BI-LEVEL PL-SBL-DBL User manual

BI-LEVEL TABLE ASSEMBLY INSTRUCTIONS
Assembled front view.
Note that computer components
are not included and are shown
for demonstration purposes only.
Assembled approach view.
www.smartdesks.com

BI-LEVEL TABLE ASSEMBLY INSTRUCTIONS
Place the table top on a carpeted oor, or a packing
blanket, inserts face up. Avoid scratching the top.
Using 1/4-20 hex head, Phillips drive bolts, install
the legs.
Using Hae barrel bolts, install the modesty panel
to the legs.
Install the monitor pan to the top inserts on either
side of the monitor notch using 1/4-20 bolts.
Install the keyboard tray, using #8 wood screws,
provided.
Install the CPU holder on the right or left using
1/4-20 bolts into the set of inserts in front of the leg
bracket.
Install keyboard tray
with 8 wood screws
CPU
4 bolts
CPU
4 bolts
LEG
8 bolts
LEG
8 bolts
Monitor Pan
4 bolts
Install modesty panel to legs using
Hae barrel bolts BEFORE installing the
Monitor Pan.
Modesty Panel
www.smartdesks.com
