BitFenix SHADOW User manual

SHADOW
Quick Installation Guide

Box Contents
* Contents and specificaons subject to change without noce.
•Shadow Case
•
Shadow Quick Installaon Guide
Screws:
Accessories:
6-32 Long screws for front fans : x 4
Power supply bracket: x 1
6-32 Flat screws for MB and HDD (black): x 28
6-32 Hex screws for power supply/PCI bracket (black): x 6
M3 Round screws for ODD/SSD (black): x 12
Motherboard standoffs for mATX motherboards (brass): x 2
01

Removing side panels
a. Remove side panelsb.
Remove thumbscrews
Top Front Side Back
Basic Installaon
02

Installing 5.25" drives
a. Remove ODD bay cover b. Turn counterclockwise and pull
drive-locking mechanism
d. Replace drive-locking
mechanism
c. Slide drive into drive bay
A
03

Installing 3.5" drives
b. Install drive by sliding into place a. Turn counterclockwise and pull
drive-locking mechanism
c. Replace drive-locking
mechanism
A
04

a. Slide 2.5" drive into place
Installing 2.5" drives
b. Install device with screws
(
M3 Round screws )
05

a. b.Install side panels Replace thumbscrews
Replacing side panels
06

Headphone
Microphone
USB 3.0
USB 2.0
LED color change button
LED on/off button
Power button
Reset button
07

a.
c. d.
b.Remove front panel Install fans
Secure with screws
(6-32 Long screws)
Replace front panel
Front Fan Installaon
08

09

10

11

Dust Filters
a. Remove front filter by pressing down
the two top corners
b. Remove front filter by gently pulling out
c. Remove boom filter by pulling out
12

Ver 1.0 : 2013/08
Bitfenix Co., Ltd.
3F-10, No.79, Sec. 1, Xin Tai 5th Rd.,
Xi Zhi District, New Taipei City, Taiwan, R.O.C.
For the most updated information, please visit our official website: http://www.bitfenix.com
© 2013 BITFENIX Co., Ltd. All Rights Reserved. All trademarks are registered to their respective owners.
