BitFenix NOVA User manual

Nova Quick Installaon Guide
Accessory:
10x Mainboard screws (6-32)
3x Mainboard standoffs (6 standoffs are embedded on the Mainboard tray)
16x 3.5” HDD screws
4x 2.5” HDD/SSD screws
3x Front-Panel screws
1x Speaker
Contents

Front Panel
Dust Filter
Fan (120mm)
ODD clip
Side Panel
Windos Panel

Front Top Back Le Side
How to remove the side panels
Basic Installaon
a. Remove thumbscrews b. Slide the side panels towards the
back of the case

How to remove/clean the PSU dust filters
FRONT
Remove front panel
BOTTOM
Pull the PSU dust filter away from the case to remove it

Installing 3.5” Drives
Installing 2.5” Drives
a. Slide drive into drive bay
a. Slide drive into drive bay
b. Secure with screws (for extra support, remove right sidepanel and install screws
on the right side as well)
b. Secure with screws (for extra support, remove right
sidepanel and install screws on the right side as well)

Remove the front panel and Install up to two 120mm fan(s).
Install up to two 120mm fan.
Back Fan Installaon
Front Fan Installaon

a. Remove drive cover b. Slide drive into drive bay
c. Squeeze and pull drive-locking mechanism
PSU/PSU Cover Installaon
Installing 5.25"drives
a. Push the PSU cover up and slide it to
the right.
b. Insert your PSU and secure it with the
PSU screws(6.32-Hex).

A. HDD LED(red)
B. Power LED(white)
C. USB 2.0x1 / USB 3.0x1
D. Power Buon
E. Headphone jack
F. Microphone jack
G. Reset Buon
A B C D E F G

Contents and Specification are subject to change without notice
