biodex ATOMLAB 500 User manual

FN: 13-305 11/13


1. Procedure to add Ra-223 to the isotope library and create a dial value setting
in the Atomlab 500
2. Procedure to set a dial value for Ra-223 for the Atomlab 500
3. Procedure to adjust an isotope dial setting in the Atomlab 500 Dose Calibrator
4. Procedure to change one of the button isotopes to be Ra-223
086-330
086-332
BIODEX
Biodex Medical Systems, Inc.
20 Ramsey Road, Shir ey, New York, 11967-4704, Te : 800-224-6339 (Int’l 631-924-9000), Fax: [phone], Emai : [email protected], www.biodex.com

 +) .+ -)-)-# $,)-)* &$++1(+ - $&/&. 
, --$("$(-# -)'&
Ra-223 is not listed in the current isotope library. he user will have to add it to the isotope list.
1. Press the HOME key
2. Press SELEC U ILI IES
3. Select DOSE CALIBRA OR CONFIGURA ION
4. Select ISO OPE LIS – you must now enter the password
5. he ISO OPE LIS screen is now displayed
6. Select ADD ISO OPE – the ADD ISO OPE screen will now be displayed
7. Select the ISO OPE SYMBOL and enter Ra-223
8. Select EN ER
9. Select ISO OPE NAME, type in Radium 223
10. Select EN ER
11. Select DIAL SE ING and enter 17.8 as the factory default or
enter the other dial setting you determined
12. Select EN ER
13. Select HALF LIFE
14. Enter 11.43
15. Select EN ER
16. Select HALF LIFE UNI S and toggle it until DAYS appear
17. Select EN ER
18. Select YES to save the new isotope
NOTE: You have now added Ra-223 to your isotope list.
 +) .+ -), -$&/&. !)+!)+-# -)'&
1. If the user has a Ra-223 NIS traceable standard sent from the manufacturer, they can
place the standard into the dose calibrator chamber and verify the factory determined
isotope setting or create their own custom dial value.
2. he dose calibrator should be on the dose calibrator measurement screen. With the Ra-223
standard in the chamber an activity is shown. Select Ra-223 from the isotope library.
Press the isotope name next to the activity reading and the dial value adjustment screen
pops up. he factory preset dial value for Ra-223 is 17.8.
3. Calculate the current decayed activity of the Ra-223 standard. If you want to adjust the dial
setting to have the dose calibrator read exactly the activity you have calculated. Use the
⇑⇓ arrows to modify your dial setting. Write down this dial value.
NOTE: What you have done does not change the system s dial setting. You must go to the
Utilities Functions and adjust the Ra-223 isotope in the system memory with the dial value
you want to use. See Section III.
4. If you press BACK in the dial value adjustment box, the system returns to the current
operation or you can just press the large isotope name next to the activity and it will return
to standard operation.

 +) .+ -)%.,-($,)-)* $&, --$("$(-# 
-)'&), &$+-)+
1. Press the HOME key
2. Press SELEC U ILI IES
3. Select DOSE CALIBRA OR CONFIGURA ION
4. Select ISO OPE LIS – you must now enter the password
5. he ISO OPE LIS screen is now displayed
6. Select CHANGE DIAL VALUES; the Change Dial Values Isotope List is now displayed
7. Use ⇑⇓ arrows to go to the NEW ISO OPES LIS
8. Select ISO OPE Ra-223
9. Select CHANGE DIAL VALUE
10. Enter dial value you determined in Part II
11. Select EN ER
12. Select EN ER to save the new dial value or CANCEL to cancel the change
13. Select HOME to return to the Home Screen
NOTE: You have now adjusted Ra-223 dial value on your isotope list.
 +) .+ -)#(" )( )!-# .--)($,)-)* ,-) 
1. Press the HOME key
2. Press SELEC U ILI IES
3. Select DOSE CALIBRA OR CONFIGURA ION
4. Select ISO OPE LIS – you must now enter the password
5. he ISO OPE LIS screen is now displayed
6. Select the SE UP Button isotopes
7. Use the ⇑⇓ arrows to scroll down thru the routine isotopes and continue until you
display the new isotopes
8. Highlight the Ra-223 isotope by pressing it
9. Select the button you wish to change to be the Ra-223 – you will see that the name on
the button changes to the Ra-223
10. Select EN ER to record this as a change and return to the isotope list choice screen –
the system is now set for Ra-223 to be used as a button isotope
11. Select HOME to return to the Home Screen
