Beyerdynamic Unite TH User manual

UNITE TH
HANDHELD TRANSMITTER
HANDSENDER
QUICK START GUIDE
KURZANLEITUNG

english
Unite TH – Handheld Transmitter 3
This device complies with Pa 15 of the FCC Rules and with
Indury Canada licence-exempt RSS andard(s). Operation
is su ject to the following two conditions: (1) this device may
not cause harmful inteerence, and (2) this device mu
accept any inteerence received, including inteerence that
may cause undesired operation.
Le présent appareil e conforme aux CNR d’Indurie
Canada applica les aux appareils radio exempts de licence.
L’exploitation e autorisée aux deux conditions suivantes: (1)
l’appareil ne doit pas produire de rouillage, et (2) l’utilisateur
de l’appareil doit accepter tout rouillage radioélectrique
su i, même si le rouillage e suscepti le d’en compro-
mettre le fonctionnement.
This equipment has een teed and found to comply with
the limits for a Class A digital device, pursuant to Pa 15
of the FCC Rules. These limits are designed to provide
reasona le protection again harmful inteerence when
the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not inalled and used in accordance with the
inruction manual, may cause harmful inteerence to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful inteerence in which case the
user will e required to correct the inteerence at his own
expense.
Changes or modifications made to this equipment not
expressly approved y Beyerdynamic may void the FCC
authorization to operate this equipment.
Radiofrequency radiation exposure Information:
For ody worn operation, this equipment has een teed
and meets the FCC RF exposure guidelines when used with
the Beyerdynamic accessories supplied or designated for
this product. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
Ee produto eá homologado pela Anatel, de acordo com
os procedimentos regulamentados pela Resolução n°.
242/2000 e atende aos requisites técnicos aplicados,
incluindo os limites de exposição da Taxa de A sorção
Específica referente a campos elétricos, magnéticos e
eletromagnéticos de radiofreqüência de acordo com as
Resoluções n°. 303/2002 e 533/2009.
Japanese Radio Law Compliance:
This device is granted pursuant to the Japanese Radio Law
(電波法).
This device should not e modified (otherwise the granted
designation num er will ecome invalid).

Unite TH – Handheld Transmitter
4
Country Approval
USA
Canada IC: 3628C-UNITEHBT
Europe
Japan
FCC ID: OSDUNITEHBT
Compliance Information
The devices conforms to the EU guidelines
(EMC) 2014/30/EU
(LVD) 2014/35/EU
(RED) 2014/53/EU
as atteed y the CE mark.
R 202-SMH014

english
Unite TH – Handheld Transmitter 5
Thank you for choosing the Unite TH handheld
transmitter.
To ensure an optimum peormance, we would like to
give you a rief introduction on how to use this handheld
transmitter.
The Unite TH handheld transmitter was designed for
arrier-free use:
– raised sym ols or raille on the operating uttons for
the lind
– compati le with the eyerdynamic induction loop for
the hard of hearing
For detailed operating inructions in your language,
please visit: www. eyerdynamic.com/unite
1. Safety instructions
General
• Please READ this user manual efore the first use.
• Please KEEP this user manual.
• Please FOLLOW the specified operating and safety
instructions.
Disclaimer
• eyerdynamic Gm H & Co. KG will not e lia le for any
damage to the product or injury to persons caused y
negligent, improper, incorrect or inappropriate
operation of the product.
Troubleshooting / repairs
• Never open the device yourself.
• Refer all service work to authorised professionals only.
Cleaning
• Only clean the device with a dry or slightly damp cloth.
Never use solvents, as these will damage the surface.
Rechargeable battery
• The handheld transmitter is operated with the a
lithium ion attery, which must replaced y trained
service staff only.
• Use only a USB 2.0/3.0 compliant 5V power supply to
charge the attery via the integrated USB
type-C port (power consumption is max. 500 mA).
• High temperatures, paicularly in association with a
high charging atus, result in irreversi le damage of
the attery.
• If you are not intending to use the attery for an
extended period or are planning to put it into orage,
it is advisa le to lower the attery’s charging level to
around 50% and to ore it at temperatures of maxi-
mum 30 °C.
• In order to ensure safe transpo y land, sea and air,
the attery used for the handheld transmitter is teed

Unite TH – Handheld Transmitter
6
according to the UN 38.3 transpo regulation for
lithium-ion atteries.
• Misuse or improper use could damage the attery. In
extreme cases, there is a risk of explosion, heat, fire,
smoke or gas.
• Never expose the attery to excessive heat such as
sunshine, fire or the like.
• Do not expose the attery to mechanical shock.
• Charge the attery efore initial use.
• Use the specified chargers for charging the attery.
• Avoid complete draining of the attery. This could
damage the attery and shorten its service life.
• If you do not use the transmitter for several months,
the atteries should e charged at least twice a year
to prevent deterioration in performance due to self-
discharge.
• Clean the charging contacts of the transmitter with a
clean dry cloth, if they ecome dirty.
• Do not short-circuit the attery.
• The charging contacts could cause property damage,
injuries or fire damage if they come into contact with
conductive materials such as jewellery, keys or chains.
This can lead to a closed electric circuit and, therefore,
to the material overheating. To avoid this kind of
unintentional electric circuit, the charging contacts
must e handled with care. This is especially important
if the transmitter is transported in a ag or another
container containing other metallic o jects.
Moisture / heat sources
• Keep the attery clean and dry. Never expose the
device to rain or high humidity. Do not install it in the
immediate vicinity of swimming pools, shower
facilities, damp asements or other areas with
unusually high air humidity.
• Never place o jects filled with water (e.g. vases or
drinking glasses) on the device. Liquids in the devices
may cause a short circuit.
• Never install or operate the device in the immediate
vicinity of radiators, lighting systems or other heat-
generating devices.

english
Unite TH – Handheld Transmitter 7
Disposal
At the end of its operating life this product may
not e disposed of along with normal house-
hold waste. Please take it to a designated
recycling point for electric and electronic
appliances. This is indicated y the sym ol on
the product, the operating instructions or the
packaging.
Simplified EU declaration of conformity
eyerdynamic here y declares that the wireless
transmission device complies with the EU Directive
2014/53/EU (RED). The complete text of the EU declaration
of conformity is availa le online at the following
address: http://www. eyerdynamic.com/cod
2. Supplied accessories
• Unite TH handheld transmitter
• Quick Start Guide
• Coloured rings ( 2 x lack, 2 x orange)
• Storage ag
• MA-CL 36 microphone clamp

Unite TH – Handheld Transmitter
8
3. Operating elements
3.1 Device (refer to the fold-out page)
 Microphone grille, detacha le
 Mute utton with status indicator light and raille
inscription
With this utton you can mute or activate the micro-
phone.
– Status indicator light – during operation:
– in the charger:
Indicator light Operating status
Off Device is switched off
Flashing yellow
slowly
• Ready to operate and
attery status > 10%
• Out of range (in slave
mode only)
Yellow In Request mode:
Connection esta lished, ut
no audio transmission;
attery status > 10 %
Green Connection esta lished, audio
transmission running (micro-
phone open or another audio
source is used) and attery
status > 10%
Flashing green
slowly
Microphone is muted
Flashing red slowly Low attery level < 10%
Red Device is starting
Flashing red/green
rapidly
Firmware update is running
Flashing red rapidly Critical error
Indicator light Charging status
Off Device is switched off
Flashing green
slowly
Charging 0 - 100%
Green Battery is charged
Flashing yellow
slowly
Pairing information is eing
copied from the transmitter
Yellow for
10 seconds
Device information is
copied successfully to
charger/devices

english
Unite TH – Handheld Transmitter 9
 Display
The display indicates the channel name, attery
status and different menus.
On/Off and menu utton
Use the on/off utton to turn the transmitter on or off.
To switch off the device, hold down the utton for 5
seconds. In order to activate the main menu, hold
down the utton for 2 seconds. Use the menu utton
to confirm settings. For a detailed description of the
individual menus and menu items, please refer to the
Unite manual on the internet at:
www. eyerdynamic.com/unite
Multifunction utton
If you are in a menu, you can scroll through the menu
to make various settings.
Coloured ring, replacea le
Type plate
Charging contacts
The uilt-in attery is charged via the charging
contacts when the device is inserted into the char-
ger. Make sure to insert the device fully into the char-
ging slot so that the charging contacts have proper
contact.
USB port, Type C
You can use this connector to charge the integrated
attery via a USB power adapter. Furthermore, you
can connect the handheld transmitter to the USB Type
C port on a Unite charger to charge it or to pair it with
other devices.
Indicator light Charging status
Flashes red slowly
for 10 seconds
• Too many transmitters in
the charger when pairing
is initiated
• Other paring error
Flashing green/
yellow rapidly
Device is eing localised
Flashing red/green
rapidly
Firmware update is running
Flashing red rapidly Charging error

Unite TH – Handheld Transmitter
10
3.2Display
The main screen ( elow) is displayed when the handheld
transmitter is switched on and ready for operation.
Display of all active speakers
(Master, 1st slave, 2nd slave)
Highlighted display of current type of speaker
(Master, 1st slave or 2nd slave)
Current channel name
Bluetooth® status
(various sym ols; depending on the status)
Display of muted microphone or display of source (internal
microphone or Bluetooth® Headset)
Activated talk ack function on receiver
Display of remaining attery capacity
UNITE
MASTER
80
MS S %






english
Unite TH – Handheld Transmitter 11
4. General operation
•Important: Before using the handheld transmitter for
the first time, you must charge the uilt-in attery.
Please use an appropriate Unite charger or the USB
connection.
• Switch on the transmitter y pressing the on-off
utton .
• In order to esta lish an audio connection etween a
transmitter and one or more receivers, all devices
must e paired together. See chapter 5.
• All devices are supplied with the group ID 256 and
fixed audio encryption allowing quick and easy initial
use.
• The transmitter will only transmit the audio signal on a
channel with a predefined channel name. If there are
several transmitters in a group, the channel for the
respective transmitter can e selected on the receiver.
• If you require several device groups or an audio trans-
mission even more secure against eavesdropping, to
avoid listening y other groups using Unite devices,
follow the steps in chapter 5 to create a new pairing.
4.1 Maintenance
• Protect the handheld transmitter from humidity, knocks and
shock. Avoid dropping the transmitter at all times.
• For cleaning the plastic surface of the handheld transmitter
use a soft cloth moistened with a solvent-free plastic
cleaner.
• As soon as your microphone
sounds dull, you should clean
the integrated pop shield:
– Unscrew the microphone
grille
 anti-clockwise.
– Pull out the foam pop
shield, if necessary use
tweezers.
Function
Mute/Menu/Ok
Unscrew microphone grille
Pull out the pop shield

Unite TH – Handheld Transmitter
12
– Clean it under clear running water.
– If necessary, use a mild washing-up
liquid.
– Dry it afterwards with a hairdryer or
allow it to dry overnight.
– Clean the microphone grille oth
inside and out with a slightly
moistened cloth or a soft rush
under clear running water and
allow it to dry overnight.
– The microphone grille cannot e
cleaned in a dishwasher.
– Place the dry pop shield inside the
microphone grille and replace the
microphone grille y screwing it
on clockwise.
Clean the foam pop
shield
4.2 How to replace the coloured ring
• Press the coloured ring with two fingers slightly together,
gra the small loop and pull the coloured ring carefully from
the transmitter.
Gra the coloured ring
Menu/Ok
MuteFunction
/
Pull the ring from the transmitter
Menu/Ok
MuteFunction
/
• Slide the new coloured ring from the
ottom onto the transmitter.
Make sure that the coloured ring is not
twisted.
Menu/OkMute Function
/
Slide the coloured ring
onto the transmitter

english
Unite TH – Handheld Transmitter 13
4.3 Tips and Tric s
• Avoid holding the handheld transmitter at the top or ottom.
You could cover the integrated antennae and therefore
reduce the range. Always hold the handheld transmitter in
the middle.
• At the factory the ALC (Automatic Level Control) and Noise
Gate functions are activated.
With the ALC function the handheld transmitter
automatically adjusts the gain to ensure the signal volume is
as consistent as possi le. The intelligi ility of speech is
significantly increased.
The Noise Gate function suppresses annoying ackground
noise.
• If the “ALC” function is deactivated, it is advisa le to reduce
the gain for loud speakers and to increase the gain for quiet
speakers. In either case, use the on-off and menu utton 
to access the “Audio” menu and the “Volume” and “Internal
Mic” su menus. Adjust the volume or microphone gain
accordingly.
• For an optimal speech transmission,
ensure a consistent distance to the
mouth. Avoid holding the microphone
closer or farther to the mouth. Also,
avoid turning your head while
speaking.
Wrong hand position
Function
/Menu/Ok
Function
Mute/Menu/Ok
Correct hand position
Mute
Distance to the mouth
Mute

Unite TH – Handheld Transmitter
14
• The Bluetooth® function of the handheld transmitter, which
can e set in the menu, serves as an audio interface for
playing various audio sources as well as for playing ack
audio signals. In order to connect the Unite TH handheld
transmitter with another device (e.g. headphone,
smartphone or computer) via Bluetooth®, pairing with the
connecting device must e carried out first. A detailed
description of the procedure can e found in the
comprehensive “Unite” manual on the internet at
www. eyerdynamic.com.
5. Create / define a new pairing
Transmitters and receivers must e paired so that they
can communicate with each other. For a successful
pairing the channel name, group ID and audio encryption
key are required. The required audio encryption key is
generated in the charger or via the Unite Manager soft-
ware and during the pairing process it is first stored on the
charger and then it is transferred to the transmitter and
receiver in the charger. In this context, please also note
the position of the switch on the charger. The switch must
e set to the “Pair & Charge” position so that the pairing
information can e transmitted from the charger to the
transmitters and receivers.
There are three different ways to pair the Unite transmitters
with receivers:
1. Via an individual charger (refer to the following
description or system manual online).
2. Using the Unite Manager Software on a PC (refer to
the Unite Manager Software manual or system
manual online).
3. Via dynamic channel search (refer to system manual
online, chapter “Special functions”.
Use with group ID 256
By default, the transmitters and receivers are supplied
with the group ID 256.
A factory-set audio encryption key, which cannot e
changed, is used for the factory-set group ID 256. The
audio encryption key ensures additional security against
unauthorised listening. You can use the group ID 256 for
a system without pairing.
Receivers with the group ID 256 can find and connect to
all transmitters with the group ID 256. This is done via the
dynamic channel search on the receiver.
Attention: When using several transmitters (e.g. Unite AP4
and several Unite TP) with the group ID 256 at the same
time, make sure that the individual channel names differ
from each other! Otherwise this can cause connection
pro lems with the receivers!

english
Unite TH – Handheld Transmitter 15
Use with individual group ID
If several receivers are to e divided into different
groups, for each group an individual group ID can
e assigned. A separate audio encryption key is
generated for an individual group ID in order to
ensure additional security against unauthorised
listening. This audio encryption key is generated
during the pairing process, stored in the charger and
transmitted from the charger to the transmitter and
receiver, along with the channel name and group ID.
Since the audio encryption key is not transmitted via
radio, it cannot e read out. This gives the system
maximum security against unauthorised listening.
The receivers can only connect to a transmitter with
which they have een paired. If the group ID is
su sequently set manually on the receiver, no
connection can e esta lished ecause the audio
encryption key does not match. Please note that the
transmitter to which the receivers are to e
connected must e defined as the master.
5.1 Encryption
The audio data is always encrypted with an AES-256
code to ensure a secure transmission. The required ey
will be generated within the charging unit itself and
transmitted to the transmitters and receivers during the
pairing process.
As the key is not transmitted via radio, the system is even
etter protected against eavesdropping.
Should the receiver receive a different encrypted audio
signal for which no key has een saved, the received
audio signal will e muted. The receiver display will also
alternate etween showing the relevant channel name
and the “KEY!” error message.
The encryption of the audio signal is shown schema-
tically in the following diagram.
Encryption
RP
RP
A
AA
B
TH
Pairing
KEY!
80
Note: Only group ID 256 uses a factory-defined key that
cannot e changed. You can use this group ID for a
system without pairing.

Unite TH – Handheld Transmitter
16
5.2 Set group ID
The group ID identifies devices that can e placed in a
virtual group. For example, all devices of a uilding, a tour
group or a conference room.
The factory-preset group ID is 256. To set a group ID
etween 1 and 255, follow the steps elow:
• Press and hold the menu utton for 2 seconds to
activate the main menu.
• Use the multifunction utton to select “System” from
the menu.
• Press the menu utton  to open the required su menu.
• Use the multifunction utton  to select the “Group ID”
su menu.
• Press the menu utton to set an group ID.
• Use the multifunction utton to select the desired
group ID.
• Press the menu utton  to confirm the selected group ID.
Make sure to select the same group ID for all devices of a
desired group. Only devices that have the same group ID
can communicate with each other. Transmitters with other
group IDs are hidden. See the following diagram.
Group ID 256 Group ID 1
RPRP RP RP
TH1 TH2 TH3

english
Unite TH – Handheld Transmitter 17
5.3 Set channel name
Devices that are grouped with one group ID can transmit
multiple audio channels via the same group ID.
In order to differentiate etween audio channels from
several transmitters on the receiver, enter a five-digit
name for the channel on the transmitter. Proceed as
descri ed in the following:
• Hold down the menu utton on the transmitter for
more than 2 seconds to activate the main menu.
• Use the multifunction utton  to select “System” from
the menu.
• Press the menu utton  to open the required su menu.
• Use the multifunction utton  to select the “Channel
Name” su menu.
• Press the menu utton  to set the channel name.
• Use the multifunction utton  to scroll through the
characters. When the desired character appears,
confirm using the menu utton . You can input max.
five characters.
• As soon as you select the configured transmitter on
the receiver, the defined name will e displayed on the
receiver’s display.
• The following diagram shows an example of two
transmitters with different channel names, and a
receiver that can find and switch etween oth
transmitters. Finding and/or switching etween
channels can take several seconds.
Same Group ID
Name 1 | Name 2
Name 1 or Name 2
RP
Channel Name
TH1 TH2

Unite TH – Handheld Transmitter
18
The transmitter and receiver can only communicate
when encryption, group ID and channel name match.
Transmitters cannot communicate with receivers that do
not have the same pairing information. This is shown in
the following diagram:
Group ID 256
Name 1
A
Group ID 256
Name 1
A
Group ID 1
Name 2
TH
B
RP
RP
5.4 Establish pairing
The pairing is made via the charger or the PC software. A
detailed description can e found in the detailed opera-
ting instructions at www. eyerdynamic.com/ Unite
Unite 19" charger (top view)
 Button for initiating the pairing process or clearing
stored pairing information in the charger
Status indicator light for pairing status
Switch for „Pair & Charge“ or „Charge only“




english
Unite TH – Handheld Transmitter 19
The status indicator  on the charger shows the
following information:
Indicator light Operating status
Off Device is switched off
Green • Device is ready to use
• No pairing information saved
Flashing yellow Pairing information is eing
copied to the charger or receiver
Yellow Pairing information has een
stored in the charger
Flashing green/
yellow
Device is eing localised
Flashes red 5 times • No transmitter
• Too many transmitters
Flashing red rapidly • Operating error
• Charging error
In order to perform a simple pairing, proceed as
descri ed in the following:
1. Set the desired group ID on the transmitter you want
to use for pairing. See chapter 5.2 for reference.
2. Insert only one transmitter into the charging slot of
the charger. If multiple transmitters are inserted into
the charging slots of the charger, the pairing will not
start and the status indicator on the charger will
display an error (see ta le). Alternatively, you can
connect the transmitter to the USB port on the
charger via a USB ca le.
3. Insert one or more receivers into the charging slots of
the charger to e paired with the transmitter. You
can also connect another receiver to the charger
using the USB port. Remove all receivers that should
not e paired. If there is no receiver in the charging
slots, the pairing information is stored in the charger.
This is used for later pairing without connecting the
transmitter to the charger.
4. In order to transfer the pairing information from the
transmitter to the receivers in the slots and to the
charger itself for future pairing, press and hold the
“Pair/Reset” utton on the charger for more than
2 seconds. The status indicator will flash yellow for
several seconds if the pairing is successful. The
status indicator will then remain yellow ecause the
pairing information is now also stored in the charger.
5. If you want to pair other receivers, remove the trans-
mitter and all receivers from the charger, set the
switch to “Pair & Charge” and insert the unpaired
receivers into the charger. The pairing information will

Unite TH – Handheld Transmitter
20
e stored immediately in the unpaired receivers. The
status indicator on the receiver will flash yellow ra-
pidly while this happens.
6. Set the switch  ack to “Charge only” when the
pairing is finished, so that the charger can only e
used for recharging.
7. Switch on the transmitter and one receiver to check
that they have oth een paired successfully.
After a few seconds, the status indicator on the
receiver should light up green and the display should
show the channel name of the transmitter.
8. If you want to clear the stored pairing information,
hold down the “Copy/Reset utton  for more than
five seconds. The status indicator will then remain
permanently green.
6. Technical specifications
DECT RF frequency range . . . . . 1880 - 1930 MHz,
depending on the country
DECT transmission power . . . . . . up to 250 mW (peak),
depending on the country
DECT operating range . . . . . . . . . up to 300 m outside
(line of sight);
the actual operating
range depends upon the
RF output settings, the
surroundings, the signal
a sorption, signal
reflection and signal
interference
Operating mode. . . . . . . . . . . . . . . Broadcast and/or
full-duplex on all routes
Encryption. . . . . . . . . . . . . . . . . . . . . AES-256 it encryption
Display . . . . . . . . . . . . . . . . . . . . . . . . monochrome white OLED
display with high contrast
DECT audio andwidth
Low quality (SD) . . . . . . . . . . . . . . 50 Hz - 7 kHz (-3 dB)
High quality (HD) . . . . . . . . . . . . . 50 Hz - 14 kHz (-3 dB)
Simultaneously
active microphones . . . . . . . . . . . 1 x handheld transmitter,
max. 2 x via talk ack
functionality
Side-tone and
microphone gain . . . . . . . . . . . . . . individually adjusta le
Microphone capsule
Transducer type . . . . . . . . . . Condenser
( ack electret)
Operating principle. . . . . . . Pressure gradient
Polar pattern . . . . . . . . . . . . . Cardioid
