Billion at a Glance
Billion Electric Co. Ltd. (Taiex: 3027, trading as BILLION), founded in Taiwan in 1973, is one of
the leading providers of network equipment and power supply products in the Asia Pacic. With
the establishment of its Communication Division, Billion has reinforced its commitment to develop
next-generation network equipment and Internet access devices to meet the needs of home users,
telecommuters, SOHOs and SMBs around the globe. “Powering Communications with Security”
stands for Billion’s attention to its customers’ secure broadband communication needs. Billion
defines its user-friendly product range by integrating new technologies into its existing product
family, enabling its customers to benet from Billion’s compact design without the need to purchase
extra hardware. Billion has received a number of awards for its networking products and has
acquired a considerable customer base across Europe, America, the Middle East, Africa and the
Asia Pacic. For more information, please visit www.billion.com.
22

3
Wired
p. 4
Wireless
p.5
VoIP
p.8
Home
p.10
Networking
SHDSL
p.14
SSL VPN
p.16
CMS
p.15
Switch
p.13
3G / HSDPA
p.6
GPON
p.12
VDSL2
p.13
IPSec VPN
p.18
Product Range

4
Products & Models BiPAC 5200S BiPAC 5200SRC BiPAC 5210S BiPAC 5210SRC BiPAC 5200 BiPAC 7300RA BiPAC 7800 BiPAC 7402 R2
ADSL2+ v v v v v v v v
USB 1.1 port 1 1
Ethernet switch 10/100Mbps
LAN ports 1 1 1 1 4 4 4 4
Quality of Service v v v
Firewall v v v v v v v v
Easy Sign On (EZSO) v v v
Impulse noise protection for
IPTV applications v v v v v v v v
IPSec VPN pass through 16 tunnels
Remote management* by request
Target users Home and SOHO SOHO and Ofce
Wired
* The specication of Remote Management on end-user devices is available only upon request for Telco/ISP projects.

5
Products & Models BiPAC
5210SGRA
BiPAC
5200GRC
BiPAC
5200N
BiPAC
7300GRA
BiPAC
7300N
BiPAC
7800N
BiPAC
7402G
ADSL2+ v v v v v v v
USB 1.1 port 1
Ethernet switch 10/100Mbps 10/100/
1000Mbps 10/100Mbps
LAN Ports 1 4 4 4 4 4 4
802.11g with WPA/WPA2 v v v v
802.11n with WPA/WPA2 v v v
Wi-Fi Protected Setup v v v
Quality of Service v v v v
Easy Sign On (EZSO) v v v v
Firewall v v v v v v v
Impulse noise protection
for IPTV applications v v v v v v v
IPSec VPN pass through 16 tunnels
VPN with 3DES
accelerator v
Remote management*by request
Target users Home and SOHO SOHO and
Ofce
Products &
Models
BiPAC
3012G
BiPAC
3010N
USB 2.0
interface v v
WPA/WPA2 v v
802.11b
compliance v v
802.11g
compliance v v
802.11n
compliance v
Universal
Plug and Play
(UPnP)
v v
Soft AP
function v v
Windows and
Mac OS v v
Wireless
* The specication of Remote Management on end-user devices is available only upon request for Telco/ISP projects.

6
3G / HSDPA
Products & Models BiPAC 7300GX BiPAC 7402XL BiPAC 7402X BiPAC 7402GXL BiPAC 7402GX BiPAC 7402NXL BiPAC 7402NX
ADSL2+ vvvvvvv
3G supported*PCMCIA USB 2.0 host
Auto fail-over v v v v v v v
LAN ports 4 4 4 4 4 4 4
Ethernet switch 10/100Mbps 10/100/1000Mbps
802.11g with WPA/WPA2 v v v
802.11n with WPA/WPA2 v v
Wi-Fi Protected Setup v v v v v
Quality of Service v v v v v v v
Firewall vvvvvvv
IPSec VPN pass through 16 tunnels pass through 16 tunnels pass through 16 tunnels
Target users Home and SOHO SOHO and Ofce Home and SOHO SOHO and Ofce Home and SOHO SOHO and Ofce
*A 3G cardbus or a 3G modem is available separately.

7
Enjoy all the benefits of high-speed ADSL connection
right at your desk with the Dual-WAN 3G/ADSL2+ router
series, offering a secure computing experience, with an
integrated SPI rewall, DoS prevention and other robust
security features.
At the desk
The Dual-WAN 3G/ADSL2+ router series’ innovative
browser-based conguration allows you to quickly and
easily set up a WLAN, so when you're at a meeting
or training, your guests or participants can quickly
and securely access the Internet via a 3G network
to retrieve emails, share meeting minutes or training
materials with their colleagues.
In a meeting
The auto-failover feature ensures maximum connectivity
and minimum interruption by quickly and smoothly
connecting to a 3G network in the event that the landline
fails. The Dual-WAN 3G/ADSL2+ router series will then
automatically return to the ADSL connection when it's
restored, reducing connection costs. These features are
perfect for ofce situations where a constant connection
is paramount.
Always-On connection
With the integrated IPSec VPN function, the BiPAC
7402X series allows you to establish encrypted
connections of up to 16 VPN tunnels over the Internet -
so you can access your corporate intranet and transmit
sensitive data between branch ofces and remote sites
anytime; even when you are on the road, thus enhancing
productivity.
VPN security
By installing the Dual-WAN 3G/ADSL2+ router series,
public transport operators can update passengers with
real-time weather and event information, updated regularly
via a 3G Internet connection, or offer business travelers
Internet access that can be billed to create greater income
potential.
On public transport
When you're chilling out at a party or concert, the
light-weight, portable Dual-WAN 3G/ADSL2+ router
series frees you to instantly share your pictures or
video clips of the event with friends and family -- so
those close to you can share your joy.
At an event
What is 3G?
3G is the common name for third-generation digital mobile technology. It offers consistent services delivered via 3G/HSDPA, EDGE, or UMTS mobile telephony protocols. Compared to 1G
(analog wireless technology) and 2G (digital radio wireless technology such as GPRS), 3G offers faster data transfer rates up to 14.4Mbps.
Applications over 3G/ADSL networks

8
Products & Models BiPAC
6404VP
BiPAC
6404VGP
BiPAC
7401VGPR3
BiPAC
7401VGPX
BiPAC
7404VGPX
BiPAC
7404VGOX
BiPAC
7404VNPX
BiPAC
7404VNOX
ADSL2+ v v v v v v v v
3G supported USB 2.0 host
Auto fail-over v v v v v
LAN ports 3 3 4 4 4 4 4 4
Ethernet switch 10/100Mbps 10/100/1000Mbps
FXS ports 22112222
FXO ports 11111111
Gateway - Least Cost Routing v v v v
802.11g with WPA/WPA2 vvvvv
802.11n with WPA/WPA2 v v
Wi-Fi Protected Setup v v v v v v
Quality of Service v v v v v v
Firewall v v v v v v v v
IPSec VPN pass through 16 tunnels pass through 16 tunnels
Target users Home and SOHO SOHO and
Ofce
Home and
SOHO
SOHO and
Ofce
VoIP

9
Interested? Want to learn how a Billion ADSL VoIP router works, and enables you to make a call? We keep it simple using the diagrams below to guide you
through.
Gateway - The Least Cost Routing feature allows to use the most economical rates
offered provided by different Internet Telephony Service Providers (ITSPs).
Three types of VPN solutions (PPTP, IPSec and L2TP within IPSec) allow ofce users to
build secure VPN tunnels for voice and data communication between a company’s head
ofce and its branch(es).
VoIP calls to/from VoIP VoIP calls to/from PSTN
Gateway - Least Cost Routing
PSTN Fixed-line Support
Secure Voice over VPN Tunnel
Advanced VoIP Router Application
VoIP Call Applications
9

10
Home Networking
Products & Models BiPAC 104
(2x BiPAC 2071 incl.)
BiPAC P106
(2x BiPAC 2073 incl.) BiPAC 2070P BiPAC 2072 BiPAC 2073N (available in Q3)
BiPAC 2074
(available in Q2)
Type Wall mounted Desktop Wall mounted Desktop
Powerline data rate 200Mbps
Minimal power saving at
standby mode 60% 50% 60% 50% 50%
Maximal power saving at
full operation 20% 20% 20%
AC Power Supply v
LAN ports 1 1 1 1 1 1
Ethernet switch 10/100 Mbps
Wi-Fi 802.11n v
AC Pass-through socket 1 1
Quality of Service v v v v v v
Target users Home and SOHO

11
Even at the moment your family turn on
an electronic device or turns off a light,
you won't experience any interruption to
latency-sensitive applications such as
multimedia or video being shared with
your family in another room.
With noise filtering, the BiPAC 2072 / 2074
enhances power-line communicatoions
coverage and those appliances will not be
able to interfere with the data transmission
quality.
If no Ethernet device is being used, the
HomePlug AV series will automatically go into
sleep mode, which cuts power consumption
by at least 60%, increasing energy efciency
and save money on your electricity bill.
Highlights
AC Pass Through with Noise Filtering
Power Saving
11

GPON / Fiber
Products & Models BiPAC 9800N BiPAC 9300VN
Point-to-Point over Fiber
(EFM*-Fiber) v
Point-to-multipoint
Gigabit over Fiber (GPON) v
Ethernet switch (LAN ports) 4 x
10/100/1000Mbps
4 x
10/100/1000Mbps
Quality of Service v v
Firewall v v
VoIP 2 x FXS ports
Easy Sign On (EZSO) v v
IPSec VPN v
Remote management by request*OMCI*
Target users SOHO & Ofce Home, SOHO &
Ofce
A Gigabit Passive Optical Network (GPON) is a point-to-multipoint, ber to the premises network architecture
in which unpowered optical splitters are used to enable a single optical ber to serve multiple premises.
A GPON consists of an Optical Line Terminal (OLT) at the service provider's central ofce and a number of
Optical Network Units (ONUs) near end users. A GPON conguration reduces the amount of ber and central
office equipment required compared with point-to-point over fiber (EFM*-Fiber) architecture. GPON has a
maximum downstream rate of up to 2.5Gbps and upstream rates are around 1.244Gbps.
12
*EFM: Ethernet in the First Mile
*OMCI: ONT Management and Control Interface
*The specication of remote management on end-user devices is available only upon request
for Telco/ISP projects.

13
BiPAC GS08
• 8 x 10/100/1000Mbps Full-duplex, auto MDI/MDI-X ports
• Up to a total 16Gbps network data transfer rate
• Smart power saving technology for efcient energy consumption
• Store-and-forward architecture for low-latency and error-free
transmission
• NWay protocol for speed and duplex mode auto-detection
• True plug and play installation
• Ideal for home and SOHO users
VDSL2
8-port Gigabit Green Ethernet Switch
Switch
What is VDSL2?
• VDSL2 is a Very-High-Bit-Rate Digital Subscriber Line, next-generation DSL technology
• Fiber optic lines as backbone and VDSL2 line as the last mile to home or ofce
• For bandwidth-consuming applications such as voice, video-on-demand and IPTV services
• Fullls the vision of the digital home and improves ofce productivity
Products & Models BiPAC 8200M
(available in Q2)
BiPAC 8200N
(available in Q3)
VDSL2 prole 8a/b, 12a,17a, 30a 8a/b, 12a,17a, 30a
Band plan 997 & 998 v v
Supports 2/3/4/5/6 band v v
Downstream 100Mbps 100Mbps
Upstream 100Mbps 100Mbps
Ethernet switch 10/100Mbps 10/100Mbps
LAN ports 4 4
Wi-Fi 802.11n v
Firewall v
Router v
Target users Home & SOHO

14
SHDSL
Products & Models BiPAC 8500 BiPAC 8520 BiPAC 8501 BiPAC 8501R2 BiPAC 8521
SHDSL 2.3Mbps 4.6Mbps
SHDSL.bis 5.7Mbps 5.7Mbps 11.4Mbps
WAN ports 1 2 1 1 2
LAN ports 4
Ethernet switch 10/100Mbps
Back-to-back connectivity v v v v
Quality of Service v v v v v
Firewall vvvvv
IPSec VPN v v v
Target users SOHO and Ofce
Back-to-Back Connectivity
Application Diagrams

15
BiGuard CMS Lite
• Native HTML/HTTPS interface between the remote device and BiGuard CMS
• Data encryption and ID/password authentication for secure management
• No client installation needed
• Web-based user interface
• Supports PostgreSQL
• Firmware upgrade for single/grouped devices on demand or according to a schedule
• Conguration backup for single/grouped devices on demand or at regular time intervals
• Conguration restoration
• Device connectivity checking
• MS-IE to management device
• Event logs of BiGuard CMS actions
• Supports BiGuard SSL VPN series security appliances
• Supports different levels of central management :10, 20, 30 devices
• Database backup and restoration (not available in Evaluation version)
• Ideal for SMBs and service providers
BiGuard CMS Pro
• XML/HTTPS interface between the remote device and BiGuard CMS
• Data encryption and CMS server authentication by remote device for secure
management
• No client installation needed
• Web-based user interface
• Automatic device discovery
• Remote conguration management
• Supports database backup and restoration (not available in Evaluation version)
• Firmware upgrade for single/grouped devices on demand or according to a
schedule
• Conguration backup for single/grouped devices on demand or at regular time
intervals
• Conguration restoration
• Device connectivity check
• Device model auto-detection
• Fault management
• Real time monitoring and alerts
• Email alert upon emergency event
• Statistics and log reports
• Security – account management by access level for CMS
• Supports BiGuard SSL VPN series security appliances
• Supports different levels of device management :10, 30, 60, and 120; central
management for 120 above devices is provided with project-based version upon
request for Telco and ISPs.
• Ideal for SMBs and service providers
Central Management
System

SSL VPN Gateways
Products & Models BiGuard S5 BiGuard S10 BiGuard S20 BiGuard S100N BiGuard S3000 BiGuard S6000
Concurrent SSL users 5 ~ 20 10 ~ 20 20 10 ~ 30 10 ~ 50 50 ~ 200
IPSec VPN tunnels 10 30 10 30 30
WAN ports 1 x 10/100Mbps 1 x 10/100Mbps 2 x 10/100Mbps 1 x 10/100/1000
Mbps
2 x 10/100/1000
Mbps
2 x 10/100/1000
Mbps
LAN ports 4 x 10/100Mbps 4 x 10/100Mbps
8 x 10/100 Mbps
1 x 10/100/1000
Mbps
4 x 10/100/1000
Mbps
8 x 10/100/1000
Mbps
8 x 10/100/1000
Mbps
High Availibility (HA) v v
Load balancing & auto
fail-over v v v
Site to Site SSL VPN*v v v v v v
802.11n with WPA/
WPA2, WPS v
Wireless Network
Access Control (NAC) v
3G supported v*
Smart Power Saving v
Wake On LAN (WOL) v v v v v v
QoS and rewall v v v v v v
Host security checking v v v v v v
End Point Security
(EPS) checking v*v v
AD account
membership v*v v
Rack mountable v v v v v
Target users SMB up to 50 staff SMB 50 to 200 staff SME 200 to 500
staff
SME 500 to 1,000
staff
*to be available
What’s Unique about a SSL VPN
Gateway?
• SSL VPN gateway plus solid router functions
• Network / Transport Extender
• Application Proxy
• Network Places
• Green Smart Power Saving
• Host security checking
• Firewall security
• Microsoft Windows Mobile 5.0 / 6.0
compatible mobile devices support
• Wake On LAN (WOL)
• Data encryption and user authentication
• Supports Citrix
• Supports ERP applications
• Windows / Linux / Macintosh support
• Hardware DMZ support
• Granular access policy management
• Personalized web portal
• Quality of Service
16

Network Application with SMB Security Appliances
17
BiGuard One-Time Password
• One-Time Password for multiple
applications
• Ease of use anywhere at any time
BiGuard SSL VPN Tunnel
Upgrades
• Increases more SSL VPN tunnels by
upgrading existing devices
Feature and Firmware
Upgrades
BillionCare
Superb services that are applicable to
BiGuard S3000 and BiGuard S6000 models
include 2 kinds :
• Advanced Hardware Replacement
• Feature and Firmware Upgrades
Other Options:

18
BiGuard C01
BiGuard IPSec VPN Client Software
• Use USB Stick to store VPN security elements
• IPSec VPN tunneling with DES/3DES/AES
encryption
• IKE Key management
• Point-to-Point tunnel
• VPN conguration wizard
• Multiple proles
• USB Sticker to store conguration and auto-
connection
• Support all Microsoft OS (Windows 2000, Server
2003, XP, Vista 32-bit, Vista 64-bit)
• DPD (Dead Peer Detection) and redundant
gateway
• Support all Billion VPN-enabled devices such as
BiGuard, BiPAC 85xx, BiPAC 74xx
• Ideal for telecommuters and ofce users
Products & Models BiGuard 2 BiGuard 10 BiGuard 30 BiGuard 50G
WAN ports 1 x 10/100Mbps 1 x 10/100Mbps 2 x 10/100Mbps 2 x 10/100Mbps
LAN ports 8 x 10/100Mbps 8 x 10/100Mbps 8 x 10/100Mbps 4 x 10/100Mbps
Load balancing & auto fail-over v v
IPSec VPN / PPTP VPN tunnels 2 / 4 10 / 4 30 / 4 50 / 32
802.11g with WPA/WPA2 v
SIP pass-through v v v v
E-mail alerts and logs of attacks v v v v
DMZ support v v v v
Quality of Service v v v v
Trafc management v v v v
Firewall v v v v
WAN IP alias v v v v
Rack mountable v v v
Target users SOHO & branch
ofces SMB SMB SMB
IPSec VPN Gateways

Network Application with SMB Security Appliances
19
