BIOS Setup ................................................................................................ 1
1 Main Menu ............................................................................................. 3
2 Standard CMOS Features..................................................................... 6
3 Advanced BIOS Features ...................................................................... 8
4 Advanced Chipset Features................................................................. 14
5 Integrated Peripherals......................................................................... 17
6 Power Management Setup................................................................... 23
7 PnP/PCI Configurations...................................................................... 29
8 PC Health Status .................................................................................. 32
9 Performance Booster Zone.................................................................. 35

G31-M7/P31-A7
1
BIOS Setup
Introduction
The purpose of this manual is to describe the settings in the Phoenix-Award™
BIOS Setup program on this motherboard. The Setup program allows users to
mod ify the bas ic system configuratio n and save these s ettings to CMOS RAM.
The power of CMOS RAM is supplied by a battery so that it retains the Setup
information when the po wer is turned off.
Basic Input-Output System (BIOS) determines what a computer can do without
accessing programs from a disk. This system controls most of the input and
output devices suc h as keybo ard, mouse, s erial ports and disk drives. BIOS
activates at the first stage o f the boo ting process, lo ad ing and executing the
operating system. Some additional features, such as virus and password
protection or chipset fine-tuning options are also included in BIOS.
The rest of this manual will to guide you through the options and settings in
BIOS Setup.
Plug and Play Support
This PHOENIX-AWARD BIOS supports the Plug and Play Version 1.0A
specification.
EPA Green PC Support
This PHOENIX-AWARD BIOS supports Version 1.03 of the EPA Green PC
specification.
APM Support
This PHOENIX-AWARD BIOS supports Version 1.1&1.2 of the Advanced
Power Management (APM) specification. Power management features are
implemented via the System Management Interrupt (SMI). Sleep and Suspend
power management modes are supported. Power to the hard disk drives and
video monitors can also be managed by this PHOENIX-AWARD BIOS.

G31-M7/P31-A7
2
ACPI Support
Phoenix-Award ACPI BIOS support Version 1.0b of Advanced Configuration
and Po wer interface specific ation (ACPI). It provides ASL code for power
management and device configuration capabilities as defined in the ACPI
specification, developed by Microsoft, Intel and Toshiba.
PCI Bus Support
This PHOENIX-AWARD BIOS also supports Version 2.3 of the Intel PCI
(Peripheral Component Interconnect) local bus specific ation.
DRAM Support
DDR2 SDRAM (Double Data Rate Synchronous DRAM) is supported.
Supported CPUs
This PHOENIX-AWARD BIOS supports the Intel CPU.
Using Setup
Use the arrow keys to highlight items in most of the place, press <Enter> to
select, use the <PgUp> and <PgDn> keys to change entries, press <F1> for help
and press <Esc> to quit. The following table provides more detail about how to
navigate in the Setup program by us ing the keybo ard.
Keystroke Function
Up arro w Move to previous item
Down arrow Move to next item
Left arrow Move to the item on the left (menu bar)
Right arro w Move to the item on the right (menu bar)
Move Enter Move to the item you desired
PgUp key Increase the numeric value or make changes
PgDn key Decrease the numeric value or make changes
+ Key Increase the numeric value or make changes
- Key Decrease the numeric value or make changes
Esc key Main Menu – Quit and not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu – Exit
Current page and return to Main Menu
F1 key General help on Setup navigation keys
F5 key Load previous values from CMOS
F7 key Load the optimized defaults
F10 key Save all the CMOS changes and exit

G31-M7/P31-A7
3
1 Main Menu
Once you enter Phoenix-Award BIOS™ CMOS Setup Utility, the Main Menu
will appear on the screen. The Main Menu allows you to select from several
setup functions. Us e the arrow keys to select amo ng the items and press <Enter>
to accept and enter the sub-menu.
Figure 1: Main Menu
Stan dar d CMOS Features
This submenu contains industry standard configurable options.
Advanced BIOS Features
This submenu allows you to configure ad vanced features of the BIOS.
!! WARNING !!
For better system performance, the BIOS firmware is being
continuously updated. The BIOS information described in this
manual (Figure 1, 2, 3, 4, 5, 6, 7, 8, 9) is for your reference only.
The actual BIOS information and settings on board may be slightly
different from this manual.

G31-M7/P31-A7
4
Advanced Chipset Features
This submenu allows you to configure special chipset features.
Integrated Peripherals
This submenu allows you to configure certain IDE hard drive options and
Programmed Input/ Output features.
Power Management Setup
This submenu allows you to configure the power management features.
PnP/PCI Configurations
This submenu allows you to configure certain “Plug and Play” and PCI options.
PC Health Status
This sub menu allows you to monito r the hard ware of your s ystem.
Performance Booster Zone
This submenu allows you to change CPU Vcore Voltage and CPU/PCI clock.
(However, we suggest you to use the default setting. Changing the voltage and
clock improperly may damage the CP U or M/B!)
Load Optimized Defaults
This selection allows you to reload the BIOS when problem occurs during
system booting sequence. These configurations are factory settings optimized
for this s ystem. A confirmation message will be displayed befo re defaults are
set.

G31-M7/P31-A7
5
Set Supervisor Password
Setting the supervisor password will prohibit everyone except the supervisor
from making changes using the CMOS Setup Utility. You will be prompted with
to enter a password.
Set User Password
If the Supervisor Password is not set, then the User Password will function in
the same way as the Supervisor Password. If the Supervisor Password is set and
the User Password is set, the “User” will only be able to view configurations but
will not be able to change them.
Save & Exit Setup
Save all configuration changes to CMOS (memory) and exit setup. Confirmation
message will bedisplayed before proceeding.
Exit Without Saving
Abandon all changes made during the current session and exit setup.
Confirmation message will be displayed before proceeding.
Upgrade BIOS
This submenu allows you to upgrade bios.

G31-M7/P31-A7
6
2 Standard CMOS Features
The items in Standard CMOS Setup Menu are divided into several categories.
Each c ategory inc ludes no, o ne o r more than one s etup items. Use the arrow
keys to highlight the item and then use the<PgUp> or <PgDn> keys to select the
value you want in each item.
Figure 2: Standard CMOS Setup
Main Menu Selections
This table shows the items and the available options on the Main Menu.
Item Options Description
Date mm : dd : yy
Set the system date. Note
that the ‘Day’ automatically
changes when you set the
date.
Time hh : mm : ss Set the system internal
clock.
IDE Channel 0
Master/Slave
Options are in its sub
menu.
Press <Enter> to enter the
sub menu of detailed
options
IDE Channel 1
Master / Slave
Options are in its sub
menu.
Press <Enter> to enter the
sub menu of detailed
options.

G31-M7/P31-A7
7
Item Options Description
Drive A/B
None
360K, 5.25 in
1.2M, 5.25 in
720K, 3.5 in
1.44M, 3.5 in
2.88M, 3.5 in
Select the type of floppy
disk drive installed in your
system.
Video
EGA/ VG A
CGA 40
CGA 80
MONO
Select the default video
device.
Halt On
All Errors
No Errors
All, but Keyboard
All, but Diskette
All, but Disk/ Key
Select the situation in which
you want the BIOS to stop
the POST process and
notify you.
Base Memory N/A
Displays the amount of
conventional memory
detected during boot up.
Extended Memory N/A
Displays the amount of
extended memory detected
during boot up.
Total Memory N/A Displays the total memory
available in the system.

G31-M7/P31-A7
8
3 Advanced BIOS Features
Figure 3: Advanced BIOS Setup
Virus Warning
This option allows you to choose the VIRUS Warning feature that is used to
protect the IDE Hard Disk boot sector. If this function is enabled and an attempt
is made to write to the boot sector, BIOS will display a warning message on the
screen and sound an alarm beep.
Disabled (default) Virus protection is disabled.
Enabled Virus protection is activated.
Hyper-Threading Technology
This option allows you to enable or disabled Hyper-Threading Technology.
“Enabled” for Windows XP and Linux 2.4.x (OS optimized for
Hyper-Threading Technology). “Disable” for other OS (OS not optimized for
Hyper-Threading Technology).
The Choices: Enabled (default), Disabled.

G31-M7/P31-A7
9
Quick Power On Self Test
Enabling this option will cause an abridged version of the Power On Self-Test
(POST) to execute after yo u po wer up the co mputer.
Disabled Normal POST.
Enabled (default) Enable quick POST.
Boot Up NumLock Status
Selec ts the NumLock State after the system switc hed on.
The Choices:
On (default) Numpad is number keys.
Off Numpad is arrow keys.
Gate A20 Option
Select if chipset or keyboard controller should control Gate A20.
Normal A pin in the keyboard controller controls GateA20.
Fast (default) Lets chipset control Gate A20.
Typematic Rate Setting
When a key is held down, the keystroke will repeat at a rate determined by the
keyboard controller. When enabled, the typematic rate and typematic delay can
be configured.
The Choices: Disabled (default), Enabled.
Typematic Rate (Chars/Sec)
Sets the rate at which a keystroke is repeated when you hold the key down.
The Choices: 6 (default),8, 10, 12, 15, 20, 24, 30.
Typematic Delay (Msec)
Sets the delay time after the key is held down befo re it begins to repeat the
keystroke.
The Choices: 250 (default),500, 750, 1000.

G31-M7/P31-A7
10
Security Option
This option will enable only individuals with passwords to bring the system
online and/or to use the CMOS Setup Utility.
System: A password is required for the system to boot and is also
required to acc ess the Setup Utility.
Setup (default): A password is required to access the Setup Utility only.
This will only apply if p asswords are set from the Setup main menu.
APIC MODE
Selecting Enabled enables APIC device mode reporting from the BIOS to the
operating system.
The Choices: Enabled (default), Disabled.
MPS Version Control For OS
The BIOS supports version 1.1 and 1.4 of the Intel multiprocessor specification.
Selec t versio n supported by the operatio n sys tem running on this computer.
The Choices: 1.4 (default), 1.1.
OS Select For DRAM > 64MB
A choice other than Non-OS2 is only used for OS2 systems with memory
exceeding 64MB.
The Choices: Non-OS2 (default), OS2.
Small Logo(EPA) Show
This item allows you to select whether the “Small Logo” shows. Enabled
“Small Logo” shows when system boots up. Disabled (default) No “Small
Logo” shows when system boots
The Choices: Dis ab led, Enabled (default).
Summary Screen Show
This item allows you to enable/disable the summary screen. Summary screen
means system configuration and PCI device listing.
The Choices: Disabled (default), Enabled.

G31-M7/P31-A7
11
Cache Setup
CPU L3 Cache
Depending on the CPU/chipset in use, you may be able to increase memory
access time with this opt ion.
Enabled (default) Enable cache.
Disabled Disable cache.

G31-M7/P31-A7
12
Boot Seq & Floppy Setup
This item allows you to setup boot sequence & Floppy.
Hard Disk Boot Priority
The BIOS will attempt to arrange the Hard Disk boot sequence
automatically.You can change the Hard Disk booting sequence here.
The Choices: Pri. Master, Pri. Slave, Sec. Master, Sec. Slave, USB HDD0, USB
HDD1, USB HDD2 and Bootable Add-in Cards.

G31-M7/P31-A7
13
First/Second/Third Boot Device
The BIOS will attempt to load the operating system in this order.
The Choices: Floppy, LS120, Hard Disk, CDROM, ZIP100, USB-FDD,
USB-ZIP, USB-CDROM, Legacy LAN, Disabled.
Boot Other Device
When enabled, BIOS will try to load the operating system from other device
when it failed to load from the three devices above.
The Choices: Enabled (default), Disabled
Swap Floppy Drive
For systems with two floppy drives, this option allows you to swap logical
drive assignments.
The Choices: Disabled (default), Enabled
Boot Up Floppy Seek
When enabled, System will test the floppy drives to determine if they have 40
or 80 tracks during boot up. Disabling this option reduces the time it takes to
boot-up.
The Choices: Enabled (default), Disabled.
Report No FDD For WIN 95
The Choices: No (default), Yes.

G31-M7/P31-A7
14
4 Advanced Chipset Features
This submenu allows you to configure the specific features of the chipset
installed on your system. This chipset manage bus speeds and access to system
memory resources, such as DRAM. It also coordinates communications with the
PCI bus. The default settings that came with your system have been optimized
and therefore s ho uld no t be changed unless you are suspic ious that the settings
have been changed incorrectly.
Figure 4: Advanced Chipset Setup
System BIOS Cacheable
Selec ting the “ Enab led” option allo ws caching of the system BIOS ROM at
F0000h-FFFFFh, which is able to improve the system performance. However,
any programs that attempts to write to this memory block will cause conflicts
and result in system errors.
The Choices: Enabled (default), Disabled.
Memory Hole At 15M-16M
You can reserve this area of system memory for ISA adapter ROM. When this
area is res erved it cannot b e cac hed. Chec k the user information of p eripherals
that need to use this area of system memory for the memory requirements.
The Choices: Disabled (default), Enabled.

G31-M7/P31-A7
15
PCI Express Root Port Func
PCI-E Compliancy Mode
The Choices: v1.0a (default), v1.0.
PEG/Onchip VGA Control
This item allows you to enable or disable PEG/On-chip VGA controller.
The Choices: Auto (default), PEG Port, Onchip VGA.
PEG Force X1
When using on-chip VGA, this item has to be set as X1.
Disabled (default) PCI Express X16
Enabled PCI Express X1
On-Chip Frame Buffer Size
This item will be different as your memory modules. When the memory size is
decided, this frame buffer size will also be fixed.
The Choices: 8MB (default), 1MB.
DVMT Mode
This item allows you to select the UVMT mode.
The Choice: DVMT (d efault), F IXED.

G31-M7/P31-A7
16
DVMT/FIXED Memory Size
DVMT stands for „Dynamic Video Memory Technology“. This is an
enhancement of the unified memory architecture (UMA) concept. DVMT will
set the optimum amount of memory to be allocated for a balance between
graphics and system performance. DVMT dynamically respond to system
requirements and applic ations d emands, b y alloc ating the prop er amount of
disp lay, texturing and buffer memory after the operating system has booted.
The Choices: 128MB (default), 256MB, MAX.

G31-M7/P31-A7
17
5 Integrated Peripherals
Figure 5: Integrated Peripherals
OnChip IDE Device

G31-M7/P31-A7
18
IDE HDD Block Mode
Block mode is also called block transfer, mult iple commands, or multip le
sectors read / write. If your IDE hard drive supports block mode (most new
drives do), select Enabled for automatic detection of the optimal number of
block mode (most new drives do), select Enabled for automatic detection of the
optimal number of block read / write per sector where the drive can support.
The Choices: Enabled (default), Disabled.
IDE DMA Transfer Access
This item allows you to enable or disable the IDE DMA transfer access.
The Choices: Enabled (default), Disabled.
On-chip Primary/Secondary PCI IDE
This item allows you to enable or disable the primary / secondary IDE Channel.
The Choices: Enabled (default), Disabled.
IDE Primary/Secondary Master/Slave PIO
The IDE PIO (Programmed Input / Output) fields let you set a PIO mode (0-4)
for each of the IDE devices that the onboard IDE interface supports. Modes 0
to 4 will increase performance progressive ly. In Auto mode, the system
automatically determines the best mode for each device.
The Choices: Auto (default), Mode0, Mode1, Mode2, Mode3, Mode4.
IDE Primary/Secondary Master/Slave UDMA
Ultra DMA function can be implemented if it is supported by the IDE hard
drives in your system. As well, your operating environment requires a DMA
driver (Windows 95 or OSR2may need a third party IDE bus master driver). If
your hard drive and your system software both support Ultra DMA, select Auto
to enable BIOS support.
The Choices: Auto (default), Disabled.
On-Ch ip Serial AT A
T his item allows you to choose:
Disabled: disabled SATA Controller
Combined Mode: PATA and SATA are combined max of 2 IDE drivers
in each channel.
Enhanced Mode: enabled both SATA and PATA max of 6 IDE drivers
are supported.
SATA Only: SATA is operatin g in legacy mode.

G31-M7/P31-A7
19
The Choices: Disabled, Auto, Combined Mode, Enhanced Mode (default),
and SATA only.
SATA PORT Speed Settings
The Choices: Disabled (default), Force GEN I, Force GEN II.
PATA IDE Mode
The Choices: Primary (default), Secondary.
Onboard Device
If you highlight the literal “Press Enter” next to the “Onboard Device” label and
then press the enter key, it will take you a submenu with the following options:
Azalia/AC97 Audio Select
This item allows you to select the Azalia/AC97 Audio support.
The Choices: Auto (default), Azalia, AC97 Audio and Modem, AC97 Audio
only, AC97 Modem only, All Disabled..
Onboard PCIE LAN
This item allows you to enable or disable the Onboard PCIE LAN.
The Choices: Enabled (default), Disabled.
