Beyonwiz DP-P2 User manual

USER GUIDE
DP-P2
Version 1.52_Eng

Welcome Message
i
Welcome Message
Thank you for choosing a beyonwiz DP-P2, the epicentre of your home entertainment n
e
twork.
The DP-P2 supports all the features of a conventional digital broadcasting receiver or STB (Set-Top Box) and PVR (Personal Video Recorder). As
well as the dual DVB-T digital tuners, the DP-P2 also enables you to listen to or watch multimedia content from:
Line-input
Storage devices attached to the integrated USB (Universal Serial Bus) connectors
The integrated CF card slot
The integrated SD/MMC/Memory Stick port
Network devices from your PC, home network and/or the Internet
You can now pause, rewind and record the pay TV with the line-input. You don’t need any tape or DVD for recording. And you can play almost
any multimedia content from any connected storage device. With a DP-P2, you don’t have to bring your PC to your living room to enjoy your PC
or Internet based content on the big screen. You can be free to share your valuable time and experience with your family.
The DP-P2 supports the IceTV Interactive so that you can schedule programs from your PC or mobile phone.
To enjoy the newest features available on your DP-P2, make sure that the latest firmware is installed.
Note that with new firmware some features, which are not described in this manual, may be added and
some features described in this manual may be altered or removed. These changes are usually made
to give you the best performance and user experience.
Visit our website, http://www.beyonwiz.com.au/, to get updated information about firmware and
features.

Precaution
ii
Precaution
Read this manual carefully before using this product. The cautions
described below contain important information about safety, and are
categorized into: Danger, Warning and Notice. The company will not be
responsible for accidents or damage resulting from careless handling by
the user.
DANGER
If the user mishandles the product, there is loss of life risk or
critical injury.
Connect the power cord only to A/C outlets as specified by the user
manual or product specification. If the power code is connected to a
non-specified A/C outlet, it can result in fire or electric shock.
The product must not be exposed to water or liquid of any kind, or be
exposed to drips or splashes. It can result in fire or electric shock.
Do not place heavy objects, including the product itself, on top of the
power cord. If it is damaged, it can result in fire or electric shock.
Do not place metal objects on top of the apparatus. If metal objects
fall onto the apparatus, it could result in fire or electric shock.
Do not repair, disassemble or modify this apparatus yourself. It can
cause fire or electric shock. If internal checking or maintenance is
needed, please contact your service center or agency.
Do not block or cover any ventilation opening. A fire can result from
overheating.
Turn off and unplug the power as quickly as possible during electric
storms. Failure to do so can result in fire or electric shock.
Remove the antenna’s power plug from the outlet as quickly as
possible during electric storms. Failure to do so can result in fire or
electric shock.
Do not drop the apparatus (for example by putting it in a place where
it may fall) or subject it to impact. The product might be damaged. If
it is damaged, please turn off the power and remove the plug from
the power outlet, fire or electric shock may occur.
Never touch the power cord with wet hands. It can result in an
electric shock.

Precaution
iii
WARNING
If the product is mishandled, the user might receiver a serious
or minor injury. Damage or loss to the user’s property may also
occur.
The product must not be exposed to water or liquid. If the apparatus
is exposed to drips or splashes, it might cause a problem that may
not be repairable.
Do not repair, disassemble or modify this apparatus yourself. It can
be seriously damaged, possibly beyond repair.
Turn off the power and unplug the power cord as quickly as possible
during electric storms. The apparatus may be damaged.
Remove the antenna’s power plug from the outlet as quickly as
possible during electric storms; otherwise the apparatus might be
damaged.
Data recorded in the HDD may be lost due to a shock, lightening or
electricity failure. The user must back up his or her own data, and the
company does not take any responsibility for failure to do so.
NOTICE
If the product is mishandled, it might cause minor damage.
If the apparatus becomes marked, clean it gently with a soft cloth or
towel. Never use chemical solvents such as benzene, thinner, acetone
or other solvents. The surface of the apparatus might become
discoloured and the paint might peel.
Do not place or keep the apparatus in the following situations. Doing
so might cause problems.
- Where it is too hot or cold.
- Where there is high humidity.
- Where there are excessive temperatures, for example in front of
air-conditioners or heating vents.
- Where there is dust or soot.
- In confined areas where the heat cannot be released.
- Where it is exposed to direct sunlight.
Turn the apparatus off and unplug the power cord if the unit is to be
unused for a long period of time.
Do not place heavy objects on top of this apparatus. It might cause
malfunction or damage.
If the apparatus is so seriously damaged that it cannot be repaired,
or has stopped working altogether, dispose of it properly in
accordance with the local laws or regulations in your area.

Precaution
iv
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
About the internal hard disk drive
The internal hard disk drive (HDD) is a fragile piece of equipment.
Please use the apparatus within the guidelines below to protect against
possible HDD failure or to protect against accidental loss.
Do not move the apparatus whilst it is on.
Install and use the apparatus on a stable, level surface.
Do not block the top ventilation holes.
Do not use the apparatus in excessively hot or humid places, or in
places that may be subject to sudden changes in temperature.
Sudden changes in temperature can cause condensation to from
inside the apparatus. This can be a cause of HDD failure.
Whilst the apparatus is switched on, do not unplug it from the wall
socket or switch the electricity off from the circuit breaker.
Do not move the apparatus immediately after switching it off.
If there is a power failure whilst the apparatus is on, some data on
the HDD might be lost.
The HDD is very delicate. If used improperly or in an unsuitable
environment, the HDD may fail after a few years of use. Signs of
problems include playback unexpectedly freezing and noticeable block
noise (mosaic) in the picture. Sometimes there will be no warning
signs of HDD failure. If the HDD fails, no playback of recorded
material will be possible. In this case the HDD needs to be replaced
by a qualified technician.

Precaution
v
Copyright
This manual is protected by copyright laws.
Copy, use, reproduction of this manual in part or whole without beyonwiz's
prior written permission is prohibited.
Disclaimer
The manufacturers, distributors and agents are not liable to any kind of
damage caused by the use of the information contained in this manual.
The instruction and descriptions which this manual contains are based on the
time of this manual's production.
The manufacturer constantly updates it with new functions and technology.
All the specifications are subject to change without prior notice.
Trademarks
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
Manufactured under the license from Dolby Laboratories. "Dolby" and the
"double-D" symbol are trademarks of Dolby Laboratories.
The USB-IF Logos are trademarks of Universal Serial Bus Implementers
Forum, Inc.

Contents
Contents
Welcome Message i
Precaution ii
1. Package Contents 1
2. Introduction 3
1. DP-P2 Highlights 3
2. Front Panel 4
2-1.
Buttons
4
2-2.
Slot Door
4
2-3.
Front Display Window
4
3. Rear Panel 5
4. Remote Control 6
4-1.
Operating DP-P2
6
4-2.
Operating Other Beyonwiz Products
7
4-3.
Operating TV set
8
4-4.
Remote Control HEXA Code
10
3. How to Connect 11
1. Connect to TV 11
2. A/V Inputs 12
3. A/V Bypass 12
4. Recommended Configuration 13
4-1.
Case 1: Connecting DP-P2 to TV with HDMI
13
4-2.
Case 2: Connecting DP-P2 to TV with S-VIDEO
13
5. Antenna Connection 14
6. Ethernet Connection 15
6-1.
Wired Connection Using a Network Router (LAN)
15
6-2.
Direct Connection to a PC
16
6-3.
Direct Connection to Internet
17
4. Quick Setup 19
1. Start Quick Setup 19
1-1.
Quick Setup of Video Output Format
20
1-2.
Basic Operation
21
2. Configuration 24
2-1.
Time Setting
24
2-2.
A/V Output Setting
25
2-3.
Service Scan
27
2-4.
A/V Input
29
3. Network30
3-1.
Ethernet Setting
30
3-2.
Automatic Configuration
31
3-3.
Ice Guide
33
3-4.
WizPNP
34
3-5.
Windows Sharing
36
5. STB & PVR Function 37
1. Basic STB Function 37
1-1.
Service Change
37
1-2.
Information Box
40
1-3.
Volume Level Adjust
41
1-4.
Soundtrack Change
41
1-5.
Subtitle and Teletext Service
42
1-6.
Sleep Timer
43

Contents
2. Service Edit 44
2-1.
Service List Edit
44
2-2.
Favorite Group
45
3. PVR Functions 47
3-1.
Time-shifting
47
3-2.
Instant Recording
48
3-3.
Timer
50
3-4.
Trick Mode Operation
55
3-5.
Recording Control
56
3-6.
Timer Conflict
58
4. EPG (Electronic Program Guide) 60
4-1.
EPG with Multiple Services
60
4-2.
EPG with Single Service
61
4-3.
Service Change and Recording
62
6. File Playback Function 64
1. Exploring Contents 64
2. Contents Playback 69
2-1.
Movie Playback
69
2-2.
Music Playback
74
2-3.
Photo Playback
74
2-4.
Playlist
75
7. File Management 77
1. Add Folder 77
2. Delete 78
3. Auto Delete 79
4. Rename 79
5. Copy / Move 80
6. Edit Recording File 83
8. Internet Service 84
9. Advanced Setup 85
1. Miscellaneous 85
1-1.
Favorite
85
1-2.
OSD
87
1-3.
Access Control
88
1-4.
PVR
90
1-5.
File Player
94
1-6.
Preference
95
2. Management 96
2-1.
Firmware
96
2-2.
HDD
98
2-3.
Initialize
101
10. Troubleshooting Guide 103
Specification a
Warranty Conditions b
WEEE Information c
Contact Beyonwiz d

This page intentionally left as blank.

Package Contents
1
1. Package Contents
The following elements are included in the gift box.
Please check all package contents before using your product.
DP-P2
Remote Control
Batteries
(AAA size x2)
.
User Manual
RCA Audio/Video Cable
Component (Y/Pb/Pr) Video Cable
Ethernet Cable

2
This page intentionally left as blank.

Introduction
3
2. Introduction
1. DP-P2 Highlights
World first HD PVR feature
The DP-P2 can record two HD (1080i) programs concurrently while
you enjoy the time-shifting features. It can also pause, rewind and
record a pay TV with the A/V input.
IceTV Interactive support
You can get 7-day the EPG (Electronic Program Guide) from IceTV
(www.icetv.com.au) and schedule programs based on the EPG
information. You can even schedule programs from your PC or mobile
phone.
HD Multimedia player
With USB host ports and networking, the most frequently used ways of
sharing contents, the DP-P2 gives unlimited flexibility to access and play
multimedia content.
Colour Theme on your taste
The DP-P2 provides 10 different colour themes for OSD (On-screen
Display) on your taste.
Dual Tuner DVB-T Compliant with Internal Loop through
Video Output Composite, S-Video, Component (Y, Pb, Pr), HDMI
Audio Output 2ch RCA for analog audio
(Dolby Digital stereo decoding)
Coaxial and Optical S/PDIF, Digital audio in HDMI
A/V Input* Composite, S-Video
2ch RCA for stereo audio input
Interface 10/100 Ethernet Port
2 USB Host Ports (USB 2.0 Compliant)
Memory Card Slots: SD, CF, MMC and Memory Stick
Multimedia
Playback
Movie: mkv, wmv, avi, mpg, vob, mp4, asf, tp, trp
Music: mp3, wma, aac, ac3
Photo: bmp, jpeg, png
* If you connect other A/V device such as a set-top box for a pay-TV
service to these input ports, you can record or enable time-shifting
functions for the pay-TV service with the DP-P2. Please refer to 3. How
to Connect and get the recommended configurations.

Introduction
4
2. Front Panel
2-1.
Buttons
Five buttons are placed on the front panel.
STANDBY Button: it switches the DP-P2 between the operation and
standby modes.
CHANNEL Buttons: the top and bottom parts of the circular button
work as the channel-up and channel-down buttons.
VOLUME Buttons: the left and right parts of the circular button work
as the volume-down and volume-up buttons.
Standby Button
Channel, Volume Buttons
Front Display Window Slot Door
Front Panel
(USB, CF Card, SD/MMC/Memory Stick)
2-2.
Slot Door
A slot door is placed on the right side of the front panel. If you open this
door, you can find the following ports;
USB: you can connect a USB storage device which is compatible to
the USB standard specification.
CF Card: you can connect a CF-type memory card.
SD/MMC/Memory Stick: you can connect either SD-type or MMC-type
memory card. You can also connect a Memory Stick.
2-3.
Front Display Window
The front display window gives you easy way to check the status of the
DP-P2.

Introduction
5
1 Indicates hard disk space used.
2 Lights when there is no space left on the HDD.
Lights when there is no time information.
3 Lights when a timer recording is programmed in standby mode.
4 Lights when the signal comes out via HDMI.
5 Lights when the signal is High Definition (will be implemented).
6 Indicates the resolution of video output.
7 Lights when the video output is in Progressive Scan mode.
8 Lights when Ethernet connection is set up and enabled.
9 Lights when USB devices or memory cards is connected.
10 Indicates operation mode (TV or Radio).
11 Indicates the current recording status.
12 Lights when Time Shift is enabled.
13 Indicates playback of content with light on the outer circle and
revolving on the inner circle.
14 Indicates the audio format of content.
15 Lights on FR and FL when the audio output is set to stereo.
Lights on all indicators when the audio output is 5.1CH.
No light when the audio output is Pass-through.
3. Rear Panel
1. RF ANT. IN
2. RF LOOP OUT
3. HDMI
4. COXIAL AUDIO
5. OPTICAL AUDIO
6. S-VIDEO*
7. COMPONENT (Y/Pb/Pr)
8. ANALOG A/V OUTPUT*
9. ETHERNET
10. USB
11. ANALOG A/V INPUT**
* These ports can also bypass the external signals connected to the
analog A/V input ports. You can control these ports with the
AV
bypass
button.
** These ports are for connecting other A/V device such as a set-top
box for a pay-TV service.

Introduction
6
4. Remote Control
4-1.
Operating DP-P2
In order to operate the DP-P2 with the enclosed remote control, please
select
STB
mode by pressing the
STB
button. The red backlight
beneath the
STB
button lights when you press a button in this mode.
The below picture and right table show the function of each button on
the remote control.
1 STANDBY Switch the DP-P2 between Operation and Standby mode.
2 AV bypass Change the Composite, S-Video and Analog Audio outputs to
the AV bypass mode
3 STB Set Remote Control to Work for the DP-P2.
4 TV/RADIO Change to TV mode or Radio mode.
5 TV-OUT Change Video Output. (Refer to page 17. for more information)
6 TV Control standard TVs with remote control.
7 SETUP Go to SETUP Menu.
8 WizTV Go to Internet Service.
9 LIVE Go to Live TV.
10 File PLAY Go to File Play.
11 VOL +/- Adjust the volume. (Increase/Decrease)
12 CH +/- Change TV or Radio Service.
13 MUTE Enable or disable the Audio output.
14 INFO Show service information.
15 FAV Show Favorite Service List.
16 GUIDE Show EPG (Electronic Program Guide).
17 POP-UP Show advanced menus of the current mode.
18 LIST Show Service List.
19 EXIT Return to the previous menu or Cancel.
20 UP/DOWN/LEFT/
RIGHT
Move the indicator on the menu mode.
21 OK Select an item on the menu or Confirm.
22 RECALL Recall the previously viewed (or listened) service.
23 RED Optional function key, and set bookmark
24 GREEN Optional function key, and play from the bookmarked position
25 YELLOW Optional function key, and A-B Repeat
26 BLUE Optional function key
27 0~9 Numeric buttons.
28 SLEEP Set sleep time of the DP-P2.
29 ZOOM Zoom-in or Zoom-out.
30 PLAY Play Content.
31 STOP Stop playback.
32 PAUSE Pause playback.
33 SLOW FWD Slow Forward.
34 REW Rewind.
35 FF Fast Forward.
36 PREV Go to the previous track or file, and continue playing.
37 NEXT Go to the next track or file, and continue playing.
38 REC Start recording.
39 SUBTITLE Change Subtitle language.
40 TELETEXT Show Teletext.
41 SOUNDTRACK Change Soundtrack language.

Introduction
7
4-2.
Operating Other Beyonwiz Products
The enclosed remote control (Product code: BR-02) is designed to
operate the DP-P2 only. To operate other Beyonwiz products of DP-S1,
DP-P1 and DP-H1, which are designed to be operated with a remote
control of BR-01, you have to change its operating mode; please press
and hold the numeric button
1
for 5~6 seconds while pressing the
OK
button. The red backlight beneath the
TV
button blinks three-times if
the remote control changes its operating mode successfully.
If you want to return the operating mode of the remote control to
operate the DP-P2, please press and hold the numeric button
2
for 5~6
seconds while pressing the
OK
button. The red backlight beneath the
TV
button blinks three-times if the remote control changes its operating
mode successfully.

Introduction
8
4-3.
Operating TV set
The enclosed remote control can also be used to control a TV set
provided by major TV manufacturers. In order to operate a TV with the
enclosed remote control, please select
TV
mode by pressing the
TV
button. The red backlight beneath the
TV
button lights when you press
a button in this mode.
There are two ways to program the remote control to work with your TV,
automatic code search or manual set.
1) Automatic Code Search
Please turn on your TV then press and hold the
TV
button until the red-
backlight turns on. Please point the remote control at your TV and click
the
UP
button. After the red-backlight of the
TV
button blinks, please
wait at least 3 seconds to check your TV turns off or not. If your TV
turns off automatically, your remote control is ready to use for your TV.
If your TV does not turns off, please repeat clicking the
UP
button until
your TV turns off. Once your TV turns off after you click the
UP
button,
please press the
OK
button. The
TV
button blinks three times to
indicate that the remote control is set.
2) Manual Set
You can set your remote control with 3-digit code manually. Please look
at the following table and find the brand of your TV.
Turn on your TV then press and hold the
TV
button until the red-
backlight turns on. Please point the remote control at your TV and enter
the 3-digit code with the
NUMERIC
buttons. Wait until the red-
backlight blanks three times. If your TV turns off automatically, your
remote control is ready to use for your TV. If your TV does not turns off,
press the
TV
button and enter another code from the table under that
brand.
FUJITSU 208 223 224 218 253
261 286 307 325 329
410 422 423
HITACHI 206 207 208 215 218
229 231 232 236 238
240 244 253 256 286
287 292 298 299 300
301 304 305 306 307
309 3123 314 315 316
317 325 358 367 381
382 383 384 399 405
406 407 410 411

Introduction
9
JVC 207 212 247 264 323
385
LG 208 215 224 229 253
286 307 344 374 385
387 410 412
NEC 205 207 208 215 224
229 248 253 286 389
PANASONIC 208 210 211 212 213
214 216 220 230 236
237 239 242 244 245
255 258 260 278 279
286 307 309 384 410
PIONEER 208 244 246 286 287
307 374 376 380 410
SAMSUNG 205 206 208 209 215
216 218 224 229 253
260 270 277 286 287
296 325 337 374 410
412
SHARP 207 209 230 245 384
SONY 206 207 208 225 230
264 272 285 286 329
424 426 430
THOMSON 208 258 286 345 405
NOTE
If your TV brand is not listed on above, please visit the following
website to get the correct code if available: www.beyonwiz.com.au.
Your remote will not always be compatible with all branded televisions.
If this remote doesn’t work or no code exists, please obtain the
original remote from the manufacture of your TV.

Introduction
10
4-4.
Remote Control HEXA Code
The picture below and table on the right provide you with information to
allow you to program your own programmable remote control to
operate the DP-P2. The coding system used for the DP-P2 is the NEC
type.
1 STANDBY 0xBE010AF5
2 AV bypass 0xBE0140BF
3 STB N/A
4 TV/RADIO 0xBE0155AA
5 TV-OUT 0xBE0142BD
6 TV N/A
7 SETUP 0xBE0107F8
8 WizTV 0xBE0152AD
9 LIVE 0xBE0108F7
10 FILE PLAY 0xBE0144BB
11 VOL +/- 0xBE0102FD 0xBE0103FC
12 CH +/- 0xBE0100FF 0xBE0101FE
13 MUTE 0xBE010CF3
14 INFO 0xBE010DF2
15 FAV 0xBE0109F6
16 GUIDE 0xBE0143BC
17 POP-UP 0xBE011AE5
18 LIST 0xBE014CB3
19 EXIT 0xBE011CE3
20 UP/DOWN/
LEFT/RIGHT 0xBE014EB1 0xBE014FB0 0xBE0153AC 0xBE0154AB
21 OK 0xBE011FE0
22 RECALL 0xBE011EE1
23 RED 0xBE014DB2
24 GREEN 0xBE010DF2
25 YELLOW 0xBE010EF1
26 BLUE 0xBE010FF0
27 0/1/2/3/4/
5/6/7/8/9 0xBE0110EF 0xBE0111EE 0xBE0112ED 0xBE0113EC 0xBE0114EB
0xBE0115EA 0xBE0116E9 0xBE0117E8 0xBE0118E7 0xBE0119E6
28 SLEEP 0xBE011BE4
29 ZOOM 0xBE0150AF
30 PLAY 0xBE014BB4
31 STOP 0xBE014AB5
32 PAUSE 0xBE0146B9
33 SLOW FWD 0xBE0106F9
34 REW 0xBE0145BA
35 FF 0xBE0148B7
36 PREV 0xBE0104FB
37 NEXT 0xBE0105FA
38 REC 0xBE015EA1
39 SUBTITLE 0xBE0147B8
40 TELETEXT 0xBE0151AE
41 SOUNDTRACK 0xBE0149B6

How to Connect
11
3. How to Connect
1. Connect to TV
Depending on the A/V equipment you own, there are various ways you
can connect the DP-P2. To choose the best connection option, please
refer to the manual of equipment you would like to connect to.
To get High Definition playback of High Definition content, we
recommend you connect your high definition display with a HDMI cable.
HDMI supports standard, enhanced or high-definition video and multi-
channel audio in a single cable (HDMI cable can be purchased
separately).
If your TV set does not support HDMI but has a DVI input, a HDMI to
DVI converter can be purchased separately (in this case, audio signal
output through the HDMI interface is disabled). If you do not have a
high definition display, you can connect the DP-P2 and A/V equipment
via other connection options. To connect your DP-P2 to your TV or
display, the following options are available (in order from highest to
lowest quality);
HDMI (high definition compatible)
Component (Y/Pb/Pr) (high definition compatible)
S-VIDEO
Composite
To connect your DP-P2 to your TV or audio system, the following options
are available;
S/PDIF Digital Audio output (COAXIAL, OPTICAL)
2 CH Analog Audio output
NOTE
The Composite, S-VIDEO and Analog Audio output ports can also
bypass the external signals connected to the analog A/V input ports.
You can control these ports with the
AV bypass
button.
