1.0Application:
Paintoftenbecomesoiled especiallyneardoorways,windows,and inworkand playareas.
Coated surfacesneedtobetested forresistancetoabrasion caused byabrush,sponge,orothermeans.
The WetAbrasion ScrubTestercan producearepeatable, controlled condition tosimulateeverydayuse
orwearpatterns.
BGD526 WetAbrasion Scrub Tester isthe newestmachine whichisdeveloped byBiuged .It
can examine washabilityand related propertiesthataffectthe stainresistanceofcoatings.Detergent
performancetestingcan alsobedetermined inareproduciblemanner.
It accordswithstandardssuchasASTMD2486、ASTMD3450、DINEN11330、ISO11998 etc.
Feature
◆Runningspeed can besettomeet requirementsofdifferent standards.
◆Withfour-digitcounter,startthe machine anditwill automaticallybestopped when reachingset
times.
◆Compatiblewithavarietyof abrasion padstocomplywithdifferentstandardsrequirements,suchas
ISO, ASTM, DINetc..
◆Quicklyand easilytoloadandunload testingsamplesand replacingabrasion head.
◆Can worknormallyunderdifferent voltageand frequency
◆Withstableand uniformrunningspeed becauseofPush-rod design
◆Featurestwobrushholdersforside byside testing
◆Longservicelifewithhardanddurabledesign
◆The wholemachine bodyismade ofanodized aluminum,havingstableworking status,repeatable
test results,no exception even inthefastest speed ofthe stroke.
◆Liquidsolutionsarepumped tothe brushheadsfromthe detachablecontainermounted totheside of
the tester.The pumpmaybeswitched on oroffduringthe courseoftesting,and the flowcan be
adjustedforprecisedosing.
2.0MainTechnical Parameter
2.1 Specification ofbrush evenlydistributed 60-diameter3holesonthe38×90mmbaseboard,with
pigbristleinserted, lengthoffeather19mm.
2.2 Weightofbrush（includingdeviceholdingbrush） 454±10g（ASTMD2486）； 135±1g（ISO11998）
2.3 StrokeLength 300mm
2.4 Frequencyoftravel 595 times/min（adjustable）
2.5 Rangeofcount 9999times
2.6 Sizeoftest plate 430×150×0.03mm
2.7 Powerofmotor 25W
2.8 Power 110V 220V；50/60Hz
2.9 Overallsize 500×460×280mm
2.10 CapacityofWaterContainer 5L
6.0Report
Recordthe numberofcyclestoremoveone continuousthinline ofpaintfilmacross the 12.7mm
widthoftheshim.Stopthemachine andwipeoffthe shimarea todetermine,ifnecessary,ifthe end
point isachieved.
Testtwoof the drawdowns.If the tworesultsdifferbymorethan30%of theaverage,testthethird
drawdown.Ifone ofthe three resultsisobviouslydiscrepant, discardit, thenaveragethe resultsfromthe
remainingdrawdowns.
7.0WaterContainer
7.1 WashingLiquidcan’tbeusedcyclicallyincasethewaterpipeisblocked.Theoperatorshould
prepareanothercontainertoreceivethe wastewashingliquidwhichisdischarged fromdrainpipe.
7.2 Insert the feed-waterpipeintothe quick fittingsofwatercontainerand ensureit’stight
7.3 Connect theplugofwaterpumptosocket ofpumpwhichislocated theside ofmachine. Connection
forwatercontainerisfinished.
7.4 Pleaseclean thewatercontaineraftereverytest,thestepisasbelow press the blue part of quick
fittingsand pull out thesoft waterpipeat the sametime. See the belowpicture.
7.5 Open thecoverofwatercontainerthen clean it
8.0Maintenance
8.1 Clean andmachine withclean andsoft clothafterusing, keepit inthe dryandcleanenvironment。
8.2 Replacethebrushwhen the bristleshavebecomeworntoapoint that thebristlesextend less than
15mmfromthe block. Markthe endsofthebrushtoensureit isorientedinthe samedirection foreach
use.
8.3 Don’t cut off the supplyofwashingliquidwhen pumpisworking.
9. 0Warranty
9.1 Themachine iswarranted inrespectofmaterialsand workmanshipfor12 monthsfromthe dateof
purchase.Anydefectivepartswithinthe machine arisingduringthe warrantyperiod,shall be
replaced free ofchargesubject toourinspection.
9.2 Anydefectivepartswithinthemachine arisingoutofthe warrantyperiod:shall bereplacedatclient’s
expense.
9.3 Underthe following conditions,wewill notberesponsibleforthe replacementduringthe warranty
period:
lWithout invoiceorreceipt.
lDamaged bywrongassemblingordisassembling.
lDamaged bywrongorcareless operation.
lDamaged bywrongoperatingunderimpropercondition.
lDamaged bybroken packingduringtransportation.
10.0PackingList
BGD527WetAbrasion ScratchTester1unit
SpecialBrush1pair
Watercontainerwithpump1unit
Brass Shim2pcs （Optional）
Operation Manual1pc
11.0Others
11.1Selectical Optional Accessories
BGD2208----Stand scrubplasticpanels（100pcs/box）
BGD2214----Stand scrubconcretepanels（100pcs/box）
BGD1365----Stand Brush （1pair）
BGD2355----Brass Shim （2pcs）
11.2Others
Forfurtherinformation, pleasecontact Biuged,yourlocalsupplier, orvisit ourwebsiteat
www.biuged.com
