Bison 130 User manual

GASOLINE HIGH PRESSURE SHER
OWNERS MANUAL
A
CAUTION Read the instructions before using the machine.

-1-
G150
14.5Mpa 19Mpa 20Mpa 17Mpa
11-13Mpa 15-17Mpa 16-18Mpa 13.5-15Mpa
6.5 L/min 9 L/min 9 L/min 12.6 L/min

1
2
3
4
5
67
8
9
10
11
12
-2-

-3-
A

-4-
FIG. 8
WARNING:
The engine is not provided with oil. It is necessary to fill the unit before starting the engine.
ENGINE OIL (FIG. 8 & 9):
WARNING:
The engine is not provided with oil. It is necessary
to fill the unit before starting the engine. The
engine has two oil fill points at the front and back
of the engine. Remove the desired cap and fill with
the engine oil specified to the upper level mark.
Replace the oil filler cap.
FIG. 9-1
!
FIG. 11
HIGH PRESSURE
CONNECTION
(Figs. 11.-14):
Connect the high pressure
hose A to the unitis high
pressure outlet.
A
Connect the high pressure
hose to the trigger B. Insert
the lance C into the trigger.
Press firmly against the
spring tension and twist
the coupling into the locked
position. Insert the required
nozzle by retracting the
coupling at the end of the
lance, ensure the nozzle is
inserted securely
INSERTING A NOZZLE
(Fig 13):
To insert a nozzle, pull back
the locking collar at the end
of the lance, insert nozzle
and release the collar. This
will lock the nozzle in place.
Ensure the nozzle is inserted
correctly. If not it can fly out
and injure personnel or
damage property.
FIG. 12 FIG. 13 FIG. 14
BC
6
PUMP (FIG.10):
If you buy a machine
without a red breathing
plug, please ignore FIG.9-2
PUMP (FIG.9-2):
WARNING:
If you buy a machine with
a red breathing plug, be
sure to remove the yellow
plastic from the plug before
using it
red breathing plug
yellow plastic
FIG. 9-2 FIG. 10

-5-

E
FIG. 25
-6-

-7-

-8-

-9-

-10-

-11-

-12-
Following operations and maintenance will extend the service life of the pump:
1.After using 20 hours of the new machine, pour out the machine oil,
and add the appropriate amount of kerosene.
Operate the pump without load in 10-15 seconds,
then close the machine and pour out the kerosene, finally add the new oil.
2.Accumulative use after 100 hours,
change the oil in the same way like above.

-13-
