Better Homes and Gardens Sonoma Falls AAQ08801 User manual

Sonoma Falls 3-Piece Bistro Set
UPC # 0 50874 06454 7
If parts are missing or you need assistance，please contact our Customer Service Center, Monday through Friday 9am - 5pm (Eastern Time) at 1-800-416-3511.
Page 1
# AAQ08801

IMPORTANT!! PLEASE READ ENTIRE INSTRUCTION SHEET BEFORE ASSEMBLY!!
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, PLEASE KEEP INSTRUCTION SHEET, WARRANTY CARD AND RECEIPT
Step 1: Identify all parts packed in the carton against the parts list. Remove all protective materials. Place parts on a non-abrasive surface to avoid scratching. If you are missing any parts or are unsure as how to
proceed with the assembly, call our Customer Service Center at 1-800-416-3511. Do not attempt assembly if any parts are missing or damaged.
Step 2: Place the swivel base (with rocker assembly) on a flat, solid surface. Make sure the rocker assembly is positioned all the way into the base. It may have shifted or vibrated out during shipment.
Step 3: Important: We recommend 2 people work together to assemble the chair. Note the arrow labels on the "U" bar and the rocker assembly. Also note the horseshoe shape of the rocker plate. Point the
open end of the horseshoe away from you. The arrows on the rocker assembly should be pointing towards you. Set the chair frame on the rocker assembly with front of the seat facing you and the arrows
on the "U" bar pointing towards you as shown in Figure 1. This is very important for a safe, balanced rocking motion. If the chair frame has been properly positioned on the rocker assembly, all arrows
on the "U" bar and rocker assembly will be pointing in the same direction.
Step 4: Critical Step: The "U" metal plates must be installed in the proper location. Read this step and carefully examine. Insert the "U" metal plate, so that the "U" bar and rocker plate are between both
sides of the "U" metal plate. Make sure that the holes in the "U" metal plate are completely aligned with the holes in the "U" bar as shown in Figure 1. Guide the bolts through the holes on the top side
of the "U" metal plate, through the holes in the "U" bar portion of the chair, through the holes in the rocker plate and then, most importantly, through the holes in the bottom side of the "U" metal plate. It
is very important that the holes in the bottom portion of the "U" metal plate be placed directly beneath the holes in the rocker plate. Add a washer and a nut to each bolt as shown in Figure 2. Hand
tighten nuts 3-4 revolutions only. Repeat the same procedure on the other side.
CAUTION: Failure to place "U" metal plates under the rocker plates and above the "U" bar exactly as shown in diagram will cause the bolt heads and nuts to damage the structure of the rocker
plates and the "U" bar. Damage due to over tightening of bolts or improper assembly could cause injury and may void your warranty.
Step 5: Tighten all nuts and bolts with the hex wrenches provided. Do not over tighten. Remove arrow labels from "U" bar and rocker assembly. Cover bolts with bolt covers.
Step 6: Your chair should be ready for use. If your chair is not rocking properly, double-check your assembly procedure, especially Step 3. If the chair rocks too far forward to or is difficult to rock backwards, you
have probably installed the seat frame backwards on the rocker assembly. If you need further assistance, please call our Customer Service Center at 1-800-416-3511.
Estimated assembly time：20 minutes.
IMPORTANT NOTE: Damage to welds or frames resulting from over tightened bolts or improper assembly is not covered under our warranty. Please read all instructions carefully before assembly. If
you have any questions regarding your assembly, call our Customer Service Center at 1-800-416-3511.
NOTE: MAKE SURE ARROWS
FROM BOTH THE "U" BAR
AND ROCKER ASSEMBLY
ARE POINTING IN THE
SAME DIRECTION!
SEAT DESIGNS MAY
VARY BUT THE ASSEMBLY
IS THE SAME
Figure 1
ROCKER PLATE
E
D
D
A
"U" BAR
ROCKER
ASSEMBLY
"U" BAR
H
COVER
FOOT CAP
Figure 2
B
C
I
Page 2

Page 3
HEX WRENCH
PARTS LIST DESCRIPTION ORDER PART # QTY
1
A
B
C
D
4
5/16" X 40 MM BOLT HW0295
HW0015 4
NUT
HW0007 1
F
PLASTIC WASHER 4
HW0028
BOLT COVER 8
G
HW0003
E"U" METAL
PLATE 2
HW0618
HW0008
HEX WRENCH-1

1
* NOTE: PARTS SHOWN BELOW ARE NOT TO SCALE
FOOT CAP
FACTORY ASSEMBLY FC0063
1
CHAIR FRAME
SWIVEL BASE &
ROCKER
FACTORY ASSEMBLY
PARTS LIST DESCRIPTION ORDER PART # QTY
H
I
Page 4
AR19542
AR19543

Page 5
PATIO FURNITURE & ACCESSORIES
ASSEMBLY INSTRUCTIONS
IMPORTANT!!!
STOP! PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE
ASSEMBLY. MAKE SURE YOU HAVE ALL THE PARTS AND
HARDWARE AS IDENTIFIED ON THE PARTS LIST.
MISSING PARTS? DAMAGED PARTS? DON'T GO BACK TO THE
RETAILER. WE CAN HELP YOU FASTER!
CALL OUR CUSTOMER SERVICE CENTER AT 1-800-416-3511
BETWEEN 9:00AM AND 5:00PM (EASTERN TIME) MONDAY
THROUGH FRIDAY (CLOSED HOLIDAYS).
OR, VISIT OUR WEBSITE AT: www.shianco.com
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, RETAIN THE
INSTRUCTION SHEET, WARRANTY CARD AND RECEIPT FOR
FUTURE USE. YOU ARE ENCOURAGED TO REGISTER YOUR
PURCHASE ON OUR WEBSITE AT www.shianco.com
FOR ADDITIONAL ONLINE VIDEO SUPPORT ON ASSEMBLY,
TROUBLESHOOTING, AND CARE AND MAINTENANCE OF YOUR
SHIANCO OUTDOOR FURNITURE, PLEASE VISIT OUR WEBSITE AT:
www.shianco.com/support
ACOV118
CARE AND MAINTENANCE
FRAMES
Cleaning - Use mild soap and warm water. Do not use abrasive materials, cleansers or bleach products. Rinse with clean water and
dry thoroughly.
Maintenance - Periodically clean and dry thoroughly. Be sure to drain any water accumulated inside the frames. To thoroughly drain
frames, remove foot caps and tilt the frames, if necessary, to remove all water. This is critical. Water allowed to accumulate inside the
frames and then exposed to sub-freezing temperatures can cause damage to the frame tubing. Such damage is not covered under
warranty. Always clean, drain and dry thoroughly before storing for the winter. For best results, always store or cover your furniture
when not in use. We recommend commercially available outdoor furniture covers. Any small nicks or scratches can be covered with a
light application of touch-up paint.
** When cleaning or moving large or heavy items, always have two people work together. Never drag furniture.
FABRICS (CUSHIONS/SLINGS)
Cleaning - Wipe minor spills immediately. Clean with mild soap, warm clean water and soft cloth. Do not use abrasive materials,
cleansers or bleach products. Although fabric has been treated to resist stains, occasional use of commercially available fabric cleaners
may be necessary. Follow manufacturer's instructions.
Maintenance - The best way to maintain the beauty of cushions and slings is to store them in a dry area and out of the elements when
not in use or cover with commercially available outdoor furniture covers.
STRAPS
Cleaning - Wash frequently with mild soap, warm water and a soft cloth. Rinse thoroughly with warm, clean water. Do not use
abrasive materials, cleansers or bleach products.
Maintenance - Periodic application of commercially available vinyl cleaners and vinyl protectors will enhance the look and prolong the
life of straps. If your strap chair has cushions, make sure any vinyl protectors applied are completely dry before placing cushion back
on the chair.
LIMITED 5 YEAR WARRANTY
·Frames. Frame construction is warranted against defects in material and workmanship for five years from purchase date.
Damage to frames or welds resulting from improper assembly or exposure to water and/or sub-freezing temperatures is not
covered.
·Finishes. Paint finishes are warranted against peeling, cracking and blistering for one year from purchase date provided the unit
has not been scratched or abraded. Chips and scratches resulting from normal wear and tear are not covered.
·Fabrics. Fabric and cushions (if applicable) are warranted against separation at the seams for one year from purchase date.
Fading and/or discoloration resulting from exposure to the elements, oils, spills, fluids, chemicals, or any other cause is not
covered.
·Straps and/or wicker. Straps and/or wicker weave (if applicable) are warranted against separation and tearing for one year
from purchase date. Fading and/or discoloration resulting from exposure to the elements, oils, spills, fluids, chemicals, or any
other cause is not covered.
·Umbrellas. Umbrellas (if applicable) are warranted against defects in material and workmanship only for one year from
purchase date. Umbrella bases (if applicable) are not covered under any circumstance.
·Table tops. Natural stone tabletops only are warranted against defects in materials or workmanship only for one year from
purchase date. All other table tops (including without limitation glass and faux stone) are not covered under any circumstances.
Warranty limitations: This warranty is subject to the limitations set forth above. In addition, this warranty is made to the original
purchaser only, and is effective only when item(s) is purchased from one of our authorized dealers. This warranty is not transferable.
For warranty replacements based on warranty claims submitted within the first year of purchase, we will pay shipping and handling
charges within the continental North America. After the first year, shipping and handling charges are your responsibility. We will not
be responsible for charges associated with shipments outside the continental North America at any time or for any reason.
Warranty exclusions: This warranty is subject to the exclusions as set forth above. In addition, the following are excluded from
coverage under this warranty: any item used for commercial, contract or any other non-residential purpose; clearance items, display
models or items purchased "as is"; freight damage; items subject to misuse, abuse, neglect or lack of proper care and maintenance
(including without limitation as provided in any "care and maintenance guide"); normal wear and tear; damage caused by acts of
nature, acts of force majeure, vandalism, fire or other casualty, or improper assembly; hardware against corrosion or rusting; purchased
or replacement parts; and all plastic parts. Also excluded are loss of use or time; inconvenience; money; travel; packaging; or
incidental, special or consequential damages of any kind. Replacement of defective items as provided herein shall constitute your sole
and exclusive remedy for items which are not as warranted. In no event shall our responsibility exceed the purchase price of the items
found to be other than as warranted. This warranty is the exclusive statement of your rights with respect to the defects in the items you
have purchased and supersedes any other express warranty or statement, written or oral, made in connection with the purchase and sale
of such items. When used herein, the term "item" when used in the singular, refers to the specific item found to be defective, and not to
the entire set of which the item is a part.
Some states do not allow exclusion or limitation of incidental or consequential damages, so that limitation above may not apply
to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
