Billyoh INS-0054 Instruction Manual

V2.4-210120
2) Reacquaint
yourself with the
parts, QTy’s and
Sizes on the
PACKING LIST.
PACKING
LIST
1) Take 5
minutes
and have
a coffee.
3) Read the
instructions
thoroughly and
then re-read if
necessary.
BEFORE
YOU
START
6FT GABLE:
COVERS SIZES:
4x6, 8x6,
10x6, 12x6,
16x6
CODE:
INS-0054
T&G AND OVERLAP
WINDOWED / WINDOWLESS
6ft Keeper And Master Apex Shed Building Instructions
Please read the instructions carefully
and please retain for future reference
Please note that all images are for illustration purposes only.
For Queries and Help please contact Product Support: 01909 768 858
Covers All 6ft Gable Sizes

GENERAL RECOMMENDATIONS
Thank you for purchasing this building. We hope you will be delighted with your new building for many years to come.
These instructions have been written as a guide to assembling thisbuilding and will provide you with an overview of
the process of constructing this building. There are a number of considerations tobe thought of before constructing
the building and how to maintain your building upon completion. Thissection is alsoaimed at ensuring you are aware
of considerations such as: location for construction, treatment of the building and construction information.
GLAZING: The glazing isgenerally bound with a holding band and may look like one thick piece when delivered. It
REMOVE PROTECTIVE FILM FROM ALL GLAZING
BEFORE USE. The glazing is safer to use than glass and is an economicsolution for gardenbuilding use, but must be
that does not require beading. The glazing on all the garden buildings does not make the windows water tight and
we suggest using a silicon sealant to improve water resistance around the edges of the glazing.
DOORS: Generally the doors are sent loose for all buildings. Some buildings such as summerhouses may have the
transit the door frame can become misaligned. This is easily solved by hanging the door on a level surface BEFORE the
panels are attached. SUMMERHOUSES: Some summerhouse doors are held together at the base of the frame with a
screw or nail for transportation purposes. Remove thisscrew ornail before commencing construction.
PANELS: The panels that of your building may move during transit resulting in them becoming un-square. Simply tap
the panelat it’s corners and make sure that the measurements from top tobottom diagonally across the panel is equal.
This should make the panel square
BUILDING LOCATION &CONSTRUCTION:
It is very important that a solid and level foundation is prepared to ensure the building will be level and square. This will
may experience moments, such as when building the wall panels, where you feelthe building is not safe and may be
occur on completion of the construction process. We recommend that you construct your building within 1 month of
delivery as the timber may begin to warp.
TREATMENT: Treating the product when assembled isessential toensure the building will not deteriorate. We
IMPORTANT NOTICE: The natural moisture content of wood will change according to season. We recommend
WOOD CHARACTERISTICS:Wood is a natural material, which means that no two boardson your building will be
inevitable andis compensated for by the tongue and groove construction in tongue and groove buildings. The timber
in overlap buildings may warp and twist overtime, which is a natural process. The timber may crack naturally over
awayfrom trees, fences and other high moisture containing elements to reduce and help prevent warping. If boards
warp and twist it is possible topurchase replacement boards to do so call our Product Support on01636 858377.
Keep your building ventilatedtoavoid mould.
This building is water resistant, butnot water tight. Please wait for weather tochange before notifying us ifyou notice changes inthe structure.
TOOLS REQUIRED: - Drill with 4.5, 3 and 2mm drill bit/ Hammer / Spirit Level / Measuring Tape / Screwdriver (Phillips) /
Stanley Knife / Wood Saw / Step Ladder.
PLEASE NOTE: You are advised to pilot drill all screw holes and ensure all screwheads are countersunk.
CUSTOMER SERVICE: If there are any queries regarding the building construction or aftercare please contact the
supplier of the building who will do their upmost to ensure customer satisfaction.
ADDITIONAL SAFETYRULES AND GUIDELINES:
- No one should use the equipment until properly assembled.
- Readthe instructions thoroughly a couple of timesbefore attempting each section of the build.
- Take your time, do not panic.
- Construct your building within one month of delivery tostop parts warping / bowing.
ADDRESS: Kybotech, Claylands Avenue, Worksop S81 7BQ
CUSTOMER SERVICES: 01909 768 858
IMPORTANT SAFETY NOTICES
ALWAYS BE ON THE SAFE SIDE – IMPORTANT SAFETY TIPS
- This building should be constructed by at least two adults.
- Do not use this product if it has been modified or damaged.
- Allow adequate time to complete construction. If you hit any snags, take a break, keep calm, and seek additional help if
necessary.
- Make sure that there is adequate space around the construction site to enable access to all sides of the building during
construction.
- Do not attempt to construct the building in strong winds or poor weather conditions.
- Make sure that any ladders used during construction are in a good condition and that all tools are in good working order.
- The building is not completely stable until construction is complete and the roof of this building is not intended to
support significant weight. Do not climb on the roof.
- Keep bags, nails and fixings out of the reach of children.
Due to the nature of wooden panel products please watch out for the following minor blemishes:
- Protruding nails = hammer in the nails so that they are flush with the wood’s surface.
- Splintered wood = smooth down with sandpaper.
- Loose or dead knots = use a non-toxic wood glue to secure.
- Wear protective gloves and robust clothes during construction.
- Make sure that any paint or preservative that you use is non-toxic and complies with EN71 regulations.
- Perform periodical checks throughout the life of the building to ensure that the original condition is maintained.
- Construct your building within a month of delivery to reduce the chances of the panels / boards warping.
PRODUCT WARRANTY
- If there is any cause for concern or any otherproblems are foundonorafter delivery, such as damaged parts DO NOT
BUILD, please visit our Support Centre -
www.gardenbuildingsdirect.co.uk/help forfurther advice and resolution and
stop alluse before assemblyuntil issues are resolved.
- IMPORTANT:Throughout the life of the building please conduct checks to ensure the original condition is maintained.
MAINTENANCE
- Products are built to the highest quality standards and should provide convenient, secure storage for years to come,
this of course being subject to reasonable use, care and transportation.
AFTER MARKETMODIFICATION
- We do not recommend modifying this product. However, customers do enjoy modifying their buildings with their own
specific needs in mind as our products allow for a wide range of uses.
- If you modify this product for your own personal requirements you are doing so at your own risk.
- Customers who modify their buildings should make sure to do so safely and so that they do not affect the integrity of
the structure.
- If you are thinking of modifying this building be aware that any modifications invalidate your warranty and may affect
your consumer rights.
- If in doubt about the product’s limitations please read and understand all of the instructions and guidance notes. If
necessary please contact the retailer that the item was purchased from.
- Please contact the retailer from which the product was purchased for warranty and guarantee information.
- PLEASE NOTE: The warranty does not extend to damage caused by post-purchase transportation, careless handling or
- Treat your building annually with a quality timber treatment to comply with the buildings warranty.
GARDEN BUILDINGS: THESE PRODUCTS ARE INTENDED FOR DOMESTIC AND OUTDOOR USE ONLY.
- If you ever need to purchase spare parts for your building you cando so bycontacting customer services by calling our
Product Support -
01636 858 377 where our friendly team willhelp you buywhat you need.
SPAREPARTS

Flag Stones
Sharp Sand
50mm deep
CONCRETE BASE
75 mm of Concrete
laid on top of
75mm of
hardcore.
FLAG STONES
Slabs laid on 50mm
of sharp sand.
m m 051
Concrete
75mm deep
Hardcore
75mm deep
When thinking about where the
building and base are going tobe
constructed ensure that there will
be access to all sides for maintenance
work and annual treatment. This
building should be situatedat least
2 feet away from any structures or
obstructions (such as fences, buildings,
trees etc). We recommend that areas
around playhouses have a soft
surface such asplay bark or grass.
All garden buildings must be built on
BUILDING A BASE
Tongue
&
Groove
Overlap
Outside
of
building
Outside
of
building
CLADDING STYLE
Overlap: This style of cladding is
very traditional and uses rough
sawn timber.
This gives the panels their
building to blend in to it’s
natural surrondings. When the
wood has dried through hotter
weather knots may become
loose, which is natural. Overlap
is an economic solution for
lower impact use.
Shiplap Cladding:This style of
cladding allows the timber to
interlock giving greater strength
to the building. It also creates
lines throughout the panel. Due
to the natural movement of
wood the lines between tongue
and groove panels may not
marry up.
PANEL ORIENTATION
It is essential to ensure that the panels of your
building are in the correct orientation. Assembly
in the wrong orientation may lead to water
ingress and deterioration.
BOARDSOVER HANG THE EDGEOF THE FLOOR
In most cases the lower edge of the panels
the inside of the panel.
PRODUCT MAINTENANCE CHECK LIST:
Wooden Sheds / Playhouses /Summerhouses
Level Base:
maintaining the building.
Seal The Windows:
Use a silicone sealant on the inside and outside of the windows as soon
as possible after assembly is a strong way of sealing the windows.
Annually Treat The Building:
Treat your building after construction with agood quality water
resistant treatment. Repeat this process annually inside and out.
The Building Must Not Be In Contact With Anything:
Overhanging hedges or trees must be cut back regularly as a branch
Regularly Check /ReplaceDamaged Felt:
Check the felt regularly. Any damaged felt must be replaced.
Lubrication:
Use a suitable oil to lubricated all moving parts, such as hinges, for
continued propperuse.
TROUBLESHOOTING GUIDE
Pre-Assembly
Q: What type of base should I use? A:
this instruction
document).
A: Firstly check that all of your building’s parts are there by laying them
all out on the ground. Check between the panels / larger parts as the glazing comes banded together and is placed between the panels, along
sdirect.co.uk/help
Q: What tools do I require? A: Drill with 4.5, 3 and 2mm drill bit / Hammer / Spirit Level / Measuring Tape / Screwdriver (Phillips) / Stanley
Knife / Wood Saw / Step Ladder.
Q: Are my window & plain panels interchangeable?A: On apex buildings the window & plain panels are interchangeable where they
are the same size or make up the same size panel as the opposing wall with more than one part.
Q: Can I have my personnel door on the other side of my building? A: Yes.
During Assembly:
? A:
out which method your particular building uses.
Q: Which way do the joists run? A:
joists run.
? A: Your building won’t reach full rigidity until fully assembled so do not panic.
Q: Construction seems tricky? A: Take your time and read the instructions thoroughly. These buildings should be constructed by two people.
If in doubt seek professional help.
Q: The felt seems a little tight? A: To reduce waste, to help protect the environment and reduce costs for our customers we only supply the
Q: My building isn’t going together properly, it is twisted. A: It sounds like you are building on an uneven surface. You must build
Post-Assembly:
Q: Why is there a gap around the doors? A: During the year the wood of your building will shrink and expand, which will create a gap
around you building’s doors. This is natural.
Q: My building is not water tight around the windows. A:
most popular light domestic uses and we do not state that they are water tight. Use silicon sealant around the windows to improve the water
resistant qualities of the building.
Q: My building has developed a leak A: Use silicon sealant to stop the leak and make sure that your building is not in a damp area and if
necessary move it and replace the damaged boards.
For Queries and Help please call Product Support:
01909 768 858
Use the dimensionsthat are onthe
techincal details documentation for your
dimensions when laying your solid base.
Do not forget about the roof overhang when
chosing your building location. Keep in mind
maintain the building.
FLOORLESS BUILDINGS
For buildings that are bought without
download the NO FLOOR GUIDE which
will guide you in building a base for your
www.billyoh.com/global/guides/NO-FLOOR-GUIDE.pdf
BASE DIMENSIONS
BUILDING DIMENSION TERMINOLOGY
WINDOW CLOAKING
STRIPS over two
glazing panes
make sure not to
pierce the glazing
beneath.
To reduce wood splitting
BLUNT ALL NAIL and PANEL
PIN POINTS by hitting them
with a hammer before
In hard to reach areas when
CLOAKING STRIPS
try using a hammer and 6”inch
WINDOW
BEADING get your nails or
away from the glazing
positioning.
TIPS ON GLAZING YOUR BUILDING:
1
2
3
4
5
Use a piece of
CARDBOARD to protect
the glazing when
WINDOW
CLOAKING STRIPS,WINDOW
BEADING or WINDOW
CROSSES.
(Note that you dont need to treat the item if you received a pressure
treated building).
EXTERNAL RIDGE HEIGHT
EXTERNAL EAVES HEIGHT
EXTERNAL DEPTH
EXTERNAL
WIDTH

For Queries and Help please call Product Support: 01909 768 858
S50 x 4
Floor Stages (SS & TG)
Side
Back
/D\ȵRRUVHFWLRQVDFFRUGLQJWREXLOGLQJVL]HZLWK
MRLVWVIDFLQJXSZDUGVΖPDJHDERYHVKRZV[
EXLOGLQJȵRRUVDVVDPSOH
Building Size Floor Sections Roof Sections
4 x 6
8 x 6
10 x 6
12 x 6
16 x 6
1 2
2 4
3 6
3 6
4 8
Please note on the number of Floor and Roof
sections according to your building size.
Floor / Roof Details
Use a suitable drill bit for pilot hole
- 3mm is recommended for most.
3mm or 4mm
Avoid splitting wood by pre-
drilling pilot holes for all screws
This is needed for all screw codes:
S12, S30, S40, S50, S70 and S100
IMPORTANT: Pre pilot drill
all screw holes
Pilot Drilling
Recommend
x2 for speed
1 2 3 4
85
9
6 7
Approximate building time is
4 to 8 Hours assembly
based on experience and size.
1. Cordless drill
2. Phillips bit
and drill bits
3. Hammer
4. Measuring Tape
5. Pencil
6.Utility Knife
7. Woodsaw
8. Step ladder
9. Spirit level
What you need
*OD]LQJVWULSVDQGȴ[LQJVIRXQGLQSDFNVΖIQHFHVVDU\
IWDQGIW([WHQVLRQ.LWFRQWDLQVDGGL
WLRQDOVWULSVIUDPLQJDQGȴ[LQJNLW
[%XLOGLQJ:RRGNLWVFRQWDLQV
DOOVWULSVIUDPLQJȴ[LQJVDQGΖQVWUXFWLRQ
IRUWKHEXLOGLQJVL]H
7UXVVSDFNFRQWDLQVUDIWHUVDQGFROODUWLHVΖIQHFHVVDU\
:KHUHWRȴQGHYHU\WKLQJ
+$1'<7Ζ36RUWȴ[LQJVDQGZRRGNLWE\VL]HDQGSLHFH
EHIRUHVWDUWLQJȋ$OOSDFNOLVWIRXQGDWWKHHQGRIGRFXPHQWȋ
1
45 6
2 3

For Queries and Help please call Product Support: 01909 768 858
Plain Panel Fixing Stages
Lay side panel, Fix
top and bottom rails
Pilot drill holes
EHIRUHȴ[LQJ
S50 x 6 (FR-0823-SQ / FR-1116-SQ x 2)
823mm or 1116mm
Window Panel Fixing Stages
Lay side panel, Fix
top and bottom rails
S50 x 6 (FR-0823-SQ / FR-1116-SQ x 2)
823mm or 1116mm
Pilot drill holes
EHIRUHȴ[LQJ
Flip Floors back over
ZLWK-RLVWVRQȵRRU
2QO\ȵLSRYHUDPD[LPXP
RIMRLQHGȵRRUVDWRQFHWR
UHGXFHZHLJKW
Side
Back
Place 3ft or 4ft
Panel along the
HGJHRIWKHȵRRU
It should line up
with edges of
WKHȵRRU
Wall Panel Stages
7Ζ3'RQȇWȴ[SDQHOVWRȵRRUXQWLOURRILVLQSODFH
S50 x 3
Pilot drill holes
EHIRUHȴ[LQJ
Lay gable panel, Fix
bottom rails. Repeat
for all Gable Panels
Gable Panel Stages
S50 x 3 (FR-0823-SQ x 1)
823 mm
7
10 11 12
8 9

For Queries and Help please call Product Support: 01909 768 858
S50
Add the remaining Eave Panels
according to building size. (Image
below shows 12x6 building)
Pilot drill holes
EHIRUHȴ[LQJ
Place the Window Panel next
to the Back Gable Section
Back
Back
Windowed
Plain Gable Section (PG)
Plain
Panel
(PP)
Back
Side
Top View Diagram
S50 x 3
Pilot drill holes
EHIRUHȴ[LQJ
S50 x 6
Pilot drill holes
EHIRUHȴ[LQJ
Place the Plain Panel next
to the Back Gable Section
Back
Back
Windowless
13
16 17 18
14 15

For Queries and Help please call Product Support: 01909 768 858
“Fitted on both
sides”
Fix truss pieces 1 side,
following the screw pattern.
S50 x 12
Flip truss over and repeat
(TR-0491-BV2 x 2)
(TR-0990
-BM38 x 2)
Place the Door Gable Section
on the inside of the Side Panels
Truss Fixing Stage
Use the Door Gable
Sections to align the
Truss sections
4x6 building don’t
require a truss,
Except Heavy Duty.
S50 x 5
Pilot drill holes
EHIRUHȴ[LQJ S50 x 4
The Truss must be positioned where the Roof
Sheets will meet. This will be either 879mm
or 1172mm. Please see the diagram.
S50 x 3
Pilot drill holes
EHIRUHȴ[LQJ
19
22 23 24
20 21

For Queries and Help please call Product Support: 01909 768 858
19mm
Truss
S50 x 6
(FR-0879-SQ / FR-1172-SQ)
879mm or 1172mm
2
2
1
S50 x 12
4RS
991mm
Roof Sheet requires
Roof Support only
The distance 879mm
or 1172mm is the
width of a Roof Sheet.
Measure from the
framing to the
centre of the Truss
Truss Position Diagram
Side View
879mm or 1172mm
Heavy Duty
only, Halfway
point.
Side View
Correct Position Side View Incorrect Position
Roof Sheet Position
Line up the Roof Sheet with
the framing not the cladding
Position the Roof Sheet
square with the framing
N30 x 5
x 1
1172mm or
879mm
Repeat for all
roof sheets
Roof Fixing Stage
1172mm or
879mm
(FR-0879-SQ /
FR-1172-SQ)
25
28 29 30
26 27

For Queries and Help please call Product Support: 01909 768 858
Position the
Roof Sheet
square with
ȴUVWVKHHW
and push up
to the centre
N30 x 12
N30 x 12
7KH5RRI6KHHWVKRXOGȴWKDOI
ZD\DFURVVWKH5RRI7UXVV
N30 x 12
N30 x 12
N30 x 12
Push the Roof Sheet
up to the centre.
This will require 2
people and make
the building ridgid SKIP TO STAGE 46
1 x 12
Push the Roof Sheet
up to the centre.
This will require 2
people and make
the building ridgid
31
34 35 36
32 33

For Queries and Help please call Product Support: 01909 768 858
Side View
Correct Position Side View Incorrect Position
7*5RRI3RVLWLRQ
Line up the 7*Roof with
the framing not the cladding
Position the 7*Roof 
square with theframing
Lay T&G roof ,Fix
bottom rails.
Repeat for all T&G
roof sections.
T&G Roof Only
S50 x 3 (FR-0879-SQ / FR-1172-SQ x1)
823mm or 1116mm
Position the
7*Roof
square with
ȴUVWVKHHW
and push up
to the centre
S70 x 8
S70 x 8
7KH7*5RRIVKRXOGȴWKDOI
ZD\DFURVVWKH5RRI7UXVV
S70 x 8
37
40 41 42
38 39

For Queries and Help please call Product Support: 01909 768 858
S70 x 8
S70 x 8
Push the 7*Roof 
up to the centre.
This will require 2
people and make
the building ridgid
S0 x 8
Push the 7*Roof
up to the centre.
This will require 2
people and make
the building ridgid
S50 x 8
(FR-1637
-SQ x 2)
1637mm Line up framing to
outside of cladding
S30 x 3 (CL-0823-28RS x 1)
823mm
Line up the Top Door Threshold
to the back of the Gable framing
S50 x 3 (FR-0879-SQ x 1)
879mm
Line up the Door Threshold
to the front of the Floor
43
46 47 48
44 45

For Queries and Help please call Product Support: 01909 768 858
Hingesȴ[
WRWKH
)UDPLQJ
Back View of Doors
Door Fixing Stage
S30 x 24
x 6
S50
Screw the Wall
Panels to the
ȵRRU
(CL-1680
-40RS x 1)
S30 x 3
1680mm
S30 x 4
S25 x 2
x 2
x 2
100mm
Top
Bottom
2mm
Gap
4mm
Gap
S30 x18
S25 x 1
x 
49
52 53 54
50 51

For Queries and Help please call Product Support: 01909 768 858
S30 x 3
(CL-0532-SQ x 1)
532mm
Windowed Building Only
Do not screw through
the glazing
S30 x 6
(CL-0532
-SQ x 2)
GL x 1
532mm
WS x 1
Windowed Building Only
Do not screw
through the
glazing
Windowed Fixing Stage
WS x 1 GL x 1
Cloaking Strip Fixing Stage
N30
Cut to size (Windowed Building Only)
(CL-1511-40RS)
1511mm
This will
require
cutting
to size
Cloaking Strip Fixing Stage
N30 (CL-1511-40RS)
1511mm
(Windowless Building Only)
S30 x 18
(CL-0532-SQ x 6) x 4
532mm
Windowed Building Only
55
58 59 60
56 57

For Queries and Help please call Product Support: 01909 768 858
Felt Fixing Stage
Length of
roof + 140mm
x 3
Front View
(6ft Gables)
(3 PIECES OF FELT)
Felt
Felt
Felt
LENGTH
STAGE 1 STAGE 2
STAGE 3
Tack to hold
in place
70mm overhang at
each end
Fold over
Eaves
T10
Mineral Felt
Sand Felt T8
N30 (CL-1511-40RS)
1511mm
T10
Repeat previous stages
for this side 100mm
T10
T10
Fold over
Corner
100mm
61
64 65 66
62 63

For Queries and Help please call Product Support: 01909 768 858
T10
Repeat previous stages
for this side
T13
Use the shingles Instructions
that comes with the packs
For Shingles Roof Covering Only
Only 1 roll of felt is used
as a starter layer for the
Shingles
Cut the full roll of felt in half
lengWK ways
x 1
N30 x 16
(FB-1100-90RS x 4)
1100mm
Facia Fixing Stage
N30 (CL-1511-40RS)
1511mm
Cloaking Strip Fixing Stage
Cut to size
N30 (CL-1511-40RS)
1511mm
Cut to size
This will
require
cutiing
to size
67
70 71 72
68 69

For Queries and Help please call Product Support: 01909 768 858
N30 x 4
x 2
3LORWGULOOKROHVȴUVW
Treat after assembly and
annually to protect
Protect your building
8x6 Keeper Overlap Windowless Shown
6DPHIRU[[[DQG[
Treat after assembly and
annually to protect
Protect your building
12x6 Keeper Overlap Windowed Shown
Same for 4x6, 8x6, 10x6 and 16x6
Treat after assembly and
annually to protect
Protect your building
10x6 Keeper Overlap Windowed Shown
Same for 4x6, 8x6, 12x6 and 16x6
73
76
74 75

Name:
Woodkit Building Apex 4ftx6ft Plain U1511
PACKED PART
ID:
25445
Pack List
GROUP PART ID Description / Image Part Code Length Z (m) X1 QTY
Tick when
Packed
Door Head
Strip 31781
11mm x 28mm Strip - Rough Sawn
CL-0823-28RS 0.823 -1
Cloak 31782
11mm x 40mm Cloak Strip - Rough Sawn
CL-1511-40RS 1.511 -6
Cloak 31783
11mm x 40mm Cloak Strip - Rough Sawn
CL-1680-40RS 1.680 -1
Finial 14471
11mm x 90mm Finial Diamond
FB-0138-90RS 0.138 -2
Fascia 31786
11mm x 90mm Fascia Board - Rough Sawn - Bevelled x1
FB-1100-90RS-BV1 1.100 66 4
Door Block 31139
28mm x 28mm Framing Rough Sawn - Homegrown
FR-0100-SQ 0.100 -2
Bottom Frame 25812
28mm x 28mm Framing Rough Sawn - Homegrown
FR-0823-SQ 0.823 -2
Threshold 31439
28mm x 28mm Framing Rough Sawn - Homegrown
FR-0879-SQ 0.879 1
Top & Bottom
rails 25813
28mm x 28mm Framing Rough Sawn - Homegrown
FR-1116-SQ 1.116 -4
Barge Boards
& Purlin 31105
28mm x 28mm Framing Rough Sawn - Homegrown
FR-1172-SQ 1.172 -3
Door Uprights 31333
28mm x 28mm Framing Rough Sawn - Homegrown
FR-1631-SQ 1.631 -2
Instructions -
6ft Keeper or Master Apex Shed Building Instructions
INS-0054 --1
Fixing Kit 25559
Fixing Kit Building Apex 4ftx6ft U1511
FK-4x6-A-PL-
U1511 --1
FINAL PART CHECKING: TO BE FILLED IN BY THE FINAL PACKER OR CHECKER:
I, __________________________, have checked that all components have been packed in good quality on ____/____/__________
Kybotech, Claylands Avenue, Worksop S81 7BQ
V2.0 061118

Name:
PACKED PART
ID:
GROUP
PART ID Description / Image Part Code Length Z (m) QTY
Tick when
Packed
Cloak -
11mm x 40mm Cloak Strip - Rough Sawn
CL-1511-40RS 1.511 2
Floor Joining
Block
-
28mm x 28mm Framing Rough Sawn - Homegrown
FR-0100-SQ 0.100 2
Top & Bottom
rails
-
28mm x 28mm Framing Rough Sawn - Homegrown
FR-1116-SQ 1.116 4
Barge Boards
& Purlin
-
28mm x 28mm Framing Rough Sawn - Homegrown
FR-1172-SQ 1.172 3
Fixing Kit 25561
Fixing Kit Extension Apex 3ft and 4ft Plain
FK-3ft-4ft-A-
PL -1
Woodkit Extension Apex 4ft Plain U1511
25449
Pack List
FINAL PART CHECKING: TO BE FILLED IN BY THE FINAL PACKER OR CHECKER:
I, __________________________, have checked that all components have been packed in good quality on ____/____/__________
Kybotech, Claylands Avenue, Worksop S81 7BQ
V1.0 050117

Name:
PACKED PART
ID:
GROUP
PART ID Description / Image Part Code Length Z (m) QTY
Tick when
Packed
Cloak -
11mm x 40mm Cloak Strip - Rough Sawn
CL-1511-40RS 1.511 2
Floor Joining
Block
-
28mm x 28mm Framing Rough Sawn - Homegrown
FR-0100-SQ 0.100 2
Top & Bottom
rails
-
28mm x 28mm Framing Rough Sawn - Homegrown
FR-0823-SQ 0.823 4
Barge Boards
& Purlin
-
28mm x 28mm Framing Rough Sawn - Homegrown
FR-0879-SQ 0.879 3
Fixing Kit 25561
Fixing Kit Extension Apex 3ft and 4ft Plain
FK-3ft-4ft-A-
PL -1
Woodkit Extension Apex 3ft Plain U1511
25448
Pack List
FINAL PART CHECKING: TO BE FILLED IN BY THE FINAL PACKER OR CHECKER:
I, __________________________, have checked that all components have been packed in good quality on ____/____/__________
Kybotech, Claylands Avenue, Worksop S81 7BQ
V1.0 050117

Part Name:
Part ID:
Code Name Image QTY Ticked
N30
30mm Nails 75
S25
25mm Black
Screws
3
S30
30mm Screws 52
S50
50mm Screws 69
S70
70mm Screws 16
TB
Black Turn
Button Black
3
H01
10" T Hinges -
Silver
6
Fixing Kit Building Apex 4ftx6ft U1511
25559
FINAL PART CHECKING: TO BE FILLED IN BY THE FINAL PACKER OR CHECKER:
I, __________________________, have checked that all components have been packed in good quality on
____/____/__________
Kybotech, Claylands Avenue, Worksop S81 7BQ
V1.0 - 050117
* PLEASE NOTE: Not all buildings are independently QA checked - these are done at scheduled intervals.
