Big Dutchman AirMaster EM50 User manual

These instructions are the original instructions!
Operation Manual
AirMaster EM50
Code No. 99-97-2341
Edition: 03/2015 GB

Table of contents Page I
AirMaster EM50
Edition: 03/2015 M 2341 GB
1 Basic instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.1 Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Designated use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3 Prevention of reasonably predictable incorrect uses. . . . . . . . . . . . . . . . . . . 2
1.4 Explaining the symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4.1 Safety symbols in this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4.2 Safety symbols in the manual and on the installation . . . . . . . . . . . . . . . . . . . . 3
1.4.3 Safety symbols and notes on your installation. . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.5 Scope of deliverables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6 Ordering spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.7 Obligations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.8 Warranty and liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.9 Disorders due to power failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.10 First aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.11 Pollution abatement regulations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.12 Waste disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.13 Notes for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.14 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.1 General safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Safety instructions when operating electrical appliances . . . . . . . . . . . . . . 10
2.3 System safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3.1 Danger zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3.2 Entire system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3.3 Individual components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3.3.1 Ventilation system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3.3.2 Electrical components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4 Personal safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.4.1 Clothing for personal safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.4.1.1 Clothing and footwear. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.4.1.2 Jewellery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.4.1.3 Hair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . 14
2.5 Safety contrivances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.6 Dangers resulting from non-compliance with the safety instructions . . . . 15
2.7 Safety component parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 Mounting instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
3.1 Dimensions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.3 Assembly / mounting / installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.4 Storage and transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Page II Table of contents
AirMaster EM50
Edition: 03/2015 M 2341 GB
3.5 General cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
3.6 Complaints / questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
4 Maintenance schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
5 Spare parts list for EM50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.1 Complete central pulley - exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
5.2 Spare parts list for protection (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
5.3 Spare parts list for pyramidal shape mesh for CE-protection. . . . . . . . . . . .26
5.4 Assembled Motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
5.5 Motors Code Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
5.6 Pulley Codes Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
5.7 Bolts and nuts description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
5.8 Assembling tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
6 Assembling Guideline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
6.1 Housing Assembling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
6.2 Centrifugal System and Pulley to Propeller Assembling. . . . . . . . . . . . . . . .37
6.3 Shutter Blades Assembling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
6.4 Safety Meshes Guard Assembling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
6.5 Safety-Kit Assembling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
6.6 Pyramidal Shape Mesh Assembling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Basic instructions Page 1
AirMaster EM50
Edition: 03/2015 M 2341 GB
1 Basic instructions
1.1 Basics
The Big Dutchman installation has been constructed according to the current state of
the art and all acknowledged regulations regarding technical safety. The installation is
reliable. Upon operation, however, dangers to life and limb of the user or third persons
or impairments of the system or other material property are still possible.
The system may only be mounted, attended, repaired and used:
•for due use
•in an excellent state from the safety and technical point of view
•by persons who are familiar with the safety regulations
In the event of special problems which are not described in detail in this manual, we
recommend to contact us for your own safety.
1.2 Designated use
The Big Dutchman fans must only be used according to their designated use. The Big
Dutchman fan EM50 serves the purpose of moving or circulating exhaust air in
livestock facilities.
Every other use is considered improper use. The manufacturer is not liable for any
damage caused by improper use. The user bears the sole risk. The designated use
also includes the exact adherence to the operating, maintenance and assembly
requirements of the manufacturer.
!
Please take care of this manual and always keep it in the same place
close to the installation for quick reference. All persons working with the
system, assembling, cleaning and servicing have to be familiar with the
contents of these instructions.
Please observe the contained safety instructions!
If this manual is damaged or lost, request a new copy from Big
Dutchman.

Page 2 Basic instructions
AirMaster EM50
Edition: 03/2015 M 2341 GB
1.3 Prevention of reasonably predictable incorrect uses
The following uses of this Big Dutchman system are not permitted and are therefore
deemed a misuse:
•Utilising the system with aggressive and/or corrosive materials in quantities that do
not constitute good professional practise.
•The use in explosive environments
•The use for gas, substances, sprays, fumes, fluids, solids, particulate matter or any
mixtures thereof.
A non-designated use will lead to a liability exclusion by Big Dutchman.
The operator of the system exclusively bears the risk resulting from misuse!
1.4 Explaining the symbols
1.4.1 Safety symbols in this manual
Upon reading this manual you will come across the following symbols
WARNING
This symbol indicates risks possibly leading to personal injury resulting in
death or to severe injuries.
CAUTION
This symbol indicates risks or insecure procedures possibly leading to
injuries or material damage.
NOTE
This symbol indicates notes leading to an effective, economic and
environmentally-conscious handling of the installation.

Basic instructions Page 3
AirMaster EM50
Edition: 03/2015 M 2341 GB
1.4.2 Safety symbols in the manual and on the installation
These safety symbols illustrate remaining dangers when handling the system. They are
supplements to the above-mentioned symbols:
1.4.3 Safety symbols and notes on your installation
Depending on the type of installation you will find the following safety symbols. They
indicate technically remaining dangers when handling the system and give information
on how to avoid these dangers.
Warning against dangerous electrical voltage
Warning against the cold
Warning against slippery surface
GENERAL DANGER!
Installation automatically starts working. Before starting repair,
maintenance or cleaning work, put main switch to ”OFF”.
Danger of bruising due to rotating machine parts!
Close protective devices each time before taking the system
into operation. Opening protective devices is only allowed
when the system is in a standstill and by authorised persons.
RISK OF INJURY due to operating auger, chain or cable
discs!
Never reach into or climb into a feed container or trough while
the motor is running.

Page 4 Basic instructions
AirMaster EM50
Edition: 03/2015 M 2341 GB
Observe the instructions attached to the installation, such as the arrow on the motor
indicating the direction of rotation.
The signs and safety instructions always have to be visible and must not be damaged.
If they are soiled by dust, manure, feed remains, oil or grease, clean them by means of
a water-detergent mixture.
1.5 Scope of deliverables
After removing the packaging, check for completeness and integrity of the product.
Contact the supplier immediately in case of missing or damaged components.
DANGER OF SKIN CORROSION due to purifying agents!
Always wear protective clothing when repairing, maintaining
and cleaning the installation. Always observe the
manufacturer’s instructions when using acids!
If a safety symbol or instruction is fixed to a part to be replaced,
ensure that it will be fixed to the new part as well.
Caution:
Never install a damaged or incomplete device.

Basic instructions Page 5
AirMaster EM50
Edition: 03/2015 M 2341 GB
1.6 Ordering spare parts
Indicate the following for ordering spare parts:
•Code no. and description of the spare part or
•Invoice no. of original invoice
•Current supply, e.g. 230/380 V 50/60 Hz
1.7 Obligations
Closely adhere to the instructions in this manual.
A basic condition for safe operation and trouble-free handling of this system is the
knowledge of the basic safety instructions and regulations.
These mounting and operating instructions, particularly the safety instructions, have to
be observed by everyone working with this system. Moreover, the regulations and
instructions for the prevention of accidents valid at the respective place of use have to
be observed.
The manufacturer is not responsible for any damages to the machine resulting from
changes done by the user.
Operational safety is the prime necessity!
For your own safety only use original Big Dutchman spare parts. For
foreign products that have not been released or recommended or for
modifications carried out (e.g. software, control units) we cannot judge
whether there is a safety risk in connection with the Big Dutchman
systems.
You can find the exact description (Code no.) of the parts for ordering
spare parts by means of the position numbers in the spare parts lists (see
appendix).

Page 6 Basic instructions
AirMaster EM50
Edition: 03/2015 M 2341 GB
1.8 Warranty and liability
Warranty and liability claims regarding personal and material damage are excluded if
they result from one or several of the following causes:
•non-designated use of the installation
•inappropriate mounting and operating of the system
•operating the system with defective safety equipment or not duly fixed or not
functioning safety and protective devices,
•non-observance of the instructions in this manual regarding transport, stock
keeping, mounting, maintenance, operating and upgrading of the system
•unauthorised modifications on the system
•inappropriate repairs
•in the event of disasters caused by foreign matters or force majeure.
1.9 Disorders due to power failure
We recommend the installation of warning systems for a better monitoring of your
production units and the installation of an emergency power-generating set for
adequate supply with power in case of power failure. With this, you protect the animals
and thus your own economical health. For further information please contact your
property insurance.
1.10 First aid
In the case of an accident, a first-aid kit must always be available at the place of work,
unless specified otherwise. Material taken out and used is to be replaced immediately.
If you need help, describe the accident as follows:
•where it happened
•what happened
•the number of persons injured
•what type of injury
•who is reporting the accident!

Basic instructions Page 7
AirMaster EM50
Edition: 03/2015 M 2341 GB
1.11 Pollution abatement regulations
All works on and with the installation have to be carried out in compliance with the legal
requirements concerning waste prevention and proper recycling / disposal of waste.
Special care has to be taken when carrying out installation, repair and maintenance
works, as water pollutants like lubricating grease and oils, as well as solvent-containing
cleaning solutions are not to pollute the soil or get into the canalisation! These materials
have to be kept, transported, collected and disposed of in appropriate containers!
1.12 Waste disposal
After finishing the assembly or repair of this installation, dispose of the packing material
and remains which do not need to be further used according to the legal provisions for
recycling. The same applies to the component parts after putting the installation out of
service.
1.13 Notes for use
We reserve the right to modify the construction and technical data for reasons of further
development.
Therefore, no claims can be derived from the information, pictures, drawings and
descriptions. Errors and omissions excepted.
Inform yourself about mounting, adjusting, operating and maintaining before taking the
system into operation.
Apart from the safety-relevant instructions in this manual and the safety precautions
valid in the country of use, also observe the generally acknowledged technical
regulations (safe and appropriate working according to UVV, VBG, VDE etc.).

Page 8 Basic instructions
AirMaster EM50
Edition: 03/2015 M 2341 GB
1.14 Copyright
This manual is subject to copyright. The information and drawings included in this
manual shall not be copied without the manufacturer's consent, nor shall they be used
for anything other than the designated use. Neither shall they be disclosed to third
parties.
If you find mistakes or unclear information in this manual, please do not hesitate to let
us know.
All trade marks mentioned or shown in the text are trade marks of their respective
owners and are recognised as patented.
© Copyright 2015 by Big Dutchman
For further information please contact:
Big Dutchman International GmbH · P.O. Box 11 · D-49360 Vechta · Germany
Phone [phone] Fax [phone]
E-Mail: [email protected], Internet: www.bigdutchman.de

Safety instructions Page 9
AirMaster EM50
Edition: 03/2015 M 2341 GB
2 Safety instructions
These mounting and operating instructions, particularly the safety regulations, have to
be observed by all persons working on this system. Moreover the regulations for
accident prevention valid for this place have to be observed!
2.1 General safety instructions
All established safety precautions and other generally accepted safety regulations and
medical references have to be observed. Please check safety and function control
devices to ensure safe and accurate operation:
•before putting into operation
•at adequate time intervals
•after modifications or repairs.
Check the proper functioning of the system after any kind of repair works. You may only
take the device into operation when all protective systems have been put into place
again. Follow the directions of the electric and water supply company.

Page 10 Safety instructions
AirMaster EM50
Edition: 03/2015 M 2341 GB
2.2 Safety instructions when operating electrical appliances
You have to ensure that the system with the electrical appliances is operated and
maintained according to the electro-technical regulations.
Immediately switch off the installation in the event of malfunctions of the power supply
units. Use a bipolar voltage probe to make sure that the electrical equipment is not
alive.
Check the electrical wiring and cables for recognisable damage before putting the
device into operation. Replace damaged wiring and cables before taking the device
into operation.
Only use the fuses indicated in the circuit diagram. Immediately replace damaged
fuses. Never repair or bypass the fuses!
Never cover the electrical motor. This can cause high temperatures resulting in fire and
a break-down of the equipment.
The control box as well as the terminal and connector boxes of the installation must
always be kept shut.
Let damaged or broken plugs be replaced by an electrician.
Do not pull the plug from the socket at the flexible cable.
For the respective connections please see the enclosed connecting plan of the system
parts delivered.
Installation and work on electric components/structural groups may only
be carried out by qualified personnel according to electro-technical
regulations (e.g. EN 60204, DIN VDE 0100/0113/0160).
Dangerous electric tensions are bare in case of open control equipment.
Be aware of the danger and keep workers of other professions away from
the danger zone!
Do not install control devices directly in the house, but in the service room
to prevent corrosion caused by ammonia gas.
Warning
Never repair or bypass the fuses!
Damaged fuses have to be replaced with new fuses!

Safety instructions Page 11
AirMaster EM50
Edition: 03/2015 M 2341 GB
2.3 System safety instructions
2.3.1 Danger zone
The different areas of the Big Dutchman installations are characterised by different
types of construction.
There are several system parts that run out, rotate or slide that can increase the risk of
an accident when you are unaware of the type of construction.
There are hazard areas where a risk of injury exists
•due to rotating parts
•due to electrical current in case of non-reliable or defective switching-off of
overload current.
2.3.2 Entire system
•Parts lying about on the system and in its vicinity can cause persons to stumble
and/or fall and thus risk injuring themselves by contact with system components.
•Lack of knowledge about the structural design of the system can lead to injury.
•Parts lying about in or on the components can lead to serious damage of the
system.
Never reach into the running installation. Before reaching into the
installation, turn the system off and secure it against unintentional
actuation.
Assure yourself beforehand that the main switch is in the OFF position and
can not be put in the ON position without your knowledge.
After repair or maintenance work, never place any objects (e.g. spare
parts, replaced parts, tools, cleaning implements etc.) in the accessible
areas of the system or around it!
Make sure that all loose or replaced parts have been removed from the
system components before the system is taken into operation again!
Make yourself familiar with the construction of the system in sufficient
light! If this is not possible at site, get all available information on the
remaining dangers in connection with this system!
When working under the installation, always wear a safety helmet!

Page 12 Safety instructions
AirMaster EM50
Edition: 03/2015 M 2341 GB
2.3.3 Individual components
2.3.3.1 Ventilation system
•Rotating fans can lead to severe injuries.
•Fans can start due to their automatic control units.
2.3.3.2 Electrical components
Never reach through the protective grills or blade flaps into a fan, even if
it is not in operation!
Before carrying out repair or maintenance work, disconnect power supply
and indicate this by a sign fixed to the main switch!
High electric tension!
Touching live parts might lead to severe injuries caused by electric shock!
During repair or maintenance work, live parts may be bare!
Never touch bare electrical components. Equipment with bare electrical
components must not be used by the farm staff.

Safety instructions Page 13
AirMaster EM50
Edition: 03/2015 M 2341 GB
2.4 Personal safety instructions
These safety instructions are intended to make you familiar with all information
regarding the system that are important for your safety and that of the system.
Maintenance may only be carried out by specially trained and briefed users.
Keep with the safety instructions in this manual.
2.4.1 Clothing for personal safety
Lack of knowledge about the structural design of the system can lead to
injury.
Make yourself familiar with the design and construction of the installation
under sufficient lighting! Inform yourself and your colleagues about the
remaining dangers in connection with this installation!
Wear close-fitting clothes when carrying out mounting, maintenance and
cleaning work at the installation.
Do not wear rings, necklaces, watches or other items which could get
caught at parts of the installation.
Never work with long hair that is not tied together. Your hair could get
caught in moving devices or system parts and thus cause serious injuries.
During all mounting, maintenance and cleaning work at the installation,
wear protective clothes and shoes as well as safety glasses and gloves if
required.

Page 14 Safety instructions
AirMaster EM50
Edition: 03/2015 M 2341 GB
2.4.1.1 Clothing and footwear
•Wide, fluttering clothes increase the risk of an accident.
•Wide pieces of clothing, ties, scarves etc. can get caught in the moving or rotating
system parts.
•High heels are a safety risk.
•If you stumble, you can knock against sharp-edged, moving or rotating system
parts and get severely injured.
2.4.1.2 Jewellery
•Loose or large jewellery increases the risk of an accident.
•The large or loose parts of jewellery can get caught in components of the
installation.
2.4.1.3 Hair
•Long hair increases the risk of an accident.
•Long hair can get caught in moving or rotating system parts.
Secure wide, fluttering clothes or take them off!
When working at or on the system, only wear slip-free footwear and safety
shoes when replacing heavy system parts!
Take off all jewellery, particularly necklaces, bracelets and rings!
Secure long hair by tying it back or wearing a bandanna or cap!
