BioZone MobiZone MZ-III User manual

1
BioZone Portugal, Lubelias, www.biozone.one, [phone]
BioZone MobiZone
GENUINE PURE AIR ON-THE-GO
Pure air everywere
Applications:
MobiZone is installed in cars or boats for
clean air in general or to remove
contaminants and odors caused by for
example cigarette smoke, exhaust gas, food,
exercise clothes and/or pets.
MobiZone is installed in lorries, taxis,
ambulances to prevent contamination and
remove unwanted smells.
MobiZone is easy to bring on the trip for use
in hotel rooms to prevent contamination by
viruses and bacteria and/or to clean the air.
MobiZone is installed on the desktop for
improvement of air around the workplace.
MobiZone is installed in bedrooms between
1-15 sqm for improvement of air.

How does BioZone work?
2
BioZone Portugal, Lubelias, www.biozone.one, [phone]
Problems
We are increasingly exposed to pollution that damages our health. These
pollutants can be divided into three groups: biological pollutants, poisonous
gases and particles. Mold or moisture in the basement, pet, cigarette
smoke, viruses and bacteria creates an unhealthy environment in the home
that increases the risk of asthma and allergies.
BioZone cleans the air in the car, boat or room. Place on the
dashboard with the supplied mat or on the bedside table in the hotel
room or on the desk. Plug it into the 12 V socket in the car or the boat
or in a regular power outlet and enjoy fresh and clean air without any
pollution. Adapters for both outputs included. Biozone has a nice
design and the sound level is negligible.
Air that passes inside a device is exposed to intense bactericidal UV light that breaks
down organic pollutants. The special wavelengths of the UV light react with a catalyst
(aluminum dioxide) and creates from the oxygen and the water in the air, a purifying
plasma that kills bacteria, viruses, mold spores and reduces VOC (volatile chemical
gases), and neutralizes bad odors. The plasma, that is, the ultra-air, is then blown
back into space and brings with it the purifying photoplasma that seeks and destroys
harmful pollutants (at the molecular level) in all areas.
Compared with passive air purification systems, which only can filter out contaminants
and pollutants using a fan, an air purification systems based on plasma technology
are much more effective when you want to clean the air in a whole room or stationary
air that you will not be able to get through a filter.
Air purification systems based on plasma technology continuously operate because
they are not clogged with dirt and do not require replacement or cleaning of any filters.
These are environmentally friendly products that use oxygen and water molecules in
the air.
Our technology relieves the air from an excess of positive ions to negative ions.
Before a thunderstorm, the air is filled with lots of positive ions. Thunderstorms are
one of several ways nature uses to balance. When the thunder passes, a large
amount of negative ions are released.
When negative ions are introduced into the indoor air, the airborne contaminating
particles are drawn to each other, thereby becoming too heavy and falling down to the
floor. Thus they are removed from the air and do not end up in the body via our lung
system.

Do not place the device on a metal surface (fridge, freezer, stereo).
Do not place the device in, for example, a window where the temperature
is likely to rise above 40 degrees. The device can withstand up to 40
degrees Celsius and down to minus 20 degrees Celsius.
Place, if you can, the device near the supply air for maximum circulation of
the photoplasma. Do not place the unit near the exhaust air oulet.
3
Practical information
Safety
Do not look directly into the UV lamp. It's impossible to do the outside, just if you've
opened the device. In case you want to open the device, be sure to turn it off first.
Make sure the air flow to the fan is not blocked.
If the device should fall into water, disconnect it! Do not stop hands in the water.
Do not use the device if the cord or plug is damaged.
Do not use the unit outdoors or on a wet surface. Do not open the device without
disconnecting first.
Do not replace the adapter, make any changes or place heavy objects on the device.
Do not place the cord near heated surfaces.
Note that a small part of the population may be over-sensitive to ozone, even in very
small amounts. Our products are well below the limit, but if you react by having cough
or feeling dry in your throat, you can reduce the use of our products.
For example, clean the bedroom during the day and turn off the unit at night. Then you
get clean air before the night, but do not risk being sensitive to the ozone.
This applies to a very small part of the population. Most people only feel good about
the small level of ozone we produce in connection with our photocatalytic purification
process. It is the same level as you can find outdoors on a regular sunny summer day.
The scent of the cleansing process
Your unit produces a so-called, cleansing photoplasma, the fragrance of which can be
compared to the fragrance of light metal, electricity or even clean sheets. The
fragrance appears at the beginning when the device gets a lot of contaminants to
fight. The fragrance can also come back later, when it starts to get clean in the room
and then you can reduce the effect or use the appliance only occasionally. You can
also reduce the scent by moving the air purifier to a place with better ventilation or
circulation of the air. The scent indicates that the air pollution level is very low and that
the plasma is no longer bound to the contaminants. You can always raise the level
temporarily when the degree of pollution increases (increased number of persons or
animals, smoke, etc.)
BioZone Portugal, Lubelias, www.biozone.one, [phone]

4
UV-lamp replacement
After approximately 1 year of continuous operation (2 years if the device is
used occasionally) the power of the UV lamp decreases and it needs to be
replaced.
Disconnect and wait until the device is cold.
Unscrew the screws on the underside of the unit.
Open the device.
Replace lamp (use only BioZone original light, use of other lamp will cancel
warranty)
Avoid rubbing the glass on the lamp with your fingers. • Close the device,
screw down the screws on the underside, plug in and the device will start
automatically. Check that the UV light is on (low blue light from the inside)?
Note! Environmentally hazardous waste! The lamp is thrown in containers
intended for lamps containing mercury.
Unit Lamp #
MobiZone lamp # 10-04100
Operating Costs
BioZone's devices include advanced electronics with its own unique
power supply that ensures that the UV lamp can keep the wavelengths
required for optimal air purification. BioZone uses 12V, making it safe to
use. BioZone air cleaner requires almost no maintenance (except for lamp
replacements) and is easy to handle and cheap to own. The power
consumtion is less than 15W.
BioZone Portugal, Lubelias, www.biozone.one, [phone]
Practical information

5
Specifications
Size 148mm X 80mm X 37mm
Ozone Ozone levels never rise above 0.03 ppm, if the device
used according to the instructions.
Jonization A low level of negative ions is created by UV light
Material ABS, Aluminum composite
Electric 12V DC (car & boat))
100-240V AC 50-60Hz (wall socket - optional accessory)?
Manufacturing Made in China, EPA-approved factory
Warranty 1 year
BioZone Portugal, Lubelias, www.biozone.one, [phone]
Practical information

6
Before you may return your BioZone, we would like you to investigate the following:
The fan works but the lamp is not lit:
Check that the lamp is securely placed in its holder by opening the device.
Check that the cover is securely closed.
The device is equipped with a defense against overheating. It may have been activated.
Disconnect the device and wait 30 minutes before attempting again.
The lamp may be broken. Replace with a new one. Contact Us!
Neither the fan nor the lamp works:
Verify that the device is properly connected to the adapter and power cord.
Make sure there is no fault in the power outage in your home.
If none of the above works please contact us before returning, so that we can help you!
Complaints
BioZone Portugal, Lubelias, www.biozone.one, [phone]

7
Warranty
Warranty
The BioZone devices are manufactured and tested according to the
latest methods. The carefully selected components and fabrication
materials ensure you a carefree use.
We grant one (1) year product warranty on both the device and the
lamp calculated from the date of purchase.
The purchase receipt or invoice is valid as a guarantee certificate.
The warranty does not apply if the appliance has become neglected, for
example been dropped at the floor, has been exposed to water or if you
have not used original lamps or original power sources.
The warranty does not apply unless the device is used in accordance
with the instructions.
The warranty does not apply to damage caused by lightning strikes.
If you have any problems, contact us at [phone],
or via the website www.biozone.one.
BioZone Portugal, Lubelias, www.biozone.one, [phone]
