BioZone BZ-PR45/05 User manual

BioZone Maintance
The service of BioZone is simple.
The only part that needs maintenance/
replacement is the UV lamp.
If the device is used continuously, replace the
lamp once a year. If the device is used
occasionally, the lamp stays for 2-3 years
depending on the level of pollution.
If the unit is used in a smoky rooms or in a heavy
contaminated air, it is recommended to clean the
lamp with soft fabric and disinfectant every other
month. This greatly increases the life of the lamp.
(NOTE: When cleaning the UV lamp, it should be
cold.)
1
BioZone Portugal, Lubelias, www.biozone.one, [phone]

2
UV-lamp replacement
After approximately one year of continuous use (2-3 years if the device is used
occasionally) the power of the UV lamp decreases and it needs to be replaced.
You also get an indication when the light under the word "POWER" starts to
turn red.
Set the control to "Off" and disconnect the unit.
Make sure the lamp is cold
Unscrew the back piece to reach the lamp.
Remove the clips that hold the lamp. These you do not need to put back. (They
are only ment to secure the original transportation from the factory.)
Carefully remove the lamp by pulling the lamp out of the socket.
Insert the new lamp without touching the glass with your fingers. (use only
BioZone original lamps, the use of another lamp will void the warranty)
Replace the back cover, plug in and start the device. Make sure the UV light is
on (blue or green light).
Now you can reset time calculator by pressing one end of a clip or a needle for
10 seconds in the small hole under the word "RESET". You must press until the
lamp under "POWER" lights up and you can hear a click.
If you want to clean the fan, it is usually enough to spray with a standard
compressed air spray.
NOTE! Hazardous waste! The lamp is thrown in containers intended for
lamps containing mercury.
Unit Lamp #
BZ-PR45/05 lamp # 10-08010
BZ -PR90/10 lamp # 10-08025
BZ-PR180/20 lamp # 10-08050
BZ-PR270/30 lamp # 10-08100
Operating Costs
BioZone's devices include advanced electronics with its own unique
power supply that ensures that the UV lamp can keep the wavelengths
required for optimal air purification. BioZone uses 12V, making it safe to
use.
BioZone air cleaner requires almost no maintenance (except for lamp
replacements) and is easy to handle and cheap to own. The power
consumtion is less than 15W.
BioZone Portugal, Lubelias, www.biozone.one, [phone]

3
Managing Basic PR
ON / OFF button
Press once to start the device. Note that it takes a few seconds before the
lamp indicator lights up. (The indicator is the small round window under the
logo. The lamp under the word "POWER" will illuminate when the device is
operating normally. When the lamp under the word "POWER" begins to turn
red, it is time to replace the UV lamp in the device.
Press once again and the unit goes to night mode, meaning it is still cleaning,
but all lights will go out. During night mode, however, the lamp under the word
"POWER" will flash. Press again to turn the device off completely.
Note that the lights on the display and under the log can be blue or green and
differ in strenght depending on the individual device. This does not effect the
capacity.
TIMER
You can set the device for 2, 4 or 8 hours. After the specified time, it will stop
until you set new time or turn it on for continuous operation. It goes
continuously when the lamp under "ON" lights up.
FAN SPEED - LOW, MED and HIGH
For example, use LOW in the bedroom for the least possible sound. Use MED
for continuous operation in larger rooms. Use HIGH if you burn something in
the oven or that something allergic is extra difficult for a while.
Maintenance
Basic PR requires only a minimal amount of maintenance. If the device is in a
very smokey or dusty environment we suggest you open the unit and clean the
UV lamp with a soft cloth using alcohol (every 3 months). NOTE! The device
should be unplugged and the lamp should be cold first. If you do not clean the
lamp, the cleaning effect is gradually reduced.
Adapter
The adapter comes with both EU and UK contact. If you need to change, push
down the small latch next to the power plug and turn counter clockwise until the
plug is unplugged. The new plug sits down into the hole and turns clockwise until
you hear that the connector clicks.
BioZone Portugal, Lubelias, www.biozone.one, [phone]

4
Specifications
Size 80x270x220 mm
Weight approx. 1,5 kg
Cord length 2,8 m
Power consumption < 15W
Ozone output Accumulation will not exceed 0.04 ppm, if the device
is used according to instructions.
Ion Generation Photo ionization of negative ions.
Material ABS, Aluminium Composite.
Remot Control Portable Infrared Remote Controller (range up to 6 m)
Electrical input 12 V DC
Power Cord AC/DC transformer, ”B” type – center pin ”+”.
Temperatures between -20 garder C to + 40 grader C.
Manufacturing Made in China, EPA-approved factory.
Warranty 1 year
BioZone Portugal, Lubelias, www.biozone.one, [phone]

5
Before you may return your BioZone, we would like you to investigate the following:
The fan works but the lamp is not lit:
Check that the lamp is securely placed in its holder by opening the cover at the back
Check that the back cover is securely closed.
The device is equipped with a defense against overheating. It may have been activated.
Disconnect the device and wait 30 minutes before attempting again.
The lamp may be broken. Replace with a new one. Contact Us!
Neither the fan nor the lamp works:
Verify that the device is properly connected to the adapter and power cord.
Make sure there is no fault in the power outage in your home.
The lamp "Power ”flashes red:
If you have just changed the lamp and the unit starts flashing, you must press "reset" to
stop the red blinking.
Or else
Verify that the device is properly connected to the adapter and power cord.
Make sure there is no fault in the power outage in your home.
Switch off the device and disconnect the power for 10 seconds and re-enable it.
If the lamp under the word "POWER" continues to flash red replace the UV lamp.
If none of the above works please contact us before returning, so that we can help you!
Complaints
BioZone Portugal, Lubelias, www.biozone.one, [phone]

6
Warranty
Warranty
The BioZone devices are manufactured and tested according to the
latest methods. The carefully selected components and fabrication
materials ensure you a carefree use.
We grant one (1) year product warranty on both the device and the
lamp calculated from the date of purchase.
The purchase receipt or invoice is valid as a guarantee certificate.
The warranty does not apply if the appliance has become neglected, for
example been dropped at the floor, has been exposed to water or if you
have not used original lamps or original power sources.
The warranty does not apply unless the device is used in accordance
with the instructions.
The warranty does not apply to damage caused by lightning strikes.
If you have any problems, contact us at [phone], or via the
website www.biozone.zone.
