TA75 UEFI BIOS Manual
1
UEFI BIOS Setup
Introduction
The purpose of this manual is to describe the settings in the AMI UEFI BIOS Setup
program on this motherboard. The Setup program allows users to modify the basic
system configuration and save these settings to NVRAM.
UEFI BIOS determines what a computer can do without accessing programs from a
disk. This system controls most of the input and outp ut devic es such as keyboard,
mouse, serial ports and disk drives. BIOS activates at the firs t stage o f the booting
process, lo ading and executing the operating sys tem. Some add itional features, s uch
as virus and password pro tection or chipset fine-tuning op tions are also includ ed in
UEFI BIOS.
The rest of this manual will to guide you through the options and settings in UEFI
BIOS Setup.
Plug and Play Support
This AMI UEF I BIOS suppo rts the Plug and Play Version 1. 0A spec ific ation.
EPA Green PC Support
This AMI UEFI BIOS suppo rts Vers ion 1. 03 of the EPA Green PC specification.
ACPI Support
AMI ACP I UEFI BIOS s upport Version 1.0/2.0 of Advanc ed Configuration and
Power interface specification (ACPI). It provides ASL code for power
management and device configuration capabilities as defined in the ACPI
specification, developed by Microsoft, Intel and Toshiba.
PCI Bus Support
This AMI UEFI BIOS also supports Vers ion 2.3 of the Intel PCI (P eripheral
Component Interconnect) local bus specification.
DRAM Support
DDR3 SDRAM (Double Data Rate III Synchronous DRAM) is supported.

TA75 UEFI BIOS Manual
2
Supported CPUs
This AMI UEFI BIOS supports AMD CPU.
Using Setup
When starting up the computer, press <Del> during
the Power-On Self-Test (POST) to enter the UEFI
BIOS setup utility.
In the UEF I BIOS setup utility, you will see
General Help description at the top right corner,
and this is providing a brief description of the
selected item. Navigation Keys for that particular
menu are at the bottom right corner, and you c an
use thes e keys to selec t item and change the
settings.
Notice
The default UEFI BIOS settings apply for most conditions to ensure optimum
performance of the motherboard. If the system becomes unstable after
changing any settings, please load the default settings to ensure system’s
compatibility and stability. Use Load Setup Default under the Exit Menu.
For b etter system performanc e, the UEFI BIOS firmware is b eing continuously
updated. The UEFI BIOS information described in this manual is for your
reference only. The actual UEFI BIOS information and settings on board may
be slightly different from this manual.
The content of this manual is subject to be changed without notice. We will
not be responsible for any mistakes found in this user’s manual and any system
damage that may be caused by wrong-settings.

TA75 UEFI BIOS Manual
3
1 Main Menu
Once you enter AMI UEFI BIOS Setup Utility, the Main Menu will appear on the
screen providing an overview of the basic system information.
BIOS Information
Shows system information including UEFI BIOS version, Project Code, Model
Name, Build Date, etc.
Total Memor y
Shows system memory size, VGA s hard memory will be excluded.
System Date
Set the system date. Note that the ‘Day’ automatically changes when you set the
date.
System Time
Set the system internal cloc k.

TA75 UEFI BIOS Manual
4
2 Advanced Menu
The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power
Management, and other system devices.
Notice
Beware of that setting inappropriate values in items of this menu may cause system
to malfunction.
PCI Su bs ystem Settings

TA75 UEFI BIOS Manual
5
PCI ROM Priority
In case of multiple option ROMs (Legacy and EFI Compatible), this item specifies
what PCI Option ROM to launc h
Options: Legacy ROM (Default) / EFI Compatible ROM
PCI Latency Timer
This item sets the value to be programmed into PCI Latency Timer Register.
Options: 32 PCI Bus Clocks (Default) / 64 PCI Bus Clocks / 96 PCI Bus Clocks
/ 128 PCI Bus Clocks / 160 PCI Bus Clocks / 192 PCI Bus Clocks / 224 PCI Bus
Clocks / 248 PCI Bus C locks
VGA Palette Snoop
This item enables or disables VGA Palette Registers Snooping.
Options: Disabled (Default) / Enabled
PERR# Generation
This item enables or disables PCI Device to Generate PERR#.
Options: Disabled (Default) / Enabled
SERR# Generation
This item enables or disables PCI Device to Generate SERR#.
Options: Disabled (Default) / Enabled

TA75 UEFI BIOS Manual
6
PCI Express Settings
Relaxed Ordering
This item enables or disables PCI Express Device Relaxed Ordering.
Options: Disabled (Default) / Enabled
Extended Tag
If ENABLED allows Device to use 8-bit Tag field as a requester.
Options: Disabled (Default) / Enabled
No Sn oop
This item enables or disables PCI Express Device No Snoop option.
Options: Enabled (Default) / Dis abled
Maximum Payload
This item sets Maximum Payload of PCI Express Device or allows System BIOS to
select the value.
Options: Auto (Default) / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048
Bytes / 4096 Bytes
Maximum Read Request
This item sets Maximum Read Request Size of PCI Express Device or allows
System BIOS to s elec t the value.
Options: Auto (Default) / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048
Bytes / 4096 Bytes

TA75 UEFI BIOS Manual
7
ASPM Support
This item sets the ASPM Level: Force LO – Force all links to LO State; Auto –
BIOS auto co nfigures; Disab led – Dis ables ASPM.
Options: Disabled (Default) / Auto / Force L0s
Extended Synch
If ENABLED allows generation of Extended Synchronization patterns
Options: Disabled (Default) / Enabled
Link Training Retry
Defines number of Retry Attempts software will take to retrain the link if previous
training attempt was unsuccessful.
Options: Disabled (Default) / 2 / 3/ 5
Link Training Timeout (uS)
Defines number of Microseconds software will wait before polling “Link Training’
bit in Link Status register. Value range from 10 to 1000 uS.
Options: 100 to 1000 uS
Unpopulated Links
In order to save power, the software will disabled unpopulated PCI Express links, if
this option set to ‘Disabled Link’.
Options: Keep Link ON (Default) / Disabled
ACPI Settings

TA75 UEFI BIOS Manual
8
ACPI Sleep State
This item selects the highest ACPI sleep state the system will enter when the
SUSPEND button is pressed.
Options: S3 (Suspend to RAM) (Default) / Suspend Disabled
EuP Control
When EuP is enabled, the system will meet EuP requirement.
Options: Disabled (Default) / Enabled
Wake system with Fixed Time
This item enables or disables the system to wake on by alarm event. When this item
is enabled, the system will wake on the hr::min::sec specified.
Options: Disabled (Default) / Enabled
Wake up date
You can choose which date the system will boot up.
Wake up hour / Wake up minute / Wake up second
You can choos e the system boot up time, inp ut ho ur, minute and seco nd to sp ecify.
USB Device Wakeup from S3/S4
This item allo ws you to enable o r disabled the USB res ume from S3/S4 function.
Options: Disabled (Default) / Enabled
PME Wake up from S5
The item enables the s ystem to wake from S5 using PME event.
Options: Disabled (Default) / Enabled
Ring-In Wake up from S5
This item enables the system to wake from S5 using Ring-In event.
Options: Disabled (Default) / Enabled

TA75 UEFI BIOS Manual
9
PS2 Keyboard PowerOn
This item allows you to control the keyboard power on function.
Options: Disabled (Default) / Any Key / Stroke Key / Specific Key
Stroke Keys Selected
This item will s how only when Keyboard PowerOn is set “Stroke Key.”
Options: Wake Key (Default) / Power Key / Ctrl+F1 / Ctrl+F2 / Ctrl+F3 /
Ctrl +F4 / Ctrl+F5 / Ctrl+F6
Specific Key Enter
This item will show only when Keyboard PowerOn is set “Specific Key.” Press
Enter to set Specific key.
PS2 Mouse PowerOn
This item allows you to control the mouse power on function.
Options: Disabled (Default) / Enabled
CPU Configuration
This item shows CPU Information
