. Otherwise, request the intervention
of the BETCO technical assistance center.
When replacing parts ask for ORIGINAL spare parts from your Authorized BETCO Dealer and/or Retailer.
Always switch off the machine and disconnect the battery connector whenever maintenance is performed.
Never remove guards that require tools for removal.
Never wash the machine with direct or pressurized jets of water or with corrosive substances.
Have your BETCO service center check the machine once a year.
To prevent the formation of scale in the solution tank filter, do not fill the tank with detergent solution hours before using the machine.
Before using the machine make sure that all doors and covers are positioned as shown in this operating and maintenance manual.
Dispose of consumables in accordance with existing laws and codes.
When your BETCO machine is ready to be retired its entire component materials must be disposed of properly. They contain oils and
electronic components. The machine itself was built using totally recyclable materials.
Use only brushes furnished with the machine or those specified in the user's manual (page 19). Use of other brushes can compromise safety.
When removing the battery, unplug the battery connection, unplug the charger and disconnect the battery terminals.
Before recycling the machine, remove the battery.
The battery and the battery charger must be disposed of in accordance with existing laws and codes.
The machine is not intended for use by children and people with reduced physical, sensorial or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning the use of the machine by a person responsible for their safety.
Children must be supervised to ensure that they do not play with the machine.

MACHINE PREPARATION
1.HANDLING THE PACKED MACHINE
The machine is contained in specific packaging.
It is not possible to place more than two packages on top of each other.
The total weight is 220 lb (100kg)
The overall dimensions of the package are:
A: 49.6 in (1260mm)
B: 28.4 in (720mm)
C: 65.4 in (1660mm)
2. UNPACKING THE MACHINE
1. Remove the outer packaging
2. The machine is fixed to the pallet with wedges which block the wheels
3. Remove these wedges
4
.
Use a ramp to get the machine down from the pallet, pushing it backwards.
Avoid violent blows to the base
5. Keep the pallet for any future transport needs

MACHINE PREPARATION
3. BATTERY INSTALLATION
The machine will be supplied with a battery charger and either two 12V Wet or
A
GM batteries.
The batteries must be housed in the battery tray in the battery compartment
beneath the recovery tank.
To insert the batteries you must:
1. Lower the squeegee and base
2. Open the rear hinge that secures the tank
3. Rotate the recovery tank as far as it will go, using the side handle
WARNING: To avoid acid spillage you can use sealed batteries.
WARNING: Perform one battery charging cycle before using the
machine.
4. TYPE OF BATTERY
To power the machine you can use:
• Wet batteries
• AGM batteries
• Gel batteries
OTHER TYPES MUST NOT BE USED.
The maximum dimensions and weight are:
Width 6.8 in (172mm)
Length 14.2 in (360mm)
Height 11.2 in (285mm)
Weight 97 lb (44kg)
WARNING: Your charger must be set according to the type of
battery you install. Call BETCO customer service to ensure
correct charger setting after replacement batteries are installed.
The batteries must be handled using lifting and transportation means suitable for
the weight and dimensions.
They must be lifted by the handles on the upper part.
They must be connected together in series, to obtain an overall voltage of 24V on
the lugs.
The electrical connection operations must be carried out by certified trained
personnel.
2
3

MACHINE PREPARATION
5. BATTERY MAINTENANCE
For maintenance and recharging, follow the instructions provided by the battery
manufacturer.
6. BATTERY DISPOSAL
When the battery reaches the end of its working life, it must be disconnected by
certified professional, then lifted (using the handles and suitable lifting device) to
remove it from the battery compartment.
DEAD BATTERIES ARE CLASSIFIED AS HAZARDOUS WASTE AND MUST BE
DISPOSED OF AT AUTHORISED BATTERY DISPOSAL COMPANY.
7. CONNECTING THE BATTERY CHARGER
Beneath the recovery tank there is the battery connector (2), the battery charger
connector must be plugged into. Disconnect the battery plug and plug the charger
into the machine plug.
WARNING: This process must be carried out by qualified
personnel. The incorrect or faulty connection of the cables to the
connector can seriously harm people and damage objects.
2
8. BATTERY CHARGING
Perform one complete battery charge cycle before using the machine.
A
void totally discharging the battery! This can cause permanent damage to it.
Recharge as soon as the battery discharge light starts to flash.
WARNING: Never leave the batteries completely discharged, not
even if the machine is not being used. This can cause permanent
damage to them. While recharging, keep the recovery tank raised,
supporting it with the prop as shown in the figure. Ensure the
battery charger is suitable for the batteries installed, in terms of
capacity and type.
Danger of exhalation of gas and leakage of corrosive liquids.
Danger of fire: do not go near with open flames.

MACHINE PREPARATION
9. CONNECTING THE BATTERY CONNECTOR
The battery connector (2) must be connected to the machine connector (1) 2
1
10. BATTERY CHARGE INDICATOR
The battery indicator uses LEDs and has 8 positions (7 yellow - charged batteries,
and 1 red - run down batteries).
WARNING: a few seconds after the red indicator light comes on,
the brush motor switches off automatically. With the remaining
charge it is possible to complete the drying process before
recharging.

MACHINE PREPARATION
11. INSTRUMENT PANEL COMPONENTS
The instrument panel components are identified as follows:
1- Paddles to activate brushes / traction (located beneath the grip)
2- ON/OFF key switch
3- Battery level / hour-counter display
12. REAR COMPONENTS
The rear components are identified as follows:
1- Pedal to raise the brushes
2- Water level tube
3- Solution tank water inlet cap
4- Drainage tube with recovery tank cap
5- Hinge to close the tanks
6- Compartment for storage
7- Lever to raise the squeegee
8- Brake lever
9- Solution filter
13. SIDE COMPONENTS
The side components are identified as follows:
1- Lever for manual regulation of clean water outlet
2- Handle to raise the recovery tank
3- Handle to raise the suction unit
4- Upper storage compartment
14. ASSEMBLING THE SQUEEGEE
For packaging reasons, the squeegee is supplied disassembled from the machine,
and must be assembled as shown in the figure, inserting the small column of the
squeegee into the coupling mechanism until the lever is triggered.
Insert the squeegee tube in the appropriate sleeve, ensuring that the tube lies to
the right of the lifting cable.
2
1
2
5
8
3
4
6
7
9
1
2
3
4
3
1

MACHINE PREPARATION
15. ADJUSTING THE SQUEEGEE HEIGHT
The height of the squeegee must be adjusted based on wear and tear of the
squeegee. To do this, turn the knob (2) counter clockwise to raise the squeegee,
and clockwise to lower it.
Note: the right and left wheels must be adjusted to the same level, so the
squeegee can work parallel to the floor.
2
1
16. ADJUSTING THE SQUEEGEE INCLINATION
During working operation, the rear squeegee is slightly tilted backwards (by about
0.2 in (5mm)) uniformly over its whole length. If it’s necessary to increase the bend
of the squeegee in the center, you must tilt the squeegee backwards, rotating the
adjuster (1) counter clockwise. To increase the bend of the squeegee at the sides
of the squeegee, rotate the adjuster clockwise. When fully adjusted, tighten the
j
am nut.
17. RECOVERY TANK
Check the drain hose cap (on the rear of the machine) to ensure it’s closed.

MACHINE PREPARATION
18. SOLUTION TANK
Remove the front inlet cap and check the solution filter is correctly fitted.
Check the filter cover (beneath the tank) is correctly closed.
19. SOLUTION TANK
Fill the tank with clean water in the front fill location (1) or at the rear fill location (2)
at a temperature not exceeding 120°F (50°C).
Y
ou can check the level of solution in the tank by means of the rear hose (3).
A
dd the liquid detergent into the tank, in the concentration and manner specified
by the manufacturer. The formation of excess foam could damage the vacuum
motor, so be sure to use only the correct amount of detergent.
WARNING: Always use low-foam detergent. Introduce a small
amount of anti-foam detergent in the recovery tank before
starting to work to prevent foam from being generated.
WARNING: Never use pure acids.
1
2
3

MACHINE PREPARATION
20. ASSEMBLING THE BRUSH (BASE WITH DOUBLE BRUSH)
1
.
With the brush deck up, insert the brushes in the brush housing beneath the
deck base, turning them until the three pins enter the notches in the plate
itself; turn the brush until the pin is pushed towards the coupling spring and is
locked into place. The figure shows the brush rotation direction for the right-
hand brush; the left-hand brush rotates in the opposite direction.
WARNING: Make sure there are no objects or people in the
vicinity of the brush when doing this operation
2
.
Swap the right and left-hand brushes every day. If the brushes are used and
have deformed bristles, it is better to reassemble them in the same position
(the right-hand one on the right, and the left-hand one on the left), to prevent
the deformed bristles overloading the brush motor as well as excessive
vibration.
21. REGULATING THE SOLUTION
Regulate the quantity of water by means of the side valve (1).
1

OPERATION
1. PREPARING TO WORK
1. Connect the battery plug (1) to the machine plug
1
2. Turn the key (1) of the main switch to the "ON" position (clockwise). The battery
charge level indicator lights will immediately come on.
3. Turn on the water valve (2) (the water falls automatically while the brushes are turning).
4. Release the lever (3) and lower the scrubbing head. If the floor is particularly dirty, you
can apply an overpressure to the scrubbing head by raising the pedal (3) until the lock
down is triggered.
5. Lower the squeegee, turning the lever (4) counter clockwise. The vacuum motor will
switch on.
6. Check that the brake (5) is off.
7. Pressing the paddles (1), activates the brushes and the machine begins to move
(model with traction). During the first feet, check the amount of solution is correct,
and that the squeegee dries the floor perfectly.
8. The machine will now start to scrub and dry until the solution tank is empty or
recovery tank is full.
1
2
3
4
1
5

OPERATION
2. REVERSE MOVEMENTS (MODELS WITH TRACTION)
To activate the reverse direction, just push the command levers (1) counter
clockwise.
WARNING: when making even brief reverse movements,
check the squeegee and base are raised.
4. OVERFLOW DEVICE
The machine has a float in the filter basket that trips when the recovery tank is full to
stop airflow into the vacuum hose.
A
t this point
y
ou must empty the recovery tank by removing the cap of the rear drainage
hose.
WARNING: Always wear gloves when doing this
operation to protect you from contact with hazardous
chemicals.
1

SHUTTING DOWN THE MACHINE
1. AT THE END
A
t the end of the work, and before carrying out any type of maintenance:
1. Turn off the valve using its handle (1)
2. Raise the brush deck using the pedal (2)
3. Raise the squeegee using the lever (3)
4
. Turn off the key switch (4)
5. Move the machine where the tanks can be drained
6. Remove the drainage hose from its compartment, unscrew the drainage cap and
empty the recovery tank.
7. The squeegee must be raised when the machine is not operating, in order to avoid
deforming the squeegee blade blades.
8. Disassemble the pads and clean them with water (to disassemble the pads, see
“DISASSEMBLING THE PAD” below).
WARNING: Always wear gloves when doing this operation to
protect you from contact with hazardous chemicals.
1
2
3
4

DAILY MAINTENANCE
1. CLEANING THE RECOVERY TANK
1. Raise the vacuum cover (1) and prop it open using the lifting rod on the right-hand
side of the lid.
2. Remove the drainage hose (2) from its fitting and empty the tank.
3. Rinse the inside of the tank well with water.
4. Reposition the cover on the machine and replace the drainage hose cap and
drainage hose.
WARNING: Always wear gloves when doing this operation to
protect yourself from contact with hazardous chemicals
2. CLEANING THE VACUUM FILTER
1. Raise the cover.
2. Remove the vacuum filter cover by rotating it clockwise.
3. Pull the filter straight away from the lid to remove it.
4. Use water to clean the walls and base of the filter.
5. Carry out the cleaning operations carefully.
6. Reassemble all the elements.
WARNING: Always wear gloves when doing this operation to
protect yourself from contact with hazardous chemicals
3. CLEANING THE VACUUM HOSE FILTER
1. Raise the vacuum cover.
2. Rotate the inner filter (1) and remove it.
3. Use water to clean the walls and base of the filter.
4. Carry out the cleaning operations carefully.
5. Reassemble all the elements.
WARNING: Always wear gloves when doing this operation to
protect yourself from contact with hazardous chemicals
2
1
1

DAILY MAINTENANCE
4. CLEANING THE SQUEEGEE
Ensure the squeegee is always clean, for better drying results.
To clean it you must:
1. Remove the squeegee hose from the nozzle
2. Remove the cotter pins that fix the pins of the squeegee
3. Disassemble the squeegee from its support
4. Loosen the wing nuts by two turns (1)
5. Remove the squeegee band clamp and squeegee blade
6. Replace the squeegee blades
To reassemble the squeegee, repeat the above-mentioned operations in the reverse order.
WARNING: Always wear gloves when doing this operation to
protect yourself from contact with hazardous chemicals
5. DISASSEMBLING THE PADS
1. Turn the key to the “off” position
2. Raise the brush deck using the lever
3. Rotate the brush until it comes out of the brush-holder as shown in the figure. The
figure shows the rotation direction to release the right-hand brush; for the left-hand
one, rotate in the opposite direction
WARNING: Always wear gloves when doing this operation to
protect yourself from contact with hazardous chemicals
8. REPLACING THE SQUEEGEE BLADES
Check the state of wear and tear of the squeegee blades and, if necessary, replace them.
To replace them you must:
1.Remove the squeegee hose from the nozzle
2.push the release lever and unthread the small right-hand column
3.Disassemble the squeegee from its support
4.Loosen the wing nuts by two turns
5.Remove the squeegee band clamp and squeegee blade
6.Replace the squeegee blades
To reassemble the squeegee, repeat the above-mentioned operations in the reverse order.
WARNING: Always wear gloves when doing this operation to
protect yourself from contact with hazardous chemicals

WEEKLY MAINTENANCE
1. CLEANING THE SQUEEGEE HOSE
Every week, or whenever vacuum seems to be unsatisfactory, check the squeegee
hose for obstructions. To clean it, proceed as follows:
1. Remove the hose from the sleeve on the squeegee
2. Remove the other end from the recovery tank
3. Wash the inside of the hose with water introduced from the side where it is
connected to the tank
4. Reassemble the hose
WARNING: Always wear gloves when doing this operation to
protect yourself from contact with hazardous chemicals
2. CHECKING THE BRAKE
Every week, check the distance between the work brake pads and the wheels. If
necessary, adjust them by means of the nuts, so they are at a distance of 0.12 in
(3mm) when released.
2. CLEANING THE SOLUTION TANK
1. Loosen the solution tank cap.
2. Rinse with water.
3. Loosen the drainage cap (1) located on the filter, and empty the tank.
WARNING: Always wear gloves when doing this operation to
protect yourself from contact with hazardous chemicals
1

TROUBLESHOOTING
INSUFFICIENT WATER ON THE BRUSH
1. Check the valve – located beneath the symbol – (1) is turned on.
2. Check there is water in the solution tank.
THE MACHINE DOES NOT CLEAN WELL
1. Check the state of wear and tear of the pad and, if necessary, replace it.
2. Use a different kind of pad to the one fitted as standard. For cleaning floors where
the dirt is particularly resistant, we recommend the use of special brushes supplied
upon request and according to needs (see “CHOOSING AND USING THE
BRUSHES”).
THE SQUEEGEE DOES NOT DRY PERFECTLY
1. Check the squeegee blades are clean.
2. Adjust the inclination of the squeegee (see "SQUEEGEE" under “MACHINE
PREPARATION”)
3. Ensure the vacuum hose is correctly inserted in its housing on the recovery tank.
4. Check the inner filter of the recovery tank to ensure it is not dirty and, if necessary,
clean it thoroughly.
5. Disassemble the entire vacuum unit and clean it.
6. Replace the squeegee blades, if worn.
7. Ensure the vacuum motor switch is turned on.
8. Check wheel adjustment.
TOO MUCH FOAM IS GENERATED
Check that low-foam detergent is being used. If necessary add a small amount of anti-
foam liquid to the recovery tank.
Remember that more foam is generated when the floors are not very dirty. Dilute the
detergent more when cleaning floors that are not very dirty.
1
