Bigassfans HAIKU User manual

©2013 DELTA T CORP. ALL RIGHTS RESERVED. 003927 REV. I 1
HAIKU®by BIG ASS FANS
WARNING: Ensure power is disconnected at the fuse/breaker distribution panel before installing or
servicing the wall control and fan!
CAUTION: Installation must be completed in strict conformance with local building and electrical
codes.
WARNING: If installing the fan in Australia, qualified licensed professionals should perform all
installation work.
Review the safety guidelines in the complete Haiku® Installation Guide. If you have questions about any
aspect of the installation process, contact Haiku Technical Service at www.haikufan.com for assistance.
PARTS AND HARDWARE
If you are missing any parts or hardware required for the installation of your Haiku wall control, contact Haiku
Technical Service. Note: Drawings are not to scale.
Wall control (2) #6-32 x 7/8” screw RF board Antenna retainer
Note: If your wall control kit does not include a wall plate, Big Ass Fans recommends using a Decora® wall
plate. Other brands may not be compatible. The junction box and wire connectors are customer supplied.
INSTALLATION
While installing the fan(s) according to the complete Haiku Installation Guide, follow the steps below to
install the Haiku wall control and RF board. It is possible to link up to four (4) Haiku fans to a single controller
to simultaneously control airflow, lights, and special features. If installing linked fans, the first fan must be
located within 20 ft (6 m) of the wall controller. Successive fans must be within 20 ft (6 m) of each other and
with no physical obstructions.
Step 1. Set the wall control address
a) Remove the rubber covering from the back of the wall control. Locate the
DIP switch and rotary switch. See bottom right of this page for the switch
location on the wall control.
b) Toggle DIP switch 1 either on or o, and then turn the rotary switch to one
of sixteen channels. Use a small screwdriver or similar tool to turn the
rotary switch. Together DIP switch 1 and the rotary switch allow 32 unique frequency settings (two sets of
16) to prevent interference between multiple wall controls.
c) Set DIP switches 2–4 as shown below. Make sure switch 3 is o. Settings for switches 2 and 4 depend on
whether the wall control will control a single fan or multiple fans, and whether any of the fans has a light.
HAIKU®WALL CONTROL KIT
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
ON
4321
0
1
2
3
4
5
6
7
8 9
A
B
C
D
E
F
Single fan Multiple fans
Fan(s) with light
For multiple fans, this setting applies
if any of the fans has a light
Fan(s) without light

©2013 DELTA T CORP. ALL RIGHTS RESERVED. 003927 REV. I
HAIKU®by BIG ASS FANS
2
HAIKU WALL CONTROL (CONT.)
Step 2. Set the RF board address
CAUTION: Do not adjust the DIP switch settings on the fan’s circuit board! Adjust only the
DIP switches on the RF board(s) that will be plugged into the fan(s).
1. Locate the DIP switch and rotary switch on the RF board(s).
2. Set the rotary switch and DIP switch 1 to match the setting on
the wall control.
3. Set DIP switches 2–4 as shown below. Make sure switch 3 is on. Settings for switches 2 and 4 depend on the fan’s
position in the control sequence and whether the fan is alone or is linked to another fan.
Step 3. Remove lower cover
Remove the lower cover from the fan as shown below. On Haiku®Bamboo fans, pry o the cover. On Haiku®
composite fans, twist the lower cover counterclockwise to remove it.
Haiku®Bamboo
Lower Cover
Haiku®
Lower Cover
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
ON
4321
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Single fan Multiple fans
First fan (fan closest to wall control) Subsequent linked fan(s)

©2013 DELTA T CORP. ALL RIGHTS RESERVED. 003927 REV. I 3
HAIKU®by BIG ASS FANS
HAIKU WALL CONTROL (CONT.)
Step 4. Install RF board
CAUTION: Do not touch the fan electronics during installation unless necessary!
CAUTION: Do not adjust the DIP switch settings on the fan’s circuit board! Adjust only the
DIP switches on the RF board(s) that will be plugged into the fan(s).
WARNING: Ensure power is disconnected at the fuse/breaker before installing the wall control and
the fan!
Install the RF board in the fan circuit board as shown below. If linking multiple fans, install an RF board in
each fan circuit board.
If the fan’s circuit board has one row of female connectors (blue), install the lower set of six (6) RF board
prongs into the circuit board. If the fan’s circuit board has two (2) rows of female connectors (black), install all
twelve (12) RF board prongs into the circuit board.
Step 5. Install antenna retainer
Secure the antenna to the antenna retainer, and then peel the adhesive backing o the retainer.
Attach the sticky side of the retainer to the inner side of the hub wall as shown. Make sure the antenna is
straight and snug in the retainer, and that the retainer is far enough inside the hub that the lower cover will
not rub against it. Reinstall the lower cover.
Underside of Fan Hub
RF Board
Female
connectors
(two rows)
Prongs
Do NOT
adjust these
DIP switches!
Underside of Fan Hub
Antenna
Antenna
Retainer
If the fan does not respond to commands from the
wall control, adjust the position of the antenna in
the retainer until the fan responds.
tip! Hub Wall

©2013 DELTA T CORP. ALL RIGHTS RESERVED. 003927 REV. I
HAIKU®by BIG ASS FANS
4
Step 6. Wire the wall control
WARNING: Ensure power is disconnected at the fuse/breaker distribution panel before wiring the
wall control and the fan!
CAUTION: Do not use the fan with a dimmer switch.
While supporting the wall control, connect the wires with wire connectors as shown below. Switch leg wiring
is recommended by Big Ass Fans. If switch leg wiring is not possible, secure the end of the red wire with a
wire connector.
HAIKU WALL CONTROL (CONT.)
Wire color chart
Wall Control Wire Color
North America
Australia*
AC Line (L1)
Black
Red
AC Neutral (L2/N)
White
Blue
PE/Ground
AC Load (L1A) (Switch Leg)
Red
Red
Power Supply Wire
Color
North America
100–120 V System Black White Green or Bare Copper Black
North America
208–240 V System Black, Red, or Blue Red, Blue, or Black Green or Bare Copper Black
Australia*
240 V System Brown or Red Black or Light Blue Green with Yellow Tracer Brown
*Special Note: If installing the fan in Australia, a licensed electrician must perform the electrical installation.
100–240VAC
1 Φ, 50/60Hz
PE / Ground
L2 / AC Neutral
L1 / AC Line
PE / Ground
L2 / AC Neutral
L1 / AC Line
L1A / AC Load (Switch Leg) (Capped)
PE / Ground
L2 / AC Neutral
L1 / AC Line
100–240VAC
1 Φ, 50/60Hz
Can be dierent
AC circuits
100–240VAC
1 Φ, 50/60Hz
PE / Ground
L2 / AC Neutral
L1 / AC Line
PE / Ground
L2 / AC Neutral
L1A / AC Load (Switch Leg)
L1A / AC Load (Switch Leg) (Optional)
PE / Ground
L2 / AC Neutral
L1 / AC Line
100–240VAC
1 Φ, 50/60Hz
PE / Ground
L2 / AC Neutral
L1 / AC Line
PE / Ground
L2 / AC Neutral
L1 / AC Line
L1A / AC Load (Switch Leg) (Capped)
PE / Ground
L2 / AC Neutral
L1 / AC Line
100–240VAC
1 Φ, 50/60Hz
Can be dierent
AC circuits
100–240VAC
1 Φ, 50/60Hz
PE / Ground
L2 / AC Neutral
L1 / AC Line
PE / Ground
L2 / AC Neutral
L1A / AC Load (Switch Leg)
L1A / AC Load (Switch Leg) (Optional)
PE / Ground
L2 / AC Neutral
L1 / AC Line
OR

©2013 DELTA T CORP. ALL RIGHTS RESERVED. 003927 REV. I 5
HAIKU®by BIG ASS FANS
HAIKU WALL CONTROL (CONT.)
Step 8. Test the fan(s)
Reapply AC power, and then turn on the fan(s) using the wall control to test the DIP switch address. If the wall
control does not operate the fan(s) due to interference with other radio frequency devices, turn o power to
the fan(s) and wall control, select a dierent address on the wall control, and then set the matching address
on the RF board(s). Reapply power and retest. Repeat until an appropriate address is determined.
Power to the fan(s) and wall control must be turned o during address changes. If power is on during
an address change, the change may not be accepted.
Wall Control
Junction Box
(in wall)
Wall Plate
#6-32
Screw
Step 7. Install the wall control
Install the wall control with the provided #6-32 x 7/8” screws in a location within 20 ft (6 m) of the fan. Do not
overtighten the screws. Install the wall plate using the screws provided with the wall plate. Note: If your wall
control kit does not include a wall plate, Big Ass Fans recommends using a Decora® wall plate. Other brands
may not be compatible.
Step 9. Install lower cover or (optional) LED light kit
If you purchased the Haiku LED light kit, proceed to the instructions included with the kit. If you did not
purchase the LED light kit, proceed to the step for installing the lower cover in the complete Haiku Installation
Guide.

©2013 DELTA T CORP. ALL RIGHTS RESERVED. 003927 REV. I
HAIKU®by BIG ASS FANS
6
WALL CONTROL OPERATION
The fan is controlled independently from the light. Both the wall
control and the IR remote can be used to control the fan and the light.
Operating the fan
Ensure the Power Cuto Tab is flush with the wall control face. If not,
use a pen or similar object to push it into position.
Powering the fan
To turn the fan on or o, press the On/O button on the right side of
the wall control. This button can also be used to reset the fan’s speed.
CAUTION: The fan will automatically restart at the last opera-
ting speed when power is restored!
Changing fan speed
Fan speed is increased or decreased by pressing the Up or Down
Speed button on the wall control. Several fan speeds are available to
accommodate your comfort level.
To change the fan speed, press a Speed button. The Up Speed button increases fan speed; the Down Speed
button decreases fan speed. The fan mode indicators will illuminate and a short beep will be heard until the
highest speed or 0 (o) is reached.
Timer mode
In Timer mode, the fan runs at a set speed until the programmed time period ends. Note: Timer mode is
disabled if the fan speed is 0 (o) or if the fan is not running.
To set Timer mode, press the Timer button 1–7 times (once for each hour) to program the end time. During
adjustment, the fan mode indicators will flash, and then the Timer setting is displayed on the speed indicator
bar. To exit Timer mode, press the Clear button.
Sleep mode
Sleep mode reduces the fan speed by one increment every hour until the lowest speed is reached. When the
programmed time period ends, the fan automatically turns o. Sleep mode is only active when Timer mode
is used.
To activate Sleep mode, set the fan speed and Timer mode, and then press the Sleep button. The Sleep
indicator will illuminate. To exit Sleep mode, press the Sleep, Clear, or On/O button.
Whoosh mode
Whoosh mode simulates natural, relaxing breezes by automatically varying the fan speed.
To activate Whoosh mode, set the desired maximum fan speed, and then press the Whoosh button. The top
Speed indicator will flash to indicate that Whoosh mode is active. To exit Whoosh mode, press the Whoosh,
Speed, or On/O button once.
HAIKU WALL CONTROL (CONT.)
4.18” (106 mm)
1.65” (42 mm)
Power
Cuto Tab

©2013 DELTA T CORP. ALL RIGHTS RESERVED. 003927 REV. I 7
HAIKU®by BIG ASS FANS
HAIKU WALL CONTROL (CONT.)
OPERATING THE LIGHT
The Haiku LED light kit operates independently from the fan, providing a variable level of illumination that is
increased or decreased by pressing the Up or Down Light button on the wall control.
CAUTION: Do not stare directly into the light!
Powering the light
To turn the light on or o, press the Light On/O button on the left side of the wall control. The light will turn
on to the last setting when power is restored.
Changing the brightness
To increase brightness, press the Up Light button on the wall control. To decrease brightness, press the
Down Light button. To quickly increase or decrease the brightness, press and hold the Up or Down Light
button until the desired level of illumination is reached.
MAINTENANCE
Push the Power Cuto Tab at the lower end of the control face and disconnect power before performing any
maintenance. Refer to the complete Haiku Installation Guide for detailed troubleshooting and fan mainte-
nance instructions.
WARNING: Ensure AC power is disconnected at the fuse/breaker distribution panel and the Power
Cuto Tab is protruding outward (O position) before performing any maintenance on the fan or
wall control.
CAUTION: The fan will automatically restart at the last operating speed when power is restored!
Power Cuto Tab
(O position)
