bimota TESIH2 User manual
Whenever you see the symbols
shown below, heed their instructions!
Always follow safe operating and main-
tenance practices.
DANGER indicates a hazardous si-
tuation which, if not avoided, will re-
sult in death or serious injury.
WARNING
WARNING indicates a hazardous si-
tuation which, if not avoided, could
result in death or serious injury.
NOTICE
NOTICE is used to address practices
not related to personal injury.
NOTE
æNOTE indicates information that may
help or guide you in the operation or
service of the vehicle.
NOTICE
THIS PRODUCT HAS BEEN MANU-
FACTURED FOR USE IN A REASO-
NABLE AND PRUDENT MANNER
BY A QUALIFIED OPERATOR AND
AS A VEHICLE ONLY.
Foreword
Congratulations on your purchase of a new Bimota motorcycle. Your new mo-
torcycle is the product of Bimota’s advanced engineering, exhaustive testing, and
continuous striving for superior reliability, safety and performance.
Please read this Owner’s Manual carefully before riding so that you will be tho-
roughly familiar with the proper operation of your motorcycle’s controls, its features,
capabilities, and limitations. This manual oers many safe riding tips, but its pur-
pose is not to provide instruction in all the techniques and skills required to ride
a motorcycle safely. Bimota strongly recommends that all operators of this vehicle
enroll in a motorcycle rider training program to attain awareness of the mental and
physical requirements necessary for safe motorcycle operation.
To ensure a long, trouble-free life for your motorcycle, give it the proper care and
maintenance described in this manual.
This manual should be considered a permanent part of the motorcycle and should
remain with the motorcycle when it is sold.
All rights reserved. No part of this publication may be reproduced without our prior
written permission.
This publication includes the latest information available at the time of printing.
However, there may be minor dierences between the actual product and illustra-
tions and text in this manual.
All products are subject to change without prior notice or obligation.
Bimota s.p.a.
Aug. 27, 2020
TABLE OF CONTENTS
SAFETY INFORMATION ........................10
Read Owner’s Manual ......................... 10
Training ...............................................10
Daily Checks and Periodic
Maintenance ........................................10
Loading and Accessories Information ....11
Accessories ..................................... 12
Other Load .......................................13
If You are Involved in an Accident .........13
Safe Operation .................................... 14
Carbon Monoxide Hazard .................14
Fueling .............................................14
Never Ride with Drugs or Alcohol ...... 15
Protective Gear and Clothing ............ 15
Safe Riding Techniques .................... 16
Additional Considerations for High
Speed Operation .............................. 18
GENERAL INFORMATION .....................20
Specications ......................................20
Serial Number Locations ...................... 24
Location of Labels ................................ 25
Location of Parts ..................................32
Meter Instruments ...............................35
Indicators .........................................41
Speedometer/Tachometer ............... 48
Features...........................................49
Control Buttons ................................ 55
Multifunction Display .........................56
Multifunction Display Resetting ..........63
Setting Mode ....................................66
Keys ....................................................88
Ignition Switch/Steering Lock ............... 90
Right Handlebar Switches .................... 92
Left Handlebar Switches ......................94
Brake Lever Adjuster............................ 96
Clutch Lever Adjuster ...........................97
Fuel .....................................................98
Fuel Requirements...........................98
Filling the Tank................................ 100
Side Stand.........................................102
Seat ...................................................103
Air Cleaner Intake .............................106
Event Data Recorder.........................106
HOW TO RIDE THE MOTORCYCLE ...108
Break-In.............................................108
Starting the Engine............................109
Moving O ......................................... 112
Shifting Gears ................................... 112
Braking .............................................. 113
Anti-lock Brake System (ABS) .......... 115
Bimota Intelligent anti-lock Brake
System (KIBS)................................... 117
Stopping the Engine .......................... 118
Stopping the Motorcycle
in an Emergency ............................... 118
Parking .............................................. 119
Bimota Traction Control (KTRC) .......121
Rain Mode .........................................126
Bimota Launch Control Mode (KLCM)
..........................................................127
Bimota Engine Brake Control (KEBC)
..........................................................130
Bimota Quick Shift (KQS)..................130
Bimota Cornering Management
Function (KCMF) ..............................131
MAINTENANCE AND ADJUSTMENT . . 133
Daily Checks .....................................135
Periodic Maintenance........................138
Engine Oil..........................................143
Coolant ..............................................145
Air Cleaner ........................................148
Throttle Control System ....................149
Idle Speed .........................................151
Clutch ................................................152
Drive Chain .......................................153
Brakes ...............................................155
Brake Light Switches.........................157
Electronic Steering Damper (ESD) ...158
Suspension System ..........................158
Front Shock Absorber .......................159
Rear Shock Absorber.....................161
Setting Tables ................................165
Wheels ..............................................169
Battery ...............................................173
Headlight ...........................................177
Fuses ................................................178
General Lubrication ...........................179
Cleaning ............................................180
General Precautions ......................180
Where to be Careful.......................184
Washing Your Vehicle ....................185
APPENDIX ...........................................187
Storage..............................................187
Troubleshooting Guide ......................190
Environmental Protection ..................195
Location of DFI System Diagnostic
Connector..........................................196
Vehicle Data Recording.....................196
MAINTENANCE RECORD ...................198
10 SAFETY INFORMATION
SAFETY INFORMATION
Read Owner’s Manual
Read this Owner’s Manual carefully
before riding so that you will be tho-
roughly familiar with the proper opera-
tion of your motorcycle’s controls, its
features, capabilities, and limitations.
This manual oers many safe riding
tips, but its purpose is not to provide
instruction in all of the techniques and
skills required to ride a motorcycle
safely.
Training
Bimota strongly recommends that
all operators of this vehicle complete
a suitable motorcycle rider training
program to learn the proper skills and
techniques necessary for safe motorcy-
cle operation.
Daily Checks and Periodic
Maintenance
It is important to keep your motor-
cycle properly maintained and in safe
riding condition. Inspect your motor-
cycle before every ride and carry out
all periodic maintenance. See the Daily
Checks section and the Periodic Main-
tenance section in the MAINTENANCE
AND ADJUSTMENT chapter for more
information.
SAFETY INFORMATION 11
WARNING
Failure to perform these checks or
to correct a problem before opera-
tion may result in serious damage
or an accident. Always perform daily
checks before operation.
To ensure your motorcycle is ser-
viced using the latest servicing infor-
mation, it is recommended that an
authorized dealer performs the pe-
riodic maintenance as directed in the
Owner’s Manual.
If you notice any irregular opera-
ting condition, have your motorcycle
thoroughly checked at an authorized
dealer as soon as possible.
Loading and Accessories
Information
WARNING
Incorrect loading, improper instal-
lation or use of accessories or
modication of your motorcycle may
result in an unsafe riding condition.
Before you ride the motorcycle, make
sure it is not overloaded and that you
have followed these instructions.
Maximum Load
Weight of rider, baggage, and accessories
must not exceed 105 kg (231 lb).
With the exception of genuine Bimota
Parts and Accessories, Bimota has no
control over the design or application of
accessories. In some cases, improper
installation or use of accessories, or
12 SAFETY INFORMATION
motorcycle modication, will void the
motorcycle warranty; can negatively
aect performance, stability and safety;
and can even be illegal.
In selecting and using accessories,
and in loading the motorcycle, you are
personally responsible for your own
safety and the safety of other persons
involved.
NOTE
æBimota Parts and Accessories have
been specially designed for use on
Bimota motorcycles. We strongly re-
commend that all parts and accesso-
ries you add to your motorcycle be
genuine Bimota components.
Because a motorcycle is sensitive to
changes in weight and aerodynamic
forces, you must take extreme care in
carrying cargo, passengers and/or in
tting additional accessories. The fol-
lowing general guidelines have been
prepared to assist you in making your
determinations.
Accessories
1. Do not install accessories or carry
baggage that impairs the perfor-
mance of the motorcycle. Make sure
that you have not adversely aected
any lighting components, road clea-
rance, banking capability (i.e., lean
angle), control operation, wheel tra-
vel, front suspension movement, or
any other aspects of the motorcy-
cle’s operation.
2. Weight attached to the handlebars
or front fork will increase the mass of
the steering assembly and can result
SAFETY INFORMATION 13
in an unsafe riding condition.
3. Fairings, windshields, backrests,
and other large items have the ca-
pability of adversely aecting stabi-
lity and handling of the motorcycle,
not only due to their weight, but also
due to the aerodynamic force acting
on these surfaces while the motorcy-
cle is in operation. Poorly designed
or installed items can result in an un-
safe riding condition.
Other Load
1. This motorcycle is not intended to be
equipped with a sidecar or to be used
to tow any trailers or other vehicles.
Bimota does not manufacture side-
cars or trailers for motorcycles and
cannot predict the eects of such
accessories on handling or stability,
but can only warn that the eects can
be adverse and that Bimota cannot
assume responsibility for the results
of such unintended use of the motor-
cycle.
2. Furthermore, any adverse eects on
motorcycle components caused by
the use of such accessories will not
be remedied under warranty.
If You are Involved
in an Accident
Make sure of your own safety rst.
Determine the severity of any injuries
and call for emergency assistance if
needed. Always follow applicable laws
and regulations if any other person,
vehicle or property is involved.
Do not attempt to continue riding
without rst evaluating your motorcy-
14 SAFETY INFORMATION
cle’s condition. Inspect for uid leaks,
check critical nuts and bolts, and check
the handlebars, control levers, brakes,
and wheels for damage and proper
function. Ride slowly and cautiously -
your motorcycle may have suered
damage that is not immediately appa-
rent. Have your motorcycle thoroughly
checked at a authorised dealer as soon
as possible.
Safe Operation
The following should be carefully ob-
served for safe and eective vehicle
operation.
Carbon Monoxide Hazard
Exhaust gas contains carbon monoxide,
a colorless, odorless poisonous gas In-
haling carbon monoxide can cause se-
rious brain injury or death DO NOT run
the engine in enclosed areas. Operate
only in a well ventilated area
Fueling
WARNING
Gasoline is extremely ammable and
can be explosive under certain condi-
tions. To prevent re or explosion, turn
the ignition key o. Do not smoke. Make
sure the area is well ventilated and free
from any source of ame or sparks; this
includes any appliance with a pilot light.
SAFETY INFORMATION 15
Never Ride with Drugs or Alcohol
Alcohol and drugs impair your
judgment and reaction time. Never
consume alcohol or drugs before or
while riding motorcycles.
Protective Gear and Clothing
Helmet
Bimota strongly recommends the
operator wear a helmet even if this is
not a legal requirement.
- Make sure that your helmet ts correc-
tly and is properly fastened.
- Choose a motorcycle helmet that
meets the safety standards appli-
cable to your country. Ask your mo-
torcycle dealer to advise you if neces-
sary.
Eye Protection
Always use eye protection. If your
helmet does not have a visor installed,
wear goggles.
Gloves
Wear gloves which have suitable
protection for your hands, especially
against abrasion.
Clothing
Wear the riding wear which have
protectors for each parts of the body
(chest, shoulders, back, elbows and
knees, etc.) as much as possible, or
wear protectors for them.
- Always wear a longsleeved jacket
and long trousers which are abrasion
resistant and keep you warm.
- Wear clothing that allows freedom of
movement.
16 SAFETY INFORMATION
- Avoid wearing clothes which have
loose cus or other fastenings which
could interfere with the controls of
your motorcycle.
- Wear bright, highly visible clothing.
Boots
Wear proper protective boots that t
properly and do not interfere with gear
shifting or braking.
Safe Riding Techniques
Keep Hands on Handlebars
When riding always keep both hands
on the handlebars and both feet on the
foot pegs. Removing your hands from
the handlebars or feet from the foot
pegs while riding can be hazardous. If
you remove even one hand or foot, you
reduce your ability to control the mo-
torcycle.
Look Over Your Shoulder
Before changing lanes, look over
your shoulder to make sure the way
is clear. Do not rely solely on the
rear view mirror; you may misjudge
a vehicle’s distance and speed, or you
may not see it at all.
Accelerate and Brake Smoothly
In general your actions should be
smooth as sudden acceleration, bra-
king or turning may cause loss of
control, especially when riding in wet
conditions or on loose road surfaces,
when the ability to maneuver will be re-
duced.
Select Correct GearSpeeds
When going up steep slopes, shift to
SAFETY INFORMATION 17
a lower gear so that there is power to
spare rather than overloading the en-
gine.
Use Both Front and Rear Brakes
When applying the brakes, use both
the front and rear brakes. Applying only
one brake for sudden braking may
cause the motorcycle to skid and lose
control.
Use Engine Brake
When going down long slopes, help
control vehicle speed by closing the
throttle so that the engine can act as an
auxiliary brake. Use the front and rear
brakes for primary braking.
Riding in Wet Conditions
Rely more on the throttle to control
vehicle speed and less on the front and
rear brakes. The throttle should also be
used judiciously to avoid skidding the
rear wheel from too rapid acceleration
or deceleration.
Braking performance is also reduced
in wet conditions. Carefully ride at
a slow speed and apply the brakes se-
veral times to help dry and restores
them to normal operating performance.
Lubricate the drive chain after wet
weather riding to prevent rust and cor-
rosion.
Ride Prudently
Riding at the proper speed and avoi-
ding unnecessarily fast acceleration
are important not only for safety and
low fuel consumption but also for long
vehicle life and quieter operation.
18 SAFETY INFORMATION
Riding on Rough Roads
Exercise caution, slow down, and
grip the fuel tank with the knees for
better stability.
Acceleration
When quick acceleration is neces-
sary to pass another vehicle, shift to
a lower gear to obtain the necessary
power.
Downshifting
To avoid engine damage and rear
wheel lock-up do not downshift at high
rpm.
Avoid Unnecessary Weaving
Unnecessary weaving jeopardizes
the safety of both the rider and other
motorists.
Additional Considerations
for High Speed
WARNING
Handling characteristics of a motor-
cycle at high speeds may vary from
those you are familiar with at legal
highway speeds. Do not attempt high
speed operation unless you have
received sucient training and have
the required skills.
Do not operate at high speeds on pu-
blic roads.
Brakes
The importance of the brakes, espe-
cially during high speed operation, can-
not be overemphasized. Check to see
that they are correctly adjusted and
functioning properly.
SAFETY INFORMATION 19
Steering
Looseness in the steering can cause
loss of control. Check to see that the
handlebars turns freely but has no play.
Tires
High speed operation is hard on
tires, and good tires are crucial for safe
riding. Examine their overall condition,
inate them to the proper pressure,
and check the wheel balance.
Fuel
Have sucient fuel for the high fuel
consumption during high speed opera-
tion.
Engine Oil
To avoid engine seizure and resul-
ting loss of control, make sure that the
oil level is at the upper level line.
Coolant
To avoid overheating, check that the
coolant level is at the upper level line.
Electrical Equipment
Make sure that the headlight, tail/
brake light, turn signals, horn, etc., all
work properly.
Miscellaneous
Make sure that all nuts and bolts are
tight and that all safety related parts
are in good condition.
20 GENERAL INFORMATION
GENERAL INFORMATION
Specications
PERFORMANCE
Maximum Horsepower 170.0 kW (231 PS) @11 500 r/min(rpm)
Maximum Torque 141.7 N·m (14.4 kgf·m) @11 000 r/min (rpm)
Minimum Turning Radius 27 degrees left and right
DIMENSIONS
Overall Length 2 074 mm
Overall Width 770 mm
Overall Height 1 155 mm
Wheelbase 1 445 mm
Road Clearance 140 mm +-10
Curb Mass 214 kg
ENGINE
Type DOHC, 4-cylinder, 4-stroke, liquid-cooled
Displacement 998 cm³
Bore × Stroke 76.0 × 55.0 mm
Compression Ratio 8.5:1
Starting System Electric starter
Table of contents
Other bimota Motorcycle manuals
