Part No. 500264 Form No. F101001APage 1 of 12
Operator Owner's Manual
Thank You for Selecting
1
3Specifications
The Powerful BC2401 SELF-PROPELLED BRUSH CUTTER
UNITSIZE: OVERALLLENGTH: 82.5"(2.09m) OVERALL WIDTH 32.0" (0.81m) OVERALL HEIGHT43"(1.09m)
ACCESSORIES
NUT REPLACEMENT KIT
P/N 500208.
Toreplacestrippedor
damagedinsertnutsin
enginebase.
BLADE BC2401
P/N 500210.
OriginalEquipment Blade
forreplacement.
BELT TRACTION DRIVE
P/N 500119.
TractionDriveBelt
forBC2401
BELT BLADE DRIVE
P/N 500237.
BladeDrive Belt
forBC2401
BC2401IC, BC2401H, BC2401HE
BC2401IC BC2401H BC2401HE
ENGINE: H.P. 10.5 (7.83 kW) 11 (8.20 kW) 11 (8.20 kW)
ENGINE:TYPE B&S HONDA HONDA
ENGINE MODEL NO: 28B702118-E1 GXV340K1DX3 GXV340K1DE33
ENGINE:FUELCAP. 3.0qt.(2.84L) 2.3qt.(2.18L) 2.3qt.(2.18L)
ENGINE: OIL CAP. 1.34 qt. (1.41 L) 1.20 qt. (1.13 L) 1.20 qt. (1.13 L)
WEIGHT:UNIT 282# (128.5 kg) 278# (126.1 kg) 282# (127.9 kg)
WEIGHT:SHIPPING 310# (141.3 kg) 306# (138.8 kg) 310# (140.6 kg)
ENGINEWEIGHT: 66.0# (30.0 kg) 70.5# (32.0 kg) 72.5# (32.9 kg)
MAX.OPERATINGSLOPE 15°20°20°
2
BLADE HIGH LIFT
BC2401
P/N 500102.
Optionalblade for
replacement

Part No. 500264 Form No. F101001A
WARNING:DO NOT
1. DO NOT run engine in an enclosed
area. Exhaustgasescontaincarbon
monoxide,anodorlessanddeadlypoison.
2. DO NOT place hands or feet near
movingorrotatingparts.
3. DO NOT store, spilloruse gasoline
nearan openflame, ordevices suchas a
stove,furnace, orwater heaterwhich use
apilotlight ordeviceswhichcan createa
spark.
4. DO NOT refuel indoorswherearea is
notwellventilated. Outdoorrefueling is
recommended.
5. DO NOT fill fuel tank while engine is
running. Allowengine tocoolfor 2
minutesbeforerefueling. Storefuel in
approvedsafety containers.
6. DO NOT remove fueltankcap while
engineis running.
7. DO NOT operateenginewhensmellof
gasolineispresentorotherexplosive
conditionsexist.
8. DONOT operate engineifgasoline is
spilled. Movemachineawayfromthespill
andavoidcreatinganyignitionuntilthe
gasolinehasevaporated.
9. DO NOT transport unit with fuel in tank.
10. DO NOT smoke whenfillingfuel tank.
11. DO NOT choke carburetorto stop
engine. Wheneverpossible,gradually
reduceenginespeedbeforestopping.
12. DO NOT run engineat exces-
sivespeeds. This mayresult in
injury
lawsapplyonfederallands.
21. DO NOT touch hot muffler, cylinder, or
finsbecause contact maycauseburns.
22. DONOT run enginewithoutair cleaner
oraircleanercover.
23. DONOToperateduringexcessive
vibration!
24. DONOTleavemachineunattended
whilein operation.
25. DO NOT park machineon asteep grade
orslope.
WARNING: DO
1. ALWAYS DO remove the wire from the
sparkplugwhenservicing the engineor
equipmentTOPREVENTACCIDENTAL
STARTING.
2. DOkeepcylinderfinsandgovernor
parts free of grass and other debris
whichcanaffectenginespeed.
3. DOpull starter cord slowly until resis-
tanceis felt. Thenpull cordrapidly to avoid
kickbackandpreventhand or arminjury.
4. DOexaminemufflerperiodicallytobe
sure it is functioning effectively. A worn or
leakingmufflershouldberepairedor
replacedas necessary.
5. DOuse fresh gasoline. Stale fuel can
gumcarburetorandcauseleakage.
6. DOcheckfuellines andfittings frequently
for cracks or leaks. Replace if necessary
7. Followenginemanufactureroperating
andmaintenance instructions.
8. Inspectmachine andwork areabefore
starting unit.
SAFETY INSTRUCTIONS
GENERAL SAFETY
ASSEMBLY
LIT. BAG & CONTROLS
LABELS
OPERATION
MAINTENANCE
PARTS DRAWING & LIST
TROUBLESHOOTING
WARRANTY PROCEDURE
Page 2 of 12
TABLE OF CONTENTS
10 - 12
12
12
6 - 8
4
4
3
3
2
OPERATOR
VIBRATION
SOUNDTESTS VIBRATION LEVEL 1.1g
Vibration levels at the operators handles were
measured in the vertical, lateral, and longitudinal
directions using calibrated vibration test equipment.
Tests were performed on 05/19/95 under the
conditions listed:
WINDSPEED:
WINDDIRECTION:
HUMIDITY:
TEMPERATURE:
BAROMETRICPRESSURE:
GENERALCONDITION:
SOUND
Sound tests conducted were in accordance
with 79/113/EEC and were performed on 05/19/
95 under the conditions listed:
GENERALCONDITION:
30.06" Hg (763mm Hg)
67%
South
5 MPH (8 kmh) WINDSPEED:
WINDDIRECTION:
HUMIDITY:
TEMPERATURE:
BAROMETRICPRESSURE:
Sunny
30.06" Hg (763mm Hg)
67 %
S.W.
5 MPH (8 kmh)
72 °F (22.2 °C)
Sunny
6
7 8
THIS SYMBOL MEANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY
DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY.
BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S MANUAL &
ENGINE MANUAL.”
& /or damage to unit.
13. DO NOT tamper with governor springs,
governorlinksorother parts whichmay
changethegovernedenginespeed.
14. DO NOT tamper withtheengine speed
selectedbytheenginemanufacturer.
15. DO NOT check for spark with spark plug
or spark plug wire removed. Use an
approvedtester.
16. DO NOT crank enginewithspark plug
removed. Ifengine isflooded,place throttle
in“FAST”positionandcrankuntilengine
starts.
17. DO NOT strike flywheel with a hard
object or metal tool as this may cause
flywheelto shatterinoperation. Use proper
toolstoserviceengine.
18. DONOT operate enginewithout a
muffler. Inspectperiodically andreplace, if
necessary. Ifengineisequipped with
mufflerdeflector,inspectperiodicallyand
replace, if necessary, with correct deflector.
19. DONOT operate enginewith an
accumulationofgrass,leaves, dirt orother
combustiblematerialinthemufflerarea.
20. DO NOT use thisengine onany forest
covered,brushcovered,orgrasscovered
unimprovedlandunlessa spark arresteris
installed on the muffler. The arrester must
bemaintainedineffective working orderby
the operator. In the State of California the
aboveisrequiredbylaw(Section4442of
theCaliforniaPublicResourcesCode).
Otherstates mayhavesimilar laws. Federal
5IN THE INTEREST OF SAFETY
WARNING: The Engine Exhaust from this product contains chemicals known
to the State of California to cause cancer, birth defects or other reproductive harm.
62 °F (16.7 °C)
5, 9

Part No. 500264 Form No. F101001APage 3 of 12
For your safety and the safety of others, these directions should be followed:
Do not operate this machine without first reading
owner's manual and engine manufacturer's manual.
Use of Eye and Breathing protection is recom-
mended when using this machine.
·DO NOT place hands or feet beneath cutting deck, near
debris outlet or near any moving parts.
·DO NOT start engine or operate unit with bystanders in or
neartheworkarea.
·DO NOT start or operate machine with blade or drive clutch
engaged.
PUT OIL IN ENGINE BEFORE STARTING.
Read all safety and operating instructions
before assembling or starting this unit.
·DO NOToperateduringexcessivevibration.
·DO NOTperformanymaintenanceorinspectionuntilenginehas
been turned off and has come to a complete stop, and the spark
plughasbeenremoved
·DO NOToperatemachinewithguardsremoved.
·DO NOT use thismachine forcutting areascontaining rock,
glass, string like material, wire, rags, cans, metal, or other non-
organicmaterial.
·DO NOT operatethismachineonslopesgreaterthanspecified
onpage 1.
·DO NOT operate machinenearany hotorburning debris, orany
toxicorexplosivematerial.
·DO NOTallowchildrentooperatethisequipment.
GENERAL SAFETY
ASSEMBLY
Your Billy Goat Brush Cutter is shipped from the
factory in one carton, completely assembled except
for the upper handle, and front guard bar.
Literature
Assy LiteratureAssy
500263
Per Model
PACKINGCHECKLIST
9
10
11
Briggs & Stratton
1. REMOVE unit from carton and allow upper handle (item 40) to lay on
ground behind unit. Set guard bar(Item 31) to the side for now.
2. REMOVE hardware items 115, 117, 141, 143, & 144 from temporary
storagepositionsonlowerhandle(items51,&52).
3. ATTACHupperhandletolowerasshownbelow,andsecurelytighten
allfasteners.Foreasyalignmentofhandlesduringinstallation,loosenthe
fourscrewsthat securethelower handles. Line upandhand tightenall
handlehardwarebefore finaltightening. Note:Besure the enginestarter
ropeisproperly installedinthestarter rope guide(item145)before
tighteningthecorrespondingfasteners.
4. REMOVE hardware items 102, 103, 117, 119, 124, 141, & 152 from
temporary storage positions on deck and skid assy at front of unit
(items 2, 155, & 156)
5. ATTACHguard bar(Item31) todeck asshown below.Install thecenter
bolts(Item 153) first, and install the bolts that fasten through the sides of
the deck last. Securely tighten all fasteners. Note: Hardware items 117,
119, & 141 are used to secure both the front skid attachment and the
sides of the guard bar. Be sure both are securely attached.
6. CONNECTspark plug wire to spark plug.
Engine
Manual Honda(English)
Use of Ear Protection is recommended while
operating this machine.
These items should be included in your carton. If
anyofthese parts aremissing,contact your dealer.
DISCONNECT SPARK PLUG WIRE
BEFORE ASSEMBLING UNIT.
BarSupport WA
500235
HandleUpper
Assembly
500256
HondaW/Electric
Start(English)

Part No. 500264 Form No. F101001A
Page 4 of 12
INSTRUCTION LABELS
CONTROLS
Throttle Control
Owner's
Manual Owner's
Manual
500264
Warranty
Card
Warranty
Card
400972
EU Declaration
of Conformity &
EU Distributor
List 500265
EU Declaration
of Conformity
& EU
Distributor List
Literature Checklist
Theselabels should beincluded on yourBrush Cutter. If anyof these
labelsare damaged,replace thembefore puttingthis equipmentinto
operation.Item andpart numbersare givento helpin orderingreplace-
mentlabels..
Label Do Not Fill While
Engine Is Hot
Item 63 Part No.400268
12 13
14
LITERATURE ASSY P/N 500263
ENGINE LABELS
15
Label Read Owner's
Manual Item No. 187
Part No. 890301
Label Danger Keep Hands and
Feet Away
Item 180 PartNo.400424
Label Danger Flying
Material Item 184
Part No.810736
Label Warning Guards
Item 185 Part No.900327
Label Ear Eye Breathing Item
No. 188 Part No. 890254
Label Chock Wheels Item No. 189 Part No. 500168
Label Clutch Drive
Item 191
Part No.500176
Briggs engines have a choke
type carburetor that is
operated by moving the
throttle control to the full start
position. See STARTING
section, see page 5.
Label Clutch Blade
Item 192
Part No.500177
Briggs & Stratton
Read Owner’s Manual Before Operating.
Lire le manuel d’utilisation avant la mise en route.
Vor Inbetriebnahme Bedienungs - und Wartungsanleitung lesen.
Favor leer las instrucciones de operacion antes de operar el motor.
Consultare il Manuale Uso e Manutenzione prima dell utilizzo.
Las Skotselinstruktionen Innan Start.
'
' '
..
..
Honda
Label Shift BC2400
Item No. 186
Part No. 500202
Ty Wrap 900407
Qty: (4)
Label Patent No
Item 190 Part No.500279
BRIGGS &
STRATTON HONDA
Honda engines have a separate choke lever that is
operated by pulling back along with moving the throttle
control to the full start position if necessary. See
STARTING section, see page 5.
Pull to choke

Part No. 500264 Form No. F101001A
ENGINE:Seeenginemanufacturer’sinstructions
fortypeandamountofoilandgasolineused.
Enginemustbelevelwhencheckingand fillingoiland
gasoline.
ENGINE SPEED:Controlledbythrottleleveronthehandle.
FUELVALVE:Movefuel valveto "ON"position (when
providedon engine).
CHOKE:
Briggs engines have a choke type carburetor that is
operated by moving the throttle control to the full start
position.
Honda engineshave aseparate chokelever thatis oper-
ated by pulling back when starting. Push it back to its
original position after the engine has started.
THROTTLE: Move remote throttle control to fast position.
Pull starting rope to start engine.
ELECTRIC START: Chokethe engine ifnecessary.Push
and hole down on the rocker switch until engine starts, then
release switch to run.
IF YOUR UNIT FAILS TO START:
SeeTroubleshootingonpage12.
Page 5 of 12
GENERAL OPERATION:Toengagetheblade,depress
theoperator'slefthandcontrolleveragainstoperator'shandle.
Thebladeisdisengagedbyreleasingthislever.(SeeFig.1.1)
Toengage the wheeldrive,lift the operator'srighthand
controlleveragainstoperator'shandle.Thedriveisdisen-
gagedby releasing thislever.(SeeFig. 1.2) Groundspeedcan
bevariedbyshifting gears asdescribedonpage9. To begin
cuttingengagethebladelever,allowthebladetospinupto
speed,andengagethewheeldrivetobeginmovingforward
into the material to be cut.
CUTTINGOPERATION
PUT OIL IN ENGINE BEFORE STARTING.
OPERATION
16
16.1 STARTING
16.2
INTENDED USE: This isnot alawn mower. TheBC2401 is
designedforcuttingovergrownweeds,brush,andother
types of organic growth to a height of 3-1/2". The unit may
also be used to clear small saplings 1-1/2" in dia. or less. It
doesnot providethe cut qualityof afinish cutlawnmower.
Theunitis designedforusein rural areas,andshouldnot
beused in settingswhereconditions requirethatthe unitbe
operated in tight or confined areas. Be sure to inspect work
areaandmachinebefore operating. Make surethatall
operatorsofthisequipmentaretrainedingeneralmachine
useand safety.
Donot operateifexcessive vibrationoccurs. If excessive
vibrationoccurs,shutengineoffimmediatelyandcheckfor
damagedorwornblade,loosebladebolt, loosebladeadapter
key,loose engineor lodged foreignobjects. Note: Seeparts list
forproperbladebolttorquespecifications.(Seetroubleshooting
sectiononpage12).
TheBrushCutterblade clutch iscontrolledbyanoperator
presencecontrol.Toengagetheblade,depresstheoperator's
lefthandcontrolleveragainstoperator'shandle.Thebladeis
disengagedbyreleasingthis lever.(See Fig.1.1)
NOTE: Thebladeclutchmustbeeitherfullyengagedforcutting
orfully disengagedto bringthe bladeto astop. Donot operate
theunit with thebladeclutch partiallyengaged. Prematurebelt
wearandclutchfailurewillresult from improperoperationofthe
clutch.
BLADE CLUTCH
CAUTION: Use extreme care when operating the
blade. Inspect the work area for foriegn objects
that could cause damage to the unit or injure the
operator if struck by the blade. Never operate the
blade with bystanders in the work area.
Lever
Down
Engages
Clutch
Lever Up
Disengages
Clutch
Lever
Handle
Fig. 1.1
Thebestperformance isachievedwhencutting indry
conditions. Ifthe deckbecomes chokedwith grassor debris
duringoperation,backunitoffofdebrisallowingmachineto
clear itself and continue cutting, or shut the unit off and clear the
clogby hand (Seebelow). A dropin engine RPM or anotice-
ablechangeinenginesoundisusuallyagoodindicatorofa
cloggeddischargeorotherinterference.
Undermost conditionscuttingshould bedone infirstor
secondgear. Thirdgearshouldbereservedforconditions
where weeds and brush are thinned out or not as tall. The
quality of the cut produced is directly related to the unit's ground
speed during cutting. If the quality of the cut is not satisfactory
(i.e.material left standing)youshould shiftintoa lowergear
duringcutting. Forimprovedcontrol in confinedareas,this
machinecanbepushedforwardorbackwardbyreleasingthe
operator'sclutchlever,placingthetransaxleinneutral,and
pushingthe machine.
CLEARING A CLOGGED CUTTING DECK:
Turn engine off and wait for blade to stop completely.
Disconnect spark plug wire. Wearing durable gloves,
remove clog.
Danger, the clog may contain sharp materials.
Reconnect spark plug wire.
Likeallmechanicaltools, reasonable caremust
beusedwhenoperatingmachine. Donotoperateunit
inareaswherebystanders may bepresent.
NOTE:Donotengagebladeduringtransportbetweenwork
sites. Thebladeshouldremaindisengagedatalltimeswhen
workisnotbeingperformed.

Part No. 500264 Form No. F101001A
Page 6 of 12
PARTS DRAWING
18
BC2401HE, BC2401H, BC2401IC

Part No. 500264 Form No. F101001A
Page 7 of 12
19 PARTS
LIST
ITEM BC2401HE BC2401H BC2401IC
NO. DESCRIPTION Part No QTY Part No QTY Part No QTY
1Deck Assembly with labels 500239 1500239 1500239 1
2Deck WA BC2401 500266 1500266 1500266 1
3Deflector Front BC2400 500125 1500125 1500125 1
4Base Assembly with labels 500240 1500240 1500240 1
5Handle Brace Left 500196 1500196 1500196 1
6Handle Brace Right 500200 1500200 1500200 1
7Door Base Engine 500233 1500233 1500233 1
8Transaxle 3 SPD BC2400 500100 1500100 1500100 1
9Pulley 5.0" OD ‘A’ Sec. 830180 1830180 1830180 1
10 Belt Traction Drive 500119 1500119 1500119 1
11 Plate Pivot Idler / Shifter 500122 1500122 1500122 1
12 ShifterPivotWA 500169 1500169 1500169 1
13 Pulley Idler 800260 1800260 1800260 1
14 Wheel & Tire 16" AG SP LH 500103 1500103 1500103 1
15 Wheel & Tire 16" AG SP RH 500104 1500104 1500104 1
16 Arm Idler WA 500170 1500170 1500170 1
17 Cable Clutch Blade BC2400 500259 1500259 1500259 1
18 Cable Clutch Drive BC2400 500327 1500327 1500327 1
19 Bar Shift T-axle 500121 1500121 1500121 1
20 Angle Support T-axle 500127 1500127 1500127 1
21 Rod Link Shifter 500144 1500144 1500144 1
22 Tube Shift With Grip 500171 1500171 1500171 1
23 Clutch Brake BC2401 500258 1500258 1500258 1
24 Grip 3/4 ID - Black 610102 1610102 1610102 1
25 Tube Pointer 500184 1500184 1500184 1
26 Plate Mount Idler WA 500228 1500228 1500228 1
27 Pulley Idler 4.5" OD X 3/8 500270 1500270 1500270 1
28 Hub Cap 900486 2900486 2900486 2
29 Belt Blade Drive 500237 1500237 1500237 1
30 Spacer Spindle BC2401 500232 1500232 1500232 1
31 Bar Guard WA BC2401 500235 1500235 1500235 1
32 Bushing Shifter 500130 1500130 1500130 1
33 Washer Hub Cap 850237 2850237 2850237 2
34 Spindle WA BC2400 500174 1500174 1500174 1
35 Bearing 7/8" ID Sealed Press 500101 2500101 2500101 2
36 Shaft Drive Blade 500107 1500107 1500107 1
37 Spacer Spindle Bearing 500115 1500115 1500115 1
38 Pulley 7" OD x 7/8" BORE 500253 1500253 1500253 1
39 Lever Control Blade 500312 1500312 1500312 1
40 Handle Upper BC2400 500243 1500243 1500243 1
41 Grip Handle 1 ID x 7.5 500267 2500267 2500267 2
42 Lever Control Clutch 500142 1500142 1500142 1
43 Bushing Lever Control 500152 4500152 4500152 4
44 Fitting Mount Cable 500187 2500187 2500187 2
45 Engine 11 HP Honda GXV340 Electric Start 500294 1- - - -
Engine 11 HP Honda GXV340 - - 620100 1- -
Engine 10.5 HP B & S I/C - - - - 500323 1
46 Pulley Drive Traction BC2401 500238 1500238 1500238 1
47 Spacer Engine WA 2401 500262 1500262 1500262 1
48 Control Throttle BC2400 500154 1500154 1500213 1
49 Tube Cable Cover 500186 2500186 2500186 2
50 Blade 24" BC2400 500210 1500210 1500210 1
51 Handle Lower RH BC2400 500140 1500140 1500140 1
52 Handle Lower LH BC2400 500141 1500141 1500141 1
53 Adapter Blade WA 500191 1500191 1500191 1
54 Washer Friction Blade 500108 1500108 1500108 1
55 Guard Hand BC2401 500257 2500257 2500257 2
56 Screwcap 8x3/8 HWH Type B 100121 2100121 2100121 2
100 Washer Lock 5/16 Twist. Tooth 8177011 28177011 28177011 2
101 Bolt Carraige 1/4 - 20 x 3/4 8024021 48024021 48024021 4
102 Nut Lock 1/4 - 20 *8160001 14 *8160001 10 *8160001 10
103 Screw Cap 5/16 - 18 x 1 1/4 *8041029 18 *8041029 18 *8041029 18
104 Washer Lock 5/16 split *8177011 7*8177011 7*8177011 7
105 Plate Impeller Washer 850443 1850443 1850443 1
106 Screw Cap 7/16-20 X 3" 500269 1500269 1500269 1
107 SCREWCAP 5/16-18 X 1" *8041028 5*8041028 4*8041028 4
108 Screw Cap 5/16 - 18 x 2 3/4 *8041035 6*8041035 6*8041035 6
109 Bolt Carraige 5/16 - 18 x 3/4 8024039 28024039 28024039 2
110 Washer Flat 1/2" 900230 1900230 1900230 1
111 Pin Cotter 3/32 x 3/4" *8197016 1*8197016 1*8197016 1

Part No. 500264 Form No. F101001A
Page 8 of 12
PartsList
continuedfrom
page 9.
19
*Denotes
standard
hardwareitem,
thatmay be
purchased
locally.
Item Description BC2401HE Qty. BC2401H Qty. BC2401IC Qty.
No. Part No. Part No. Part No.
112 Bolt Shoulder 1/2 x 1 500114 1500114 1500114 1
113 Nut Lock 3/8-16 *8160003 3*8160003 3*8160003 3
114 Bolt Idler 800888 1800888 1800888 1
115 Screw Cap 5/16 x 2" *8041032 5*8041032 5*8041032 5
116 Nut Jam 5/16 - 18 *8142002 3*8142002 3*8142002 3
117 Nut Lock 5/16 - 18 *8160002 29 *8160002 28 *8160002 30
118 Bolt Carraige 5/16 - 18 x 1 *8024040 6*8024040 6*8024040 6
119 Screw Cap 5/16 x 1 1/2 *8041030 4*8041030 4*8041030 4
120 Washer 3/8 FC *8171004 1*8171004 1*8171004 1
121 Terminal Piggyback 3/16 890010 1890010 1- -
122 Screw Cap 1/4 - 28 x 1/2 GR5 850408 1850408 1850408 1
123 Washer Lock 1/4 Split *8177010 1*8177010 1*8177010 1
124 Washer 1/4 FC *8171002 5*8171002 5*8171002 5
125 Screw Self Tap 5/16 *8123128 1*8123128 1*8123128 1
126 Pin Hair Cotter 900471 2900471 2900471 2
127 Washer 5/16 SAE *8172008 2*8172008 2*8172008 2
128 Screw Cap 1/4 - 20 x 2 1/2 *8041012 1*8041012 1*8041012 1
129 Washer 3/4 SAE *8172015 2*8172015 2*8172015 2
130 Washer 0.765 x 1.250 x 0.060 850238 2850238 2850238 2
131 Plate Control Box 500305 1500305 1- -
132 Ring Snap 0.750 850230 2850230 2850230 2
133 Key 3/16 x 2 1/8 9201087 29201087 29201087 2
134 Washer Fender 1/4" 8172019 4
135 Screw Cap 7/16 - 20 x 1 1/4 GR8 800554 1800554 1800554 1
136 Washer 1.25 x 0.882 x 0.125 500182 1500182 1500182 1
137 Ty Wrap 900407 4900407 4900407 4
138 Key Sq 3/16 x 5/8 9201072 29201072 29201072 2
139 Screw Cap 7/16 - 20 x 2 GR8 500188 1500188 1500188 1
140 Washer Lock 7/16 Tw. Tooth 850132 3850132 3850132 3
141 Washer 5/16 FC *8171003 27 *8171003 27 *8171003 23
142 Bracket Clutch Cable Guard 500321 1500321 1500321 1
143 Screw Cap 5/16 - 18 x 1 3/4 *8041031 7*8041031 7*8041031 9
144 Screw Cap 5/16 - 18 x 2 1/2 *8041034 1*8041034 1*8041034 1
145 Guide Rope 830533 2830533 2830533 2
146 Grip Lever 500181 2500181 2500181 2
147 Label Start/Stop Toggle 500329 1
148 Spacer Engine Honda SP VQ 830113 1830113 1830113 1
149 Guide Belt LH 500230 1500230 1500230 1
150 Guide Belt RH 500231 1500231 1500231 1
151 Screw Cap 5/16 - 24 x 1 *400164 2*400164 2*400164 2
152 Screw Cap 1/4 - 20 x 1 1/4 *8041007 7*8041007 3*8041007 3
153 Screw Cap 1/4 - 20 x 2 3/4 *8041013 1*8041013 1*8041013 1
154 Screwcap 1/4-20 x 2” *8041010 2*8041010 2*8041010 2
155 Skid RH BC v-cup WA 500291 1500291 1500291 1
156 Skid LH BC v-cup WA 500292 1500292 1500292 1
157 Switch Box Assy BC 500318 1500283 1500283 1
158 Switch Toggle 500307 1500281 1500281 1
159 Harness Assy 500306 1890442 1890442 1
160 Bushing Strain Relief 500282 1500282 1500282 1
161 Label Throttle 810656 1810656 1810656 1
162 Cable Battery Red W/Charge 500304 1
163 Cable Battery Black 10" 790133 1
164 Lid Box Battery 500301 1
165 Box Battery Drilled 500299 1
166 Plate Guard Bottom Battery 500303 1
167 Strap Battery 500302 1
168 Bracket Mount Battery Wa 500297 1
169 Bar Support Battery 500298 1
180 Label OPEI 400424 2400424 2400424 2
184 Label Flying Debris 810736 1810736 1810736 1
185 Label Guards 900327 2900327 2900327 2
186 Label Shift BC2400 500202 1500202 1500202 1
187 Label Read 890301 1890301 1890301 1
188 Label Ear Eye Breathe 890254 1890254 1890254 1
189 Label Chock Wheels 500168 1500168 1500168 1
190 Label Patent No 500279 1500279 1500279 1
191 Label Clutch Drive 500176 1500176 1500176 1
192 Label Clutch Blade 500177 1500177 1500177 1
193 Plate cChoke Mount BC 500325 1500325 1
194 Screw Machine 10-24x5/8" 8059135 18059135 1
195 Control Cable Choke BC 500326 1500326 1

Part No. 500264 Form No. F101001A
Page 9 of 12
OPERATION continued
16
Neverstoreengineindoorsorinenclosedpoorlyventilated
areas with fuel in tank, where fuel fumes may reach an open
flame, spark or pilot light, as on a furnace, water heater, clothes
dryerorothergasappliance.
If engine is to be unused for 30 days or more, prepare as
follows:
Besureengine iscool. Donotsmoke. Remove allgasoline
from carburetor and fuel tank to prevent gum deposits from
formingonthesepartsandcausingpossiblemalfunctionof
engine.Drainfueloutdoors,intoanapprovedcontainer,away
from open flame. Run engine until fuel tank is empty and
enginerunsoutofgasoline.
Using three people to lift machine is recommended. Lift holding the
handle and front of deck. Secure in place during transport.
NOTE: Fuelstabilizer (suchasSta-Bil) isanacceptable
alternativeinminimizingtheformationoffuelgumdeposits
duringstorage. Addstabilizer togasolineinfuel tank orstorage
container. Alwaysfollowmixratiofoundonstabilizercontainer.
Runengine atleast 10min. afteradding stabilizerto allowit to
reachthecarburetor.
CAUTION: Wheels must be chocked or blocked
when unit is parked on a slope.
STORAGE
HANDLING & TRANSPORTING:
16.5
16.6
GROUND SPEEDcanbevariedbyselectingahigherorlower
gear using the gear shift lever at the rear of the machine(See
Fig. 2), or by changing the engine rpm. To shift the Brush
Cutterinto reverse, releaseallcontrols androtatethe shiftlever
to the left, when the lever stops lift it up and continue to turn it to
the left until it stops again.
Undermost conditions cuttingshouldbe doneinfirst orsecond
gear. Thirdgearshouldbereservedforconditionswhere
weeds and brush are thinned out or not as tall. The quality of
thecut producedis directlyrelated tothe unit'sground speed
during cutting. If the quality of the cut is not satisfactory (i.e.
materialleftstanding)youshouldshift into alowergearduring
cutting. Forimprovedcontrolin confined areas,thismachine
canbepushedforwardorbackwardby releasingtheoperator's
clutchlever,placingthetransaxleinneutral,andpushingthe
machine.
ThisBrushCutteris self-propelled, andiscontrolledbyan
operatorpresencecontrol.Toengagethewheeldrive,liftthe
operator'srighthandcontrolleveragainstoperator'shandle.The
driveisdisengagedbyreleasingthislever.(SeeFig.1.2)
16.3 PROPULSION
Fig. 2
Fig. 1.2
Handle
Lever
Lever Up
Engages
Clutch
SHIFTLEVER
16.4 CUTTING HEIGHT ADJUSTMENT
Cuttingheightcanbeadjustedtoallowa1”lowercuttingheight.
Thisis particularly usefulforcutting grassesthatlay overwhen
over grown. (i.e. Bermuda, Johnson, etc.)
Note: Whencutting brushand normalfield grassesit is
stronglyrecommended thatyouoperate yourbrush cutteratthe
standard(top)cuttingheight.

Part No. 500264 Form No. F101001A
Whenreplacingonebelttheothershouldbeinspectedforwearand
replaced if worn. It is good practice to change both belts when either
iswornbeyonduse. Useonlyoriginalequipmentbeltsforreplace-
ment. BillyGoatuses onlypremiumquality,kevlar corded andcoated
belts in your unit. Substitute belts do not meet the design and
performance requirements for your unit , and will greatly reduce
machine performance and belt life.
Page 10 of 12
Use only a qualified mechanic for
any adjustments, disassembly or
any kind of repair .
WARNING: TO AVOID PERSONAL INJURY,ALWAYS
TURN MACHINE OFF,MAKE SURE ALL MOVING
PARTS COMETO A COMPLETE STOP.
17 MAINTENANCE
RECONNECT SPARK PLUG WIRE,
AND ALL GUARDS BEFORE START-
ING ENGINE.
DISCONNECT SPARK PLUG WIRE
BEFORE SERVICING UNIT.
Note: Blade, and drive belts are normal wear items.
These should be inspected on a regular basis and
replaced if worn.
BELT REPLACEMENT
17.2
BLADE REMOVAL / SHARPENING
17.1
ENGINE
Whenservicingenginerefertospecificmanufacturersengine
owner'smanual. Allenginewarrantyiscovered by thespecific
enginemanufacturer. Ifyourengine requires warrantyorother
repairworkcontactyourlocalservicingenginedealer. When
contactinga dealerfor serviceit isa goodidea tohave your
enginemodelnumberavailableforreference(Seetablepage11).
Ifyou cannot locatea servicingdealer inyour areayou can
contactthemanufacturersnationalserviceorganization.
To reach:
Briggs & Stratton: 800-233-3723
American Honda: 800-426-7701
Blade Drive Belt
NOTE:When sharpeningthe bladeit isa goodidea tocheck the
balanceoftheblade. Aproperlybalanced blade willincrease
lifeofthebearings and othercomponents.
Toolsrequired:5/8inchsocket,torquewrench,adequate
support.
1.Disconnectsparkplugwire.
2. Support front of unit to allow access to the blade. Note: Unit
isheavy. Be suresupport is adequateto preventpersonal injury.
3.Block theblade toprevent itfrom rotatingduring removal.
4.Removetheblade bolt (Item139),lockwasher(140),and
largefrictionwasher(54).
5.Removetheblade(50)and, replace orsharpentheblade.
NOTE: When replacing the blade use only B.G.I. Part no.
500210.
6.Replace the blade using all fasteners in the exact order
they were removed. Torque blade screw to 60 ft-lbs. NOTE:
Before installing the fasteners inspect them for wear and
replace as necessary.
Toolsrequired:1/2 inchsocket,1/2inch universal extensionbar,prybar
orlongscrewdriver,adequatesupportformachine.
1.Disconnectsparkplugwire.
2. Support rear of unit to allow access to underside of the machine
towards the rear. Note: Unit is heavy. Be sure support is adequate to
preventpersonal injury.
3.Removethetwoscrews(103)andwashers(141)holdingtheengine
basedoor (7),and removethe door.
4.Loosen butdo notremovethe twonuts (116)holding the platemount
idler(item26)inplace.This willreleasethetensiononthebladedrive
belt (29). NOTE: It may be necessary to apply some force to the pulley
to slide it over from it’s tight position and release the belt.
5.Working from theunderside of themachine, loosen butdo not remove
thefour screws (103)holding the twobelt guides(Items 149& 150) in
placenext to thecrankshaft drivepulley (9) at the rearof themachine.
Thiswill loosen thebelt guides(Items 149& 150) andallow them to
move to the side. NOTE: This step requires the use of a universal joint
oruniversalextensionbartoreach the screws(103)holdingthebelt
guide(149). Ifuniversaljointisnotavailableyoumayremovethe
“neutralstop bolt”(Item115) and associatednuts (116& 117)toallow
theidlerarmto swing backandallowaccessto the screws(103)holding
thebelt guide(149).
Transaxle Drive Belt
Toolsrequired: 1/2 inchsocket,1/2 inchuniversalextension bar,pry
barorlong screwdriver,adequatesupport formachine.
1.Disconnectsparkplugwire.
2. Support rear of unit to allow access to underside of the machine
towards the rear. Note: Unit is heavy. Be sure support is adequate to
preventpersonal injury.
3.Loosen butdo notremovethe twonuts (116)holding the platemount
idler(item26)inplace.This willreleasethetensiononthebladedrive
belt (29). NOTE: It may be necessary to apply some force to the pulley
to slide it over from it’s tight position and release the belt.
4.Working fromthe underside ofthe machine,loosen butdonot
removethefour screws(103)holdingthe two beltguides(Items149&
150) in place next to the crankshaft drive pulley (9) at the rear of the
machine. Thiswillloosenthebeltguides(Items149&150)andallow
them to move to the side. NOTE: This step requires the use of a
universaljointoruniversalextensionbartoreachthescrews(103)
holdingthebeltguide(149). Ifuniversaljointisnotavailableyoumay
removethe “neutral stopbolt”(Item115) andassociatednuts (116&
117)to allowthe idlerarmto swingback andallow access tothe
screws(103)holdingthebeltguide(149).
5. With the guides loose slip the transaxle drive belt(Item 10) out of the
grooveonthedrivepulleyanddown pastthepulley.
6. Slip the old belt(10) up and over the pulley on the transaxle (Item 9)
andremovebeltfrommachine.
7.Installnewbelt in grooveontransaxlepulley(Item9) and slipinto
grooveontransaxledrivepulley(46).
8.Tightenfourscrews(103)tosecurebeltguides(149&150)inplace.
Note:Withclutch leversengaged,besure belt guidesdonottouch
beltsafterinstallation.
9.Reconnectsparkplugwire.

Part No. 500264 Form No. F101001APage 11 of 12
MAINTENANCE continued17
Transaxle
Drive Belt
Blade Drive Belt
Fig. 3
Belt in top groove
of engine pulley Belt in bottom groove
of engine pulley
Engine (See Engine Manual)
Check for excessive vibration
Inspect for loose parts
MaintenanceOperation
Follow these hourly
maintenance intervals.
Maintenance Schedule
Inspect for worn or damaged parts
Every
Use Every 50
hrs
Every 5 hrs
or (Daily) Every 25 hrs
SharpenBlade
Inspect belts for wear
Replace blade and traction belts
Checkblade clutchcable tension
MAINTENANCEHISTORY
ServicePerformedDate of Service
1.Disconnectsparkplugwire.
2.Removethe twoscrewsholdingthe engine basedoor(item7),
andremovethedoor.
3.Examine the conditionof thebelt and note the positionof theidler
assemblyandtheamount of tensiononthebladebelt.
3.Loosen the twonuts (Item117) on top of theengine base,holding
the idler arm assembly (Item 26) in place .
4.Reset tension onbelt by reachingin through topof engine base
withalongscrewdriverorotherprybarandpushingtheidlerpulley
overagainstthe belttoincreasetension. While holding thebelt
undertension tightenthe twoscrews thathold theidler armin place.
5.Replaceenginebasedoorandverifybladebelttensionsettingby
operatingthe unitin theconditions thatcaused itto slip
originally.NOTE: If belt continues to slip it may be worn out and
requirereplacementbeforeproperoperationcanresume.
BLADEDRIVEBELT TENSIONADJUSTMENT
6.With theguides looseslip theblade drivebelt(29) out ofthe groove
on the drive pulley and down past the pulley. Note: It is necessary to
removethetransaxledrivebelt(10)fromitsgroovetoallowremovalof
thebladedrivebelt.
7. Pull the belt back through the hole in the top of the engine base
and remove it from the machine. NOTE: Removal of the belt from the
bladedrive pulley requiressome force towalk the beltpast the front
portionofthepulley.
8.Installnewbeltintogrooveonbladedrivepulley. Pushremaining
lengthofbeltbackthroughenginebasetowardclutch/brakedrive
pulley.
9.Reach through fromrear of machineand pull newbelt through and
installitin thegrooveonthe clutch/brake drivepulley.NOTE:Make
surethebladebeltisproperly seated intheclutch/brakedrive
pulley(Item23)andnotrestingin the gapbetweentheclutch/brake
pulley(23)andthetransaxledrivepulley(46)
10.Tighten fourscrews tosecure beltguides (item149 &150) in
place.NOTE: Besure beltis correctlyrouted whenreplacing. (See
Fig.3)
11.Set tensionon beltbyreaching inthrough topof engine basewith
alongscrewdriverorotherprybarandpushingtheidlerpulleyover
againstthebelt toincreasetension. Whileholding the beltunder
tensiontighten the twoscrews (107) thathold the idlerarm in place.
Note:Proper belttension can beverified bychecking thetightside
(non-idlerside)beltdeflection. Thebeltshoulddeflect3/16”-1/4”with
forceappliedperpendiculartothebeltaftertensioning.
12.Replace enginebase door(item7) andtighten screwsto hold itin
place
13.Reconnectsparkplug.
Inspect battery for damage or leak
Check battery terminal for corrosion
STARTERSWITCHWIRING Lubricate throttle control cable and
linkage.

Part No. 500264 Form No. F101001APage 12 of 12
Purchased
from
Purchase
Date
Engine Service and Warranty
Contactyournearestenginemanufacturer'sauthorized
servicingdealer.
22.1
21 Serial Plate Record your machine model, serial number and
date-of-purchase and where purchased
22
min-1
Operator
BILLY GOAT INDUSTRIES INC.
1803 S.W. JEFFERSON STREET LEE'S SUMMIT, MO 64082 / USA
PHONE: [phone] FAX: [phone] www.billygoat.com
WARRANTYPROCEDURE
Please fill in the WARRANTY CARD and send the upper part to Billy Goat.
The WARRANTY terms are stated on the lower part which remains with the
user. Whenever a Billy Goat Machine is faulty due to a defect in material
and / or workmanship, the owner should make a warranty claim as follows:
The Machine should be taken to the dealer from whom it was
purchased or to an authorized Billy Goat dealer.
The owner should present the remaining half of the Warranty
Registration Card, or, if this is not available, the invoice or receipt.
The Warranty Claim will be filled in by the authorized Billy Goat Dealer,
who will send it with the faulty part to Billy Goat headquarters.
The Quality / Service department at Billy Goat headquarters will study
the claim and parts and will notify their conclusions.
The decision by the Quality / Service department at Billy Goat
headquarters to approve or reject a Warranty claim is final and
binding.
Note: To process a Warranty Claim, it is necessary to quote the Model
& Serial number who are printed on the Billy Goat Serial Plate.
MAINTENANCE continued
17
Solution
Problem PossibleCause
Will not cut or has poor
cutting performance. Unclog deck (see page 5). Sharpen blade.
Check engine RPM.(see page 11 for settings)
Dull Blade. Clogged deck. Excessive quantity of debris built up or
blocking blade. Engine RPM set too low.
Belt slips or smokes.
Operator's clutch lever not releasing clutch. Broken or out of
adjustment clutch cable. Worn or broken belt.
Belt tension too low . Belt worn or stretched. Pulleys worn or
damaged.
Abnormal vibration. Loose or out of balance blade or loose engine. Check blade and replace if required. Check Engine.
Increase tension at idler(see page 11). Replace belt. Replace
pulleys
Adjust clutch cable. Replace any worn, damaged or malfunctioning
parts.
TROUBLESHOOTING BeforeRequestingServiceReviewThese Suggestions 20
CLUTCH ADJUSTMENT
17.3
Clutch/BrakeAdjustment:
As theclutch/brakewears, adjustmentsmay berequiredto
maintainpropercontrolcabletension,andclutchengagement.
Iftheclutch/brakebeginsslippingorsquealingduringnormal
operationitmayrequire an adjustmenttoincreasetheclutch
cabletension.Aproperlyadjustedbladeclutchshouldrequirea
minimum of 10 lbs. of force to completely depress the end of the
clutchlever.(See Fig. 4) Adjustbytightening orbyloosening
clutchcable adjustingnut as required,located atthe rearofthe
enginebase. Whenadjustingcabletensiononbladecontrol
cablebesuretoleaveslackincabletoallowforengagementof
bladebrake. Replacementofcableorclutch/brakemay be
necessaryifadjustmentwill not allowforproperclutchand
brakeengagement.
Model Serial No.
Unit(Weight) Engine Power
lbs. kg kW rpm
WARNING: If the clutch begins to squeal or slip, do not
continuetooperateyourunituntiladequateadjustmentorrepair
hasbeen performed.
Improperadjustmentcancauseclutchtoslipandoverheat,
greatlyreducingmachineperformance and clutchlife.
MOVE ADJUSTER OUT TO
INCREASE CABLE TENSION
MOVE ADJUSTER IN TO
DECREASE CABLE TENSION
MINIMUM FORCE = 3 LBS.
WHEN FULLY DEPRESSED
Fig. 4
Remove debris (see page 5 ). Contact an engine servicing dealer
for engine problems.(see page 10)
Adjust clutch cable. See page 12 Clutch Adjustment.
Self propelled drive will not
release . Clutch cable out of adjustment.
Engine is locked, will not
pull over. Debris locked against blade. Engine problem.
No self propelling.
Clutch slips or squeals. Clutch cable tension too low . Clutch worn or damaged. Increase clutch cable tension (see above). Replace clutch/brake
Blade brake will not engage. Inadequate slack in clutch cable . Clutch worn or damaged. Adjust or replace cable (see above). Replace clutch/brake
The engine will not stop
The engine will not start
Damaged stop switch. Stop switch wire is disconnected. Stop switch
wire is worn or damaged.
Stop switch is off. Throttle is not in ON position. Out of gasoline. Bad
or old gasoline. Spark plug wire disconnected. Dirty air cleaner.
Replace stop switch. Connect stop switch wire. Replace stop switch
wire.
Check switch, throttle, & gasoline. Check for spark with an approved
tester. Clean or replace air cleaner. Contact service dealer.
Starter does not turn
(Electric start unit only) Battery is too low or dead. Battery cable is disconnected or battery
terminal is corroded. Bad starter switch or wire harness. Bad starter.
Charge battery or replace with a new one. Clean battery terminals.
Replace starter switch. Replace Wire harness. Contact service dealer.

Gardening Suppl
y
Patio Barbecues Outdoor Barbecues Landmann Barbecues Gas Barbecues UK
Charcoal Barbecues Gas Barbecues Cheap Gas Barbecues Masonry Barbecues
Brush Cutters Brushcutters Blower Vacs Chain Saws
Chainsaws Cultivators Cylinder Lawn Mowers Echo Chainsaws
Echo Strimmers Electric Chainsaws Fertiliser Spreaders Garden Blowers
Garden Rollers Lawn Rollers Garden Shredders Garden Tractors
Garden Vacuums Hayter Lawn Mowers Hedge Cutters Hedgecutters
Hover Mowers Husqvarna chainsaws Kawasaki Brush Cutters Kawasaki
Strimmers
Lawn Mowers Scarifiers Lawn Tractors Leaf Blowers
Leaf Vacuums Petrol Chainsaws Petrol Hedge Cutters Ride on lawn
mowers
Ride on mowers Rotary Mowers Rotavators Ryobi Strimmers
Electric Garden
Shredders Petrol Garden shredders ALKO Garden Shredders Cheap Garden Shredders
Garden Patio Heaters Outdoor Patio Heaters Gas Patio Heaters Patio Heaters
Patio Heater Covers Garden Heaters Greenhouse Heaters
G
reen
h
ouse
heaters
Gas Greenhouse
heaters Stainless Steel Patio Heaters Table Top Patio Heaters Patio Heaters UK
Grit Spreaders Gardena Hedgecutters Kawasaki brushcutters Petrol Strimmers
Patio Heaters with
Covers Christmas Gardening Gifts Midgeater Plus Barbecues
Cylinder Mowers
