Bionic fire RAIS User manual



1





















UserManualforNewZealand
ENVRIONMENTALLYFRIENDLYFIRE
EnviroSolveLtd
ExclusiveAgentforNewZealand
DrReneHaeberli
OhakuneRoad
RD3
Raetihi
Phone:064854871
Mobile:0212424211
Email:[email protected]
Web:  www.envirosolve.co.nz

Authorisationnumber:152619 (AS/NZS4012/4013)
Authorisationnumber:154319(ULEB)
Websiteforauthorisedburners:
http://ecan.govt.nz/services/online‐services/pages/authorised‐solid‐fuel‐burners.aspx



2

Contents
1.5Eco‐friendlyadvicesforsensibleheating.............................................................................4
2.Introduction...........................................................................................................................5
2.1Warranty.......................................................................................................................................5
3.Bionicfirespecification..........................................................................................................6
4.Installationinstruction...........................................................................................................7
4.1Warning:HealthandSafetyadvicenotice....................................................................................7
4.1.1Handling.................................................................................................................................7
4.1.2FireCement............................................................................................................................7
4.1.3Asbestos.................................................................................................................................7
4.1.4MetalParts.............................................................................................................................7
4.1.5ImportantWarning–PreparatoryWorkandSafetyChecks.................................................7
5.Installation.............................................................................................................................8
5.1Installationdistanceincaseofcombustiblewalls........................................................................8
5.1.1ClearanceDistance–ParallelPosition............................................................................9
5.1.2.ClearanceDistance–CornerPosition...............................................................................9
6.Fortheinstaller.....................................................................................................................10
6.1Operatinginstructions................................................................................................................10
6.1.1Fuel................................................................................................................................10
6.1.2Dryingandstorage........................................................................................................11
6.1.3Roomventilationandstoves...............................................................................................11
6.2Stovefunctioning........................................................................................................................11
6.2.1Automaticregulationforcombustionair............................................................................12
7.FirstUsage............................................................................................................................13
8.ImportantSafetyAdvice............................................................................................................14
8.1.Tipsbeforefiringup...................................................................................................................14
8.2‘Top‐down’Lighting....................................................................................................................14
8.3Warning!.....................................................................................................................................16
8.4CleaningandCare.......................................................................................................................17
8.4.1Glass.....................................................................................................................................17
8.4.2Paintfinish...........................................................................................................................17
8.4.3Mechanicalcleaning............................................................................................................17
8.4.4.Prolongedperiodofnon‐use..............................................................................................17
8.4.5Cleaningthecombustionchamber.
.....................................................................................18
8.4.6Cleaningofflueways...........................................................................................................19





3


9.Interruptionofoperation......................................................................................................21
9.1.Smokespillagearoundthedoor................................................................................................21
9.2Sootonglass...............................................................................................................................21
9.3Stoveisburningtoostrong.........................................................................................................21
9.4Stoveisburningtooweakly........................................................................................................21
10.Securethefire.........................................................................................................................22
Appendix......................................................................................................................................23
1.Drawingsforthesparepart......................................................................................................23
2.Legendforthespareparts........................................................................................................24
3.Technicaldrawingofthebionicfire..........................................................................................25




























4


1. 5Eco‐friendlyadvicesforsensibleheating

 Effectivelighting:usedrybrushwood,kindlingandpossibleapieceofnewspaperor
afirelighter
 Lightthefirewithonlylittlewoodatthetime–thisgivethebestcombustion
 Leanthedoortocatchfor5–10minutesuntilanicefirehasestablished
 Shutthedoorproperlyafterwards
 Useonlydrywood‐i.e.woodwithahumidityof15–22%

Theoveniswrappedinpackagingthatisrecyclable.Thismustbedisposedaccordinglyto
nationalruleregardingthedisposalofwaste.
Theglasscannotbereused.
Theglassshouldbediscardedalongwiththeresidualwastefromceramicsandporcelain.
Pyrexglasshasahighermeltingtemperatureandthereforecannotbereused.
Ifdiscardedyoumakeanimportantpositivecontributiontotheenvironment.













5

2. Introduction

ThankyouforpurchasingaRAISwoodburningstove.
ARAISwoodburningstoveismorethanjustaheatsource.Italsoshowsthatyoucare
aboutdesignandqualityinyourhome.
Tomakethemostofyourwoodburningstoveitisimportantthatyoureadthemanual
thoroughlybeforeinstallingandusingit.
Inthecaseofwarrantycoverageandforgeneralqueriesregardingyourwoodburning
stove,itisimportantthatyouknowthestove’sproductionnumber.We,therefore,
recommendthatyounotedownthenumberinthetablebelow.Theproductionnumberis
locatedonthebackofthestoveatthebottom.
2.1Warranty
YourRaiswoodburningstovecomewitha5yearwarranty.Thewarranty,however,does
notcoverheat‐insulatingmaterials,glassandseals.
Theappliancemustbeservicedandmaintainedusingpartsapprovedbythe
manufacturer,toachievetheproperperformanceoftheappliance.
Anyalterationsmadetothestovewillvoidthewarranty.

Thenameisaregisteredtrademark.


Date:…………………………………
Distributor:EnviroSolveLtd
 OhakuneRoademail:[email protected]
 RD3phone: +64(0)63854871
 Wanganuimobile:+64(0)212424211
 NewZealandwww.envirosolve.co.nz




6

3. Bionicfirespecification































NominalOutput(kW)4.6
 
Min./Max.Output(kW)3.9–4.6
 
Heatingarea(m2)45‐83
 
Stove'swidth/depth/height(mm)withoutsocket472‐482‐1064
 
Combustionchamber'swidth/depth/height(mm)
Uppercombustionchamber280‐200‐300
 
Recommendedamountofwhenfuelling(kg)
Distributedp1‐2logsofwoodapprox.25cm1.1
 
Weightsocketincluded(kg)approx.180kg
 
Intermittentoperation
Refuellingshould
beundertaken
within11/2hours




7

4. Installationinstruction

Thefollowingpagesgiveinstructionsforthesafeandproperinstallationofthisheating
applianceinNewZealand.Theseinstructionscoverthebasicprinciplesofinstallation,
althoughdetailmayneedslightmodificationtosuitparticularlocalsiteconditions.Inall
casestheinstallationmustcomplywiththecurrentNewZealandBuildingRegulations,local
authoritybyelawsandotherspecificationsorregulationsastheyaffecttheinstallationof
thestove.PleasenotthatitisalegalrequirementunderNewZealandBuildingRegulations
thattheinstallationofthestoveiseithercarriedoutunderLocalAuthoritybuildingcontrol
approvalorisinstalledbyacompetentpersonregisteredwithagovernmentapproved
competentpersonscheme.

4.1Warning:HealthandSafetyadvicenotice

Ensuretheheaterisinstalledinaccordancewithallcurrentlocalbuildingandsafety
regulations.Attentionisdrawninparticulartothefollowing.
4.1.1Handling
Theapplianceisaheavyitemandadequatefacilitiesmustbeavailableforloading,
unloadingandsitehandling.
4.1.2FireCement
Sometypesoffirecementarecausticandshouldnotbeallowedtocomeintocontactwith
theskin.Protectiveglovesshouldbewornwhenhandlingfirecement.Incaseofcontact
withskintheskinshouldbewashedimmediatelywithplentyofwater.
4.1.3Asbestos
Thisstovecontainsnoasbestos.Ithereisapossibilityofdisturbinganyasbestosinthe
courseofinstallationthenpleaseseekspecialistguidanceanduseappropriateprotective
equipment.
4.1.4MetalParts
Wheninstallingorservicingthisstovecareshouldbetakentoavoidthepossibilityof
personalinjury.
4.1.5ImportantWarning–PreparatoryWorkandSafetyChecks

 Thisstovemustnotbeinstalledintoachimneythatservesanyotherheating
appliance.

 Itisrecommendednottohaveanextractorfanfittedinthesameroomasthestove
asthiscancausethestovetoemitfumesintotheroom.





8

5. Installation

Theisafreestandingstoveandhasasteelsocket.
Thestovemustbesetupandinstalledinaccordancewithallcurrentnationalandlocalrules
andregulations.Localauthoritiesandachimneyspecialistshouldbecontactedpriortoset
up.
Itisprohibitedtocarryoutunauthorizedalterationstothestove.
Theremustbeplentyoffreshairintheroomwherethestoveisbeinginstalled,inorderto
ensurepropercombustion.Notethatanymechanicalexhaustventilation‐i.e.an
extractionhood‐mayreducetheairsupply.Anyairgratesmustbeplaceinsuchamanner,
thattheairsupplyisnotblocked.
Thefloorstructuremustbeabletocarrytheweightofthewoodburningstoveaswellas
theweightofthechimney,ifnecessary.
Thefireisplacedonfireproofmaterial.
WhenyouchoosewheretosetupyourRAISwoodburningstove,youshouldconsiderthe
heatdistributiontotheotherrooms.Thiswillenableyoutogetthebestuseoutofyour
stove.Thestoveshouldbesetupatasafedistancefrominflammablematerial.

Uponreceivingthestovemustbeinspectedfordefects!

5.1Installationdistanceincaseofcombustiblewalls

Todeterminewhetherthewallnexttowherethestoveisgoingtobeinstalledisflammable,
youshouldcontactyourbuildingcontractororthelocalbuildingauthorities.
Thehearthshouldbeabletoaccommodatetheweightforthestove.Theweightofthe
stoveisindicatedinthebrochure.
Ifthestoveistobeinstalledonawoodenfloor,itmustbecoveredwithanon‐combustible
materialatleast12mmthickinaccordancewithNewZealandBuildingCode.
Theclearancedistancetocombustiblematerialbeneathsurroundingoruponthehearth
andwalladjacenttothehearthshouldcomplywiththeguidanceoftheNewZealand
StandardAS/NZS2918‐2001AppendixB.










9

5.1.1 ClearanceDistance–ParallelPosition

Parallel Position Clearance Distance Position Clearance
(mm)
(A) Rear 100
(B) Side 250
(C) Floor
protector
(front) 300
(D) Floor
protector
(side) 200
(E) Flue
(rear)
5.1.2.ClearanceDistance–CornerPosition

Corner Position Clearance Distance Position Clearance
(mm)
(F) Side 120
(G) Side 120
(H) Floor
protector
(front) 300
(I) Floor
protector
(side) 200
(J) Flue
(rear)
*Note that this temperature passed within the laboratories margin of uncertainty.
Technical Note: !No flue shield is required!
1. The clearance measurement A, B, F and J were taken from the distance between walls and
closest point of the appliance, C and H was measured from the front of the fuel-loading
opening to the edge of the floor protector, D and I was measured from each side of fuel-
loading opening, E and J were calculated from the flue’s centre to the rear wall.
2. The flue was installed onto the flue spigot, extended centrally and vertically without bend
before and after penetration of the ceiling plane.
3. Drawings shown above are not to scale.
A
B
C
E
D
D
F
G
H
J
I
I



10

6. Fortheinstaller

Finally,beforefiringthestovethefirsttimeacheckshouldbemadetoensurethatthe
assemblyandstoveinstallationhasbeensatisfactoryandthattherearenoleaksinanyseals
intheapplianceandapplianceconnectionstothechimney.
Ensurethattheapplianceandthechimneyfluearefunctioningcorrectlybeforefinally
handingovertotheuser.Ifnecessaryreadthelaterpartsofthismanualforguidanceon
carerequiredwhenfirstlighting.
Informtheuserthattheappliancehasbeencommissionedandreadytouseandgive
instructiononthesafeoperationofthestove.
Theseinstructionsmustbeleftwiththeuserandtheusershouldbeinstructedtokeep
theminasafeplace.

6.1Operatinginstructions

Pleasenotethattheapplianceapprovalonlycoverstheuseofdryseasonedwoodlogson
thisappliance.Thisapprovaldoesnotcovertheuseofotherfuelseitheraloneormixed
withthewoodlogsnordoesitcoverinstructionsfortheuseofotherfuels.

6.1.1 Fuel

ThestoveisdesignedandapprovedinaccordancewithAS/NZS4012/4013andAS/NZS
2918‐2001AppendixBforstockingdriedfirewood.Thefirewoodmusthaveawatercontent
of15–22%anditmaximumlengthshouldbethewidthofthecombustionchamberminus
50–60mm.
Stockingwithwetfirewoodcausesbothsootandenvironmentalpollutionandisbadfuel
economy.Freshlycutwoodcontainsapprox.50–70%waterandisthoroughlyunsuitable
forstocking.
Countmin.1yearofstoragetimefornewlycutwoodbeforeusing.
Woodwithadiameterofnomorethan100mmshouldbesplit.Regardlessofwoodsize,it
shouldalwayshaveatleastonesurfaceareafreeofbark.
Thefollowingfuelsareprohibitedandmustnotbeused:Painted,laminatedortreated
(impregnated)wood,woodwithasyntheticsurface,paintedrefusewood,chipboard,
plywood,domesticwaste,paperbriquettesandpitcoal,asthiswillproducemalodorous
smoke,whichcouldbepoisonous.Theuseofsuchfuelsmaydamagetheapplianceandwill
voidthewarranty.
Whenfiringwiththeabovementioneditemsandtheamountslargerthanthose
recommended,thestoveissubjectedtoalargeramountofheat,whichresultsinahigher
chimneytemperatureandlowerefficiency.Thiscanresultinthestoveandchimney
becomingdamagedandwouldvoidthewarranty.



11

Thecalorificvalueofthefirewoodiscloselyconnectedtothemoisturelevelofthe
firewood.Moistfirewoodhasalowheatvalue.Themorewaterthewoodcontainsthe
moreenergyittakesthiswatertovaporizeresultinginenergyisbeinglost.

6.1.2 Dryingandstorage

Dryingwoodtakestime.Properairdryingtakesapprox.2years.
Heresometips:
 Storethewoodsawn,splitandstackedinanairy,sunnyplace,whichisprotected
againstrain.
 Storefirewoodstacksatahand’sbreadthapartasthisensuresthattheairflowing
throughtakesthemoisturewithit.
 Itisagoodideatobringthefirewoodintothehouse2–3daysbeforeyouneedit.

6.1.3Roomventilationandstoves

Ifthereisanextractorfaninthesameroomasthebionicfirepleasemakesurethatthe
bionicfireisnotcloserthan2metertotheextractorfan.
Thestoverequiresapermanentandadequateairsupplyinorderforittooperatesafelyand
efficiently.
Inaccordancewiththecurrentbuildingregulationtheinstallermayhavefittedapermanent
airsupplyventintotheroominwhichthestoveisinstalledtoprovidecombustionair.This
airventsshouldnotunderanycircumstancebeshutofforsealed.

6.2Stovefunctioning

Thestovehas2combustionchambers:
 Theuppercombustionchamber(UCC)isforkindlingandre‐fuelling
 Thelowercombustionchamber(LCC)isforthepost‐combustionandmustnotbe
usedforkindlingandre‐fuelling.








Dome
UpperCombustion
Chamber(UCC)
LowerCombustion
Chamber(LCC)



12

Apost‐combustionprovidesagoodusageoffuelenergyandanalmostcomplete
combustionofthetoxicandharmfulsubstancesfromthesmoke.
UponlightingtheairflowsthroughtheUCCandtothefluepipe(chimney).Whenthestove
reachesacertaintemperaturetheairflowisdivertedandthestillunburnedgassesarelead
fromtheUCCthroughanopeninginthebottomstoneplatetotheLCC.Overtheopeningis
asteeldomeplaced.
FlamesarethusleadthroughtheopeningtotheLCCforpost‐combustionofthegases.

6.2.1Automaticregulationforcombustionair

Thestoveisequippedwithanindependentandself‐regulatingairdamper.Hencethereisno
damperhandle.
Theprimaryairisaddedtotheprimarycombustionzone,i.e.thebedofglowingembers.Thecold
airisonlyusedinthelightingstage.
Secondaryairisaddedinthegascombustionzone,i.e.airwhichcontributestothecombustionof
thepyrolysisgases(preheatedair,whichisusedforthecleanerglasssystemandthecombustion).
Thisisairsuckedthroughthedamperandispre‐heatedthroughthesidechannelsandthenemitted
ashotscavengingairontotheglass.Thehotairrinsestheglassandkeepsitsootfree.
Acleancombustionisindicatedbyclearyellowflames.
Thepilotnozzlesareplacedinthebackplateoftheuppercombustionchamber.Theyensurethat
thebedofglowingembersisfedwithairandthereforeholdsahightemperature.Itprovidesaquick
startwhenre‐fuellingandreducestheriskoffiregoingout.



Important!‐duringkindling/refuelling

Ifanashpanisuse,itmustbeplaced
atthebottomonlowercombustionchamber.












13

7. FirstUsage

Important:
Placewoodonlyintheuppercombustionchamber.Thisappliesforkindlingand
re‐fuelling.
Acarefulstartpaysoff.Startwithasmallfire,sothatthewoodburningstovecanget
accustomedtothehightemperature.Thisgivesthebeststartandanydamageisavoided.

 Beawarethatastrangebutharmlessodourandsmokeconcoctionmayemanate
fromthesurfaceofthestove,thefirsttimeyoufireup.Thisisbecausethepaintand
materialsneedtoharden.Theodourdisappearsquickly,butyoushouldcheckthe
ventilationanddraught,ifpossible.Seealsotheimportantwarningnoticebelow
aboutpersistentfumes.
 Duringthisprocessyoumustbecarefulnottotouchthepaintedsurfaces.Itis
recommendedthatyouregularlyopenandclosethedoortopreventthedoorseal
fromsticking.
 Thestovemayalsoproduces‘clickingnoises’duringheatingandcoolingcausedby
thelargetemperaturedifferenceswitchthematerialissubjectedto.
 Neveruseanytypeofliquidfuelforkindlingormaintainingthefire.Thereisa
dangerofexplosion.
 Thestovegetsveryhotwheninuse.Alwayswearprotectivegloveswhentending
thestove.
 Ifthestovehasnotbeenusedforawhile,followthestepsasifyouwereusingitfor
thefirsttime

ImportantWarningNote!
Properlyinstalled,operatedandmaintained,thisappliancewillnotemitfumesintothe
dwelling.Occasionalfumesfromde‐ashingandre‐fuellingmayoccur.However,persistent
fumeemissionispotentiallydangerousandmustnotbetolerated.Iffumeemissiondoes
persistthefollowingimmediateactionsshouldbetaken:
 Opendoorsandwindowstoventilatetheroom.
 Letthefireoutorejectandsafelydisposeoffuelfromtheappliance.
 Checkforflueorchimneyblockageandcleanifrequired.
 Donotattempttorelightthefireuntilthecauseofthefumeemissionhasbeen
identifiedandcorrected.Ifnecessaryseekexpertadvice.

ImportantWarningNote!
Donotuseanaerosolsprayonornearthestovewhenitisalight!





14

8.ImportantSafetyAdvice

Whenusingthestoveinsituationswherechildren,agedand/orinfirmpersonsarepresenta
fireguardmustbeusedtopreventaccidentalcontactwiththestove.Thefireguardshould
bemanufacturedinaccordancewithallcurrentlocalbuildingandsafetyregulation.

Lightingandfuelling
Note:
 Iftheairsystemisconnectedthevalvemustbeopen.
 LoadingthestovewithlargeramountsofwoodfuelthanisrecommendedinSection
8oftheseinstructionsmaygenerateexcessiveheat.Thismayalsodamagethe
applianceandvoidthewarranty

8.1.Tipsbeforefiringup

Openadoororwindowclosetothewoodburning.Ithereisa‘storm’inthestovecoming
fromthechimney,itisadvisabletoplaceascrewed‐uppieceofnewspaperbetweenthe
upperbaffleplateandthechimney,setthepaperonfireandwaituntilyouheara
‘rumbling’noiseinthechimney.Thismeansthereisdefinitelyadraughtinthechimneyand
avoidsmokeintheroom.

8.2‘Top‐down’Lighting

 Openthedooranlockitusingthesmallbracketatthebottomofthedoor.

 

 Startbyplacing1pieceofsplitlog–approx.1kg–atthebottomoftheupper
combustionchamber(UCC)infrontofthedometothesmallfrontglass.
 Placeapprox.1.2kgofdryfirewood,splitintokindlingsticksbehindtheloganda
coupleofalcoholbriquettes(firelighter)orsimilar.
 Lightthefireandclosetheupperconvectionplateofthestove.






15




 Closethedoorandleaveitajarbytippingthehandle.






 Whenthefirehascaughtthekindlingclosethedoorcompletely(approx.5–10
minutes).
 Whenthetemperaturereachesacertainvaluethedamperwilldivertthesmoke.
Thiscausesadownwardflameformtheupper(UCC)tothelowerchamber(LCC).
 Whenthelastflamesareextinguishedandthereisanicelayerofembersadd1–2
pieceswood(about1½kg).Placethewoodontopofthedomeattherearofthe
UCC.Closethedoorcompletely.
Note!
Ifthefirehasburneddowntoolow(toosmallember)itmaytakelongerfortheflamesto
bedivertedtotheLCCandthusachieveacleanerburns.
Whenfiringthesmokeoutofthechimneyshouldbealmostinvisible–justa‘flicker’inthe
airisobserved.
Whenre‐fuelling,openthedoorcarefullytoavoidsmokesescaping.Neveraddwoodwhile
itisburning(flames!)inthestove.
RAISrecommendre‐fuellingwith1–2pieceswood(approx.1–1½kg)within1½hours
(intermittenceoperation).

Attention!
Keepaneyeonthestovewhenlighting.Duringtheoperationthedoorshouldalways
remainshut.

Control
Lookforsignsthatindicatedacorrectfiringinthestove:
 Ashiswhite
 Thewallsofthecombustionchamberarefreeofsoot
 Thewoodissufficientlydry




16




8.3Warning!

Ifthefirewoodisonlyburningslowlywithoutflamesorissmokingandtoolittleairisadded,
unburnedexhaustgasesaredeveloped.
Exhaustgasescanbeignitedandexplode,leadingtodamagethematerialandpossible
injurepersonal.

























Ifthereareonlyafewembers
remainingyoumustlightthefireagain.
Ifyoujustaddfirewoodthefirewillnotbelit,
butunburnedexhaustgaseswilldevelop.
Herefirewoodhasbeenaddedtoanember
layerwhichistoosmall.Theairflowistoo
small–smokehasbeendeveloped.
Avoidheavysmoke–dangerof
exhaustgasexplosion.
Incaseofveryheavysmokeopenthe
doorandlightthefireagain.



17




8.4CleaningandCare
8.4.1Glass
Mostofthewoodstovesuseaceramicglassproductwhichisresistanttoheatbutrequires
cleaningtokeepitsappearance.
Sootoropaquemarkscanbeeasilycleanedifthemarksarefresh.However,iftheglassleft
dirtyforanylengthoftimetheacidfromthewoodcanetchthesurfaceoftheglass
permanently(wetunseasonedwood,softwoodsuchasusedinthebuildingindustryand
palletwoodshouldbeavoided.
Onlycleanwhencold.
Useonlystoveglasscleanerstoremoveheavytar/sootdeposits.Allothermarkscan
normallyberemovedwithadampcloth,thendrywithacleanclothornewspaper.Donot
lettheglassdrybeforeapplyingadrycleancloth.
Withmorestubbornmarksi.e.opaqueareas/frosting,youneedtoputasmallamountof
woodashonacleandampcloth.Iftheopaquemark/frostingdoesn’tcomeout,contactyou
dealerforaspecialremover.

8.4.2Paintfinish
Theappliancehasbeencoatedwithahightemperaturepaintwhichcanlastforyears.Do
notcleanwithadampclothoranycleaningproductsastheycancauserustordiscoloration.
Onlycleanwhencold,useabrushwithsoftbristlesordustwithalintfreecloth.Onlyre‐
spraywhennecessary.

8.4.3Mechanicalcleaning
Thewoodburningstoveandthechimneymustbeservicebyachimneysweepatleastonce
ayear.Duringcleaningandcare,thestovemustbecold.

8.4.4.Prolongedperiodofnon‐use
Ifthestoveistobeleftunusedforaprolongedperiodoftimethenitshouldbegivena
thoroughleantoremoveashandunburnedfuelresidues.Toenableagoodflowofair
throughtheappliancetoreducecondensationandsubsequentdamageleavetheair
controlsfullyopen.
Priortoanewhatingseasonitshouldbecheckedthatehchimneyandsmokegasconnector
arenotblocked.




18

8.4.5Cleaningthecombustionchamber.
Scrapeorshoveltheashoutandstoreitinanon‐flammablecontaineruntilithascooled
down.Youcandisposetheashwithyournormalhouseholdwaste.
REMEMBER!Neverremovealltheashesfromthecombustionchamber–thewoodwill
burnatitsbestwithalayerofashesofapprox.20mm.

Removegentlythesteeldomeandthesmallfrontglass(ashstop).







Regardingthecleaningoftheuppercombustionchambertheashpancanbeused.Thepan
isplacedunderneaththeUCCin2brackets.

















Theashpanmustnotremainundertheuppercombustionchamber:
 Thedoorcannotbeclosedandcanbedamaged.
Frontglass
(ashstop)
Dome
Ashpan
Bracket
Theashesaresweptontotheashpanand
disposedof.Replacetheashpaninitsposition
inthelowercombustionchamberagain.



19

 Theashpanwilldamagethespecialfunctionofthestove(afterburninginthelower
combustionchamber).



8.4.6Cleaningofflueways
8.4.6.1Uppercombustionchamber(UCC)
Inordertoaccessthefluewaysgentlyremovethesmokeconverterplate(vermiculite)by
tiltingIttoonesideandturningitalittleslantwise.



Pullouttheplatecarefully.Removedirtanddustandthepartsinreverseorder.
Note!Becarefulwhenreplacingthesmokeconverterplate.

8.4.6.2Lowercombustionchamber(LCC)





1. Onebracketfortheashpanunderneath
theUCCisremoved(useAllenkey4mm)



20





















Note!Becarefulwhenreplacingtheplates.
2. Thebottomplateisgentlyliftedoutofits
positionwithawideslottedscrewdriver
3. Thesideplateisgentlyremoved.
4. Thebackplateisgentlyremoved.
5. Removedirtanddustandmountthe
partsinreverseorder.
