AbodeFit WalkSlim WalkPad 630 User manual

WalkSlim WalkPad 630
TREADMILL • USER MANUAL

Congratulations on your purchase of the AbodeFit Health™
WalkSlim WalkPad630.
Please read the user manual carefully before using,
pay special attention to the safety precautions and keep
for future reference.
WARNING
Keep young children away from this treadmill at all times.
Contact with the moving surface may result in severe friction burns.
Please contact AbodeFit Health’s warranty provider,
Vitality 4 Life, (details on back page) if any malfunction
occurs and a qualified technician will assist you.
Unauthorised dismantling of the treadmill will void
warranty.
Stop using the treadmill immediately if:
• Water comes into contact with the treadmill or
the controller
• Any foreign bodies have been lodged inside the
treadmill
• Power failure
• Thunder / lightning weather
• If you feel unwell
• If the power cord has any damage

Safety Precautions 4
Parts and Features 6
Operating Instructions 7
Using your Walkslim WalkPad 630 8
Warm-Up Exercises 10
Maintenance 11
Troubleshooting 12
Warranty 15
EN
3

EN
4
Safety Precautions
• The WalkSlim WalkPad 630 is only suitable for adults over the age of 18. It is not a
toy and should not be used by children. The Automatic 3 Zone Sensor Mode can be
activated by young children.
• The WalkSlim WalkPad 630 is for personal use only and is unsuitable for professional
training, testing or medical purposes.
• The WalkSlim WalkPad 630 is designed for indoor use only. Do not use in areas of
strong light or heat (including direct exposure to the sun), when temperatures
exceed 40°C or near water
• Do not use the WalkSlim WalkPad 630 in humid or dusty environments to avoid any
risk of electric shock.
• To avoid any injury, warm up exercises are advised prior to using the treadmill. It is
not recommended to use your WalkSlim WalkPad 630 for walking within 40 minutes
of eating.
• Only use if you are in good health. If you feel uncomfortable (dizzy, headache or have
physical problems such as ligament injuries or joint replacements) stop using the
treadmill immediately and seek professional advice.
• The WalkSlim WalkPad 630 is not suitable for use by individuals with reduced
physical, sensory or mental capabilities unless professional guidance has been given.
• Always wear appropriate footwear when using the treadmill, avoid exercising
barefoot or wearing any loose jewellery or clothing with belts or strings.
• Do not insert hands or feet or any body parts into the treadmill or in areas between
the tread belt and foot rails.
• Stop for 30 minutes after each one hour walking session to avoid any damage to the
motor as a result of overheating.
• Ensure the WalkSlim WalkPad 630 is on a flat and dry surface before use and there
are no sharp items close by.
• The WalkSlim WalkPad 630 is not suitable for using on every carpet type, therefore
if you intend to use the treadmill on any carpeted areas, it is strongly advised that a
hard-mat type material is placed beneath the treadmill.
• Only connect the WalkSlim WalkPad 630 to a power outlet that is the correct size for
the power plug and do not use if the power plug is damaged.
• Do not use force to disassemble any parts or attempt to turn off the power while
in use.

EN
5
• Do not insert foreign objects into any of the parts or use unauthorised parts.
• Do not apply pressure or stand on the display.
• Do not exceed the treadmill’s maximum weight capacity of 105kgs, the treadmill is
only suitable for individual use.
• Keep a distance of 1 metre between the treadmill and the rear space and on both
sides.
• Please do not stand on the treadmill when its auto callibrating and displays WAIT on
the display screen.
• Unplug the WalkSlim WalkPad 630 when it is not likely to be used for long periods of
time.
• Do not let the cord contact any other parts such as the tread belt.
• Make sure the cord is undamaged and located where it cannot be damaged.
• Please turn off and dry any spilt liquid before cleaning the treadmill
BEFORE USING THE WALKSLIM 630
• Wait an appropriate time after eating
• Ensure children and pets are kept away from the treadmill
• Make sure no fingers or foreign bodies are near the gap between the cover and the
base of the treadmill whilst in operation
• Always supervise young and elderly people whilst on the treadmill
• Only one person may be on the tread belt at a time
CONSULT YOUR DOCTOR PRIOR TO USE IF ANY OF THE FOLLOWING APPLIES:
• you are undergoing medical treatment or have any medical concerns
• you are pregnant
• you have heart disease
• you have osteoporosis
• you have a pacemaker or other medical electronic instrument implanted
• you have artificial limb/s

EN
6
Parts and Features
RollersMode SwitchFold Hinge
Tread Belt
Display Screen
Power
Switch
Power
Socket
Mode Indicator Lights
Standby
Manual
Automatic
DISPLAY SCREEN
Display Time Display Speed Display Distance Display Steps
Remote Control,
Silicone Oil Lubricant
& Allen Key
Wrist Strap
Lanyard Holder
Display
Screen
Start/Stop
Speed
Increase
Speed
Decrease
Mode

EN
7
Operating Instructions
STARTING YOUR WALKSLIM WALKPAD 630
1. First find the right spot for your WalkSlim WalkPad 630, ensuring you choose a
location that is flat and open, free of sharp objects, with a sufficient 1 metre clear
space around the treadmill.
2. Remove the WalkSlim WalkPad 630 from its packaging and place on the floor.
3. Unfold the WalkSlim WalkingPad 630 slowly and press it down completely flat.
4. Check and adjust the tread belt to make sure its centered.
5. Before you use the WalkSlim WalkPad 630 the tread belt must be lubricated with the
oil provided.
Note: Do not connect the power before the treadmill is fully unfolded and lubricated
HOW TO LUBRICATE THE TREAD BELT
• Lubricating your WalkSlim Walkpad 630 treadmill is essential before starting to use it
for the first time along with during normal use.
• During normal use, friction marks may appear between the tread belt surface and
the treadmill base. To avoid unnecessary friction and to maximize the life of your
treadmill, it is recommended to lubricate the tread belt surface with lubricant after
every 10-15 times or according to the following schedule:
– Lightweight users (less than 3 hours/week) – Lubricate once every 3 months
– Moderate users (3-6 hours/week) – Lubricate once every 2 months
– Heavyweight users (more than 7 hours/week) – once every month
The following is a step-by-step guide
1. Make sure the treadmill is unplugged and place it on an even, non-slippery surface.
2. Lay the treadmill down so its left side is facing up.
3. Lift the tread belt surface up starting from the upper corner.

EN
8
4. Apply the lubricant by squeezing droplets underneath the tread belt surface,
ensuring the lubricant is applied at least 10-15cm towards the middle of the tread
belt. Only apply 5-10ml of lubricant each time.
5. Lift the treadmill back up, and lay it down so the right side is facing up
6. Lift the tread belt surface and apply the lubricant underneath as you did in steps
3 and 4.
7. Return the treadmill to its operating position.
Remember proper lubrication is an important factor in maintaining the treadmill. To
check if you need to add lubricant, make sure the treadmill is turned off at the power
outlet. Run your hand under the tread belt from the top to the bottom. If your hand is
slightly damp with silicone oil there is no need to lubricate. If your hand is completely
dry, it is time to add lubricant
Once lubricated, it’s easy to get started as there is no assembly required.
Using your Walkslim WalkPad 630
Starting the WalkSlim WalkPad 630 using the Manual Mode (M)
• The Manual mode is for beginners and uses the Remote Control to
adjust speed. It is recommended to start walking using the Manual
mode and once proficient the Automatic mode can be used.
• Plug in the power, turn on the power switch.
• Press the Mode button on the Remote Control to switch to
Manual Mode. M will be displayed on screen in red.
• If you stop using the Walkslim 630 for more than 10 minutes, it will switch to Standby
Mode automatically. In Standby Mode the treadmill motor stops functioning to prevent
non-users from setting off the treadmill. will be displayed in red on the display screen.
• When the Treadmill stops, you can lock the treadmill by pressing and holding the
Mode button for more than 2 seconds.
• To retstart the Treadmill, press and hold the Start/Stop button for more than 2 seconds.
• Speed Increase/Decrease: A single press of the +Speed Increase or – Speed
Decrease on the remote control will accelerate or decelerate the speed by 0.5km/hr.
Press and hold to continuously accelerate or decelerate.

EN
9
• Starting/Stopping the Treadmill: Press the Start/ Stop button on the remote
control to Start or Stop theTreadmill. By Pressing Stop when you have finished your
session, the Treadmill will stop slowly and enter Standby mode. Press and hold the
Start/Stop button for more than 2 seconds to unlock the Treadmill.
Syncing your WalkSlim WalkPad 630 with the Remote Control
Your remote control is synced to the treadmill during manufacture so a re-sync is only
necessary if you are replacing the first remote with another one.
To re-sync your new remote control
1. Remove the battery cover on the backside of the remote control and take the battery
out of the remote and place it back in again into its correct position.
2. Switch the treadmill on by pressing the Start/Stop Button, once the display panel
is lit, press the Mode Switch Button.
If the re-sync is not successful, switch the treadmill off, and repeat steps 1 & 2 again.
Pairing the Remote Control to Bluetooth
Restart the treadmill and press and hold the Mode button on the remote control. A beep
sound indicates the success of pairing.
During operation, the remote control should always be close to the display screen of the
treadmill.
Starting the WalkSlim WalkPad 630 using the Automatic Mode (A)
This Automatic (3 Zone Sensor) Mode uses infrared induction
technology to automatically control and adjust the speed by
sensing the location of your feet according to the slow down,
speed up and constant zones on the tread belt.
It is an advanced mode that is suitable for those who have
strong sports skills or treadmill experience.
Plug in the power, turn on the power switch which is located on
the underside of the LED Display Screen.
Press the Mode button once on the Remote Control to switch
to the Automatic Mode. A will be displayed on screen in red.
Now you can control speed without use of the Remote Control.
HOW TO SPEED UP
Walk or run in the Speed Up Zone. The speed will gradually
increase until it reaches the max speed of 6km/h.
HOW TO MAINTAIN A CONSTANT SPEED
Walk or run in the Constant Zone to maintain a steady
uniform speed.
Speed Up
Zone
Constant
Zone
Slow Down
Zone

EN
10
HOW TO SLOW DOWN
• From the Speed Up Zone, slow your speed gradually from jogging to fast walking and
move to the Constant Zone. Keep walking for about 5 seconds and the speed will
steadily reduce.
• From the Constant Zone, slow down gradually from fast walking to walking with wide
steps and move to the Slow Down Zone. Keep walking for about 5 seconds and the
WalkSlim WalkPad 630 will slow down and stop automatically.
HOW TO STOP
• From the Speed Up Zone, keep walking for about 5 seconds, slowing down gradually
from fast walking to walking with wide steps and move to the Slow Down Zone. Keep
walking in the Slow Down Zone for about 5 seconds. It is safe to get off once the
WalkSlim WalkPad 630 has stopped.
• From the Constant Zone, slow down gradually from fast walking to walking with wide
steps and move to the Slow Down Zone. Keep walking in the Slow Down Zone. It is
safe to get off once the WalkSlim WalkPad 630 has stopped.
Warm-Up Exercises
It is recommended to warm up for 5 to 10 minutes before exercise to prevent sports
injuries. Refer to the following stretching exercises and repeat after your treadmill
exercise program.
1. Stretch down: Keep knees slightly flexed and your body slowly bent forward, relax
your back and shoulders, touch your toes with your hands as much as possible, and
keep for 10~15 seconds, then relax. Repeat 3 times.
2. Foot tendon stretch: Sit on a clean seat cushion, straighten one leg and keep the
other leg inward to fit the inner side of the straight leg. Try to touch your toes with
your hands for 10 to 15 seconds, then relax. Repeat 3 times for each leg.
3. Stretch the calves and Achilles tendon: Stand close to a wall with your hands on it, with
one foot behind, keep the back leg upright and heels touching the ground, incline to
the wall and keep for 10 to 15 seconds, then relax. Repeat 3 times for each leg.
4. Stretch the quadriceps: Balance yourself with the left hand holding a wall or a desk,
then extend your right hand backwards, grab your right heel and slowly pull it to your
buttocks until you feel the muscles on the front of the thighs in tension, keep for 10 to
15 seconds, then relax. Repeat 3 times for each leg.
5. Stretch the sartorius muscle (muscle inside the thigh): Keep the soles opposite and
sit with the knees outwards. Grasp your feet with your hands and pull in the direction
of your groin, keep for 10 to 15 seconds, then relax. Repeat 3 times.

EN
11
Storing the WalkSlim WalkPad 630
• The maximum ground clearance is 13cm so you can easily store the treadmill under
a bed/coach or other places that are suitable for its size.
Maintenance
Daily Maintenance
• Regular comprehensive cleaning will extend the life of your WalkSlim WalkPad 630.
• Always turn the power off at the power outlet and make sure there is no moisture
before daily cleaning and maintenance.
• Wipe off dust and stains on the frame, front panel and tread belt. Do not wipe
backside of the tread belt.
• Wear clean sports shoes to avoid any dust or impurities getting into the tread belt
and board.
• Use a damp cloth with soap or detergent to clean the tread belt. Do not use
excessive water and avoid leakage to the electrical parts.
• Disconnect the power cord when the WalkSlim WalkPad 630 will not be used for a
long time.
• Do not store the treadmill in the bathroom or outside and avoid areas with a lot
of moisture.
WARNING
Unplug the treadmill before performing maintenance.
Do not pinch your finger!
Do not walk on the tread
belt when turned off
Turn power off
before folding Remove plug when not in use
Do not store
vertically Do not store laterally

EN
12
Troubleshooting
The treadmill is
not working
•Make sure the power cord is properly secured into the power
outlet and that the switch is turned to the ‘ON’ position.
The tread belt is
not working
• Insufficient lubrication. Add silicone oil lubricant.
The tread belt is
slipping
•Tread belt is too loose or too tight. Adjust the tread belt
tightness to the correct tension by turning both left and
right adjusting screws for half a cicle clockwise at the same
time. The tread belt should be able to be lifted from the base
by about 5-7.5cm by hand. If you feel there are occasional
pauses as you are walking normally, it means the belt has
become loose. Over time the tread belt will loosen due to
wear or stretching and an adjustment must be made.
The Treadmill
will not speed up
slow down
Please contact our Customer Service Centre.
The Display
Screen does not
work
Please contact our Customer Service Centre.
The Treadmill is
losing speed
Add lubricant oil to the underside of the tread belt as per
instructions of this manual.
Display Screen
is on but the
Treadmill does
not start
The treadmill has not been started according to the instructions
of this manual. If the treadmill still does not start please contact
our Customer Service Centre.
Unreadable
/ Incoherent
Display Screen
Motor is overheating. Turn the power off, unplug and leave for
one hour then restart. If it does not restart please contact our
Customer Service Centre.

EN
13
The belt is
running to
the left
1. Press and hold both Mode button and speed Increase button
on the Remote Control for over 3 seconds. Front panel will
display “CALI” and the speed is 4km/h.
2. Turn the left adjusting screw half a cicle clockwise using the
Allen key. Start the WalkSlim WalkPad 630 to check the new
position of the belt.
3. If the belt is still not in the middle repeat the action until
adjusted to a central middle position.
4. After adjusting the belt to the middle, start the WalkSlim
WalkPad 630, set to the maximum speed and observe
the tread belt to ensure that is running smoothly. If it’s not
centralised, then repeat the adjustment steps again.
The belt is
running to
the right
1. Press and hold both Mode button and speed Increase button
on the Remote Control for over 3 seconds. Front panel will
display “CALI” and the speed is 4km/h.
2. Turn the right adjusting screw a half circle clockwise using the
Allen key. Start the WalkSlim WalkPad 630 to check the new
position of the belt.
3. If the belt is still not in the middle repeat the action until
adjusted to a central middle position.
4. After adjusting the belt to the middle, start the WalkSlim
WalkPad 630, set to the maximum speed and observe
the tread belt to ensure that is running smoothly. If it’s not
centralised, then repeat the adjustment steps again.
The belt is
skidding
Turn the left and right screw half a turn clockwise at the same
time and then repeat the adjustment until running normally. Do
not tighten the screw excessively.
Tread belt
adjustment screws

EN
14
Error Message Codes
Error
Code Fault Description Solution
E01 Drive
Communication
Fault
Unplug the WalkSlim WalkPad 630, leave for several
minutes and then restart. If it does not restart please
contact our Customer Service Centre.
E02 Motor Issue Turn the power off, unplug and leave for one hour
then restart. If it does not restart please contact our
Customer Service Centre.
E05 Overcurrent
Protection
Please contact our Customer Service Centre.
E06 Motor Protection Please contact our Customer Service Centre.
E10 Temperature
Protection
Please contact our Customer Service Centre.
E11 Overload
Protection
Add Lubricant to the underside of the tread belt .
Fault Warning Light

EN
15
ABODEFIT HEALTH™ WALKSLIM WALKPAD 630 WARRANTY
Warranty Period: Lifetime Frame, 5 Years Motor, 2 Years Parts & Labour. Vitality 4 Life are the warranty
providers for AbodeFit Health™ products. Vitality 4 Life warrant this product to be free from defects in
materials and workmanship while in normal domestic use for a period of five years on the motor and two
years on other parts (with the exception of a life warranty on the frame) from the original date of purchase.
DO NOT RETURN THE PRODUCT TO THE STORE.
LODGING A WARRANTY CLAIM
Should you experience any issues with your product, please follow
these steps to lodge a warranty claim:
1. Contact your local Vitality 4 Life Service Centre with the
following details: Your warranty details including name, email
and phone number
– Product name and model number
Product serial number, found on the rating label of the
product
Explanation of how the damage occurred
Photos of the damage or issue is highly beneficial to
expediting your claim
2. Vitality 4 Life will assess your claim and respond within 24-48
hours.
3. In the event the product is required to be sent to the Service
Centre, the customer is liable for all packing, freight and
insurance costs for transit of the product to Vitality 4 Life.
Subject to the applicable consumer laws in your jurisdiction.
4. If the product, or one of its parts, qualifies for replacement or
service within the 30-Day period after date of purchase, Vitality
4 Life will arrange the shipping at no cost to you.
5. Any product sent to a Vitality 4 Life Service Centre must include
a Return Authorization Form. Failure to include this form may
result in the product being rejected from our warehouse or a
delayed service time.
6. Vitality 4 Life will contact you with a quote prior to undertaking
any service work outside of the warranty coverage.
7. Typical turn-around times to address warranty claims can be
between 10-14 business days, plus shipping, depending on
location and type of damage or warranty claim.
TERMS OF PRODUCT WARRANTY COVERAGE
Vitality 4 Life provides the Product Warranty coverage as further
described below and limited to the terms and conditions hereof:
1. If the Product exhibits a defect while in normal domestic use,
within the warranty period; we will, at our option, either repair
or replace the product or defective part free of charge. The
Product must be delivered by insured mail, in proper packaging
to your Service Centre as indicated on the back of the manual
as a condition to any warranty service obligation.
2. In the event that the warranty period for a product has expired,
or if a Product does not qualify for warranty service, repair
or replacement, consumers may still buy replacement parts
or have products repaired by one of Vitality 4 Life’s Service
Centres. Please contact Vitality 4 Life for further information.
3. Do not send the product back to the Service Centre without a
Return Authorization Form.
4. In no event shall our liability exceed the retail value of the
product. We make no warranty with respect to parts, from a
source other than Vitality 4 Life.
5. In the event that warranty parts or products are provided, the
customer must cover the related shipping costs to receive
goods.
6. All exchanged or substitute parts and products replaced
under warranty service will become the property of Vitality
4 Life. Repaired or replaced products or parts thereof will
be warranted by Vitality 4 Life for the balance of the original
warranty period.
7. (Australia only) Our goods come with guarantees that cannot
be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
WARRANTY DOES NOT COVER
1. Damage, accidental or otherwise, to the Product, not caused by
direct defect in factory workmanship or materials.
2. Damage due to abuse, mishandling, alteration, misuse,
commercial service, tampering, accident, failure to follow care,
operating and handling provisions indicated in the instructions.
3. Damage caused by parts or service not authorized or
performed by Vitality 4 Life.
4. ‘Normal’ wear and tear that naturally and inevitably occurs as a
result of normal use or aging.
5. Some states do not allow the exclusion or limitation of
incidental or consequential damages. Therefore, the above
limitations may not apply to you in the case of damage
in shipment. If your product was damaged in shipment:
Immediately report this type of damage to the parcel carrier
and have them file an inspection report to contact the
distributor from whom you purchased the product for further
instructions.
6. You have rights and benefits under the consumer laws in
your jurisdiction. Without detracting from these rights or
benefits, Vitality 4 Life excludes all liability in respect of this
product for any other loss which is not reasonably foreseeable
from a failure of this product, which may include liability for
negligence, loss of expenditure associated with the product and
loss of enjoyment.

Support & Service Centres
Contact your local distributor for warranty & service
Vitality 4 Life – Australia & New Zealand
E: [email protected]
W: www.vitality4life.com.au
Vitality 4 Life – United Kingdom
E: [email protected].uk
W: www.vitality4life.co.uk
Vitality 4 Life - United States
E: [email protected]
W: www.vitality4life.com
Vitality 4 Life – France
E: [e-mail]
W: www.vitality4life.fr
Vitality 4 Life – Deutschland
E: [email protected]
W: www.vitality4life.de
Vitality 4 Life – Italia
E: [e-mail]
W: www.vitality4life.it
Vitality 4 Life – España
E: [e-mail]
W: www.vitality4life.es
Vitality 4 Life – Netherlands
E: [e-mail]
W: www.vitality4life.co.nl
