Burkert SE56 User manual

SE56
p. 1/7
www.burkert.com
Transmitter for electromagnetic-
inductive flow sensor fittings
The electronics Type SE56 (blind in compact ver-
sion or with display in compact or remote version) con-
nected to the magnetic flow sensor fitting Type
S051, S054, S055 or S056 is designed for
applications with liquids with a minimum con-
ductivity of 5 μS/cm.
The device can be parameterize either with 3
keypads (version with display) or by computer via a
serial interface.
As standard, the equipment is supplied with
one or two transistor outputs and one digital
input. As options, other features are available:
such as high frequency output, current output,
PROFIBUS DP, HART.
Technical data - Electronics SE56 standard with display
Compatibility
S051, S054, S055, S056 sensor fitting
(see separate data
sheet 8051, 8054/8055, 8056)
Housing materials Die casting aluminium or
stainless steel 304 electro-polish
Display
Graphic display 8 lines x 16 Characters, 128 x 64 pixels
with back light
Keyboard 3 membrane keys
Electrical connection 6 cable glands PG 11
Medium temperature, please see separate data sheets of the complete magflowmeter 8051, 8054/8055, 8056
Environment
Ambient temperature
Operating and storage - 20 … + 60 °C (- 4 … + 140 °F)
Relative humidity
≤
85 %, without condensation
Height above sea level - 200 … + 6000 m
Standards, directives and certifications
Protection
Class I, IP67, category of installation II
Standards and directives The applied standards, which verify conformity with the EU
Directives, can be found on the EU Type Examination Certifi-
cate and/or the EU Declaration of conformity
(if applicable)
Type SE56 must be combined with...
• Must be equipped with sensor fitting S051, S054,
S055 or S056
• Continuous measurement or batch control
• High accuracy
• PROFIBUS DP, HART available
SE56 standard
with display,
Housing in
stainless steel SE56 blind
SE56 basic
Type S056
Magnetic sensor fitting
- Hygienic
Type S051
Magnetic sensor fitting
- for low flow
Type S054
Magnetic sensor fitting
- Wafer
Type S055
Magnetic sensor fitting
- Flange
Downloaded from Arrow.com.

SE56
p. 2/7
Technical data - Electronics SE56 standard with display (continued)
Electrical data
(continued)
Measurements
tolerance
Flow rate
(volume)
= ± 0.05 % of reading
Out 4/20 mA = ± 0.08 % of reading
Frequency out = ± 0.08 % of reading
Measurement deviation1)2) ± 0.2 % of reading
Repeatability ± 0.1 % of reading
Galvanic isolation All the input/outputs are galvanically iso-
lated from power supply
Data storage An EEPROM stores the measured values
(in case of power failure)
Special functions
Bidirectional measure
Dual measurement range
Diagnostic function
Empty pipe detection
Remote configuration (for connection to PC or
hand terminal through remote configuration tool kit)
Batch function
1) under reference conditions: water temperature = 20 °C, ambient temperature = 25 °C,
constant flow rate during the test, liquid speed > 1 m/s
2) =“measurement bias” as defined in the standard JCGM 200:2012
Technical data - Electronics SE56 blind
Electrical data
Power supply
90 … 265 V AC - 44 Hz...66 Hz
Power consumption max. 25 VA
Cable length max. 20 m
(distance between sensor fitting and electronics)
Input circuit 1 digital, selectable function
Outputs
Transistor
Current
Serial interface*
2 outputs, selectable open collector as
pulse/frequency (1250 Hz, 100 mA, 40 V DC)
or alarm (adjustable usage)
1 output, 4 … 20 mA - RL = 1000 W
(+ a second output)*
RS- 485, RS232, PROFIBUS DP or
HART
Velocity range
0.4 … 10 m/s
* on request.
General data
Compatibility
S051, S054, S055, S056 sensor fitting
(see separate data sheet 8051, 8054/8055, 8056)
Materials
Housing
Cover
Seal
Stainless steel
PPS
EPDM
Display None
Parameterization Through remote configuration tool kit (ac-
cessories Article no. 559 374)
Electrical connection 2 cable glands PG 9
Medium temperature, please see separate data sheets of the complete magflow-
meter 8051, 8054/8055, 8056
Electrical data
Power supply
20 … 30 V DC
Power consumption
max. 10 W
Input 1 digital, selectable function
Outputs
Transistor
Current
Serial interface*
2 outputs, selectable open collector as
pulse/frequency (1250 Hz, 100 mA, 40 V DC)
or alarm (adjustable usage)
1 output, 4 … 20 mA -
RL = 800 W passive
RS- 485 or PROFIBUS DP
* on request.
Electrical data
(continued)
Measurement deviation1)2)
± 0.2 % of reading
Repeatability ± 0.1 % of reading
Galvanic isolation All the input/outputs are galvanically iso-
lated from power supply
Data storage An EEPROM stores the measured values
(in case of power failure)
Special functions Bidirectional measure
Diagnostic function
Empty pipe detection
Remote configuration (for connection to PC or
hand terminal)
Batch function
Velocity range 0.4 … 10 m/s
Environment
Ambient temperature
Operating and storage - 20 … + 40 °C (- 4 … + 104 °F)
Relative humidity ≤ 85 %, without condensation
Height above sea level
- 200 … + 6000 m
Standards, directives and certifications
Protection
Class I, IP67, category of installation II
Standards and direc-
tives
The applied standards, which verify con-
formity with the EU Directives, can be found
on the EU Type Examination Certificate and/
or the EU Declaration of conformity (if ap-
plicable)
1) under reference conditions: water temperature = 20 °C, ambient temperature = 25 °C,
constant flow rate during the test, liquid speed > 1 m/s
2) =“measurement bias” as defined in the standard JCGM 200:2012
Downloaded from Arrow.com.Downloaded from Arrow.com.

SE56
p. 3/7
Technical data - Electronics SE56 basic
General data
Compatibility
S051, S054, S055, S056 sensor fitting
(see corresponding data sheet)
Materials
Housing PA6 with glass fibre
Display Alphanumeric display 2 lines x 16 Charac-
ters, without back light
Parameterization
Through remote configuration tool kit
(ac-
cessories Article no. 559 374) or 3 keys inside
Electrical connection
3 cable glands PG 11
Medium temperature, please see separate data sheets of the complete magflow-
meter 8051, 8054/8055, 8056
Electrical data
Power supply
90 … 265 V AC or 12 … 60 V DC
Power consumption max. 6 W
Input 1 digital, selectable function
Outputs
Transistor
Current
Serial interface*
2 outputs, selectable open collector as
pulse/frequency (1250 Hz, 100 mA, 40 V DC)
or alarm (adjustable usage)
1 output, 4 … 20 mA -
RL = 800 W passive
RS- 485
* on request.
Electrical data (continued)
Measurements
tolerance
Flow rate
(volume)
= ± 0.1 % of reading
Out 4/20 mA = ± 0.12 % of reading
Frequency out = ± 0.12 % of reading
Measurement deviation1)2) ± 0.8 % of reading
Repeatability
± 0.2 % of reading
Galvanic isolation All the input/outputs are galvanically iso-
lated from power supply
Data storage An EEPROM stores the measured values
(in case of power failure)
Special function Bidirectional measure
Diagnostic function
Empty pipe detection
Plug in (protected plug for connection to PC or
hand terminal)
Velocity range 0.4 … 10 m/s
Environment
Ambient temperature
Operating
Storage
- 10 … + 50 °C (14 … + 122 °F)
- 20 … + 50 °C (- 4 … + 122 °F)
Relative humidity ≤ 85 %, without condensation
Height above sea level - 200 … + 6000 m
Standards, directives and certifications
Protection
Class I, IP65, category of installation II
Standards and direc-
tives
The applied standards, which verify con-
formity with the EU Directives, can be found
on the EU Type Examination Certificate and/
or the EU Declaration of conformity (if ap-
plicable)
1) under reference conditions: water temperature = 20 °C, ambient temperature = 25 °C,
constant flow rate during the test, liquid speed > 1 m/s
2) =“measurement bias” as defined in the standard JCGM 200:2012
Dimensions [mm]
Electronics SE56 blind
184
144.5
15.5
58
90,5
65
53
113
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

SE56
p. 4/7
Dimensions [mm]
Electronics SE56 Basic
168
124
127
129
79
Electronics SE56 standard with display
171
146
146
40 125
230
152*
162
25
170
Compact version Remote version
* Dimension of compact version
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

SE56
p. 5/7
Ordering information for complete full bore magflowmeter Type 8051, 8054/8055 or 8056
A complete full bore magflowmeter consists of a sensor fitting and an electronics SE56.
Examples for variations of complete full bore magflowmeter (electronics + sensor fitting)
Electronics Type SE56
Standard with display
remote version
Standard with display
compact version
Without display (blind)
compact version
Basic (with or without display)
compact version
Magflowmeter Type 8051
More info.
For more technical
information about this
product, click on this
box... you will come
to our website for this
product where you
can download the
datasheet.
Compact version
sensor fitting
Type S051
Remote version
sensor fitting
Type S051
Magflowmeter Type 8054/8055
More info.
For more technical
information about this
product, click on this
box... you will come
to our website for this
product where you
can download the
datasheet.
Compact version
sensor fitting
Type S054
Type S055
Remote version
sensor fitting
Type S054
Type S055
Magflowmeter Type 8056
More info.
For more technical
information about this
product, click on this
box... you will come
to our website for this
product where you
can download the
datasheet.
Compact version
sensor fitting
Type S056
Remote version
sensor fitting
Type S056
The following information is necessary for the selection of a complete full bore magflowmeter:
• item no. of the sensor fitting Type S051, Type S054/Type S055 or Type S056 (see separate data sheets of the complete magflowmeter 8051, 8054/8055,
8056)
• item no. of the electronics Type SE56 (Ordering chart on page 6)
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

SE56
p. 6/7
Ordering chart for electronics Type SE56 for magflowmeter
Description Power supply Output Body material Electrical con- nection Article no.
Standard compact
version with display
90 … 265 V AC
2 transistors
Aluminium
6 cable glands
558745 
Stainless steel 6 cable glands
559780 
2 transistors + 4 … 20 mA
Aluminium
6 cable glands
558747

Stainless steel 6 cable glands 558306

Standard wall-
mounting version
with display
90 … 265 V AC 2 transistors Aluminium 6 cable glands
559781 
Stainless steel 6 cable glands
558310 
2 transistors + 4 … 20 mA
Aluminium
6 cable glands
558750

Stainless steel 6 cable glands 558308

Basic compact ver-
sion with display
90 … 265 V AC 2 transistors Nylon 3 cable glands
562439 
2 transistors + 4 … 20 mA Nylon 3 cable glands
562440 
12 … 60 V DC 2 transistors Nylon 3 cable glands 562443

2 transistors + 4 … 20 mA Nylon 3 cable glands 562444

Basic compact ver-
sion without display
90 … 265 V AC 2 transistors Nylon 3 cable glands
562441 
2 transistors + 4 … 20 mA Nylon 3 cable glands
562442 
12 … 60 V DC 2 transistors Nylon 3 cable glands 562445

2 transistors + 4 … 20 mA Nylon 3 cable glands 562446

Blind compact ver-
sion
20 … 30 V DC up to 4 transistors Stainless steel 2 cable glands
559132 
up to 4 transistors + 4 … 20 mA Stainless steel 2 cable glands
559133 
up to 4 transistors + PROFIBUS DP Stainless steel 2 cable glands
559134 
Further versions on request
i
Please also use the “request for quotation” form on page 7
for ordering a customized electronics.
Ordering chart - accessories
Description Article no.
Remote configuration tool kit
559374 
Configuration accessories
IF2
ENGLISH
AND
ITALIAN
SER.# 5 5J001 5
USB COMMUNICATION
SOFTWA RE
IF2
ENGLISH
AND
ITALIAN
SER.# 5 5J001 5
USB COMMUNICATION
SOFTWARE
Remote configuration tool kit
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

SE56
p. 7/7
To find your nearest Bürkert office, click on the orange box www.burkert.com
In case of special application conditions,
please consult for advice.
Subject to alteration.
© Christian Bürkert GmbH & Co. KG 1803/9_EU-en_00895031
Electronics Type SE56 for magflowmeter - request for quotation
Please fill out and send to your nearest Bürkert facility* with your inquiry or order.
NOTE : Please take into account that the electronics Type SE56 must be associated with a sensor fitting Type S051, S054, S055 or S056.
Company: Contact person:
Customer No.: Department:
Address: Tel. / Fax.:
Postcode / Town: E-mail:
Electronics SE56 standard with display
Quantity: Desired delivery date:
Mounting version Compact Wall-mounting Panel-mounting (body only in plastic)
Body material Aluminium Stainless steel
Power supply 90 … 265 V AC 18 … 63 V DC / 15 … 45 V AC 10 … 35 V DC
Outputs 4 … 20 mA RS 485 PROFIBUS DP
2 transistors 2 transistors + 4 … 20 mA 2 transistors (one of them: 10 KHz)
2 transistors + 1 x RS- 232 2 transistors + 4 … 20 mA + 1 x RS - 232
HART Protocol 2 Relays 60 V AC 2 Relays 250 V AC
Electronics SE56 blind, compact, in stainless steel, 20 … 30 V DC
Quantity: Desired delivery date:
Outputs 4 … 20 mA RS- 485 PROFIBUS DP
Electronics SE56 basic, compact, in plastic
Quantity: Desired delivery date:
Display With Without
Power supply 90 … 265 V AC 12 … 60 V DC/18 … 45 V AC
Outputs 4 … 20 mA RS- 485
Note
You can fill out
the fields directly
in the PDF file
before printing
out the form.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.
