BH G863T User manual

Ellipcal UserManual
橢圓機裝配說明書
椭圆机装配说明书
G863T
G863T
G863T
Version 1.00

Product Safety
Basic precautions should always be followed, including the following safety instructions when using this
equipment: Read all instructions before using this equipment.
1. Read all the instructions in this manual and do warm up exercises before using this equipment.
2. Before exercise, in order to avoid injuring your muscles, warm-up exercise for every muscle group is highly
recommended. Please refer to the Warm Up pages for pre and post workout.
3. Please make sure all components are not damaged and in working order before use. This equipment should be
placed on a flat surface while in use. Using a mat or other material on the ground is recommended.
4. Please wear proper clothes and shoes when using this equipment; do not wear clothes that might catch in any
part of the equipment.
5. Do not attempt any maintenance or adjustments other than those described in this manual. Should any problems
arise, discontinue use and consult an Authorized Service Representative.
6. Be careful when stepping on or leaving the pedals. Always hold the handlebars first and make sure the pedal at
your side is at its lowest position. Step on the pedal, and stride over the Main Frame (A01) then step on the other
pedal. When using, please hold onto the handlebars. To ensure the pedals run smoothly push or pull on the
handlebars first, then follow with leg motion. When stepping off the machine, make sure one pedal is at its lowest
position and step out of there before stepping out of the pedal at the highest position.
7. Do not use the equipment outdoors.
8. This equipment is for household use only.
9. Only one person should be on the equipment while in use.
10. Keep children and pets away from the product while in use. This machine is designed for adults only. If you feel
any chest pains, nausea, dizziness, or short of breath, you should stop exercising immediately and consult your
physician before continuing.
11. If you feel any chest pains, nausea, dizziness, or short of breath, you should stop exercising immediately and
consult your physician before continuing.
12. The maximum weight capacity for this product is 360lbs /160kgs.
WARNING: Before beginning any exercise program consult your physician. This is especially important for the
persons who are over 35 years old or who have pre-existing health problems. Read all instructions
before using any fitness equipment.
CAUTION: Read all instructions carefully before operating this product. Retain this Owner’s Manual for future
reference.
G863T Elliptical User Manual

Part Drawing & Contents
Box A
A01 1Set
A09 1Set
A15 1Set
A02 1Set
D02 1PC
Main Frame
Front Stabilizer
Guide Raill
Upright Post
Computer
C07/C08 1Set
C12 2PC
C27/C28 2Set
C29 1 PC
D08 1PC
Upright Joint Cover L/R
Foot Pedal
Wheel Cap A/B
Water Bottle Holder
AC Adaptor
1PC
F02 1PC
C23 2PC
Lubricant
Water Bottle
Cushion Pad
Box B
A05/A07 1Set
A06/A08 1Set
A03 1Set
A04 1Set
A13/A14 1Set
Foot Bar Assy /L
Foot Bar Assy /R
Handrail Arm /L
Handrail Arm /R
Handrail L/R
C11 4PC
C04 6 PC
C17/C18 2Set
Nut Cap
End Cap ∅4”
Handrail Arm
Decorative Cover -A/B
G863T Elliptical User Manual

Hardware & Tools
B13 8PC
B30 12PC
B32 8PC
B21 23PC
B24 2PC
Screw M8*18 mm
Curve Washer
M8x20x1.5T
Hexagon Head Bolt
M8x16mm
Screw M5x16mm
Bolt M8x80mm
B29 6PC
B18 2PC
B33 4PC
B23 8PC
B28 4PC
Nylon Nut M8
Washer 5/16"*20*2.0T
Washer 10x32x5.0T
Screw M6*16 mm
Bolt M8x50mm
1PC
1PC
1PC
Hex Tool with Phillips Screwdriver (13mm/14mm)
Allen Key (M6)
Allen Key (M5)
G863T Elliptical User Manual

Assembly
1. Front stabilizer installation
1.1 End caps [C04] installation
1.2 Remove Two 3/8” Screws (B41) and Two Washers 3/8” (B42) from the
Main Frame (A01).
1.3 Position the Front Stabilizer Tube (A09) in front curve of Main Frame
(A01) and align bolt holes.
1.4 Assemble the Front Stabilizer Tube (A09) to front curve plate of Main
Frame (A01) with Two Screws 3/8” (B41) and Two Washers 3/8” (B42)
which were removed from step .1.2
[Tighten nuts with the Hex Tool with Phillips Screwdriver provided.]
2. PRE-ASSEMBLY
1.1 Loosen slightly 4 M8 screws [B13] at GUIDE RAIL[A15].
[Undo screws with the M5 Allen Key provided.]
3. GUIDE RAIL INSTALLATION -1
3.1 Assemble the GUIDE RAIL [A15] to rear tube of MAIN FRAME
[A01] with 8 M8 screws [B13] and 8 M8 curve washers [B30]
3.2 Tighten 8 M8 screws [B13] at GUIDE RAIL[A15].
[Tighten screws with the M5 Allen Keyprovided.]
B13
B30
A15
A09 C04
C04
B42
A15
B13
B41
G863T Elliptical User Manual

Assembly
4. GUIDE RAIL INSTALLATION -2
4.1 End caps [C04] installation at GUIDE RAIL[A15].
5. ADJUSTING THE ADJUSTABLE FOOTPAD
5.1 Adjust theADJUSTABLE FOOT PADS [C05] on the MAIN FRAME [A01] and GUIDE RAIL[A15] as needed to level the
ellipticaltrainer.
5.2 The elliptical trainer has to be leveled to prevent from wobble or shaking during the exercise.
6. UPRIGHT POST ASSY INSTALLATION
6.1 The assembly steps required 2 persons.
6.2 Connect matching connectors from Main Frame [A01] and Upright Post [A02],
then slide extra length cables into the opening of Main Frame [A01].
6.3 Assemble the Upright Post [A02] to the plate of Main Frame [A01] with 4 Screws
M8 [B32].
[Tighten screws with the Hex Toolwith Phillips Screwdriverprovided.]
Note: Please do not fully tighten M8 screws [B32] with the Hex Tool with Phillips
Screwdriver provided, only handtighten.
Attention: Do not pinch cables.
C04
A15
A15
C05
A01
A02
B32
A01
G863T Elliptical User Manual

Assembly
7. DECORATIVE COVER INSTALLATION
7.1 Assemble 1 set of UPRIGHT POST DECORATIVE COVERS
[C07/C08] to the UPRIGHT POST [A02] with 3 M5 screws[B21].
[Tighten screws with the Hex Toolwith Phillips Screwdriverprovided.]
8. LUBRICATINGOIL
8.1 Apply some lubricants onto both horizontal axles of the UPRIGHT POST[A02]
and both axles of the CRANK [A12].
Remark: Gently apply lubricant evenly on UPRIGHTPOST[A02].
Brush tool is recommended.
9. FOOT BAR ASSY INSTALLATION
9.1 Insert the HANDRAILARM [A04] all the way onto the
horizontal axle of UPRIGHT POST [A02] and secure the
HANDRAILARM [A04] in position with 1 M8 bolt [B32]and
1 5/16” Washer [B33].
9.2 Repeat above steps to install the left side parts
[Tighten screws with the Hex Toolwith Phillips Screwdriverprovided.]
A02
A12
A02
B21
C07
A02
C08
A04
B33
B32
G863T Elliptical User Manual

Assembly
9.3 Insert the ROTATETUBE [A08] to the axle of CRANK [A12]. The ROLLER [C20] has to be placed on the ALUMINUM PLATE [F01]
of GUIDE RAIL [A15]. Secure the ROTATETUBE [A08] in position with 1 M8 bolt [B32] and 1 5/16” Washer [B33] then fit 1 NUT
CAP [C11].
[Tighten screw with the Hex Toolwith Phillips Screwdriverprovided.]
9.4 Before assembling, please check WASHER [C22] parts still
attach onFOOT PEDAL TUBE [A06]. (Right Figure)
9.5 Put the HANDRAILARM [A16] on the FOOT PEDAL TUBE
[A06] and assemble them with 1 M8 bolt [B24], 1 5/16”
washer [B18] and 1 M8 nylon nut [B29]
9.6 Repeat above steps to install the left side parts
[A03/A05/A07].
[Tighten bolt and nut with the Allen Key M6 & Hex Toolwith Phillips
Screwdriver provided.]
10. FOOT PEDAL INSTALLATION
10.1 Assemble the FOOT PEDAL [C12] on FOOT PEDALASSY [A06] with 4 M6
screws [B23]
10.2 Assemble the FOOT PEDAL PLUG [C23] on the FOOT PEDAL
[C12]
A
[Tighten screws with the Hex Toolwith Phillips Screwdriverprovided.]
NOTE: Please Fully Tighten Bolts [B32] With The Hex Tool With
Phillips Screwdriver Provided In Step 6
A12
A08
B33
C11
B32
C20
A15
F01
A16
C11
B29
B18
B24
C22
A06
C23
B23
C12
A06
G863T Elliptical User Manual

Assembly
11. Wheel Cap Covers Installation
11.1 Assemble 2 sets of Wheel Caps [C27/C28] to
the wheel of the Left/Right Rotate Tube
[A07/A08] with 8 Screws M5 [B21]
[Tighten nylon nuts with the Hex Toolwith Phillips Screwdriver provided.]
12. HANDRAIL INSTALLATION
12.1 Assemble HANDRAIL [A14] to HANDRAILARM [A04]
with 2 M8 bolts [B28], 2 M8 curve washers [B30] and 2
M8 nylon nuts [B29].
12.2 Refer above step to assemble left side part.
[Tighten nylon nuts with the Hex Toolwith Phillips
Screwdriver provided.]
13. DECORATIVE COVER INSTALLATION
13.1 Assemble 1 set of HANDRAILARM DECORATIVE COVER -A/B
[C17/C18] to the HANDRAILARM[A04] with 4 M5 screws [B21].
13.2 Refer to FIG. 13.2a and 13.2b To ensure the wires do not get
pinched 13.2 Connect the matching connectors as shown in Fig.
13.2a. Carefully insert the connectors and excess wire into the
opening in the C17 cap as shown in Fig. 13.2b.
13.3 Refer above step to assemble left side parts.
[Tighten screws with the Hex Toolwith Phillips Screwdriverprovided.]
C18
B21
C17
A04
A14
A13
A04
B29
B30
B28
B21
C27
C28
FIG. 13.2a FIG. 13.2b
G863T Elliptical User Manual

Assembly
14. WATER BOTTLE HOLDER INSTALLATION
14.1 Assemble Water Bottle Holder [C29] to HANDRAILARM [A02]
with 4 M5 bolts [B21]
[Tighten screws with the Hex Toolwith Phillips Screwdriverprovided.]
Attention: Do not pinch cables.
15. COMPUTER INSTALLATION
15.1 Undo 4 M5 screws [B17] from bottom ofCOMPUTER [D02]
15 .2 Connect all connectors from STATIONARY HANDLEBAR [A02]
and COMPUTER [D02] to matching connectors, then slide all
extra length of cables into the square opening of STATIONARY
HANDLEBAR [A02].
15 .3 Assemble the COMPUTER [D02] on plate of STATIONARY
HANDLEBAR [A02] with 4 M5 screws [B17] which were
undid from step 15.1
[Undo/ Tighten screws with the Hex Toolwith Phillips
Screwdriver provided.]
Attention: Do not pinch cables.
C29
B21
A02
B17
A02
D02
G863T Elliptical User Manual

Adjustment
.Adjustment
Adjusting the ADJUSTABLE FOOTPAD
Adjust theADJUSTABLE FOOT PADS on the MAIN FRAME, GUIDE RAILas needed to level the elliptical trainer. The
elliptical trainer has to be leveled to prevent from wobble or shaking during theexercise.
G863T Elliptical User Manual

Trouble Shooting & Maintenance
Trouble Shooting
Computer not working correctly
Check to make sure the computer cable is connected securely.
Check to make sure the adaptor is connected correctly.
The elliptical trainer wobbles when in use
Turn the adjustable leveler on the Main Frame, Front Stabilizer and U Shape Guide Rail as needed to level the
elliptical trainer.
Squeaking noise when in use
The bolts may be loose on the elliptical trainer, please inspect the bolts and tighten the loose ones.
No, inconsistent, or erratic heart rate reading
Always hold on to the handlebar grip sensors with two hands instead of just one.
Try to maintain moderate pressure while holding onto the hand pulse sensors.
Make sure that the wire connections for the hand pulse sensors are secure.
Maintenance
Cleaning
The elliptical trainer can be cleaned with a soft cloth and mild detergent. Do not use abrasives or solvents on plastic
parts. Please wipe your perspiration off the elliptical trainer after each use. Be careful not get excessive moisture on
the computer display panel as this might cause an electrical hazard or electronics to fail. Please keep the elliptical
trainer, specially, the computer console, out of direct sunlight to prevent screen damage. Please inspect all assembly
bolts and pedals on the machine for proper tightness every week.
Storage
Store the elliptical trainer in a clean and dry environment away from children
G863T Elliptical User Manual

G863T Elliptical User Manual
Owner’s Manual of Computer Monitor
I.Display:
1. The field is an individual LCD displaying :
TIME, RPM\SPEED, DISTANCE, WATT\CALORIES, PULSE, USER .
2. Dot matrix display:
●The LCD screen will have a single dot matrix display with 12 rows and 16 columns.
●This dot matrix will be used to display the in work profile for the active program.
II. Modes:
1. POWER Mode: When powered on, the beeper beeps a long sound, and the full screen is display is 2 seconds,
then it is into the Manual mode.(As Fig-1,Fig -2)
2. SLEEP Mode: When rpm signal or data is not input for 4 minutes, it will automatically enter Sleep Mode.
Pedal the machine to start, or press any key to awaken the console.
Fig - 1 Fig - 2
III.USER Operation instructions(U0~U4):
Select USER 0, USER 1, USER2, USER 3, USER 4:
The message reads “U0” until a selection is made. By pressing ▲or ▼button to choose from “U0 ~U4”.
1. Press ENTER button to accept “U0~U4”. By pressing the ▲or ▼button to adjust the SEX(FEM\MALE).
2. Press ENTER button to accept SEX. By pressing the ▲or ▼button to adjust the AGE value.
3. Press ENTER button to accept AGE. By pressing the ▲or ▼button to adjust the HEIGHT(H.t) value.
4. Press ENTER button to accept HEIGHT. By pressing the ▲or ▼button to adjust the WEIGHT(W.t) value.
SEX AGE H.t. W.t.
IV.Program operation instructions:
Press ENTER button into Choose PROGRAM:
By pressing the ▲or ▼button to adjust the profiles and it can be set the circle(select programs):
MANUAL→PROGRAM→FITNESS→WATT→PERSONAL→H.R.C.→RANDOM
Computer

G863T Elliptical User Manual
1. If Press ENTER button to accept MANUAL
By pressing the ▲or ▼button to adjust the LEVEL(1-24).
Press ENTER button to accept LEVEL. By pressing the ▲or ▼button to adjust the TIME value.
Press ENTER button to accept TIME. By pressing the ▲or ▼button to adjust the DISTANCE value.
Press ENTER button to accept DISTANCE. By pressing the ▲or ▼button to adjust the CALORIES value.
2. If Press ENTER button to accept PROGRAM
By pressing the ▲or ▼button to adjust the P1-P12
Press ENTER button to accept program. By pressing the ▲or ▼button to adjust the LEVEL(1-24).
Press ENTER button to accept LEVEL. By pressing the ▲or ▼button to adjust the TIME value.
Press ENTER button to accept TIME. By pressing the ▲or ▼button to adjust the DISTANCE value.
Press ENTER button to accept DISTANCE. By pressing the ▲or ▼button to adjust the CALORIES value.
3. If Press ENTER button to accept FITNESS
Press the START/STOP button and started testing.
4. If Press ENTER button to accept WATT
By pressing the ▲or ▼button to adjust the TIME value.
Press ENTER button to accept TIME. By pressing the ▲or ▼button to adjust the DISTANCE value.
Press ENTER button to accept DISTANCE. By pressing the ▲or ▼button to adjust the CALORIES value.
5. If Press ENTER button to accept PERSONAL, and you can set your own exercise program.
By pressing the ▲or ▼button to adjust the LEVEL(1-24), and press ENTER button to accept LEVEL
Press ENTER button for 3 seconds and into set the target TIME. By pressing the ▲or ▼button to adjust the
TIME value.
Press ENTER button to accept TIME. By pressing the ▲or ▼button to adjust the DISTANCE value.
Press ENTER button to accept DISTANCE. By pressing the ▲or ▼button to adjust the CALORIES value.
6. If Press ENTER button to accept H.R.C. (55%, 75%, 90%, Tag)
By pressing the ▲or ▼button to choose the 55%, 75%, 90% and Tag
If choose the 55%, 75% and 90% , Press ENTER button to accept the mode and into set the target TIME.
If choose the Tag, Press ENTER button to accept the mode and into set the target Heart.
By pressing the ▲or ▼button to adjust the Heart value, Press ENTER button to accept Heart.
By pressing the ▲or ▼button to adjust the TIME value.
Press ENTER button to accept TIME. By pressing the ▲or ▼button to adjust the DISTANCE value.
Press ENTER button to accept DISTANCE. By pressing the ▲or ▼button to adjust the CALORIES value.
Computer

G863T Elliptical User Manual
7. If Press ENTER button to accept RANDOM
By pressing the ▲or ▼button to adjust the TIME value.
Press ENTER button to accept TIME. By pressing the ▲or ▼button to adjust the DISTANCE value.
Press ENTER button to accept DISTANCE. By pressing the ▲or ▼button to adjust the CALORIES value.
V.Pre-defined program profile:
●MANUAL ●PROGRAM ●FITNESS
●WATT ●PERSONAL ●H.R.C.
●RANDOM
Program Profile for the P1~P12 Program
●P1 ●P2 ●P3
●P4 ●P5 ●P6
●P7 ●P8 ●P9
●P10 ●P11 ●P12
Computer

G863T Elliptical User Manual
Program Profile for the H.R.C.(55%, 75%, 90%, Tag) Program
●HRC(55%) ●HRC(75%) ●HRC(90%)
●HRC(Tag)
VI. Recovery Test:
During the START or PAUSE stage, leave the hands holding on grips or leave the chest transmitter attached and
then press PULSE RECOV. button , all function displays will stop except “TIME”.
The testing will measure the heartbeat rate, Time starts counting from 00:10 - 00:09 - - to 00:00 if the
measurement does not show within 10 seconds, the measuring system will shut down and return to the sport
mode.
If 10 seconds after the heart rate value is not equal to zero , Time starts counting from 00:60 - 00:59 - - to 00:00. As
soon as 00:00 is reached, the computer will show your heart rate recovery status with the grade F1 to F6.
●TESTING ●Result
Note: Fitness of a user is shown by Message.
Figure
State
F1
EXCELLENT
F2
VERY GOOD
F3
GOOD
F4
FAIR
F5
POOR
F6
VERY POOR
Computer

G863T Elliptical User Manual
VII.FITNESS Test:
Entry into the FITNESS program, started testing and the test time is 8 minutes. The results as follows:
Figure
State
F1
VERY GOOD
F2
GOOD
F3
FAIR
F4
POOR
F5
VERY POOR
VIII. Key Functions:
1. START/STOP button :
Press this button to start workout in sport mode, and during exercising, press this key to pause the
workout, then press this key to go on to exercise.
2. ENTER button :
To confirm set value and enter into the next set value
3. ▲and ▼button :
Used to change SEX, AGE, HEIGHT, WEIGHT, TIME, DISTANCE, CALORIES, TARGET HRC
value and work LEVEL.
Work level can be changed during a workout..
4. RECOVERY button :
Press the button to activate heart rate recovery function.
5. RESET button :
Set in USERS state, press the button to return to select the USER mode.
Set in Program state, press the button to return to the initial state of choose program.
Press and hold this button for three seconds for Total Reset (go to Power Up Mode).
6. QUICK START button:
Press this key can be directly into the MANUAL program and start workout.
Time (0: 00), Distance (0) and Calories (0), began to count.
Computer

G863T Elliptical User Manual
IX.Functions View:
Item
Windows
Display Rang
Default
Stored
1
SEX
MALE/ FEM
Male
Yes
2
AGE
10 - 100
30
Yes
3
WEIGHT
20 - 330(Lb)
10 - 150(KG)
70
70
Yes
4
HEIGHT
36 - 84(INCH)
90 –210(CM)
70
175
Yes
5
TIME
0:00 - 99:59
0: 00
No
6
DISTANCE
0.0 - 99.99
0.0
No
7
CALORIES
0 - 999
0
No
8
SPEED
0.0 - 99.9
0.0
No
9
PULSE
30 - 200 bpm
0
No
10
RPM
0 - 250 rpm
0
No
11
BRAKE RESISTANCE LEVEL
L1 - L24
L1
No
12
USER
U0-U4
U0
Yes
Computer

G863T Elliptical User Manual
Bluetooth Connection to Fitness Machine User Guide
I.The use of equipment:
1. Fitness machine with Bluetooth function;
2. IPOD/ IPhone/ IPAD
II.Download the APP application:
Open the IPOD, selectApp Store, and input character “pafers pedal monitor”or “run on earth”in the
search box. (The instructions use pafers pedal monitor) Download the installation is complete, the
main screen will appear "pedal Monitor" applications.
Computer

G863T Elliptical User Manual
III.Bluetooth connection
Computer
