Bissell PROHEAT ADVANCED User manual

Assembly Instructions
WARNING
Refer to the enclosed user guide for complete
instructions and important safety notices.
PROHEAT®
QUICK START GUIDE
160-8122 01/16 RevB
PARTS INCLUDED a. b. c. d.
e. g.
a. Upper Handle
b. Base
c. 3” Tough Stain Tool
d. Upper Hose Rack
e. Lower Hose Rack
f. Long Screws (2)
(taped to Upper Handle)
g. Short Screws (2)
(taped to Upper Handle)
f. h. i.
h. Nozzle Clean Out Tool
i. Trial-Size BISSELL Formula
1
2
1. The only tool you will
need to assemble your
deep cleaner is a Phillips
screwdriver.
2. Slide Upper Handle (a.)
assembly onto lower body
and secure with two long
screws. These screws can be
found taped to the handle.
3. Attach the Upper Hose Rack
(d.) to the back of upper
handle by pushing into open
slots and sliding down until it
snaps into place.
1
2
4. Attach Lower Hose Rack (e.)
by sliding it in place on the
lower body assembly and
securing it with two short
screws.
5. Attach Tough Stain tool to
end of hose. Then wrap flex
hose around hose rack and
secure it into notched out
holder as shown.
1
2

Other Deep Cleaning Formulas
›› BISSELL®OXY Boost
Life makes messes,
especially on carpet. OXY
Boost removes those
stains from your life –
permanently. Tough stains
are no match for this
oxygen formula.
Bst Your
DEEP CLEAN
These formulas shown are not
required to use your deep cleaner.
You can add these to your formula
for dierent cleaning needs.
QUICK START GUIDE For further instructions
reference the User Guide or visit
www.BISSELL.com
›› BISSELL® Renew Boost
Maximize your carpet
cleaner’s performance with
BISSELL Renew Boost
carpet cleaning formula
Enhancer. Renew Boost
revives carpets to look
their best.
Product Features
Measuring Cup
Your deep cleaner is equipped with a
measuring cup for adding the proper amount
of formula to the 2-in-1 tank. For convenience,
the measuring cup is built into the lid.
2-in-1 Tank ™
Our 2-in-1 Tank™ system is designed with a
heavy duty bladder inside. As you clean, the
clean water in the bladder will mix with the
cleaning formula. Dirty water will be pulled
out of your carpets and collect around the
outside of the bladder, keeping the clean and
dirty water separate. This allows for maximum
space, while still only carrying one tank to and
from the sink.
Removable Nozzle
Cleaning your machine after you’re done has
never been easier! With the machine turned
o and unplugged, this nozzle pops o for
rinsing in the sink. Use the Nozzle Clean Out
Tool also! Slide the tool into the slot that
touches the floor. Work the tool to remove
debris that may be caught in the nozzle.
