ADDENDUM
GAIT TRAINERTM 3 AND RTM600 TREADMILL
Version 2.02
SOFTWARE MANUAL – User’s Guide
950-400
950-402
950-406
950-420
950-422
950-426
FN: 14-075 Rev A 12/15

2Biodex Medical Systems, Inc. © 2015
This manual covers procedures for the following software:
Software Upgrade v2.02 for Biodex Gait Trainer 3™ and/or RTM600
This software can be used with the following products:
Version 2.02 of Gait Trainer 3 & RTM600 software can only be used on units with 12-inch
display. For any other size display, contact Biodex Customer Service.
Gait Trainer 3
950-400 Gait Trainer 3, 115V – Includes Support Bar
950-402 Gait Trainer 3, 115V – Includes Extended Handrails
950-406 Gait Trainer 3, 115V – Includes Geriatric/Pediatric Handrails
RTM600 Treadmill
950-420 RTM600 Treadmill 115V - Includes Support Bar
950-422 RTM600 Treadmill 115V - Includes Extended Handrails
950-426 RTM600 Treadmill 115V - Includes Geriatric/Pediatric Handrails
Need Help?
Contact Biodex Software Support
1-800-224-6339 ext 2120, or
[e-mail]

GAIT TRAINER 3 & RTM600 TREADMILL SOFTWARE V2.02 ADDENDUM 3
Table of Contents
1 OVERVIEW OF UPDATES..........................................................................................................4
2 ENABLING THE SPEED LIMIT FUNCTIONALITY..........................................................................5
3 USING THE QUICK SETTING OPTION FOR SPEED VALUES .........................................................9

4Biodex Medical Systems, Inc. © 2015
1. Overview of Updates
Speed Limit Functionality
The new version of the software for the Gait Trainer 3 and RTM600 now includes an additional
safety setting to limit treadbelt movement to a predetermined speed during Treadmill Training
activities. Clinicians can determine what the speed limit would be most appropriate for the type
of patients in their facilities. Speed limits can be set in either MPH or KMH.
Quick Setting Option for Speed Values
The software also includes additional functionality allowing faster setting of treadbelt speed.
Previously, users would need to touch the “UP” arrow multiple times to achieve a certain
treadbelt speed. There is now a keypad entry function that eliminates the multiple presses of
the “UP” button. (Each touch of the “UP” or “DOWN” buttons increases or decreases the treadbelt
speed by 0.1 MPH.) The keypad entry is programmed to account for speed limit settings, if
those settings are enabled.

GAIT TRAINER 3 & RTM600 TREADMILL SOFTWARE V2.02 ADDENDUM 5
2. Enabling the Speed Limit Functionality
From the Main Screen of the interface, choose the <Utilities> button.
Figure 2.1 The main menu of the Gait Trainer 3 interface.
Touch the <Configuration> button on the Utilities menu. If the Secure Access ID function of the
device is activated, you will need to input your code to access the Configuration of Patient
Management menus. (The default Secure Access ID is 781.)
Figure 2.2 The Utilities menu.

6Biodex Medical Systems, Inc. © 2015
Touch the <Treadmill Settings> button on the Configuration screen.
Figure 2.3 The Configuration screen.
On the Treadmill Settings screen, users will see the <Speed Limit> functionality. The product
will ship with the Speed Limit functionality disabled.
Figure 2.4 The Treadmill Settings screen.
To enable the Speed Limit functionality, simply touch and toggle the dropdown menu to
<Enabled>.

GAIT TRAINER 3 & RTM600 TREADMILL SOFTWARE V2.02 ADDENDUM 7
Figure 2.5 The Disabled/Enabled dropdown menu toggle.
Once enabled, the default speed limit will be 5.0 MPH. Increase or decrease this value with the
<UP> and <DOWN> arrows.
Figure 2.6 Speed Limit functionality--enabled.
Touching <Measure Units> allows you to toggle between MPH and KMH. The value in the Speed
Limit field will automatically update with the translated speed value.

8Biodex Medical Systems, Inc. © 2015
Figure 2.7 Changing the Measure Units value.
Figure 2.8 The measurement unit has changed from US to metric.
If the Speed Limit functionality is set, users and clinicians will find that they cannot exceed that
speed limit when setting treadbelt speed on the “Quick Start” and “Manual Start” screen within
Treadmill Training. (The speed limit can be exceeded when setting a Custom Profile, however.
Also the speed limit is not applicable to Gait Training, which has a built-in speed limit of 4.5
MPH.)

GAIT TRAINER 3 & RTM600 TREADMILL SOFTWARE V2.02 ADDENDUM 9
3. Quick Setting Option for Speed Values
Clinicians and users now have the option of bringing the treadbelt to a designated speed
without having to press the “UP” button on the Quick Start and Manual Start multiple times.
To use this function, select either the Quick Start or Manual Start option on the Treadmill
Training menu.
Figure 3.1 The Treadmill Training menu.

10 Biodex Medical Systems, Inc. © 2015
Select the <Keypad> button.
Figure 3.2 The quick entry keypad is next to the Speed value.
The keypad will appear on the screen for 10 seconds. If a Speed Limit has been enabled, the
speed limit—in MPH or KMH—will appear at the top of the screen. Users will not be able to
press a number value that is higher than the speed limit.
Figure 3.3 A treadbelt speed can be entered using the keypad.

GAIT TRAINER 3 & RTM600 TREADMILL SOFTWARE V2.02 ADDENDUM 11
To set a speed, touch a number button and then <ENTER>. The window will close and the
treadbelt will start “ramping up” to that speed.
Figure 3.4 The user must touch <ENTER> after selecting a speed.
