Bettcher E-Z EDGE Series User manual

BETTCHER
Industries, Inc.
Operating Instructions & Spare Parts List for the
BETTCHER®
Manual # 173297
Issued : June 15, 2018
TMC # 814
For Assistance, Write:
BETTCHER INDUSTRIES INC.
P.O. Box 336
Vermilion, Ohio 44089-0336
U.S.A.
Phone: [phone]
Phone: [phone]
Fax: [phone]
Internet: http://www.bettcher.com
COMPANY CONFIDENTIAL

Information in this document is subject to change without notice.
No part of this document may be reproduced or transmitted in any form or any means, electronic
or mechanical, for any purpose, without the express written permission of Bettcher Industries Inc.
Written permission to reproduce in whole or part is herewith granted to the legal owners of the
Bettcher®E-Z EDGE sharpener with which these Operating Instructions have been supplied.
Operating Instructions in other languages are available on request. Additional copies of Operating
Instructions are available by calling or writing the local Representative or by contacting:
Bettcher Industries, Inc. BETTCHER GmbH
P.O. Box 336 Pilatusstrasse 4
Vermilion, Ohio 44089 CH-6036 Dierikon
USA SWITZERLAND
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
Bettcher do Brasil Comércio de Máquinas Ltda.
Av. Fagundes Filho, 145 Cj 101/102 - São Judas
São Paulo - SP
CEP 04304-010 - BRASIL
Tel: [phone]
Fax: [phone]
The Information Provided in these Operating Instructions is Important
to Your Health, Comfort and Safety.
For Safe and Proper Operation, Read this Entire Manual
Before Using this Equipment.
Copyright 2018 by Bettcher Industries, Inc.
All Rights Reserved
Original Instructions
Page i
COMPANY CONFIDENTIAL

Table of Contents
Section 1……………Safety and Ergonomics
Section 2……………Designated Use
Section 3……………Instructions for Operation
Section 4……………Maintenance
Section 5……………Cleaning
Section 6……………Service Parts
Section 7……………Contact and Document Information
BETTCHER®
COMPANY CONFIDENTIAL

COMPANY CONFIDENTIAL

Safety and Ergonomics
BETTCHER
Industries, Inc.
Manual No. 173297
June 15, 2018
Safety and Ergonomics
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
1-1
Section 1
Safety a
nd
Ergonomics
CONTENTS OF THIS SECTION
Safety Recommendations and Warnings ............................................................................... 1-2
COMPANY CONFIDENTIAL

BETTCHER
Industries, Inc. Safety and Ergonomics
1-2
Safety and Ergonomics
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
Manual No. 173297
June 15, 2018
Safety Recommendations and Warnings
Warnings identify conditions that can cause serious bodily injury to the user.
Cautions identify conditions that are important to the operation, care and maintenance of the machine.
WARNING
THE MANUFACTURER ASSUMES NO LIABILTY FOR ANY
UNAUTHORIZED DESIGN CHANGES, MODIFICATION,
OR USE OF PARTS NOT SUPPLIED BY THE MANUFACTURER
OR
THE USE OF PARTS NOT DESIGNED FOR USE ON THAT
SPECIFIC MODEL, INCLUDING CHANGES IN OPERATING
PROCEDURES MADE BY THE OWNER OR ANY OF HIS
PERSONNEL.
THE USE OF PARTS OTHER THAN THOSE LISTED IN THE
PARTS LIST FOR THE SPECIFIC MODEL MAY CAUSE BLADE
LOCK-UP RESULTING IN AN UNSAFE OPERATING
CONDITION.
COMPANY CONFIDENTIAL

Designated Use
BETTCHER
Industries, Inc.
Manual No. 173297
June 15, 2018
Designated Use
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
2-1
Section 2
Designated Use
CONTENTS OF THIS SECTION
Designated Use...................................................................................................................... 2-2
COMPANY CONFIDENTIAL

BETTCHER
Industries, Inc. Designated Use
2-2
Designated Use
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
Manual No. 173297
June 15, 2018
Designated Use
The Bettcher®E-Z EDGE sharpener has been designed for use with Bettcher®Whizard®Trimmers.
Its function is to sharpen the blade’s cutting edge effectively and inexpensively.
Use of the Bettcher®E-Z EDGE sharpener will ensure your operators a sharp blade to work with at all
times.
The Bettcher®E-Z EDGE sharpener model number, located on the I.D. steel, or on the plastic locator,
indicates which Whizard®Trimmer it should be used with.
COMPANY CONFIDENTIAL

Instructions for Operation
BETTCHER
Industries, Inc.
Manual No. 173297
June 15, 2018
Instructions for Operation
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
3-1
Section 3
Instructions for
Operation
CONTENTS OF THIS SECTION
Safety Precautions ................................................................................................................. 3-2
Operating Procedure – Straight Blade and Cone Blade Models............................................. 3-3
Operating Procedure – Flat Blade Models.............................................................................. 3-5
COMPANY CONFIDENTIAL

BETTCHER
Industries, Inc. Instructions for Operation
3-2
Instructions for Operation
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
Manual No. 173297
June 15, 2018
Safety Precautions
The Bettcher®E-Z EDGE sharpener is used with the Bettcher® Whizard®Trimmer. Proper protective
equipment should be worn when using a Bettcher®E-Z EDGE sharpener.
WARNING
SHARP BLADE MAY CAUSE CUT INJURY!
FOR PROPER PROTECTION OF HANDS,A PROTECTIVE GLOVE SHOULD BE
USED WHEN OPERATING THIS DEVICE.
The sharpening operation should be performed away from the product in order to avoid possible
contamination of the product.
COMPANY CONFIDENTIAL

Instructions for Operation
BETTCHER
Industries, Inc.
Manual No. 173297
June 15, 2018
Instructions for Operation
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
3-3
Operating Procedure – Straight Blade and Cone Blade Models
Models: 350, 440, 620, 500 and 750
•Hold the Bettcher® Whizard® Trimmer in your right hand, with the blade facing down and running.
•Hold the Bettcher® E-Z EDGE Sharpening device in your left hand, with the steeling and sharpening
rods pointing down.
•Place the Bettcher® E-Z EDGE’s locator over the trimmer blade housing. Lower the locator down
on the blade housing until the blade housing is held in the locator.
•While holding the Bettcher® E-Z EDGE Sharpening device locator down firmly on the trimmer
blade housing, push the sharpening rod toward the trimmer blade. Hold the sharpening rod against
the outside blade edge for a few seconds, with very light pressure applied. This sharpens the outside
edge of the blade.
COMPANY CONFIDENTIAL

BETTCHER
Industries, Inc. Instructions for Operation
3-4
Instructions for Operation
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
Manual No. 173297
June 15, 2018
Operating Procedure – Straight Blade and Cone Blade Models
(Continued)
Models: 350, 440, 620, 500 and 750
•Pull the sharpening rod away from the trimmer and hold the steeling rod against the inside blade
edge for a few seconds, with very light pressure applied. This steels the inside edge of the blade.
Note: The forward and backward motion need only be performed
once to sharpen and steel the blade’s edge.
Note: It is important to hold the trimmer and the locator flat to
one another while steeling and to only apply light pressure
against the blade with the steeling rod. Do not tilt or rock the
trimmer in the locator while steeling as this will possibly dull the
cutting edge.
•After performing the forward and backward motion to sharpen and steel the blade edge, simply lift
the locator up and off of the trimmer.
COMPANY CONFIDENTIAL

Instructions for Operation
BETTCHER
Industries, Inc.
Manual No. 173297
June 15, 2018
Instructions for Operation
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
3-5
Operating Procedure – Flat Blade Models
Models: 625, 505, 850, 880-B, 880-S, 1000, 1300, 1400, 1500, 1850 and 1880
•Hold the Bettcher Whizard® Trimmer in your right hand, with the blade facing down and running.
•Hold the trimmer over the sharpener; insert the trimmer into the locator by tilting the right side of the
trimmer blade down at a slight angle and sliding it under the slight lip on the right end of the locator.
The center of the blade diameter should be between the two rods.
•With very light pressure applied, hold the blade down on the rods and slide the trimmer along the
rods toward the I.D. steel until the locator stops. (Approximately ½ inch of travel.)
•Hold the blade against the I.D. steel for a few seconds, and then slide the trimmer back away from
the steel.
Note: The forward and backward motion need only be
performed once, with a relatively slow stroke.
•Lift the tool out of the locator.
COMPANY CONFIDENTIAL

COMPANY CONFIDENTIAL

Maintenance
BETTCHER
Industries, Inc.
Manual No. 173297
June 15, 2018
Maintenance
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
4-1
Section 4
Maintenance
CONTENTS OF THIS SECTION
Sharpening and/or Steeling Rod Adjustment – Straight Blade and Cone Blade Models........ 4-2
Sharpening and/or Steeling Rod Adjustment – Flat Blade Models......................................... 4-4
Disassembly – Straight Blade and Cone Blade Models.......................................................... 4-5
Assembly - Straight Blade and Cone Blade Models............................................................... 4-8
Disassembly – Flat Blade Models..........................................................................................4-11
Assembly – Flat Blade Models ..............................................................................................4-14
Disassembly – Model 360 .....................................................................................................4-17
Assembly – Model 360..........................................................................................................4-19
Fault Detection and Correction..............................................................................................4-23
COMPANY CONFIDENTIAL

BETTCHER
Industries, Inc. Maintenance
4-2
Maintenance
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
Manual No. 173297
June 15, 2018
Sharpening and/or Steeling Rod Adjustment – Straight Blade and
Cone Blade Models
Models: 350, 440, 620, 500 and 750
•Loosen the steeling rod screw in the rod mount. Remove the steeling rod shaft from the rod mount
and slide it out of the locator.
•To adjust the steeling rod:
•Remove the cover screw at the right end of the steeling rod shaft.
•Loosen the set screw inside the right end of the steeling rod shaft using a 3/32” hex wrench.
•Rotate the steeling rod by hand to expose a new wear surface.
•Tighten the set screw.
•Replace the cover screw at the right end of the steeling rod shaft.
COMPANY CONFIDENTIAL

Maintenance
BETTCHER
Industries, Inc.
Manual No. 173297
June 15, 2018
Maintenance
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
4-3
Sharpening and/or Steeling Rod Adjustment – Straight Blade and
Cone Blade Models
Models: 350, 440, 620, 500 and 750
•To adjust the sharpening rod:
•Loosen the set screw inside the left end of the steeling rod shaft using a 3/32” hex wrench.
•Rotate the sharpening rod by hand to expose a new wear surface.
•Tighten the set screw.
•Slide the steeling rod shaft through the locator and into the rod mount. Tighten the steeling
rod screw.
COMPANY CONFIDENTIAL

BETTCHER
Industries, Inc. Maintenance
4-4
Maintenance
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
Manual No. 173297
June 15, 2018
Sharpening and/or Steeling Rod Adjustment – Flat Blade Models
Models: 625, 505, 850, 880-B, 880-S, 1000, 1300, 1400 and 1500
•To adjust the sharpening rod:
•Loosen the sharpening rod screw on top of the rod mount.
•Rotate the sharpening rod by hand to expose a new wear surface.
•Tighten the sharpening rod screw.
•To adjust the steeling rod:
•Loosen the steeling rod screw on top of the rod mount.
•Rotate the sharpening rod by hand to expose a new wear surface.
•Tighten the steeling rod screw.
COMPANY CONFIDENTIAL

Maintenance
BETTCHER
Industries, Inc.
Manual No. 173297
June 15, 2018
Maintenance
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
4-5
Disassembly – Straight Blade and Cone Blade Models
Models: 350, 440, 620, 500 and 750
•Remove the spring rod screw and slide off the locator and springs.
•Remove the steeling rod screw from the rod mount and remove the steeling rod shaft.
COMPANY CONFIDENTIAL

BETTCHER
Industries, Inc. Maintenance
4-6
Maintenance
Bettcher®E-Z EDGE sharpener Operation and
Maintenance Manual
Manual No. 173297
June 15, 2018
Disassembly - Straight Blade and Cone Blade Models (Continued)
Models: 350, 440, 620, 500 and 750
•Remove the handle screw and pull apart the handle and rod mount.
•To remove the steeling rod:
•Remove the steeling rod screw on the right side of the steeling rod shaft.
•Remove the set screw inside the right end of the steeling rod shaft using a 3/32” hex wrench.
•Press out the spring pin.
•Remove the steeling rod.
COMPANY CONFIDENTIAL
