BH Cavislim YS35 User manual

YS35
cavitation
User manual
Manual de l’utilisateur
safe and effective figure shaping modelage sûr et efficace de la silhouette
cavitat io n
ENGLISH
FRANÇAIS

2
cavitat io n
modelage sûr et
efficace de la silhouette
safe and effective
figure shaping

3
Congratulations. First we would like to thank you
for purchasing CAVISLIM and for the trust you have
placed in us. By means of this handy User Manual
and following its simple instructions you will achieve
results comparable to those obtained from the hands
of a professional beautician. We strongly recommend
that you read this User Manual thoroughly. Reading
and understanding it will help you use CAVISLIM
effectively and safely.
Félicitations ! Nous tenons en tout premier lieu à
vous remercier d’avoir acheté l’appareil CAVISLIM
et de la confiance que vous nous accordez. En suivant
les conseils contenus dans ce pratique manuel de
l’utilisateur vous obtiendrez pour ainsi dire les mêmes
résultats que ceux produits par les mains d’un
professionnel de la beauté. Nous vous
recommandons vivement de lire entièrement ce
manuel de l’utilisateur ce qui vous permettra d’utiliser
l’appareil CAVISLIM d’une manière plus efficace et
sure.

content
safe and effective
figure shaping
cavita tio n
4
chapter 1
• contents of the box
• assembling Cavislim
chapter 2
• basic characteristics of Cavislim
• cavislim operating instructions
chapter 3
• cavislim application modes
chapter 4
• for correct, safe use of Cavislim
chapter 5
• frequently asked questions
chapter 6
• important safety instructions
• warranty
• certificates
• technical specifications
• parts list

Inside this box you will find everything you need to enjoy CAVISLIM
from now onward. Carefully check the following illustration showing
all of the elements that the pack should contain.
chapter 1
5
contents of the box
DVD
Operating
pedal Cavitation
gel
Allen key 4 screws Mains cable Anti-cellulite
serum
Toning
serum
EN
Hand unit
Hand
unit support. User
manual
Main unit

safe and effective
figure shaping
cavita tio n
6
essembling Cavislim
First we are going to fit the hand unit support onto the main unit. To
do this, place the main unit on a table and position the hand unit
support by inserting the screws as shown in the diagram.
Using the Allen key tighten the screws securely so that the two parts
fit together perfectly.

basic characteristics
of Cavislim
chapter 2
7
EN
CAVISLIM is a high-tech device that allow to selectively and
efficiently remove the build-up of fat (cellulite, orange skin
syndrome) from our body. The technology used is that of ultrasound
emission which produces the physical phenomenon known as
cavitation, causing the removal of fat cells. The technology with
proven results is widely used in beauty salons all over the world in
order to fight cellulite painlessly and non-invasively.
Characteristics for model CAVISLIM Ref. YS35
Time: Programmable from 1 to 15 minutes.
Intensity: 5 intensity levels (5-10-15-20-25)
Mode: 4 programmable pulsed work modes (P1-P2-P3-P4)
1 continuous work mode (P5)
With these units you only have to worry about programming in three
simple functions: intensity, time and work mode. The intensity function
controls how deep the sound waves penetrate your skin. The greater
the intensity, the deeper the waves reach. The time function allows
you to choose how long you wish to work with CAVISLIM. For reasons
of safety the time function allows you to choose up to 15 minutes
which corresponds to the maximum recommended time for working
a specific area. However, you can reduce this maximum time by 1
minute intervals. Once the selected time has elapsed CAVISLIM will
alert you with a beep and a message on the display showing the text
"Time out".
CAVISLIM also lets you choose the work mode, helping you select the
time interval during which the waves reach your skin.

safe and effective
figure shaping
cavita tio n
8
Cavislim operating
instructions
fig. 2.3
fig. 2.1 fig. 2.2
Start up
• Connect the hand unit to the main unit. To do this, take the plug for
the hand unit and insert into the socket on the main body as shown
in Fig. 2.1.
• Next, take the jack for the operating pedal and insert into the socket
on the main body as shown in Fig. 2.2. Check that all the connections
are made correctly before connecting it to the mains supply.
• Plug one end of the mains cable into the socket on the machine and
the other end into the electric wall socket (220V) Fig. 2.3. Switch the
machine to position (I) to start the machine.
Precautions: Consult your doctor before beginning to use
this appliance. This warning is especially important for
people with health problems. Use by those under 18 years
of age is not recommended. Keep this appliance out of
children’s reach.

TIME = 5:00
MODE = P1
INTENSITY = 5
9
EN
Monitor elements
The CAVISLIM monitor consists of a display screen, an LED and five
buttons or keys.
• The display provides information about the cavitation session.
• The ON LED (green) tells you that the device is operating.
• The keys have the following functions:
-and change the work MODE
-+and -adjust TIME and INTENSITY
- pause and start session

safe and effective
figure shaping
cavita tio n
10
Cavitation session
There are 3 variables for the massage:
• Time: measures the session in minutes and seconds. Choose between
1 to 15 minutes (in steps of 1 minute).
•Intensity: establishes the intensity level for the session.
On Mod. YS35you can select from levels 5, 10, 15, 20 and 25.
•Work mode: Pulse type (impulse emission frequency).
Mod. YS35allows you to select from levels P1, P2, P3, P4 and
P5. Impulse emission frequency: P1 very low
P2 low
P3 high
P4 very high
P5 continuous
Beginning a session
Once you have plugged the
machine into the mains
supply and switched it to
position (I) the following
message will appear on the
monitor: BIENVENIDO
(WELCOME)
This message will remain
visible for 3 seconds, after
which the following default
settings will appear:
TIME: 10:00
MODE: P1
INTENSITY: 5
BIENVENIDO

TIME = 12:00
MODE = P2
INTENSITY = 5
TIME = 12:00
MODE = P1
INTENSITY = 5
11
EN
From here you can modify
the time and work mode
settings to establish the type
of session you want:
Changing session duration
Once you are on the default
setting screen you can modify
the duration of the session
using
+and -
The displayed default value
is 10 minutes but this can be
changed in intervals of 1
minute between the values 1
and 15.
Changing work mode
On the same default screen
you can change the work
mode for your session using
the and keys.
The default value shown is
P1 (very low pulse frequency)
but this can be modified by
selecting from the values P1,
P2, P3, P4 and P5.

TIME = 12:00
MODE = P2
INTENSITY = 10
safe and effective
figure shaping
cavita tio n
12
Changing massage
intensity
Once you have selected the
desired time and work mode
settings, you can set the last
of the parameters: Intensity.
To do this, press the button
and with the machine on
(a green light appears in the
centre of the unit), you can
use the +and -keys to
select the intensity level.
The default intensity level is
5 but this can be changed by
selecting from 5, 10, 15,20
and 25.
After pressing the key it
is not possible to modify the
time setting.
Finally, take hold of the hand unit and push down on the pedal to begin
your cavitation session.
When you tread on the pedal you will see the time countdown on the
screen and the hand unit will begin to emit impulses. Place the hand unit
on the area you wish to work and massage it as shown on the DVD on in
the “Application modes” section.
If you wish to pause the session, just stop pressing on the pedal and the
impulse emission will stop immediately.

13
EN
When the time counter
reaches 0.00 the unit will stop
and emit a series of beeps
to tell you that the selected
session has finished. The
following message will
appear on the monitor:
TIME OUT PRESS A
KEY TO BEGIN (TIEMPO
AGOTADO PULSE UNA
TECLA PARA COMENZAR)
Pressing any key on the
machine will take you back
to the default screen.
TIME: 10:00
MODE: P1
INTENSITY: 5
TIEMPO AGOTADO
PULSE UNA TECLA
PARA COMENZAR

20cm.
20cm.
20cm.
20cm.
20cm.
20cm.
espiral circulatelongitudinal
abdomen central
chapter 3
safe and effective
figure shaping
cavita tio n
14
Cavislim application modes
Nivel
A
B
C
D
E
F
3
3
3
2
2
2
YS35
Mode Intensity
10
10
10
10
10
10
Time
10’
10’
7’
7’
7’
7’
Always apply an abundant amount of gel to the area and begin to work
it by sliding the hand unit slowly and without pressing, as shown in the
diagrams.
If you need to purchase gel or any of our preparation creams you can find
them in the shop where you purchased CAVISLIM.
In each of the following sections you will find a table with application
protocols. You should decide which level applies to you.
ALarge accumulation of high density fat
BLarge accumulation of medium density fat
CMedium accumulation of medium density fat
DSmall accumulation of fat
Eorange peel syndrome
FMaintenance sessions
Slide the hand unit slowly, without pressing. For best results we
recommend applying CAVISLIM by combining different massage
Remember, do not
to apply CAVISLIM
to the navel, breast
or the thorax area
techniques (spiral, crossways, circular) in different sessions.

circulate longitudinal
circulate longitudinal
horizontal
sides
longitudinal
vertical
15
Nivel
A
B
C
D
E
F
3
2
2
1
1
1
YS35
Mode Intensity
10
10
5
5
5
5
Time
7’
7’
7’
5’
5’
5’
Nivel
A
B
C
D
E
F
4
3
2
1
1
2
YS35
Mode Intensity
15
10
10
5
5
5
Time
10’
10’
7’
7’
5’
5’
EN
hips
Circular and longitudinal massage should be applied from top to bottom
as shown in the diagrams. It is important to massage in the correct
direction as this will promote drainage.
Apply gel over the
area to be worked
using CAVISLIM
Both the circular and longitudinal massage should be applied from
bottom to top as shown in diagrams. This will produce an effect on a
larger accumulation of fat during treatment.
Apply gel over the
area to be worked
using CAVISLIM

circulate longitudinal
circulate longitudinal
safe and effective
figure shaping
cavita tio n
16
Nivel
A
B
C
D
E
F
5
5
4
3
2
3
YS35
Mode Intensity
25
15
20
15
15
15
Time
10’
7’
7’
7’
10’
10’
Nivel
A
B
C
D
E
F
3
3
3
2
2
2
YS35
Mode Intensity
10
10
10
10
10
10
Time
10’
10’
7’
7’
7’
7’
buttocks
inner thigh
Both the longitudinal and circular massage should be done from
bottom to top, as shown in the diagrams. Follow these simple
instructions to help you get the best results.
Longitudinal and circular massage should be done in the direction of the
arrows, as shown in the diagrams.
Apply gel over the
area to be worked
using CAVISLIM
Remember, do
not to apply
CAVISLIM from
the knee to the
foot, there is no
significant
accumulation of
fat in this area.

circulate
back of the knee
17
longitudinal circulate
Nivel
A
B
C
D
E
F
3
3
3
2
2
2
YS35
Mode Intensity
5
5
5
5
5
5
Time
10’
10’
7’
7’
7’
7’
Nivel
A
B
C
D
E
F
2
2
1
1
1
1
YS35
Mode Intensity
5
5
5
5
5
5
Time
7’
5’
5’
3’
3’
5’
EN
Put a generous amount of gel on the area to be worked and this will
improve the effectiveness of the treatment. Massaging this area should
be applied toward the body, as shown in the diagram.
arms
Remember, do not
to apply CAVISLIM
on the kneecap.
Apply gel on the
area to be worked
using CAVISLIM
Remember, never
apply CAVISLIM
on the hands,
forearms or joints.
Apply a light circular massage to this area, as shown in the diagram.

safe and effective
figure shaping
cavita tio n
18
for correct and safe use
of Cavislim
chapter 4
For correct and safe use of Cavislim, you should keep the following
application times in mind:
•Per work area:
15 minutes maximum.
By "work area" we mean each one of the body parts where CAVISLIM
can be applied. The various work areas are: arms, abdomen, waist, hips,
inner thighs and inner knees.
E.g.: In a single session you can apply Cavislim for 15 minutes on your
sides and 15 minutes on your arms. But, for example, you must NEVER
perform a 30 minute application session just on your sides in the same
day.
•Per session:
30 minutes maximum.
By session we mean using CAVISLIM on 2 different work areas (15 minutes
per area) in the same day.
•Between sessions:
72 hours minimum.
By “between sessions” we mean the rest time between each session.
E.g.: In one week the session schedule (maximum) would be: Monday,
Thursday and Sunday.
•Every 20 sessions:
You should rest for 3 weeks.
After this period you may decide to repeat the first treatment or start the
maintenance program.
•Maintenance sessions:
This depends on the individual, but one session per month should suffice.

frequently
asked questions
chapter 5
19
EN
What is cavitation?
Cavitation is a non-invasive (surgery free) body shaping technique that
reduces volume by eliminating cellulite and localised fat deposits in the
abdomen, hips, flanks, arms, inner thighs and knees.
What are the advantages over other methods?
The main advantage is that we can choose the specific areas of the body
that we want to work. It could be said that it is a technology which allows
us to concentrate on cellulite selectively.
Is cavitation painful?
Use of CAVISLIM should never cause pain.
Is it normal to hear a slight buzzing in your ears while using CAVISLIM?
Yes, some users may detect a slight buzzing sound during its application.
Can it be used on all parts of the body?
It cannot be applied to all parts of the body. Under no circumstances can
it be applied to the head or face, neck, breasts, the thorax, navel, forearm,
joints, genitals, back, ankles or lymph glands.
Does CAVISLIM reduce weight and volume?
CAVISLIM eliminates clusters of fat, which have weight, consequently your
body loses volume.
Is CAVISLIM effective on orange peel syndrome?
Yes, CAVISLIM is effective on orange peel syndrome because it destroys
adipose cells that cause fat storage.
Can CAVISLIM be used to remove wrinkles?
No, CAVISLIM has not been designed to remove wrinkles.
Can CAVISLIM be used on the face?
CAVISLIM must never be used on the face or eyes.
After how many sessions will I begin to see results?
You should notice results after the first five sessions, however results may
vary depending on the individual.
How long should I wait between sessions?
It is advisable to wait 72 hours between sessions.
Does cellulite reappear after using CAVISLIM?
Although CAVISLIM ensures effective and long-lasting results, we can not
guarantee against cellulite reappearing. To prevent the reappearance of

safe and effective
figure shaping
cavita tio n
20
cellulite we recommend a balanced diet, regular physical exercise and
maintenance sessions using CAVISLIM.
Are there any side effects?
If you are healthy, CAVISLIM has no reported side effects, nevertheless
in some people it may produce a reddening of the skin that can last for
about 2 hours.
What are the anti-cellulite and toning gels for? When do I use them?
1. Anti-cellulite gel: Contains active ingredients that help eliminate cellulite.
2. Toning gel: Contains active ingredients that make the treated area firmer.
The application sequence is as follows: during the first days of application
we use the anti-cellulite gel and the toning gel during the last days of
application. This is applied before the Cavitation gel. It is applied like any
other serum. Make sure it is fully absorbed. Then apply the cavitation gel
to begin the session.
Is it necessary to combine CAVISLIM with a special diet?
No, it is not necessary to follow any special diet, but a balanced diet and
proper hydration is highly advisable.
How much water should I drink?
It is essential to begin hydrating yourself two hours before applying
CAVISLIM. It is also advisable to drink more water after finishing a session.
The recommended quantity is at least 2 litres during these periods, as it
helps to eliminate toxins.
Is it necessary to combine CAVISLIM with a sports activity?
No, this is not strictly necessary, but at least 30 minutes of physical activity
will enhance the results as it helps to drain fluids.
Which sports activities can supplement CAVISLIM?
The vibration platform is the ideal complement due to its toning and draining
qualities. But if you do not have access to a platform, then walking, exercise
bike, swimming or any other aerobic exercise for at least 30 minutes is
very helpful.
How can I enhance the effects of CAVISLIM?
By combining a balanced diet with regular physical exercise.
Added to which, drainage massage can also be very useful.
Can I use CAVISLIM without applying gel?
Never, because the gel acts as a conductor for the ultrasonic sound waves
with your body. If you do not use gel then the CAVISLIM application loses
its effectiveness and the machine can be severely damaged.
Can I use any type of gel?
We recommend using only TECNOVITA by BH gel, as the use of any other
type may damage the machine.
