Beyerdynamic Unite TP User manual

NITE
TP
––
BODYPACK TRANSMITTER
TASCHENSENDER
Quick Start Guide

2
This device complies with Part 15 of the F Rules and with Industry
anada licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause harmful inter-
ference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Le présent appareil est conforme aux NR d’Industrie anada
applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas
produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
This equipment has been tested and found to comply with the limits
for a lass A digital device, pursuant to Part 15 of the F Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio commu-
nications. Operation of this equipment in a residential area is likely to
cause harmful interference in
which case the user will be required to correct the interference at his
own expense.
hanges or modifications made to this equipment not expressly
approved by Beyerdynamic may void the F authorization to operate
this equipment.
Radiofrequency radiation exposure Information:
For body worn operation, this equipment has been tested and meets
the F RF exposure guidelines when used with the Beyerdynamic
accessories supplied or designated for this product. Use of other
accessories may not ensure compliance with F RF exposure guide-
lines.

3
Este produto está homologado pela Anatel, de acordo com os
procedimentos regulamentados pela Resolução n°. 242/2000 e atende
aos requisites técnicos aplicados, incluindo os limites de exposição da
Taxa de Absorção Específica referente a campos elétricos, magnéticos
e eletromagnéticos de radiofreqüência de acordo com as Resoluções
n°. 303/2002 e 533/2009.
This device is granted pursuant to the Japanese Radio Law (電波法)
and the Japanese Telecommunications Business Law (電気通信事業法). This device should not be modified (otherwise the granted
designation number will become invalid).
The devices conforms to the EU guidelines
(EM ) 2014/30/EU
(LVD) 2014/35/EU
(RED) 2014/53/EU
as attested by the E mark.
F ID: OSDUNITEPBT
I : UNITEPBT

Unite TP – Bodypack Transmitter
4
Thank you for choosing the Unite TP bodypack transmitter.
To ensure an optimum performance, we would like to give you
a brief introduction on how to use this bodypack transmitter.
The Unite TP bodypack transmitter was designed for barrier-
free use:
– raised symbols on the front operating buttons for the blind
– Braille on the side mute button for the blind
– compatible with the beyerdynamic induction loop for the
hard of hearing
For detailed operating instructions in your language, please
visit: www.beyerdynamic.com/unite
1. Safety instructions
General
• Please READ this user manual before the first use.
• Please KEEP this user manual.
• Please FOLLOW the specified operating and safety
instructions.
Disclaimer
• beyerdynamic GmbH & o. KG will not be liable for any
damage to the product or injury to persons caused by
negligent, improper, incorrect or inappropriate operation of
the product.
Danger to life
• lip-on microphones can be very small. There is a risk of
suffocation if accidentally swallowed. Therefore, keep such
microphones out of the reach of children.

english
Unite TP – Bodypack Transmitter 5
• The supplied strap is only used for wearing the device
around the neck. If it is not used correctly, the risk of
strangulation may occur.
Volume
• When using headphones/headsets, make sure that the
volume is set to minimum. Adjust the volume only after
putting on the headphones/headset.
Too high volumes and too long listening times can damage
your hearing. Hearing damage always represents an irrever-
sible impairment of hearing.
• Always pay attention to the volume. As a rule of thumb, the
higher the volume, the shorter the listening time. By law,
the maximum allowed value is 85 dB at a maximum
listening time of 8 hours.
• Temporary symptoms that you have been exposed to loud
noise are:
– ringing or whistling in the ears
– high tones can no longer be perceived
Troubleshooting / repairs
• Never open the device yourself.
• Refer all service work to authorised professionals only.
Cleaning
• Only clean the device with a dry or slightly damp cloth.
Never use solvents, as these will damage the surface.
Rechargeable battery
• The bodypack transmitter is operated with the following
battery type: BAT-3707, lithium-ion, 3.7 V, 1.88 Ah,
6.96 Wh (order # 727.679)

Unite TP – Bodypack Transmitter
6
• Use only a USB 2.0/3.0 compliant 5V power supply to
charge the battery pack via the integrated USB type- port
(power consumption is max. 500 mA).
• High temperatures, particularly in association with a high
charging status, result in irreversible damage of the battery
pack.
• If you are not intending to use the battery for an extended
period or are planning to put it into storage, it is advisable
to lower the battery’s charging level to around 50% and to
store it at temperatures of maximum 30 ° .
• In order to ensure safe transport by land, sea and air, the
battery pack used for the bodypack transmitter is tested ac-
cording to the UN 38.3 transport regulation for lithium-ion
batteries.
• Misuse or improper use could damage the battery pack. In
extreme cases, there is a risk of explosion, heat, fire, smoke
or gas.
• Never expose the battery pack to excessive heat such as
sunshine, fire or the like.
• Do not expose the battery pack to mechanical shock.
• harge the battery pack before initial use.
• Use the specified chargers for charging the battery pack.
• Avoid complete draining of the battery. This could damage
the battery and shorten its service life.
• If you do not use the transmitter for several months, the
batteries should be charged at least twice a year to prevent
deterioration in performance due to self-discharge.
• lean the charging contacts of the transmitter with a clean
dry cloth, if they become dirty.
• Do not short-circuit the battery.

english
Unite TP – Bodypack Transmitter 7
• The charging contacts could cause property damage, injuries
or fire damage if they come into contact with conductive
materials such as jewellery, keys or chains. This can lead to
a closed electric circuit and, therefore, to the material
overheating. To avoid this kind of unintentional electric
circuit, the charging contacts must be handled with care.
This is especially important if the transmitter is transported
in a bag or another container containing other metallic
objects.
Moisture / heat sources
• Keep the battery pack clean and dry. Never expose the device
to rain or high humidity. Do not install it in the immediate
vicinity of swimming pools, shower facilities, damp base-
ments or other areas with unusually high air humidity.
• Never place objects filled with water (e.g. vases or drinking
glasses) on the device. Liquids in the devices may cause a
short circuit.
• Never install or operate the device in the immediate vicinity
of radiators, lighting systems or other heat-generating
devices.
Disposal
At the end of its operating life this product may not
be disposed of along with normal household waste.
Please take it to a designated recycling point for
electric and electronic appliances. This is
indicated by the symbol on the product, the
operating instructions or the packaging.

Unite TP – Bodypack Transmitter
8
Simplified E declaration of conformity
beyerdynamic hereby declares that the wireless transmission
device complies with the EU Directive 2014/53/EU (RED). The
complete text of the EU declaration of conformity is available
online at the following address:
http://www.beyerdynamic.com/cod
2. Supplied accessories
• Unite TP bodypack transmitter with mounted belt clip
• Quick Start Guide
• Strap
• Two spare caps for the mute button

english
Unite TP – Bodypack Transmitter 9
3. Operating elements
3.1 Device
Display
The display indicates the channel name, battery status and
different menus.
On/Off and menu button
Use the on/off button to turn the transmitter on or off. To
switch off the device, hold down the button for 5 seconds.
In order to activate the main menu, hold down the button
for 2 seconds. Use the menu button to confirm settings.

















Unite TP – Bodypack Transmitter
10
Status indicator light – during operation:
– in the charger:
Indicator light Operating status
Off Device is switched off
Green Ready to operate and
battery status > 2 h
Flashing red ritical battery level < 30 min
Red • Low battery level
• Out of range
• Microphone is muted
• Device is starting
Flashing red rapidly ritical error
Indicator light Charging status
Off Device is switched off
Flashing yellow slowly harging 0 - 90%
Flashing green slowly harging 90 - 100%
Green Battery is charged
Flashing green/yellow Device is being localised
Flashing yellow rapidly Pairing information is being
copied from the transmitter
Flashing red rapidly harging error
Flashes red 5 times Too many transmitters

english
Unite TP – Bodypack Transmitter 11
Multifunction button
You can use this button to select predefined channel names,
which are then shown on the paired receivers. If you are in
a menu, you can scroll through the menu to make various
settings.
Volume button
Use this button to adjust the volume of a possibly connected
headphone/headset/induction loop. Use this button to adjust
the volume of any connected headphones/headsets/induc-
tion loops. With “+” the volume is increased, with “-” the
volume is reduced.
Important: Please note the safety instructions regarding the
volume.
Mute button
Use this button to enable or mute the internal or externally
connected microphone.
Strap attachment
Attach the supplied strap by pushing the pin pieces on the
end of the strap into the fastening holes. For safety reasons,
the fastening will detach when pulled strongly.
Integrated microphone
If no external microphone or headset is connected, you can
speak directly into the integrated microphone.
Maintain a distance of 10 cm from the microphone when
speaking.
Headphone/headset/induction loop connector
You can connect headphones, a headset or an induction loop
to the jack connection.

Unite TP – Bodypack Transmitter
12
Microphone connector
You can connect a microphone with a 4-pin mini XLR
connector to the microphone connector (for pin assignment,
please refer to chapter 5 “Technical Specifications”).
Line-In, 3-pin jack connector 3.5 mm
You can connect an external player to the jack connector.
USB port, Type
You can use this connector to charge the integrated battery
pack via a USB power adapter. Furthermore, you can con-
nect the bodypack transmitter to the USB Type port on a
Unite charger to charge it or to pair it with other devices.
Belt clip
The belt clip allows you to attach the device to clothing such
as a waistband or belt.
harging contacts
The built-in battery is charged via the charging contacts
when the device is inserted into the charger. Make sure to
insert the device fully into the charging slot so that the
charging contacts have proper contact.
Type plate
The type plate provides information about the name, article
number, certification numbers, hardware version, serial
number and production date.

english
Unite TP – Bodypack Transmitter 13
3.2 Display
The main screen (below) is displayed when the bodypack trans-
mitter is switched on and ready for operation.
Display of all active speakers (Master, 1st slave, 2nd slave)
Display of current type of speaker (the bar indicates Master,
1st slave or 2nd slave)
urrent channel name
Bluetooth status (various symbols; depending on the status)
Headset connected
Microphone muted
Display of remaining battery capacity
Display of the current type of speaker
U




U

Unite TP – Bodypack Transmitter
14
4. General operation
•Important: Before using the bodypack transmitter for the
first time, you must charge the built-in battery. Please use
an appropriate Unite charger.
• onnect a headphone or induction loop to jack socket .
• onnect a microphone to the 4-pin mini XLR connector or
use a headset with the connector (at/on connector ).
• Hold down the on/off button to switch on the transmitter.
• The integrated microphone  will be automatically activated
if no external microphone is connected.
• In order to establish an audio connection between a trans-
mitter and one or more receivers, all devices must be paired
together. See chapter 4.
• All devices are supplied with the group ID 256 and fixed
audio encryption. This allows for quick and easy initial use.
• The transmitter will only transmit the audio signal on a
channel with a predefined channel name. If there are several
transmitters in a group, the channel for the respective trans-
mitter can be selected on the receiver.
• If you require several device groups or a tap-proof audio
transmission, follow the steps in chapter 4 to create a new
pairing.
• If you require several device groups or a more tap-proof
audio transmission, to avoid listening by other groups using
Unite devices, follow the steps in chapter 4 to create a new
pairing.

english
Unite TP – Bodypack Transmitter 15
5. Create / define a new pairing
5.1 Encryption
The audio data is always encrypted with an AES-256 code to
ensure a tap-proof transmission. The required key will be
generated within the transmitter itself and only transmitted via
the chargers during the pairing process. As the key is not trans-
mitted via radio, the system is even better protected against
eavesdropping.
Should the receiver receive a differently encrypted audio signal
for which no key has been saved, the received audio signal will
be muted. The receiver display will also alternate between showing
the relevant channel name and the “KEY!” error message.
The encryption of the audio signal is shown schematically in
the following diagram.
Note: Only group ID 256 uses a factory-defined key that cannot
be changed. You can use this group ID for a system without
pairing.
RP
A
Encryption
TP
A
ARP
B

Unite TP – Bodypack Transmitter
16
5.2 Set group ID
The group ID identifies devices that can be placed in a virtual
group. For example, all devices of a building, a tour group or a
conference room.
The factory preset group ID is 256. To set a group ID between
1 and 255, follow the steps below:
• Press and hold the menu button for 2 seconds to activate
the main menu.
• Use the multifunction button to select “System” from the
menu.
• Press the menu button  to open the required submenu.
• Use the multifunction button  to select the “ID” submenu.
• Press the menu button to set an ID.
• Use the multifunction button to select the desired ID.
• Press the menu button  to confirm the selected ID.
Make sure to select the same group ID for all devices of a
desired group. Only devices that have the same group ID can
communicate with each other. Transmitters with other group
IDs are hidden. See the following diagram.
RP
TP 3
Group-ID 1
Group-ID 255
RP RP RP
TP 1 TP 2

english
Unite TP – Bodypack Transmitter 17
5.3 Set channel name
Devices that are grouped with one group ID can transmit
multiple audio channels via the same group ID.
In order to differentiate between audio channels from several
transmitters on the receiver, enter a five-digit name for the
channel on the transmitter. Proceed as described in the
following:
• Hold down the menu button on the transmitter for more
than 2 seconds to activate the main menu.
• Use the multifunction button  to select “System” from the
menu.
• Press the menu button  to open the required submenu.
• Use the multifunction button  to select the “ hannel
Name” submenu.
• Press the menu button  to set the channel name.
• Use the multifunction button  to scroll through the cha-
racters. When the desired character appears, confirm using
the menu button . You can input max. five characters.
• As soon as you select the configured transmitter on the
receiver, the set name will be displayed on the receiver’s
display.

Unite TP – Bodypack Transmitter
18
• The following diagram shows an example of two transmitters
with different channel names, and a receiver that can find
and switch between both transmitters. Finding and/or
switching between channels can take several seconds.
same Group-ID
Channel Name
TP 1
NAME 1
NAME 1 NAME 2
RP
1
N
OR
TP 2
NAME 2

english
Unite TP – Bodypack Transmitter 19
The transmitter and receiver can only communicate if the
settings in chapters 4.1 to 4.3 match. Transmitters cannot
communicate with receivers that do not have the same pairing
information. This is shown in the following diagram:
Group-ID 255
Name 1
A
RP
TP
RP
Group-ID 255
Name 1
A
Group-ID 1
Name 2
B

Unite TP – Bodypack Transmitter
20
5.4 Establish pairing
The pairing is made via the charger or the P software. A
detailed description can be found in the detailed operating
instructions at www.beyerdynamic.com/ Unite
Button for starting the pairing process or clearing stored
pairing information in the charger
Status indicator light for pairing status
Switch for „Pair & harge“ or „ harge only“
Unite charging case or 19" charger (top view)



Unite desktop charger (rear view)
Reset
Control
USB
12 V DC / 2 A
Charge
only
Pair &
Charge
Pair/Reset
Status

