H61B UEFI BIOS Manual
1
UEFI BIOS Setup
Introduction
The purpose of this manual is to describe the settings in the AMI UEFI BIOS Setup
program on this motherboard. The Setup program allows users to modify the basic
system configuration and save these settings to NVRAM.
UEFI BIOS determines what a computer can do without accessing programs from a
disk. This sys tem controls most of the input and output d evic es s uch as keyboard,
mouse, serial ports and dis k drives. BIOS activates at the first stage o f the booting
process, loading and executing the op erating s ys tem. Some add itional features, s uch
as virus and pass word protectio n or chips et fine-tuning op tions are also includ ed in
UEFI BIOS.
The rest of this manual will to guide you through the options and settings in UEFI
BIOS Setup.
Plug and Play Support
This AMI UEFI BIOS suppo rts the Plug and Play Version 1. 0A spec ificatio n.
EPA Green PC Support
This AMI UEFI BIOS s upports Vers ion 1.03 of the EPA Green PC specification.
ACPI Support
AMI ACPI UEFI BIOS s uppo rt Vers ion 1.0/2.0 of Advanc ed Co nfiguration and
Power interface specification (ACPI). It provides ASL code for power
management and device configuration capabilities as defined in the ACPI
specification, developed by Microsoft, Intel and Toshiba.
PCI Bus Support
This AMI UEFI BIOS also s uppo rts Vers ion 2.3 of the Intel PCI (Perip heral
Component Interconnect) local bus specification.
DRAM Support
DDR3 SDRAM (Double Data Rate III Synchronous DRAM) is supported.

H61B UEFI BIOS Manual
2
Supported CPUs
This AMI UEF I BIOS s uppo rts the Intel CPU.
Using Setup
When starting up the co mp uter, press
<Del> during the Power-On Self-Test
(POST) to enter the UEFI BIOS setup
utility.
In the UEFI BIOS setup utility, you will
see General Help description at the top
right corner, and this is providing a brief
description of the selected item.
Navigation Keys for that particular menu
are at the bottom right corner, and you can
use thes e keys to select item and change
the settings.
Notice
zThe default UEFI BIOS settings apply for most conditions to ensure optimum
performance of the motherboard. If the system becomes unstable after changing
any s ettings, please load the default settings to ensure system’s compatibility and
stability. Use Load Setup Default under the Exit Menu.
zFor better system performance, the UEFI BIOS firmware is being continuously
updated. The UEFI BIOS information describ ed in this manual is fo r your reference
only. The actual UEFI BIOS information and settings on board may be slightly
different from this manual.
zThe content of this manual is subject to be changed without notice. We will not be
responsible for any mistakes fo und in this user’s manual and any system damage that
may be caused by wrong-s ettings.

H61B UEFI BIOS Manual
3
1 Main Menu
Once you enter AMI UEFI BIOS Setup Utility, the Main Menu will appear on the
screen providing an overview of the basic system information.
BIOS Information
Shows system information including UEFI BIOS version, project code, model name,
built date, etc.
Total Memor y
Shows system memory s ize, VGA shard memory will be excluded.
System Date
Set the system date. Note that the ‘Day’ automatically changes when you set the
date.
System Time
Set the s ystem internal c loc k.
Access Level
Shows the access level of current user.

H61B UEFI BIOS Manual
4
2 Advanced Menu
The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power
Management, and other system devices.
Notice
zBeware of that setting inappropriate values in items of this menu may cause
system to malfunction.
PCI Su bs ystem Settings

H61B UEFI BIOS Manual
5
PCI ROM Priority
In case of multiple option ROMs (Legacy and EFI Compatible), this item specifies
what PCI Option ROM to launc h
Options: Legacy ROM (Default) / EFI Compatible ROM
PCI Latency Timer
This item sets the value to be programmed into PCI Latency Timer Register.
Optio ns: 32 PCI Bus Clocks (Default) / 64 PCI Bus Clocks / 96 PCI Bus Clocks /
128 PCI Bus Clocks / 160 PCI Bus Clocks / 192 PCI Bus Clocks / 224
PCI Bus Clocks / 248 PCI Bus Clocks
VGA Palette Snoop
This item enables or disables VGA Palette Registers Snooping.
Options: Dis abled (Default) / Enabled
PERR# Generation
This item enables or dis ables PCI Device to generate PERR#.
Options: Dis abled (Default) / Enabled
SERR# Generation
This item enables or dis ables PCI Device to generate SERR#.
Options: Dis abled (Default) / Enabled
Relaxed Ordering
This item enables or disables PCI Express Device Relaxed Ordering.
Options: Dis abled (Default) / Enabled
Extended Tag
If this item is enabled, the system allows Devic e to use 8-bit Tag field as a requester.
Options: Dis abled (Default) / Enabled
No Snoop
This item enables or disables PCI Express Device No Snoop option.
Options: Enabled (Default) / Disabled

H61B UEFI BIOS Manual
6
Maximum Payload
This item sets Maximum Payload of PCI Express Device or allows System BIOS to
select the value.
Options: Auto (Default) / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048
Bytes / 4096 Bytes
Maximum Read Request
This item sets Maximum Read Request Size of PCI Express Device or allows
System BIOS to select the value.
Options: Auto (Default) / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048
Bytes / 4096 Bytes
ASPM Support
This item sets the ASPM Level: Force LO – Force all links to LO State; Auto –
BIOS auto configures; Disab led – Dis ab les ASPM.
Options: Disabled (Default) / Auto / Force LO
Extended Synch
If this item is enab led, the sys tem allows generation of Extended Synchro nization
patterns.
Options: Dis abled (Default) / Enabled
ACPI Settings/WakeUp Event control

H61B UEFI BIOS Manual
7
ACPI Sleep State
This item selects the highest ACPI sleep state the system will enter when the
SUSPEND button is pressed.
Options: S1 (CPU Stop Clock) (Default) / Suspend Disabled / S3 (Suspend to
RAM)
EuP Control
When EuP is enabled, the system will meet EuP requirement.
Options: Dis abled (Default) / Enabled
PME Wake up from S5
The item enables the s ystem to wake from S5 using P ME event.
Options: Dis abled (Default) / Enabled
Wake system with Fixed Time
This item enables or disables the system to wake on by alarm event. W hen this item
is enabled, the system will wake on the hr::min::sec specified.
Options: Dis abled (Default) / Enabled
Wake up date
You can choose which date the system will boot up.
Wake up hour / Wake up minute / Wake up second
You can c hoose the system boot up time, inp ut ho ur, minute and second to specify.
Ring-In Wake up from S5
This item enables the system to wake from S5 using Ring-In event.
Options: Disabled (Default) / Enabled
PS2 Keyboard PowerOn
This item allows you to control the keyboard power on function.
Options: Disabled (Default) / Any Key / Stroke Key / Specific Key

H61B UEFI BIOS Manual
8
Stroke Keys Selected
This item will show only when Keyboard PowerOn is set “Stroke Key.”
Optio ns: Wake Key (Default) / Power Key / Ctrl+F1 / Ctrl+F2 / Ctrl+F3 /
Ctrl +F4 / Ctrl+F5 / Ctrl+F6
Specific Key Enter
This item will show only when Keyboard PowerOn is s et “Specific Key.” Press
Enter to set Specific key.
PS2 Mouse PowerOn
This item allows you to control the mouse power on function.
Options: Dis abled (Default) / Enabled
USB Device Wakeup from S3/S4
This item allows you to enable or disabled the US B res ume from S 3/S4 function.
Options: Dis abled (Default) / Enabled
CPU Configuration
Active Processor Cores
This item sets number of cores to enable in each processor package.
Options: All (Default) / 1 / 2 / 3

H61B UEFI BIOS Manual
9
Limit CPUID Maximum
When the computer is booted up, the operating system executes the CPUID
instruction to identify the processor and its c apabilities. Before it can do so, it must
first query the processor to find out the highest input value CPUID recognizes. This
determines the kind of basic information CPUID can provide the operating system.
Options: Dis abled (Default) / Enabled
Execute-Disable Bit
XD can prevent certain classes of malicious buffer overflow attacks when combined
with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux
9.2, Red Hat Enterp rise 3 Update 3. ).
Options: Enabled (Default) / Disabled
Hardware Prefetcher
The processor has a hardware prefetcher that automatically analyzes its requirements
and p refetc hes data and ins tructions from the memory into the Level 2 cache that are
likely to be required in the near future. This reduces the latency associated with
memory reads.
Options: Enabled (Default) / Disabled
Adjacent Cache Line Prefetch
The processor has a hard ware adjacent c ache line prefetch mechanis m that
automatically fetches an extra 64-byte cache line whenever the processor requests for
a 64-byte cache line. This red uces cac he latenc y b y making the next cac he line
immediately available if the processor requires it as well.
Options: Enabled (Default) / Disabled
Intel Virtualization Technology
Virtualization Techno logy c an virtually sep arate your system reso urce into several
parts, thus enhance the performance when running virtual machines or multi
interface systems.
Options: Dis abled (Default) / Enabled
Power Technology
This item enables the power management features.
Options: Energy Efficient (Default) / Disabled / Custom

H61B UEFI BIOS Manual
10
SATA Configuration
SATA Mode
This item sets SATA Mode.
Options: IDE Mode (Default) / AHCI Mode / Disabled
Serial-ATA Controller 0
This item enables/disables Serial ATA Controller 0.
Options: Compatible (Default) / Disabled / Enhanced
Serial-ATA Controller 1
This item enables/disables Serial ATA Controller 1.
Options: Enhanced (Default) / Disabled

H61B UEFI BIOS Manual
11
USB Configuration
Legacy USB Support
This item determines if the BIOS should provide legacy support for USB devices
like the keyboard, mouse, and USB drive. This is a useful feature when using such
USB devices with operating systems that do not natively support USB (e.g.
Microsoft DOS or Windows NT).
Options: Enabled (Default) / Disabled / Auto
EHCI Hand-Off
This is a workaround for OSes without EHCI hand-off support. The EHCI ownership
change should be claimed by EHCI driver.
Options: Dis abled (Default) / Enabled
Port 60/64 Emulation
This item enables I/O port 60h/64h emulation support. This should be enabled for the
complete USB keyboard legacy support for non-USB aware OSes.
Options: Enabled (Default) / Disabled

H61B UEFI BIOS Manual
12
SMART FAN Control
CPU Smart FAN
This item allows you to control the CPU Smart Fan function.
Options: Dis abled (Default) / Auto
CPU FAN Calibrate
Press [ENTER] to calibrate CPU FAN.
Control Mode
This item provides several operation modes of the fan.
Options: Quiet / Aggressive / Manual
Fan Ctrl OFF(℃)
When CPU temperature is lower than this value, the CPU fan will keep lowest RP M.
Optio ns: 10 (℃) (default)
Fan Ctrl On(℃)
When CPU temperature is higher than this value, the CPU fan controller will turn on.
Optio ns: 20 (℃) (Default)

H61B UEFI BIOS Manual
13
Fan Ctrl Start Value
This item sets CPU FAN Start Speed Value.
Options: 50 (Default)
Fan Ctrl Sensitive
The bigger the numeral is, the higher the FAN speed is.
Options: 30 (Default)
Super IO Configuration
Restore AC Power Loss
This setting specifies how your system should behave after a power fail or interrupts
occurs. Power Off: Leaving the system in power-off status after power recovers.
Power O N: Po wering o n the s ys tem immed iat ely when po wer r etur ns. Last S tat e: 1.
Leaving the system in power-off if the system shuts down at DC off status; 2.
Powering on the system immediately if the system shuts down at DC on status.
Options: Power Off (Default) / Power On / Last State

H61B UEFI BIOS Manual
14
Serial Port 1 Configuration
Serial Port
This item enab les or disables Serial Port (COM).
Options: Enabled (Default) / Disabled
Change Settings
This item allows you to select an optimal setting for Super IO device.
Optio ns: Auto (Default) / IO=3F8h; IRQ=4 / IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11,
12 / IO=2F 8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 / IO=3E8h; IRQ=3, 4, 5, 6,
7, 9, 10, 11, 12 / IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12
Parallel Port Configuration

H61B UEFI BIOS Manual
15
Parallel Port
This item enables or disables Parallel Port (LPT/LPTE).
Options: Enabled (Default) / Disabled
Change Settings
This item allows you to select an optimal setting for Super IO device.
Optio ns: Auto (Default) / IO=378h; IRQ=5 / IO=378h; IRQ=5, 6, 7, 9, 10, 11, 12 /
IO=278h; IRQ=5, 6, 7, 9, 10, 11, 12 / IO=3BCh; IRQ=5, 6, 7, 9, 10, 11,
12
Device Mode
This item allows you to determine how the parallel port should function.
Options: Standard Parallel Port Mode (Default) (Using Parallel port as Standard
Printer Port) /
EPP Mode (Using Parallel Port as Enhanced Parallel Port) /
ECP Mode (Using Parallel port as Extended Capabilities Port) /
ECP Mode & EPP Mode (Using Parallel port as ECP & EPP mode)

H61B UEFI BIOS Manual
16
H/W Monitor
Shutdown Temperature
This item allows you to set up the CPU shutdown Temperature.
Options: Disabled (Default) / 70 /158 / 75 /167 / 80 /176 / 85 /185℃℉℃℉℃℉℃℉
/ 90 /194℃℉

H61B UEFI BIOS Manual
17
3 Chipset Menu
This section describes configuring the PCI bus system. PCI, or Personal Computer
Interconnect, is a system whic h allows I/O devic es to operate at speeds nearing the
speed of the CPU itself uses when communicating with its own special components.
Notice
zBeware of that setting inappropriate values in items of this menu may cause
system to malfunction.
North Bridge

H61B UEFI BIOS Manual
18
Low MMIO Align
MMIO resources align at 64MB/1024MB.
Options: 1024M (Default) / 64M
VT-d
This item enables/disables VT-d function.
Options: Disabled (Default) / Enabled
Initiate Graphic Adapter
This item allows you to select which graphics controller to use as the primary boot
device.
Options: PEG/IGD (Default) / IGD / PCI/IGD / PCI/PEG / PEG/PCI
IGD Memory
This item sets IGD Share Memory Size.
Options: 64M (Default) / Disabled / 32M / 96M / 128M / 160M / 192M / 224M /
256M / 288M / 320M / 352M / 384M / 416M / 448M / 480M / 512M /
1024M
Render Standby
This item enables/disables Render Standby by Internal Graphics Device.
Options: Enabled (Default) / Disabled
DVMT Mode Select
This item selects DVMT Mode used by Internal Graphics Device.
Options: DVMT Mode (Default) / Fixed Mode
DVMT/FIXED Memory Size
DVMT stands for “Dynamic Video Memory Technology”. This is an enhancement
of the unified memory architecture (UMA) concept. DVMT will set the optimum
amount of memory to be allocated for a balance between graphics and system
performance. DVMT dynamically respond to system requirements and applications
demands, by allocating the proper amount of display, texturing and buffer memory
after the operating system has booted.
Options: 256MB (Default) / 128MB / Maximum

H61B UEFI BIOS Manual
19
IGD Multi-Monitor
This item enables/disables IGD Multi-Monitor by Internal Graphics Device.
Options: Disabled (Default) / Enabled
PCI Express Port
This item allows user to control PCI Express x16 Port.
Options: Auto (Default) / Disabled / Enabled
PEG Force Gen1
Some non-graphics PCI-E devices may not follow PCI-E Specification and may
incorrectly report their Gen capability or link width.
Options: Disabled (Default) / Enabled
Detect Non-Compliance Device
Detect Non-Complianc e PCI Express Device in PEG.
Options: Enabled (Default) / Disabled
South Bridge Configuration
Azalia HD Audio
This item enables/disables Azalia HD Audio.
Options: Enabled (Default) / Disabled
