BITMAIN AntMiner D3 User manual

AntMiner D3
Installation Guide
Document Version 0.1
Aug 2017
© Copyright Bitmain Technologies Ltd. 2007 –2016. All rights reserved.
Bitmain Technologies Ltd. (Bitmain) reserves the right to make corrections, modifications, enhancements,
improvements, and other changes to its products and services at any time and to discontinue any product
or service without notice.
Customers should obtain the latest relevant information before placing orders and should verify that such
information is current and complete. All products are sold subject to Bitmain's terms and conditions of
sale supplied at the time of order acknowledgment.
Bitmain warrants performance of its products to the specifications applicable at the time of sale in accordance
with Bitmain's standard warranty. Testing and other quality control techniques are used to the extent Bitmain

- 2 -
AntMinerD3InstallationGuide
deems necessary to support this warranty. Except where mandated by government requirements, testing of all
parameters of each product is not necessarily performed.
Bitmain assumes no liability for third-party applications assistance. Customers are responsible for their
products and applications using Bitmain components. To minimize the risks associated with customer products
and applications, customers should provide adequate design and operating safeguards.
Bitmain does not warrant or represent that any license, either express or implied, is granted under any Bitmain
patent right, copyright or other Bitmain intellectual property right relating to any combination, machine, or
process in which Bitmain products or services are used. Information published by Bitmain regarding third-party
products or services does not constitute a license from Bitmain to use such products or services or a warranty
or endorsement thereof. Use of such information may require a license from a third party under the patents or
other intellectual property of the third party, or a license from Bitmain under the patents or other intellectual
property of Bitmain.
Resale of Bitmain products or services with statements different from or beyond the parameters stated by
Bitmain for that product or service voids all express and any implied warranties for the associated Bitmain
product or service and is an unfair and deceptive business practice. Bitmain is not responsible or liable for any
such statements.
All company and brand products and service names are trademarks or registered trademarks of their
respective holders.
All text and figures included in this publication are the exclusive property of Bitmain Technologies Ltd.
(Bitmain), and may not be copied, reproduced, or used in any way without the express written permission of
Bitmain. Information in this document is subject to change without notice and does not represent a
commitment on the part of Bitmain. Although the information in this document has been carefully reviewed,
Bitmain does not warrant it to be free of errors or omissions. Bitmain reserves the right to make corrections,
updates, revisions or changes to the information in this document.
Bitmain Technologies Ltd.
Tel: [phone]
www.bitmain.com

- 3 -
AntMinerD3InstallationGuide
Table of Contents
1. Overview .....................................................................................................................................................4
1.1 AntMiner D3 Components.........................................................................................................................5
1.2 Specification ..............................................................................................................................................6
2. Connecting the Power Supply ......................................................................................................................7
3. Setting Up the Miner....................................................................................................................................9
4. Configuring the Miner ................................................................................................................................ 11
4.1 Setting Up the Pool..................................................................................................................................11
4.2 Modifying the Frequency ........................................................................................................................12
5. Monitoring Your Miner ..............................................................................................................................13
6. Administering Your Miner ................................................................................................................................14
6.1 Checking Your Firmware Version ............................................................................................................14
6.2 Upgrading Your System ...........................................................................................................................14
6.3 Modifying Your Password........................................................................................................................15
6.4 Restoring Initial Settings..........................................................................................................................15

- 4 -
AntMinerD3InstallationGuide
1.Overview.
1. Overview
The AntMiner D3 is Bitmain’s newest version in the AntMiner D3 series. It boasts a state-of-the-art
BM1760 custom-made chip using 28nm technology. All AntMiners D3 are tested and configured prior to
shipping to ensure easy set up.
Power supply unit is not included. Please provide your own ATX power supply.

- 5 -
AntMinerD3InstallationGuide
1.Overview.
1.1 AntMiner D3 Components
The AntMiner D3 main components and controller front panel are shown in the following figure:

- 6 -
AntMinerD3InstallationGuide
1.2 Specification
Hash Rate
17 GH/s±5%
Rated voltage
11.60 ~ 13.00V
Frequency
487M
Estimated wall outlet power consumption (with
APW3, 93% efficiency, 25°C ambient temperature)
970W + 7%
Estimated wall outlet power efficiency (with
APW3, 93% efficiency, 25°C ambient temperature)
57mJ/MH + 7%
Dimensions (L x W x H)
320mm*130mm*190mm
Net weight without packaging
4.2kg
Operating ambient temperature
0 ~ 40°C
The miner does not contain a DC/DC converter; therefore, higher input voltage will cause higher
Mining efficiency.

- 7 -
AntMinerD3InstallationGuide
2. Connecting the Power Supply
2. Connecting the Power Supply
Ten PCI-e connectors are located at the top of the AntMiner D3 for connecting the PSU as follows:
●Nine PCI-e connectors for the hash boards. Each hash board has a set of three PCI-e connectors.
●One PCI-e connector located on the controller.
To connect the power supply:
1. Connect PSU power cable connectors to each of the nine PCI-e connectors on the top of the AntMiner D3,
ensuring that each hash board is powered by the same PSU.
2. Connect a PSU power cable connector to the AntMiner D3 PCI-e connector on the controller.
3. Connect the network cable to the ETH port. (WIFI is unavailable for AntMiners)
4. To power up your AntMiner D3, connect the PSUs to the power wall outlet.
Each hashboard must be powered by the same PSU on both connectors to prevent
Possible damage and instability.
If you are using more than one PSU, power up the PSU connected to the controller AFTER you have
powered up the other PSU(s).

- 8 -
AntMinerD3InstallationGuide
2. Connecting the Power Supply
Figure 2-1. PCI-E Connectors - Correct Connection
Figure 2-2. PCI-E Connectors - Incorrect Connection

- 9 -
AntMinerD3InstallationGuide
3. Setting Up the Miner
3. Setting Up the Miner
To set up the miner:
1. Go to the following site:
https://shop.bitmain.com/support.htm?pid=00720160906053730999PVD2K0vz0693
2. Download the file: IPReporter.zip
3. Extract the file.
4. Right-click IPReporter.exe and run it as Administrator.
5. Select one of the following options:
■ Shelf, Step, Position –suitable for farm miners to mark the location of the miners.
■ Default –suitable for home miners.
6. Click Start.
The file IPReporter.zip is supported by Microsoft Windows only.
The default DHCP network protocol distributes IP addresses automatically.

- 10 -
AntMinerD3InstallationGuide
3. Setting Up the Miner
7. On the controller board, click the IP Report button. Hold it down until it beeps (about 5 seconds).
The IP address will be displayed in a window on your computer screen.
8. In your web browser, enter the IP address provided.
9. Proceed to login using root for both the username and password.
10. In the Network section, you can assign a Static IP address (optional).
11. Click Save & Apply.

- 11 -
AntMinerD3InstallationGuide
4. Configuring the Miner
4. Configuring the Miner
4.1 Setting Up the Pool
To configure the miner:
1. In Miner Configuration, click General Settings.
2. Set the options according to the following table:
Option
Description
Pool URL
Enter the URL of your desired pool.
The AntMiner D3 can be set up with three mining pools, with decreasing
priority from the first pool (pool 1) to the third pool (pool 3).
The pools with low priority will only be used if all higher priority pools are
offline.
Worker
Your worker ID on the selected pool.
Password
The password for your selected worker.
3. Click Save & Apply.

- 12 -
AntMinerD3InstallationGuide
4.2 Modifying the Frequency
You are able to modify the frequency value through ‘Miner Configuration —>Advanced Settings’.
Bitmain recommend a default frequency of AntMiner D3, and Overlocking the miner will void the
warranty immediately.

- 13 -
AntMinerD3InstallationGuide
5. Monitoring Your Miner
5. Monitoring Your Miner
To check the operating status of your miner:
1. Click Miner Status.
2. Under AntMiner, monitor your miner according to the descriptions in the following table:
Option
Description
ASIC#
Number of chips detected in the chain.
Frequency
ASIC frequency setting.
GH/S(RT)
Hash rate of each hash board ( GH/s)
Temp(PCB)
Temperature of each hash board (°C).(Applied only to miner with fixed frequency)
Temp(Chip)
Temperature of the chips on each hash board (°C).
ASIC status
One of the following statuses will appear:
●O - indicates OK
●X - indicates error
●- - indicates dead
6. Administering Your Miner
Note: The D3 miner will stop running when the Temp(PCB) exceeds to
85°C, there will be an error
message “Fatal Error: Temperature is too high!”shown in the bottom of kernel log page.

- 14 -
AntMinerD3InstallationGuide
6. Administering Your Miner
6.1 Checking Your Firmware Version
To check your firmware version:
1. In System, click the Overview tab.
2. File System Version displays the date of the firmware your miner use. (Screenshot below of S9 AntMiner
just for your reference to display the message, the message shows on your computer shall prevail.
6.2 Upgrading Your System
Make sure that the AntMiner D3 remains powered during the upgrade process. If power fails
before the upgrade is completed, you will need to return it to Bitmain for repair.
To upgrade the miner’s firmware:
1. In System, click Upgrade.
2. For Keep Settings:
■ Select the check box to keep your current settings (default).
■ Clear the check box to reset the miner to default settings.
3. Click the (Browse) button and navigate to the upgrade file. Select the upgrade file, then click Flash
image. A message appears notifying you if the AntMiner D3 firmware can be upgraded and if yes, will then

- 15 -
AntMinerD3InstallationGuide
proceed to flash the image. (Note: Please do not extract the update file and keep the power on during
updating firmware or otherwise the AntMiner need to be returned to the factory to repair. And around
two minutes will be needed to complete updating.)
3. When the upgrade is completed successfully, the following message will appear: (Screenshot below of S9
AntMiner just for your reference to show the message, the message shows on your computer shall
prevail.).
6.3 Modifying Your Password
To change your login password:
1. In System, click the Administration tab.
2. Set your new password, then click Save & Apply.
6.4 Restoring Initial Settings
To restore your initial settings, two methods below for your reference.
1. Turn on the miner and let it run for 5 minutes.

- 16 -
AntMinerD3InstallationGuide
2. On the controller front panel, press and hold the Reset button for 10 seconds.
Resetting your miner will reboot it and restore its default settings. The red LED will automatically
flash once every 15 seconds if the reset is operated successfully.
