BIOLUX iEOG Series User manual

Healthy Naturally
Owner’s Manual
The Best Choice for Your Family’s Health and Hygiene
For Your New Biolux iEOG Water Generator Series
HOS - Hydrogen & Ozonated Water System

1
Hydrogen & Ozonated Water System
Consumable Parts
Troubleshooting Guide
Warranty Information
Table of Contents
Introduction
Installation
Service &
Maintenance
Operation & Use
Limited Warranty
To Our Valued Customers
Intended Use
Important Safety Warnings and Precautions
Product Features
Product Specifications
Package Contents
Unit Overview
LCD Display & Control Panel
How to Install the Unit
Unit Start-Up
Directions for Product Use
Other Functions
Overall Icon Displays and Interpretations vs.
All Operation Status
Recommendations for Using this Unit
2
2
3
5
5
6
7
8
10
16
17
18
21
25
27
28
EOS7130H-V1.05

2
This device produces filtered water with saturated dissolved hydrogen for drinking and ozonated water
for disinfection – this is a real one machine for unlimited benefits for your home !
Just exactly what are those? Your HOS employs computer accurate low-voltage electric current and
selectable proton exchange energy to perform water electrolysis through patented Indirect Electrolytic
Ozone Generation (iEOG) cell. Inside this advanced cell, driving force from the electric current and proton
exchange energy split water into pure hydrogen gas (H2) and high portion ozone (O3) contained oxygen
gases (O3+O2) without using any chemicals. Then, the hydrogen water and ozonated water are to be
created by dissolving these gaseous streams in water individually once usage is requested.
Therefore, you can choose between Hydrogen Water for Drinking (the upper button) and Ozonated
Water for Disinfection Use (the lower button):
Intended Use
Hydrogen Water
Ozonated Water
肌
肌
This is the natural bactericidal agent and disinfectant, eective against infestation of harmful
bacteria and virus as well as dangerous chemical and pesticide residues. It is highly eective,
ecient and free of residues.
High-reducing power hydrogen water helps neutralize harmful free radicals, which further helps
with health improvement, anti-oxidation and anti-aging.
Introduction
To Our Valued Customers
Thank you for purchasing a Biolux HOS- Hydrogen & Ozonated Water System. You have just purchased
the finest, most beneficial and advanced water system in the world! Your new HOS is designed to provide
you with many years of the cleanest, healthiest and most “functional” water available. There are many
specific uses and benefits of this amazing water generator, so read this manual carefully to learn how to
get both optimum performance out of your HOS and to protect your investment.
This product is intended for domestic use only. Please read all safety warnings and this User’s Manual
carefully before using this product to ensure proper product usage. (Keep the manual handy for easy
reference.)
• We are not responsible for any accidents and/or malfunctions due to improper use of this product.
• Please refer to this manual often when you have questions during the use or when troubleshooting this
unit.

3
Introduction
Important Safety Warnings and Precautions
WARNING
Please read these pages carefully. They contain very important information to protect you and the valuable
warranty on your HOS. Please make sure you are familiar with all the safety warning and precautions
associated with this unit.
DANGER
Could cause personal injury or have an adverse effect on health.
1. Do not drink hydrogen water with medication.
2. Never drink ozonated water. (Ozonated water is for disinfection only, not for drinking.)
3. Only use potable drinking water in your HOS. It is recommended that you use potable municipal water as
source water (raw water).
4. Poor water quality may have negative effects on your health and your HOS! Most potable municipal water
sources will be fine in your HOS. If on hard water please ask about pre-treatment options.
5. Well water and water from smaller system should be checked, and may require pre-filtering. Your HOS is
not under warranty for any damage or required cleaning by hard or poor quality water deposits.
6. Do not move the unit by the front cover. Move the unit by putting both hands underneath it. This will
prevent the unit from falling during movement.
CAUTION
Could cause damage to HOS and possibly void your warranty.
Risk of Fire and Electric Shock
1. Power MUST be connected at all times! Do not plug and unplug power cord repeatedly. The product’s
limited warranty does not cover any damage to the iEOG cell resulting from power disconnection for many
times repeatedly. Reconnecting power more than 36 times a year will void the limited warranty to the
entire product.
2. Never run hot water through this unit. Connecting it to a hot water (>35°C) source could damage the iEOG
cell or other parts of the HOS.
3. Protect your HOS from freezing temperatures or from direct sunlight.
4. Keep the power cord and your HOS away from hot surfaces or appliances – failure to do so may result in
electric shock or fire!

4
Introduction
5. To reduce the risk of electric shock, do not remove cover; no user-serviceable parts inside. Refer servicing
to qualified service personnel. Remove the cover will void the warranty.
6. Do not try to fix the HOS yourself. Call the dealer to have it fixed by a qualified technician.
7. Do not use if the power cord is damaged or in a loose power outlet.
8. If the power cord develops a break or short, stop using the unit and call customer service to have it
replaced.
9. Do not reconnect or splice a defective power cord as it could result in electric shock or become a fire
hazard.
10. Do not pull the power cord. Never touch power cord or power outlet with wet hands.
11. Do not use power surge protectors with this unit. Use unit with its own dedicated power source.
12. Do not forcibly bend, squeeze, damage or crush the power cord under heavy objects.
13. Do not use the unit in a dusty place. This may cause the unit to malfunction.
14. Do not spray water on the main unit. Do not clean with a damp cloth or any chemicals, which may leak
into the unit.
15. Do not place this unit on an uneven surface. Do not drop or use excessive force on this unit.
16. Place this product near a sink and always allow water to drain into the sink and drain.
17. When moving the unit, please be sure not to drag by the power cord as this could cause electric shock.
18. Please be sure to keep the power cord dust free.
19. Do not place ANY objects on top of this unit regardless of how small.
20. In case water leaks out of the unit (other than hoses) or unit is standing in a puddle of water, shut off
the water supply, unplug the power cord and refer servicing to qualified service personnel.
21. In the event that water gets into power supply, unplug the power cord and completely dry power outlet.
22. In case of strange noises, burning odor or smoke, unplug the power cord immediately and refer
servicing to qualified service personnel.
23. Replace iEOG Pre-Stabilizer every 12 months to optimize the purification performance of this unit even
if the replacement indicator light isn’t turned on.
24. Do not poke or scratch the touch pad or LCD display with sharp objects.
25. Keep original packaging for storage or unit transportation.
These safety precautions and warnings are provided at YOUR benefit to your health and home, for the safe
and proper use of this unit and can prevent danger, bodily harm and/or possible damage due to misuse.
Please make sure you are familiar with all the safety precautions and warnings associated with this unit.
Biolux is not responsible for any damage or injury caused by not adhering to these precautions and
warnings.

5
Introduction
Product Features
• Touch button and color LCD screen for simple operation.
• For health improvement, anti-aging and home sanitation.
• 100% pure Hydrogen and NOx-Free Ozone in outputs.
• Zero latency operation, high concentrations right on starting-up.
• Built-in gas-liquid separation and Off-gas reduction at all times.
• ORP (oxidation-reduction potential) and mv (millivolts) display system.
• ppm (concentration of dissolved ozone) display .
• Automatic self-cleaning and disinfection.
• Nontoxic, food-grade and antioxidant/ozone-compatible piping and plumbing.
• Certifications granted by major global authorities in certification of disinfection.
• Sufficient flow design for family use.
• Modern design for enhanced decor.
Product Specifications
Remark :
The output concentrations may vary depending on intervals of usage and influences from various
temperature.
Oxidation Reduction
Potential (ORP)
-518~-588mv -
Output pH
6.5 ~ 7.5 Neutral
Flow Rate
Touch Time
Upper button 0.2s (5min output) Lower button 0.2s (20s output) Lower button 1s (5min output)
Concentrations
1.1 ~ 1.2 ppm (Dissolved hydrogen) 4.0 ppm (Dissolved ozone) 4.0 ~ 1.0 ppm (Dissolved ozone )
Output Features Hydrogen Water Ozonated Water
Apply Inow Quality
Apply Power
Power Consumption
Dimension
Net Weight
Municipal Water ( Conductivity <500μs/cm , pH : 6.8 ~ 8.0 ）
AC - 100 ~ 240V / 60 ~ 50Hz
60W
300(W)＊165(D)＊400(H) [mm]
7.5 kg（Around 9.5 kg when filled with water）
90 Litre / hour（1.5 Litre / min） 180 Litre / hour（3.0 Litre / min）

Installation
Package Contents
Owner’s Manual ( x1)
Water Outlet Tube (x1)
Input Hose ( PE, white, 1.5 m )
Plumber’s Tape ( x1 )Drain Hose ( PVC, black, 1.5 m )
Connecting Adapter Mounting Bracket ( x1 ) with Screws ( x2 )
HOS Unit ( x1 )
6
Drain Clamp

Installation
Unit Overview
Front View HOS Unit
Rear View HOS Unit
Water Outlet Cap
LCD Display
Operational touch pad
Front Case
Water Outlet Tube
Hanging Grooves
Rear Case
Drain Fitting
Source Water Fitting
Power Cord
Note: The Water Outlet Cap comes with a removable plug that needs to be removed
prior to Water Outlet Tube installation. Please see page 12 for further instruction.
7

Installation
LCD Display & Control Panel
8
• Lighting up when system is refilling water for
iEOG module.
• Blinking during :
- Re-start protection ( 30 min )
- Drinking water pre-flush ( 5 sec )
- Automatic cleaning and disinfection
( 10/13 sec )
• Blinking fast when system notifying error:
- Consumable parts’ life ending.
- Faulty iEOG Cell.
- iEOG water refill timeout.
• Lighting up when system is ready.
• Blinking during drinking pre-flush
• Temperature display symbol.
• Lighting up when specific function is selected.
• ORP displays during Hydrogen Water outflow.
• Concentration displays during Ozonated
Water outflow.
• Metering performance recharge
• Power cut statistical notification
- Phase 1: showing accumulated number of
power off.
- Phase 2: Displaying " " and accumulated
number of power off.
/
/
/

• Level Indicator
Hydrogen Water Button
Ozonated water button
• Blinking when:
- Showing power cut statistical notification
- Exceeding power cut limit
(equivalent to E75)
9
Installation
• Service Notification:
- Blinking slowly for 2% life Remaining
notification.
- Lighting up when service is due.
• Call customer service notification, displayed
when:
- Consumable parts’ life ending.
- Faulty iEOG Cell.
- iEOG water refill timeout.
• Metering life-cycle consumption for :
- iEOG module
- iEOG Pre-Stablizer

Consult your local Biolux dealer for installation arrangements. The information described below in this
section is intended for user’s reference.
The most common configurations for home kitchens are discussed here. For additional installation options
or questions on your specific installation, please contact your regional Biolux service provider.
Determine if you will install the unit directly with as a counter-top setup or to mount it above and/or next to
a sink:
The HOS can either be placed on a solid and flat surface as a counter-top setup, or wall-mounted above or
next to a sink. To mount the HOS on the wall, please follow the directions below:
Instruction 1 - Counter Top or Wall Mount
Installation
Tool You Will Need
Drill two 6 mm holes in the wall 450 mm above the top of the sink or counter. The distance between the 2
holes must be 100 mm :
Press the plastic anchor inserts into the holes as pictured below. Push the plastic anchor insert so that the
opening is flush with the wall.
Place the mounting bracket on the wall and fix with screws as pictured below. Hang the HOS on the
mounting bracket.
6mm
100mm
1.
2.
3.
10
How to Install the Unit

Installation
11
Instruction 2 - Water Source Connection
Actual plumbing may vary in design, and your situation may require different setup instructions than those
featured in this manual. Please consult a qualified service professional if you are unable to correctly
complete the installation.
1. Shut off both hot and cold water main supply at pipe under the sink
2. Locate the cold water supply line valve
3. Disconnect faucet cold water supply line from main cold water pipe – use towel to catch small amount of
water that may come from faucet supply line
4. Connect connecting adaptor to cold water pipe, be sure to use plumbing pipe thread seal tape to prevent
leaks
5. Reconnect faucet cold water supply line to the connecting adaptor (now secured to main cold water pipe)
6. Be sure all connections are secure but do not over tighten
7. Drill a 10mm hole in your counter-top to accommodate the cold water supply line from the under-sink
connection to your HOS.
NOTE.
Do not turn on main water supply until all hoses are
properly installed to the unit. Unit and components
are subject to change without prior notification in
order to enhance performance.
POWER AND WATER MUST BE CONNECTED AND
STAY ON AT ALL TIMES DURING OPERATION.
Under-Sink Installation
Fittings included
Hose
Cool Water
Adapter
To your existing faucet
Water
flow
direction
Input hose
Screw anchors
Diverter & Valve
Washer
ID 1/2”
OD 1/2”

Lock nut
Lock nut
Input/Drain hose
Input/Drain hose
Hose fitting
12
Installation
Instruction 3.1 - Connect Water Outlet Tube
Place the unit on the planned installation location and remove the plastic cap positioned at the top of the
unit (rotating water output cap) to locate the water outlet hole. Screw the flexible tube anti-clockwise into
the water outlet hole. Do not over tighten.
Instruction 3.2 - Connection Water Input and Drain Hoses
Remove the joint tube from the source water fitting inlet and drain fitting on the back of the unit (the joint
tube is used for shipping purposes only). Remove the lock nut from the source water fitting. Slide the lock nut
over the input hose. Be sure the input hose is cut straight. Insert the end of the input hose into the fitting
(Cold Water In). Tightly screw the nut back onto the fitting to secure the input hose into place.
Next, connect the water inlet hose to main water supply through Pre-Filter (iEOG Pre-stabilizer), and attach
connector hose supplied to the drain fitting.
Instruction 3 - Water Hose Connection
Carefully screw the tube into the
outlet base as the arrow direction
on sticker.

13
Installation
Instruction 4 - Drain Setup
Determine if you will directly place the drain hose in the sink or connect the drain hose to sink drain pipe
(under-sink):
Option A – Sink Placement :
Attach the hose with the suction holder (not included) to your sink wall surface. (ask from your dealer if
prefered in this way)
Option B – Under-Sink Connection : (recommended)
Drill a 10 mm diameter hole into the sink drain pipe and install the drain hose with the drain outlet clamp
(included) into the drain pipe.
Installation Diagrams
1. Counter-top installation & under-sink
connections for both input and drain.
2. Wall-mount installation & under-sink
connections for both input and drain.
Drain clamp
Input water hose
iEOG Pre-stabilizer
Diverter & Valve
Drain hose Input water hose
iEOG Pre-stabilizer
Mounting Bracket
Plastic anchor
inserts
Screw
Diverter & Valve
Drain clamp
Drain hose

Operation & Use
Unit Start-Up
Connection Check
Initial Start-Up
Conditionally Shut-Down
• The HOS is intended for constant power-on, unless in necessary situations, such as before machine
servicing activities.
The following sequence of steps must be followed for manual shut-down:
1. Shut off water supply.
2. Turn off the system by un-plugging the cord from the wall outlet.
Note: Disconnecting the power frequently may cause unexpected impacts on the iEOG module and
result in degradation to the product performance. 36 times of power off in a year will void warranty.
14
Confirm all below points prior to start-up:
1. All inputs, output and drain are correctly installed to their corresponding connections.
2. Ensure that the unit is connected to cold water supply input.
3. The power supply meets the requirements as indicated in the product specifications.
4. Input water pressure is 2.0~7.0 kg/cm (29~100psi).
5. The area of operation is well ventilated.
2
The unit is switched ON by plugging the cord into wall outlet (power supply). There is no ON/OFF control
switch. Before plugging unit into wall outlet, all plumbing works should be completely set up.
To use the machine at the first time, connect the unit to power to switch on and the system preparing
indicator “ ” will light up on the display panel. At this point, the unit is in preparation stage
refilling water for iEOG start-up. This process will take about 30 minutes.
Note: Draining during this stage is normal.
Once this preparation phase is complete, the “ ” will go out automatically, and “ ” will
light up, indicating the unit is now ready for use. At this point, the panel displays the detected internal
system temperature on the display panel, too.

15
Re-Start & 30 Minutes Re-Start Protection
The unit can be switched OFF by un-plugging the cord from wall outlet (power supply). Before
shutting down the unit, the water supply to the unit should be completely turned off.
To re-start the unit, connect the unit to power to switch on. In system re-starting, all functions are
suspended for 30 minutes along with “ ” flashing slowly (blink/0.5 sec). During this waiting
period, maintenance program is running at background for self-check.
1. 20 SEC Ozonated Water Outflow
2. 5 MIN Ozonated Water Outflow
Beep~
Once
Press once on the lower button and again to stop
Disinfection
The specific “ ” icon flickers during water outflow. If the button is
not pressed again, the unit will automatically stop after 20 seconds
of water outflow.
The specific “ ” icon flickers during water outflow. If the button is
not pressed again, the unit will automatically stop after 5 minutes
of water outflow.
Water outflow stop: Lightly press the button again to stop water
flow.
Note: remember, a LIGHT PRESS is all that is required when
pressing the two functional buttons.
ONE SEC
Beep~
Twice
Press & hold for 1 sec on the lower button and again to stop
Disinfection
Beep~
Once
0.2 SEC
0.2 SEC
Press once on the upper button and again to stop
Drinking
The specific “ ” icon flickers during water outflow. If the button
is not pressed again, the unit will automatically stop after 5
minutes of water outflow.
1. 5 MIN Hydrogen Water Outflow
Directions for Product Use
To Select Hydrogen Water
To Select Ozonated Water
Select a desired water mode: you can choose between Hydrogen Water for Drinking (pressing the upper
button) or Ozonated Water for Disinfection Use (pressing the lower button) following the below instructions:
Operation & Use

16
Other Functions
The HOS Series measures system's internal temperature and displays it on the display panel for user’s
reference. This display under all states as a primary display comes as default in any new unit.
Press and hold the upper button for 10 seconds (beep twice) during system standby, then Press and hold
the lower button for 5 seconds (beep twice) to switch the readings between degree Celsius (°C) and
Fahrenheit (°F).
Parts life Cycle Displays
The HOS records Remaining Life Cycle of each consumable part for operator’s reference. The information is
displayed on the display panel. Press and hold the lower button for 5 seconds during system standby, then
press the upper button to switch the display for each of the consumable parts equipped in the units for
regular check purpose.
The first two digits are the item indicated by coding, and the last two indicate the Remaining Life Cycle of
the part in percentage (%). The codes are interpreted as follows:
Operation & Use
Drinking pre-flush
Temperature Displays
Drinking pre-flush lasts 5 seconds and is performed during hydrogen water outflow after more than 20
minutes of non-operation, or each time if ozonated water outflow has been used previously within the 20
minutes. “ ” , “ ” and “ ” will blink slowly on the display panel of the unit, indicating this
flushing mode. After 5 seconds, the selected “ ” water mode will be dispensed.
Automatic cleaning
Automatic cleaning lasts 10 seconds and is performed during system stand-by after more than 1 hour of
non-operation. Icon “ ” will light on as an indication. Internal tubing will be flushed by filtered water
and the water will be discharged through the drain. All functions are suspended during this cleaning and
disinfection process !
Automatic disinfection
Automatic cleaning lasts 13 seconds and is performed 24 hours of operation since start-up. Icon “ ”
will light on as an indication. Internal tubing will be washed and sanitized by ozonated water and the water
will be discharged through the drain. All functions are suspended during this cleaning and disinfection
process !

Part Coding Coding Interpretation
Wording translation: OG99
Indicated part: iEOG Cell
Interpretation: Remaining life 99% for iEOG Cell
17
Wording translation: ro99
Indicated part: Reverse Osmosis (RO) Module
Interpretation: Remaining life 99% for RO Module
Wording translation: dI99
Indicated part: Deionizer (DI) Module
Interpretation: Remaining life 99% for DI Module
Wording translation: du99
Indicated part: Off-Gas Destructor
Interpretation: Remaining life 99% for Off-Gas Destructor
Wording translation: Fn99
Indicated part: System Cooling Fan
Interpretation: Remaining life 99% for Fan(s)
Wording translation: IP99
Indicated part: Input hose (IP)
Interpretation: Remaining life 99% for IP
Service Notication Displays
The HOS can display various Service Codes as notifications to users when standard service is
required. The information is displayed on the display panel. Please contact your regional BioLux
Dealer for service arrangements when the code(s) are present.
For Remaining Lifecycle of any consumable part that is recorded, the unit will provide service
notification once the service or replacement is required. The Service Notification will be displayed in
two different modes according to the degree of urgency: “2% Remaining Notification” and “Life
Ending Notification” :
Operation & Use

18
Service Code Service Requirement Interpretation
Wording translation: S11
Coding Interpretation:Replace iEOG Pre-Stabilizer
Wording translation: S14
Coding Interpretation:Replace Reverse Osmosis(RO)module
Wording translation: S32
Coding Interpretation:Replace Deionizer(DI) module
Wording translation: S34
Coding Interpretation: Replace Off-Gas Destructor
Wording translation: S38
Coding Interpretation: Replace all Fans
Wording translation: S39
Coding Interpretation:Replace Input hose
(iEOGPre-Stabilizer pipes for both input & output)
Wording translation: S71
Coding Interpretation: Replace iEOG Cell
• 2% Remaining Notification
In this mode, “ ” is flashing in slow mode, 2 beeps are sounded when pressing any key.
At this time, the user should contact the local Biolux dealer to schedule a service and part replacement
within 3-week time.
• Life Ending Notification
In this mode, 10 second buzz will be sounded when the state occurs, “ ” lights up, 5 beeps
are sounded when pressing any key. All functions are suspended.
At this time, the user should contact the local Biolux dealer to schedule a service and part replacement
IMMEDIATELY.
The coding for each service requirement and the interpretation is listed as follows:
Operation & Use

19
Operation & Use
Error Code Error Interpretation
Wording translation: E10
Error Interpretation: iEOG Cell fails.
All functions are suspended.
Error Notications Displays
Power O Statistical Inspector Warning
For following detectable errors, once detected, the codes will be displayed on the display panel:
Wording translation: E45
Error Interpretation: preparation (timeout) iEOG water refilling
fails during. All functions are suspended.
Wording translation: E75
Error Interpretation:Power supply failure or power
disconnection exceeds 15 times a yearrecorded.
To maintain the system’s best performance, power must be connected at all times. Unless in
necessary situations, such as due to servicing activities or supply outage that may occur occasionally
and/or unexpectedly, attempt and care should be made in order to avoid any man-made incidence
of power off. Disconnecting the power frequently and too many times may cause unexpected
impacts on the iEOG module and will result in degradation to the product performance.
Note. to keep the warranty vaild, power off should not exceed 36 times in an operating year (3 times
per month).
Associated with the accumulated number of times of power off, system notification will be provided
with two phases. Phase 1 is to be provided as a reminder to the recorded number at the time, whereas
phase 2 notifies the limitation reached and invalid warranty on the iEOG cell, i.e., 36 times of power
off recorded in an operating year.
