Biostar M7VIZ V8.X User manual

1
M7VIZ
ENGINEERING VALIDATION TEST REPORT
COVER SHEET
CHANGE CONTROL
Description of Change Revision Sections/Pages Affected Date
Initial Release 0.9 2003/3/21
0.91 2003/4/22
1.0 2003/5/9
1.2 2003/6/27
1.3 2003/7/22
Project: M7VIZ
Date: 2003/3/21
Owner: Biostar Group
Contact: TEL: [phone] FAX: [phone]
Home Page: http://www.biostar.com.tw

2
CONTENTS
PRODUCT INFORMATION....................................................................4
Motherboard General Information.....................................................................4
Chipset Details........................................................................................................4
BIOS Details............................................................................................................4
CPU Supports..........................................................................................................4
Memory Supports...................................................................................................4
On-board Features and Devices..........................................................................4
Mechanical...............................................................................................................5
DESIGN REVIEW Ver1.3.........................................................................7
Mainboard Voltage Measurement......................................................................7
Bus Clock.................................................................................................................7
FUNCTIONALITY....................................................................................8
Setup Installation Test Of Operating System..................................................8
Basic On-board Function Test ............................................................................8
MS-DOS Operating ...............................................................................................8
Windows ME Operating.....................................................................................11
Windows2000 Operating....................................................................................14
Windows XP (Home Edition ) Operating......................................................17
Windows XP (Professional ) Operating.........................................................23
Linux (Red Hat 9.0) Operating.........................................................................25
RELIABILITY TEST..............................................................................26
Motherboard General Information...................................................................26
Burn-in Step...........................................................................................................26
PERFORMANCE TEST.........................................................................27
Windows XP..........................................................................................................27
Display Card Performance ....................................................................................28
HARDWARE COMPATIBILITY LIST................................................29
CPU..........................................................................................................................29
CD-ROM................................................................................................................30
Camera Device......................................................................................................30
DVD-ROM.............................................................................................................30
Display Card..........................................................................................................31
FDD..........................................................................................................................31
HDD.........................................................................................................................32
Joystick....................................................................................................................33
Keyboard ................................................................................................................33
LAN Card...............................................................................................................34
LAN HUB..............................................................................................................34

3
Memory...................................................................................................................34
Modem Card..........................................................................................................35
Mouse......................................................................................................................36
Monitor....................................................................................................................36
Power Supply.........................................................................................................37
Printer......................................................................................................................37
Scanner....................................................................................................................37
SCSI Card...............................................................................................................37
Sound Card.............................................................................................................38
USB HUB & USB 2.0 DEVICE......................................................................38
ZIP/LS120..............................................................................................................38
SOFTWARE COMPATIBILITY LIST .................................................40
DOS..........................................................................................................................40
Windows.................................................................................................................40
VCORE WAVEFORM MEASUREMENT-Ver 1.3 ..............................41
Vcore Transient Test(Dos Mode).....................................................................41
Vcore Ripple Test(Open up the DOS Editor) ...............................................42
Vcore Ripple Test(Standby/Resume Mode)..................................................43
Vcore Ripple Test(Standby/Resume Mode)..................................................44
Vcore Ripple Test(Standby/Resume Mode)..................................................45
FOUR CORNER TEST-Ver 1.3..............................................................46
VCORE STATIC LOAD TEST 1.3 ............................................................47
THERMAL IMAGE TEST – Ver 1.2 New.............................................48
Motherboard General Information...................................................................48

4
PRODUCT INFORMATION
Motherboard General Information
Vendor Biostar
Model Number M7VIZ
Version Number V0.90/V0.91/V1.0/V1.2/V1.3
Platform AT ATX Micro ATX Flex ATX
Chipset Details
System Chipset Vendor VIA
North Bridge Revision KM400
South Bridge Revision VT8237
Super I/O Chip Vendor Winbond
Super I/O Revision Number W83697HF
Clock Generator Vendor CY
Clock Generator Revision CY283410C-2
Audio Chipset Vendor CMEDIA
Audio Chipset Revision CMI9739A
LAN Chipset Vendor VIA
LAN Chipset Revision VT6103
SATA Chipset VT8237 BIOS Details
BIOS Vendor AMI Award Phoenix Others
BIOS Revision Number 0801
BIOS Memory Size 1M 2M 4M
Flash EPROM BIOS Yes No
CPU Supports
Type CPU CPU Frequency Front Side Bus Comments:
Socket A AMD Athlon Max =1400MHZ Max =100MHZ
Socket A AMD Athlon Max =1400MHZ Max =133MHZ
Socket A AMD Athlon XP Max =2600MHZ Max =133MHZ
Socket A AMD Athlon XP Max =3000MHZ Max =166MHZ
Socket A AMD Duron Max =1300MHZ Max =100MHZ
Memory Supports
Maximum Memory Support SDRAM (MB) DDR 2G (MB)
Number of Memory Slots DIMM 2 . RIMM .
Type of Memory Supported SDRAM RDRAM DDR RAM
Parity Support Yes No
ECC Support Yes No
On-board Features and Devices
No of PCI Full Length Slots 2 3 4 5
AMR Slot Support Yes No
CNR Slot Support Yes No

5
ACR Slot Support Yes No
Number of Shared Slots 1 None
66/100/133 MHz Front Side Bus Supports Yes No
DDR 333 Support Yes No
PCI v2.2 Compliance Yes No
ATA-3 Compliance Yes No
ATAPI Compliance Yes No
Ultra DMA 100 Support Yes No
Ultra DMA 133 Support Yes No
ATA-133 Support Yes No
USB 1.1 Connector Support Yes No
USB 2.0 Connector Support Yes No
AGP (8X/4X) Slot Support Yes No
Support AGP SideBand Addressing Mode Yes No
Power on by LAN Support Yes No
Power on by Ring Support Yes No
Power on by Keyboard Support Yes No
Power on by Mouse Support Yes No
Infrared Support Yes No
Enhanced Parallel Port Yes No
DMI Compliance Yes No
Hardware Monitor Support Yes No
ACPI v1.0B/APM v1.2 Compliance Yes No
On-board Graphics Controller Yes No
On-board Network Adapter 1Mb 10Mb 100Mb No
On-board Audio Device Hardware AC97 CODEC No
On-board RAID Yes No
Other Function Support
Mechanical
Board Dimensions Length 24.4 cm Width 22.4 cm
Visual Inspection of Soldering Excellent Fair Poor
Visual Inspection of Layout Placement Connectors Quality
Screw Holes Line Up with Case Yes No Excellent Fair Poor
Power Connector placement in PCB Yes No Excellent Fair Poor
DIMM/RIMM Socket placement in PCB Yes No Excellent Fair Poor
CPU Socket placement in PCB Yes No Excellent Fair Poor
FAN Connector placement in PCB Yes No Excellent Fair Poor
FDD Connector placement in PCB Yes No Excellent Fair Poor
IDE Connector placement in PCB Yes No Excellent Fair Poor
Front Panel Connectors in PCB Yes No None Excellent Fair Poor
PS/2 Connectors Line Up in Case Yes No None Excellent Fair Poor
USB Port Connectors Line Up in Case Yes No None Excellent Fair Poor

6
COM Port Connectors Line Up in Case Yes No None Excellent Fair Poor
Printer Port Connectors Line Up in Case Yes No None Excellent Fair Poor
VGA Port Connectors Line Up in Case Yes No None Excellent Fair Poor
Audio Port Connectors Line Up in Case Yes No None Excellent Fair Poor
Game Port Connectors Line Up in Case Yes No None Excellent Fair Poor
AGP Slot(Card) Line Up in Case Yes No None Excellent Fair Poor
PCI Slots(Card) Line Up in Case Yes No None Excellent Fair Poor
AMR Slot(Card) Line Up in Case Yes No None Excellent Fair Poor
CNR Slot(Card) Line Up in Case Yes No None Excellent Fair Poor
ACR Slot(Card) Line Up in Case Yes No None Excellent Fair Poor
Daughter Card Slot in PCB Yes No None Excellent Fair Poor
Wake-on LAN connector in PCB Yes No None Excellent Fair Poor
CD Audio-in Connector in PCB Yes No None Excellent Fair Poor
AUX Audio-in Connector in PCB Yes No None Excellent Fair Poor
Other Jumper in PCB Yes No None Excellent Fair Poor
Comments:

7
DESIGN REVIEW Ver1.3
Mainboard Voltage Measurement
Voltage List Voltage SPEC Voltage Measured Result
Battery Voltage 3.0V 3.07 Pass
Battery Current 7uA 2.1 Pass
+5V 5.0V+-5% 5.10 Pass
+12V 12.0V+-5% 11.64 Pass
-5V -5.0V+-5% -5.05 Pass
-12V -12.0V+-10% -12.00 Pass
+3.3V +3.3V+-5% 3.36 Pass
Bus Clock
Clock Frequency Spec Value
(MHz) Measured Value (MHz) Pass/Fail
CPU and Clock Host min50~max100 99.60 Pass
min50~max133 131.6 Pass
min50~max166 165.0 Pass
DDR_RAM Clock 100 100.4 Pass
133 133.7 Pass
166 165.6 Pass
AGP Clock 66.67 66.67 Pass
PCI Clock 33.33 33.56 Pass
USB Clock 48 48.08 Pass
Reference Clock 14.31818 14.20 Pass
Clock Timing Spec Value (v) Measured Value Pass/Fail
CPU Clock High Time 100 Min 1.8 ns 5.08 Pass
133 Min 1.05 ns 3.80 Pass
166 Min 1.0 ns 2.84 Pass
CPU Clock Low Time 100 Min 1.8 ns 4.92 Pass
133 Min 1.05 ns 3.76 Pass
166 Min 1.0 ns 3.2 Pass
CPU Clock Rising Time 100 Max 2.0 ns 0.36 Pass
133 Max 2.0 ns 0.24 Pass
166 Max 2.0 ns 0.32 Pass
CPU Clock Falling Time 100 Max 2.0 ns 0.28 Pass
133 Max 2.0 ns 0.20 Pass
166 Max 2.0 ns 0.32 Pass
PCI Clock High Time Min.11ns 15 Pass
PCI Clock Low Time Min.11ns 14.8 Pass
PCI Clock Rising Time 1ns~4ns 3.726 Pass
PCI Clock Falling Time 1ns~4ns 3.070 Pass
Comment:

8
FUNCTIONALITY
Setup Installation Test Of Operating System Pass/Fail
Windows ME Pass
Windows 2000 Professional Pass
Windows XP Home Edition Pass
Windows XP Professional Pass
Linux (Red Hat ) 9.0 Pass
Basic On-board Function Test
Test Platform MS-DOS Operating Comment
CPU Athlon 1700G / 133MHz
Memory HYNIX 512*1 (266)
HDD Seagate 1275M
CDROM DVD ROM OEM 316B
Sound Card Onboard
Video Card Onboard
LAN Card Intel 82557 , 82559
Test Item Pass/Fail
Clear CMOS with Jumper Pass
Cold Boot (Power Turn on ) Pass
CMOS Load Default Setup Pass
Memory Size Counter Check Pass
BIOS Lock Function Pass
Warm Boot (HW/SW Reset) Pass
System Configuration Review (CPU Type/Cache/SDRAM/HDD…) Pass
Power Fail Function Test Pass
Prompt Into DOS Mode Pass
Typing Some DOS Comment Pass
Run Scandisk Pass
PS/2 Keyboard Test Pass
USB Keyboard Legacy Support Test Pass
Boot Floppy Driver A Pass
FDISK Hard Disk Driver Pass
Format Hard Disk Driver Pass
Boot Hard Disk Driver C Pass
Power LED Check Pass
HDD LED Check Pass
Systems Speaker Pass
Buzz None
BIOS / Update BIOS Utility Test Pass
SMI Function Test ---
SMI Pin Function Test Pass

9
Time Out Function Test Pass
Power LED Flash Check Pass
Power On Control ---
Power On By RTC Test Pass
Power On By LAN Test Pass
Power On By Modem Test Pass
Boot Management ---
Boot Form CD-ROM Pass
Boot From LAN Pass
RTC Test ---
CMOS RTC Date Check Pass
Windows RTC Date Check Pass
CMOS RTC Time Out Test Pass
Windows RTC Time Out Test Pass
Memory Comparability Test ---
Bmem Memory Test (15 Times) Pass
QAplus 7.0 Test ---
All Test Pass
Checkit 4.0 ---
System Board Test Pass
Memory Test Pass
Hard Disk Test Pass
Floppy Test Pass
Serial Port Test Pass
Parallel Port Test Pass
Modem Test Pass
Video Card Test Pass
Printer Test Pass
Keyboard Test Pass
AMIDiag 6.20 ---
System ---
Processor Test Pass
DMA Controller Test Pass
Interrupt Controller Test Pass
Timer Test Pass
Real Time Clock Test Pass
CMOS Validity Test Pass
Speaker Test Pass
PCI System Test Pass
Plug-n-Play Test Pass
Multimedia CPU Extensions Pass
DMI Test Pass
Memory ---

10
BIOS ROM Test Pass
Parity Test Pass
Pattern Test Pass
Extended Pattern Test Pass
Walking 1’s Test Pass
Walking 0’s Test Pass
Random Memory Test Pass
Address Test Pass
Refresh Test Pass
Data Bus Test Pass
Cache Memory Test Pass
Quick Memory Test Pass
IDE ---
IDE HDD Test Pass
IDE CD Test Pass
FDD ---
Floppy Controller Test Pass
Drive Speed Test Pass
Diskette Read Test Pass
Elevator Seek Test Pass
Disk Change Line Test Pass
KBD ---
Controller Test Pass
Scan/ASCII code test Pass
LED Test Pass
Clock Line Test Pass
Data Line Test Pass
Video ---
Video Controller Test Pass
VGA Controller Test Pass
Video Memory Test Pass
VESA Video Memory Test Pass
AGP Test Pass
Attribute Test Pass
Page Selection Test Pass
Color Test Pass
Text Mode Test Pass
Graphics Mode Test Pass
VESA Video Mode Test Pass
Misc. ---
Serial Port Test Pass
Parallel Port Test Pass
PS/2 Mouse Test Pass

11
APM Functionality Test Pass
Device APM Test Pass
ACPI Test Pass
I82557 Ethernet chip Pass
Comments:v
Test Platform Windows ME Operating Comment
CPU ATHLON 2600+
Memory SAMSUNG 256M X2
HDD IBM DTLA -307030
CDROM BENQ 52X
Sound Card On board
Video Card On board
LAN Card On board
Test Item Pass/Fail
System Comparability Test ---
Windows ME Setup Installation Test Pass
Supports Driver Installation Test Pass
System Properties Information Review (System Device Manager) Pass
Standby Mode Test Pass
Shut Down Test Pass
Restart Test Pass
Scandisk Test Pass
Reboot The Windows Test For Over Night Pass
Suspend To RAM (S3) Test ---
Standby Button for S3 (Enter) Pass
Power Button for S3 (Enter and Wake up) Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Power LED Flash check Pass
Onboard Audio For S3 Function Supports Test (Play CD/DVD) Pass
Hibernate(S4) Test ---
Standby Button for S4 (Enter) Pass
Power Button for S4 (Enter and Wake up) Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Device Comparability Test ---
PS/2 Connector Test ---
PS/2 Keyboard Test Pass
PS/2 Mouse Test Pass
COM Port Test ---
Add Serial Mouse PnP Test Pass

12
Add Modem PnP Test Pass
Print Port Test ---
Add Printer PnP Test Pass
FDD Connector Test ---
Create Windows ME Startup Disk Pass
Format 1.44 Floppy Driver Pass
IDE Connectors Test ---
CD-ROM Data Read Test Pass
DVD-ROM Data Read Test Pass
Ultra DMA 33/66/100/133 Hard Disk Test Pass
USB Ports Test ---
Add Keyboard PnP Test Pass
Add Mouse PnP Test Pass
PCI Slots Test ---
Add LAN Cards Test ---
Boot ROM Function Test Pass
Add LAN Card Test Pass
Login Server Test Pass
ADSL Link Test Pass
Add SCSI Cards Test ---
Add SCSI Cards For PnP Function Test Pass
Add Sound Card Test ---
Add Sound Cards For PnP Function Test Pass
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Audio Control Panel Function Test Pass
Game Port Test Pass
Sound Recorder Test Pass
Speaker Out Quality Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MP3 Test Pass
CNR Slots Test ---
Add CNR Software Modem Card Test Pass
VGA Function Test ---
VGA Drivers Setup Installation Test Pass
Display Properties Information Review Pass
Run 3D Screen Saver Pass
VGA Resolution Test ---
Resolution Color Depth Optimal 75 Hz 85 Hz 100 Hz ---
640x480 16 bit √√√√Pass
640x480 32 bit √√√√Pass

13
800x600 16 bit √√√√Pass
800x600 32 bit √√√√Pass
1024x768 16 bit √√√√Pass
1024x768 32 bit √√√√Pass
1152x864 16 bit √√√√Pass
1152x864 32 bit √√√√Pass
Check Screen Have No Any Shadow Or Garbage Pass
Audio Function Test ---
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Audio Control Panel Function Test Pass
Sound Recorder Test Pass
Run MPG Files Pass
Speaker Out Quality Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MIDI Test Pass
Playing Video Test Pass
Playing MP3 Test Pass
Onboard Audio For S1 Function Supports Test Pass
SPDIF Test Pass
Windows Utility Test ---
BCM Diagnostics ---
System Info Pass
DMI Info Pass
Processor Test Pass
Memory Test Pass
Audio Test Pass
Video Test Pass
Graphics Test Pass
Hard Disk Test Pass
Floppy Disk Test Pass
CD-ROM Test Pass
Stress Test –Loop 100 Pass
MS Mouse Pass
MS Joystick Pass
MS ScanDisk Pass
Winstone 2001 ---
Business Winstone 2001 Pass
Content Creation Winstone 2002 Pass
Winbench 99 V1.2 ---
Business Disk WinMark 99 Pass

14
Business Graphics WinMark 99 Pass
DirectDraw Tests Pass
Disk Inspection Tests Pass
Disk WinMark Pass
GDI/USER Inspection Tests Pass
High-End Disk WinMark 99 Pass
High-End Graphics WinMark 99 Pass
Video Tests Pass
3D Mark 2001 SE ---
3D Marks Pass
Demo Mode Pass
Others ---
Final Reality Pass
USBready Pass
WinDVD 4 Pass
QUAKE III demo Pass
Comments:
Test Platform Windows2000 Operating Comment
CPU AMD Athlon(th)XP 2400+
Memory NANYA 128M * 2
HDD MAXTOR 6L080J4 80G
CDROM LITEON DVD-ROM LTD-165H
Sound Card Onboard
Video Card Onboard
LAN Card Onboard
Test Item Pass/Fail
System Comparability Test ---
Windows 2000 Setup Installation Test Pass
Supports Driver Installation Test Pass
System Properties Information Review Pass
S1 , S3 , S4 Mode Test Pass
Shut Down Test Pass
Restart Test Pass
Scandisk Test Pass
Setup installation Microsoft Office 2000 Test Pass
Hibernate(S4) Test ---
Standby Button for S4 (Enter) Pass
Power Button for S4 (Enter and Wake up) Pass
Windows Set RTC Time out for S4 (Enter and Wake up) Pass

15
Enter S4 mode For 1/5/10/30/60/120 Minutes Then To Do Wake Up Test. Pass
Wake Up By LAN Test Pass
Wake Up By Ring Test Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Device Comparability Test ---
PS/2 Connector Test ---
PS/2 Keyboard Test Pass
PS/2 Mouse Test Pass
COM Port Test ---
Add Serial Mouse PnP Test Pass
Add Modem PnP Test Pass
Print Port Test ---
Add Printer PnP Test Pass
FDD Connector Test ---
Format 1.44 Floppy Driver Pass
IDE Connectors Test ---
Ultra DMA 33 Hard Disk Test Pass
Ultra DMA 66 Hard Disk Test Pass
Ultra DMA 100 Hard Disk Test Pass
CD-ROM Test Pass
DVD-ROM Data Read Test Pass
ZIP Device Driver Test Pass
Format ZIP Driver With Floppy A Type Pass
LS120 Device Driver Test Pass
Onboard LAN Test ---
LAN Drivers Setup Installation Test Pass
Boot ROM Function Test Pass
Login Server Test Pass
Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass
Wake On LAN Test (Standby Mode) Pass
ADSL Link Test Pass
LAN Cards Test ---
Boot ROM Function Test Pass
RIS (Remote Install Service ) Function Test Pass
Login Server Test Pass
Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass
Wake On LAN Test . Pass
ADSL Link Test Pass
PCI Slots Test ---
Add SCSI Card Test Pass
Add LAN Card Test Pass
Wake On LAN Test (Standby Mode) Pass
Add Sound Card Test Pass

16
Add Modem Card Test Pass
Wake On Modem Test (Standby Mode) Pass
CNR Slots Test ---
Add Modem Card Test Pass
VGA Function Test ---
VGA Drivers Setup Installation Test Pass
Display Properties Information Review Pass
VGA Resolution All Test Pass
Screen Saver Test Pass
Check Screen Have No Any Shadow Or Garbage Pass
Playing MPEG Files Test Pass
Playing VCD Test Pass
Playing DVD Test(With WinDVD 4) Pass
Audio Function Test ---
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Speaker Out Quality Test Pass
R/L Channel Check Pass
CD-In Function Check Pass
Line-In Function Check Pass
Mic-In Function Check Pass
Audio Control Panel Function Test Pass
Sound Recorder Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MIDI Test Pass
Playing Video Test Pass
Playing MP3 Test Pass
Game Port Test Pass
Windows2000 Utility Test Pass/Fail
BCM Diagnostics ---
System Info Pass
DMI Info Pass
Processor Test Pass
Memory Test Pass
Audio Test Pass
Video Test Pass
Graphics Test Pass
Hard Disk Test Pass
Floppy Disk Test Pass
CD-ROM Test Pass
Stress Test –Loop 100 Pass
MS Mouse Pass

17
MS Joystick Pass
BurnIn Test ---
CPU-Maths Pass
CPU-MMX/SSE Pass
Memory (RAM) Pass
2D Graphics Pass
3D Graphics Pass
Hard Disk Test Pass
Floppy Disk Pass
Network Test Pass
CD-ROM Pass
Winbench 99 (1.2) ---
Business Disk WinMark 99 Pass
Business Graphics WinMark 99 Pass
DirectDraw Tests Pass
Disk Inspection Tests Pass
Disk WinMark Pass
GDI/USER Inspection Tests Pass
High-End Disk WinMark 99 Pass
High-End Graphics WinMark 99 Pass
Winstone 2003 ---
Business Winstone 2002 Pass
Content Creation Winstone 2003 Pass
SYSMark2002 ---
Internet Content Creation Pass
Office Productivity Pass
Others ---
PC-MARK 2002 Pass
XL-R8R Pass
3D MARK2001SE E330 Pass
Game Test ---
3D Pinball Pass
Freecell Pass
Minesweeper Pass
Solitaire Pass
Age of Empire Pass
Comments:
Test Platform Windows XP (Home Edition ) Operating Comment
CPU AMD Athlon(th)XP 2600
Memory SAMSUNG 256M * 2

18
HDD MAXTOR 6L080J4 80G
CDROM TEAC DV-516E
Sound Card Onboard
Video Card Onboard
LAN Card Onboard
Test Item Pass/Fail
System Comparability Test ---
Windows XP Setup Installation Test Pass
Supports Driver Installation Test Pass
Standby Mode Test Pass
Shut Down Test Pass
Restart Test Pass
Scandisk Test Pass
S3 and S4 Mode Test Pass
Setup installation Microsoft Office 2000 Test Pass
System Information Review ---
Hardware Resources Pass
Components Pass
Software Environment Pass
Internet Setting Pass
Net Diagnostics Pass
System restore Pass
File Signature Verification Utility Pass
DirectX Diagnostics Tool Pass
Hardware Device Manager review Pass
System Event Review Pass
Suspend To RAM (S3) Test ---
Standby Button for S3 (Enter) Pass
Power Button for S3 (Enter and Wake up) Pass
Suspend Test (Microsoft Utility) Pass
Wake Up By LAN Test Pass
Wake Up By Ring Test Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Power LED Flash check Pass
Onboard Audio For S3 Function Supports Test (Play CD/VCD/DVD/AVI) Pass
Hibernate(S4) Test ---
Standby Button for S4 (Enter) Pass
Power Button for S4 (Enter and Wake up) Pass
Windows Set RTC Time out for S4 (Enter and Wake up) Pass
Wake Up By LAN Test Pass
Wake Up By Ring Test Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass

19
Device Comparability Test ---
PS/2 Connector Test ---
PS/2 Keyboard Test Pass
PS/2 Mouse Test Pass
COM Port Test ---
Add Serial Mouse PnP Test Pass
Add Modem PnP Test Pass
Print Port Test ---
Add Printer PnP Test Pass
IrDA Function Test ---
Add IR Printer Test Pass
Peer to Peer Data Transfer Test (Ir-In/Ir-Out) Pass
FDD Connector Test ---
Format 1.44 Floppy Driver Pass
IDE Connectors Test ---
CD-ROM Data Read Test Pass
DVD-ROM Data Read Test Pass
Ultra DMA 33 Hard Disk Test Pass
Ultra DMA 66 Hard Disk Test Pass
Ultra DMA 100 Hard Disk Test Pass
Ultra DMA 133 Hard Disk Test Pass
USB Ports Test ---
Add Keyboard PnP Test Pass
Add Mouse PnP Test Pass
Add Printer PnP Test Pass
Add Scanner PnP Test Pass
Add Camera PnP Test Pass
Add Joystick PnP Test Pass
LAN Port Test ---
Boot ROM Function Test Pass
Login Server Test Pass
Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass
Setup Installation Winstone By The LAN Pass
Setup Installation 3D Mark2001 SE By The LAN Pass
ADSL Link Test Pass
PCI Slots Test ---
Add LAN Cards Test ---
Boot ROM Function Test Pass
Login Server Test Pass
Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass
Wake On LAN Test . Pass
Playing AVI Files By The LAN Pass
Setup Installation Winstone 2001 By The LAN Pass

20
Setup Installation Winbench 99 By The LAN Pass
Setup Installation 3D Mark2001 By The LAN Pass
ADSL Link Test Pass
Add SCSI Cards Test ---
Add SCSI Cards For PnP Function Test Pass
Setup installation the Windows from SCSI HDD Pass
Scandisk Test Pass
Disk Defragmenter Test Pass
System Properties Information Review (System Device Manager) Pass
Setup installation Microsoft Office 2000 Test Pass
Reboot The Windows Test For Over Night Pass
Add Sound Card Test ---
Add Sound Cards For PnP Function Test Pass
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Audio Control Panel Function Test Pass
Game Port Test Pass
Sound Recorder Test Pass
Run MPG Files Pass
Speaker Out Quality Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MIDI Test Pass
Playing Video Test Pass
Playing MP3 Test Pass
CNR Slots Test ---
Add CNR Software Modem Card Test Pass
Connect Performance Check Pass
Internet Explorer Test Pass
Netscape Browser Test Pass
Connect to ISP For 12 hours Pass
Download Files From Internet ISP Server (Over 10MB) Pass
Modem Fax Function Test (Transmit a fax to Fax Machine) Pass
Modem Fax Function Test (Transmit a fax to Modem) Pass
Modem Fax Function Test (Receive a fax from Fax Machine) Pass
Modem Fax Function Test (Receive a fax from Modem) Pass
Send & Receive e-mail Test Pass
Recording a MP3 File From Internet ISP Server Pass
FTP Transport Test (Download and Upload Test ) Pass
VGA Function Test ---
VGA Drivers Setup Installation Test Pass
Display Properties Information Review Pass
Run 3D Screen Saver Pass
