taskman Pressure Washer Service manual

OPERATORS
HANDBOOK
TASKMAN PRESSURE
WASHERS
TASKMAN
PO BOX 41
PLODDER LANE
BOLTON
LANCS
BL4 0LR
Tel: + 44 (0) 845 2304860
Fax: + 44 (0) 1204 854620
www.taskman-uk.co.uk
Issue 62013

CONTENTS
1Introduction
2Declaration of Conformity
4Identification
5Warranty Terms & Conditions
7Safe Working
12 Operation
18 Maintenance and Service
24 Technical Information

ADDENDUM
STARTING PROCEDURE FOR TASKMAN PRESSURE WASHERS FITTED
WITH EASYSTART VALVE
PLEASE ENSURE THAT YOU STAND CLEAR OF THE WATER OUTLET
ON THE PUMP. WATER WILL SPRAY FROM THE PUMP UNTIL THE
VALVE IS CLOSED.
PRIOR TO STARTING ENGINE TURN VALVE TO OPEN POSITION (FIGURE
1)
START ENGINE AS PER ENGINE MANUFACTURERS’ INSTRUCTIONS.
ONCE UNITERRUPTED FLOW OF WATER IS OBSERVED, TURN VALVE
TO CLOSED POSITION (FIGURE 2)
PRESSURE WASHER IS THEN READY TO USE AS PER OWNERS’
MANUAL SUPPLIED WITH MACHINE.
FIGURE 1
FIGURE 2

INTRODUCTION 1
The contents of this Handbook although correct at the time of
publication, may be subject to alteration by the manufacturers
without notice.
TASKMAN operate a policy of continuous product development.
Therefore, some illustrations or text within this publication may differ
from your machine.
WARNING: The operator must read both this handbook and the
Engine Operators Handbook and be familiar with all the controls
before attempting to operate this machine.
The contents of this handbook are designed as a guide to the
machines controls, operation, working capacities and maintenance. It
is not a training manual.
These are the original Instructions in the English Language
issued by TASKMAN to comply with the requirements
of Directive 2006/42/EC

Seddons Plant & Engineers Limited
DECLARATION
OF
CONFORMITY
We: Seddons Plant & Engineers Limited,
Of P.O. Box 41, Plodder Lane, Bolton, Lancs, England BL4 0LR declare that
the following TASKMAN Pressure Washers:-
Models:- PW100PH10/11/12, PW140PH12, PW150PH8/11/12/14, PW170PH13/15
PW170DY15, PW200PH13/15/21, PW200DY15, PW90PH12
Serial Numbers:- . 1001-99000 .
To which this declaration relates, with a maximum net installed power of
6.5Kw. Having been tested in accordance with the Conformity Assessment
Procedure detailed in Annexe V of Directive 2000/14/EC is in conformity with
the provisions of the “Noise Emission in the Environment by Equipment for
use Outdoors Directive 2000/14/EC”. Representative samples of this
equipment was tested and Sound Power Levels (Lwa) recorded of:-
PW100PH10 102db
PW100PH11 97db
PW100PH12 101db
PW140PH12 105db
PW150PH8 102db
PW150PH11 101db
PW150PH12 105db
PW150PH14 103db
PW170PH13 104db
PW170PH15 104db
PW170DY15 111db
PW200PH13 107db
PW200PH15 107db
PW200PH21 105db
PW200DY15 110db
PW9012 104db
