Replas PREMIER SLIMLINE SETTING User manual

ASSEMBLYINSTRUCTIONS
IMPORTANT:Pleasereadcarefullybeforeassembling.
PREMIER
SLIMLINESETTING
1.8mInGround
WheelChairAccess
1.PlaceTable&Benchtopsfacedownonaflatsurface.
2.Placesupportsinsidemetalframe.
3.Usinga3.5mmdrillbit,drillintothesupportthroughthepilotholeinthemetalframe.
4.Usingthe40mmHexscrewssupplied,screwsupportontoframe.


Installation

Oncethesettinghasbeenisassembled,drillordigholesasperinstallationdiagram.

Placethesupportsoftheassembledsettingintotheholes.Positionthesettingandensurethatitiswell
bracedtopreventmovementandsagging.Atthisstageitisimportanttouseaspiritleveltocheckthatthe
topishorizontalandthesupportsarevertical.

Oncesatisfiedthatthesettingispositionedcorrectly,filltheholeswithconcrete,makingsureitispacked
firmlyaroundthesupports.

Oncetheconcretehasset,removethebracing.
TABLE:

1XTableTop‐pre‐assembled
2XTableSupports
16X12gx40mmHexScrews
COMPONENTSLIST
BENCHES:

2XBenchTops‐pre‐assembled
4XBenchSupports
24X12gx40mmHexScrews
Ifyourequirefurtherinstallation
assistance,pleasecontactyoursupplier.

1800
8 x (40x90x1800)
20 x 40 x 4.5mm Frame
1320 mm
SIDE VIEW - Table only
PRS-1800IG/WCA
PREMIER SLIMLINE
IN GROUND
SETTING WITH
WHEELCHAIR ACCESS
630 mm
740 mm
640 mm
700 mm
640 mm
855 mm
640mm
Ground L evel
Ground L evel
Ground L evel
440 mm
280 mm
490 mm
END VIEW
1800
3 x (40x90x1800)
25 x 40 x 3mm Frame
SIDE VIEW - Bench only
755 mm
