ASSEMBLY INSTRUCTIONS
#
 BH19-092-099-83
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
Questions, problems, missing parts with this product? Do not return to your
retailer, please call our customer service department 9:00 a.m. to 5:00
p.m.Eastern Standard Time Monday through Friday Phone # [phone].
contact us at www.numarkcustomerservice.com.
Hillsboro glider bench
ITEM
DON’T RETURN TO STORE

2
WARRANTY
FREIGHT & PACKAGING
Freight and packaging are the responsibility of the original purchaser.
WARRANTY
We warrant our products to be free of manufacturing defects to the original purchaser
for the period listed below. We reserve the right to make substitutions with similar
merchandise,if the model in question is no longer in production.
EXCLUSIONS
This warranty does not cover: Furniture used for commercial or non-residential
purposes; failures caused by improper care; unreasonable or abusive use; freeze
damage; acts of nature. Steel products are not covered against rust. Tempered glass
table tops are not covered against breakage.
FINISH
Frame finish is warranted to be free of manufacturing defects for a period of one (1) year.
Discoloration or fading of the finish as a result of exposure to the elements, chemicals, or
spills is not covered.
FRAMES
Frame is warranted to be free from defects in material or workmanship for a period of
one (1) year for steel frame. This product is made with a steel frame.
ACCESSORY
F1 (6)
Short Bolt
F2 (4)
Countersink screws
F5 (22)
Metal Washer
F9 (1)
Allen Wrench
DON’T RETURN TO STORE
F3 (8 + 1 spare)
Medium Bolt
F4 (4)
Long Bolt
F6 (4)
Nut
F7 (4)
Plastic Washer
F8 (1)
Open Hex Wrench
Estimated Assembly Time: 30 minutes - 2 persons.

3
Parts
ASSEMBLY INSTRUCTIONS
1
2
A1 Left Arm
A2 Right Arm
B Seat
C Back
D Base Leg
E Base Leg Connector
1
1
1
1
2
2
ITEM DESCRIPTION QUANTITY
F1 x 4
Short Bolt
F5 x 4
Metal Washer
Don’t tighten completely.
Repeat procedure for the other arm.
Don’t tighten completely.
Repeat procedure for the other arm.
DON’T RETURN TO STORE
A1
A2
B
C
D
E
D
F1 x 2
Short Bolt
F5 x 2
Metal Washer
A1 A2
B
F5 F1
A1
A2
B
F1 F5

ASSEMBLY INSTRUCTIONS
3F2 x 4
Countersink screws
4
DON’T RETURN TO STORE
Don’t tighten completely.
Repeat procedure for the other side.
Don’t tighten completely.
Repeat procedure for the other side.
Securely tighten all bolts.
Now your glider is ready for use.
4
Note ：Make sure the arrows “↑” upside direction.
Don’t tighten completely.
Repeat procedure for the other side and other connector.
F5 x 8
Metal Washer
F3 x 8
Medium Bolt
5
F5 x 8
Metal Washer
F4 x 4
Long Bolt
F6 x 4
Nut
F7 x 4
Plastic Washer
D
E
E
D
F3 F5
Printed in China
A1
A2
B
C
F2
A2
C
Note ：Make sure the arrows “↑” pointing
upside direction.
A1
A2
D
D
F6
F5 F5
F4
F7
