Billy Goat BC2600 User manual

Part No 501505 1 Form No F021513A
BILLY GOAT ®BC2600 Hydro Series Brush Cutter
Owner’s Manual

Part No 501505 2 F021513A
BC2600 Hydro Series Brush Cutter Owner’s Manual
CONTENTS
Specifications and Sound/Vibration .................................................................................................................. 3
Instruction Labels .............................................................................................................................................. 4
Assembly Instructions ....................................................................................................................................... 5-6
Operation ........................................................................................................................................................... 7-9
Maintenance ......................................................................................................................................................10-16
Battery maintenance ………………………………………………………………………………………………………17
Troubleshooting ................................................................................................................................................. 18
Illustrated Parts List ...........................................................................................................................................19-26
Go to http://www.billygoat.com for French-Canadian translations of the product manuals.
Visitez http://www.billygoat.com pour la version canadienne-française des manuels de produits

Part No 501505 3 F021513A
BC2600 Hydro Series Brush Cutter Owner’s Manual
BC 2600 SERIES SPECIFICATIONS
BC2600ICH
BC2600HH
BC2600HEBH
Engine Type
Briggs and
Stratton
Honda GX390
Honda Electric
Model Number
219972 0151 F!
GX390UT2 DABG
V390UTDE33
Displacement
344 cc
390 cc
390 cc
Fuel Capacity
3.0 qt (2.80 L)
3.0 qt (2.80 L)
2.3 qt (2.18L)
Oil Capacity
1.5 qt (1.4L)
1.5 qt (1.4L)
1.2 qt (1.13L)
Unit Weight
325 lb (147.4 kg)
325 lb (147.4 kg)
335 lb (152 kg)
Overall Length
72 in (1.83 m)
Overall Width
31 in (0.78 m)
Overall Height
48 in (1.21 m)
Maximum Operating
Slope
15o
20o
20o
SOUND DATA
SOUND LEVEL 91.6 Dba at Operator’s position
Sound tests were conducted in accordance with 2000/14/EEC and were performed on 11/30/11 under the conditions listed below.
Sound power level listed is the highest value for any model covered in this manual. Please refer to serial plate on the unit
for the sound power level for your model.
General Conditions: Sunny
Temperature: 47oF (8.3oC)
Wind Speed: 9 mph (14.5 kph)
Wind Direction: South
Humidity: 25%
Barometric Pressure: 30.07” Hg (101.83 kPa)
VIBRATION DATA
VIBRATION LEVEL .3g (3.13 m/s2)
Vibration levels at the operator’s handles were measured in the vertical, lateral and longitudinal directions using calibrated vibration test
equipment. Tests were performed on 11/30/11 under the conditions listed below.
General Conditions: Sunny
Temperature: 47oF (8.3oC)
Wind Speed: 9 mph (14.5 kph)
Wind Direction: South
Humidity: 25%
Barometric Pressure: 30.07” Hg (101.83 kPa)
112 dB

Part No 501505 4 F021513A
BC2600 Hydro Series Brush Cutter Owner’s Manual
INSTRUCTION LABELS
The labels shown below were installed on your BILLY GOAT ®Hydro Brush Cutter. If any labels are damaged or
missing, replace them before operating this equipment. Item numbers from the Illustrated Parts List and part
numbers are provided for convenience in ordering replacement labels. The correct position for each label may
be determined by referring to the Figure and Item numbers shown.
PN 100261
(Item 61)
PN 890254
(Item 134)
PN 810736
(Item 136)
PN 890301
(Item 133)
PN 900327
(Item 20)
PN 500177
(Item 135)
PN 501502
(Item 85)
PN 400424
(Item 5)
PN 501504
(Item 139)
PN 500168
(Item 140)
PN 100256
(Item 62)
Honda
Briggs and Stratton
ENGINE LABELS

Part No 501505 5 F021513A
BC2600 Hydro Series Brush Cutter Owner’s Manual
Brush Cutter Assembly Drawing
