Billy Goat P / N 440120 User manual

Part No 440021 Form No F101706A
1
FORCE BLOWER Owner’s Manual
Patent Pending
BILLY GOAT FORCE BLOWER
Owner's Manual
Accessories
PARKING BRAKE
Effective and Easy to
use to prevent blower
from rolling.
P/N 440140
HOLD DOWN KIT
To secure blower for
transportation on
trailer floors.
P/N 440120

Part No 440021 Form No F101706A
2
FORCE BLOWER Owner’s Manual
ABOUT THIS MANUAL
THANK YOU for purchasing a BILLY GOAT
®
FORCE Blower. Your new machine has been carefully designed and
manufactured to provide years of reliable and productive service. This manual provides complete operating and
maintenance instructions that will help to maintain your FORCE Blower in top running order. Read this manual
carefully before assembling, operating, or servicing your equipment.
CONTENTS
SERIAL PLATE DATA AND SPECIFICATIONS 3
GENERAL SAFETY 4-5
SOUND AND VIBRATION 6
INSTRUCTION LABELS 7
PACKING CHECKLIST 8
ASSEMBLY
9
OPERATION 10-11
MAINTENANCE 12
TROUBLESHOOTING AND WARRANTY PROCEDURE 13
ILLUSTRATED PARTS LIST 14
PARTS LIST 15
MAINTENANCE RECORD 16

Part No 440021 Form No F101706A
3
FORCE BLOWER Owner’s Manual
SERIAL PLATE DATA
Record the model number, serial number, date of
purchase, and where purchased.
Purchase Date:
Purchased From:
Specifications F900S F900H F1300H
Engine: HP 9.0 HP (6.6kW) 9.0 HP (6.6kW) 13.0 HP (9.6kW)
Engine: Model EX270D50021 GX270K1QA2 GX390K1QAA2
Engine: Type SUBARU OHC HONDA OHV HONDA OHV
Engine: Fuel Capacity 6.4 qt. (6.1L) 6.3 qt. (6.0L) 6.5 qt. (6.1L)
Engine: Oil Capacity 1.05 qt. (1.0L) 1.16 qt. (1.1L) 1.16 qt. (1.1L)
Total Unit Weight: 138 # (62.6Kg) 143 # (64.8Kg) 160 # (72.6Kg)
Overall Length: 58"(1.43m) 58"(1.43m) 58"(1.43m)
Overall Width 29.25” (0.74m) 29.25” (0.74m) 28" (0.71m)
Overall Height 45" (1.14m) 45" (1.14m) 45" (1.14m)
In compliance with 2000/14/EEC standards 107dB(a) @3340 rpm 109dB(a) @ 3660 rpm 110dB(a) @ 3640 rpm
Sound at Operator’s ears 87dB(a) @ 3340 rpm 89dB(a) @ 3660 rpm 90dB(a) @ 3640 rpm
Vibration at operator position .96 g (9.44 m/s
2
) 1.05 g (10.30 m/s
2
) .81 g (7.96 m/s
2
)

Part No 440021 Form No F101706A
4
FORCE BLOWER Owner’s Manual
GENERAL SAFETY INSTRUCTIONS and SYMBOLS
The safety symbols shown below are used throughout this manual. You should become familiar with them before
assembling, operating, or servicing this equipment.
This symbol indicates important information that will prevent injury to yourself or others.
This symbol indicates ear protection is recommended when operating this equipment.
This symbol indicates eye protection is recommended when operating this equipment.
This symbol indicates gloves should be worn when servicing this equipment.
This symbol indicates that this manual and the engine manufacturer’s manual should be read
carefully before assembling, operation, or servicing this equipment.
This symbol indicates important information that will prevent damage to your BILLY GOAT
®
FORCE Blower.
This symbol indicates the engine oil level should be checked before operating this
equipment.
Read and make sure you thoroughly understand the following safety precautions before assembling, operating or
servicing this equipment:
READ this manual and the engine manufacturer’s manual carefully before assembling,
operating, or servicing this equipment.
EAR PROTECTION is recommended when operating this equipment.
EYE PROTECTION is recommended when operating this equipment.
BREATHING PROTECTION is recommended when operating this equipment.
EXHAUST from this product contains chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
DO NOT operate this equipment on any unimproved forested, brushy, or grass covered land
unless a spark arrester is installed on the muffler as required by Section 4442 of the
California Public Resources Code. The arrester must be maintained in good working order.
Other states may have similar laws. Federal laws apply on federal lands.
DO NOT run engine in an enclosed area. Exhaust gases contain carbon monoxide, an
odorless and possibly fatal poison.

Part No 440021 Form No F101706A
5
FORCE BLOWER Owner’s Manual
DO NOT run this equipment indoors or in any poorly ventilated area. Refueling outdoors is
recommended.
DO NOT refuel this equipment while the engine is running. Allow engine to cool for at least
two minutes before refueling.
DO NOT store gasoline near an open flame.
DO NOT remove gas cap while engine is running.
DO NOT start or operate engine if strong odor of gasoline is present.
DO NOT start or operate engine if gasoline is spilled. Move equipment away from spill until
gasoline has completely evaporated.
DO NOT smoke while filling the fuel tank.
DO NOT check for spark with spark plug or spark plug wire removed. Use an approved spark
tester.
DO NOT operate engine without a muffler. Inspect muffler periodically and replace if
necessary. If equipped with muffler deflector, inspect deflector periodically and replace if
necessary.
DO NOT operate engine with grass, leaves or other combustible material near the muffler.
DO NOT touch muffler, cylinder, or cooling fins when hot. Contact with hot surfaces may
cause severe burns.
DO NOT leave equipment unattended while in operation.
DO NOT park equipment on a steep grade or slope.
DO NOT operate equipment with bystanders in or near the work area.
DO NOT allow children to operate this equipment.
DO NOT operate equipment with guards removed.
DO NOT operate equipment near hot or burning debris or any toxic or explosive materials.
DO NOT operate equipment on slopes greater than specified in Specifications section of this
manual.
ALWAYS remove spark plug wire when servicing equipment to prevent accidental starting.
ALWAYS check fuel lines and fittings frequently for cracks or leaks. Replace if necessary.
ALWAYS keep hands and feet away from moving or rotating parts.
ALWAYS store fuel in approved safety containers.
WARNING: Important
Do not run this machine without director cone attached or with improper air director cone.
DO NOT run this machine with a cracked or damaged impeller under any circumstances.

Part No 440021 Form No F101706A
6
FORCE BLOWER Owner’s Manual
SOUND
SOUND LEVEL 90 Db(a) at Operators Position
Sound tests were conducted in accordance with 2000/14/EC, as well as ISO 11094, and were performed on 5-17-
2006 under the conditions listed below.
Sound power level listed is the highest value for any model covered in this manual. Please refer to serial plate on
the unit for the sound power level for your model.
VIBRATION DATA
VIBRATION LEVEL 1.05g (10.30m/s
2
)
Vibration levels at the operator’s handles were measured in the vertical, lateral and longitudinal directions using
calibrated vibration test equipment. Tests were performed on 5-17-2006 under the conditions listed below.
INTENDED USE
This machine is designed for cleaning outdoor surfaces, where the debris can be effectively blown into a
consolidated area for convenient pickup and removal.
Do not operate if excessive vibration occurs. If excessive vibration occurs, shut engine off immediately and check
for damaged or worn impeller, loose impeller bolt, loose impeller key, loose engine or lodged foreign objects. Note:
See parts list for proper impeller bolt torque specifications. (See trouble shooting section on page 13).
General Conditions: Sunny
Temperature: 79.7
o
F (26.5
o
C)
Wind Speed: 1.7 mph (2.8kph)
Wind Direction: South Southwest
Humidity: 31.2%
Barometric Pressure: 29.9Hg (101.25kpa )
General Conditions: Sunny
Temperature: 86.5
o
F (30.3
o
C)
Wind Speed: 2.5 mph (4.1kph)
Wind Direction: South Southwest
Humidity: 56.4%
Barometric Pressure: 29.9Hg (101.25kpa )

Part No 440021 Form No F101706A
7
FORCE BLOWER Owner’s Manual
INSTRUCTION LABELS
The labels shown below were installed on your BILLY GOAT
®
FORCE Blower. If any labels are damaged or
missing, replace them before operating this equipment. Item numbers from the Illustrated Parts List and part
numbers are provided for convenience in ordering replacement labels. The correct position for each label may be
determined by referring to the Figure and Item numbers shown.
LABEL READ OWNERS MANUAL LABEL EAR EYE BREATHING DANGER FLYING DEBRIS
ITEM #44 P/N890301 ITEM# 45 P/N890254 ITEM # 46 P/N 810736
LABEL EXPLOSIVE FUEL LABEL THROTTLE CONTROL
ITEM # 43 P/N 400268 ITEM # 42 P/N 810656
ENGINE LABELS
HONDA MOTOR CO. , LTD. MADE IN JAPAN
READ OWNER’S MANUAL BEFORE OPERATION.
LIRE LE MANUEL D UTILISATEUR AVANT USAGE.
VOR INBETRIEBNAHME UNBEDINGHT BEDIENUNGSANLEITUNG DURCHLESEN.
NO UTILIZAR SINANTES NO HABER LEIDO EL MANUAL
WHEN OIL LEVELLOW,
ENGINE STOPS IMMEDIATELY.
OIL ALERT
HONDA SUBARU
STOP
START

Part No 440021 Form No F101706A
8
FORCE BLOWER Owner’s Manual
PACKING CHECKLIST
These items should be included in your carton. If any of these parts are missing, contact your dealer.
Your BILLY GOAT
®
FORCE Blower was shipped in one carton, completely assembled except for the Upper Handle
Assembly and Front Diverter. Mounting hardware for the Upper Handle Assembly can be found in the parts bag.
READ all safety instructions before assembling unit.
TAKE CAUTION when removing the unit from the box the Handle Assembly is attached to the
unit by cables.
PUT OIL IN ENGINE BEFORE STARTING
Boxing Parts Checklist
Front Air Diverter
Item#38 P/N-440045
Handle Upper Assembly
Item #30 P/N-440035
Parts Bag & Literature Assy
P/N-440020
Honda 9 or 13 hp
Subaru 9 hp
PARTS BAG &
LITERATURE ASSY
Warranty card P/N
-
400972, Owne
r’s Manual P/N
-
440021,
Declaration of Conformity P/N
-
440022,
Handle
Hardware
-
Items #10, #11, and #36

Part No 440021 Form No F101706A
9
FORCE BLOWER Owner’s Manual
ASSEMBLY
Figure A Figure B
1
.Follow the steps in figures A and B, then securely tighten all hardware shown.
2.Connect spark plug wire.
The hardware for attaching the upper handle to the lower
is in the parts bag. Install upper handle (item 30), to
preassembled
lower handle (item 28) by sliding the upper
over and down the outside of the lower handle. Using bolt
(item #36), washers (item #10) & lock nut (item #11) to
install upper handle to lower handle. Finish installing the
other side of the upper handle assembly using screw and
lock nut provided.
The throttle control will be attached to the throttle arm on
the engine and wrapped around the engine for shipping.
Unwrap and secure throttle control (item #31) to upper
handle with screws (item #39). Screws will already be
mounted in handle, simply remove and use to mount the
throttle control.
Two ½” open ended wrenches One 3/8 open ended wrench

Part No 440021 Form No F101706A
10
FORCE BLOWER Owner’s Manual
OPERATION
Like all mechanical tools, reasonable care must be used when operating machine.
Inspect machine work area and machine before operating. Make sure that all operators of this
equipment are trained in general machine use and safety.
PUT OIL IN ENGINE BEFORE STARTING
STARTING
ENGINE: See engine manufacturer’s instructions for type and amount of oil and gasoline used. Engine must be
level when checking and filling oil and gasoline.
FUEL VALVE: Move fuel valve to "ON" position (when provided on engine).
STOP SWITCH: Located on the engine. "ON" position.
CHOKE: Operated with choke lever on side of engine.
THROTTLE: Controlled by throttle lever on the handle. Move remote throttle control to fast position. Pull starting
rope to start engine.
ENGINE SPEED: Under normal conditions, operate at minimum throttle to accomplish your current cleaning task.
IF YOUR UNIT FAILS TO START:
See Troubleshooting on page 13.
HANDLING & TRANSPORTING:
Using two people to lift machine is recommended. Lift holding the handle and handle brace. Secure in place d
uring
transportation. See F900 and F1300 series specifications on page 3 for unit weight.
Do not use the front grill as an anchor point when securing the unit for transport.
Never lift the machine while the engine is running.
BLOWING OPERATION
Your Billy Goat Force blower is equipped with an air director cone to allow the operator to direct the air stream up
or down as required to assist in moving debris. This feature is extremely useful when debris has piled up to the
point that it cannot be blown any farther. The air stream can be directed upward to blow the top of the debris pile
over and allow the operator to continue moving more debris farther.
