BUG ZAPPERBUG ZAPPER
INSTRUCTION MANUAL
CATALOG NUMBER:
BDPC971
Thank you for choosing BLACK + DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER
purchase, go to www.blackanddecker.com. If you can’t find the answer or do
not have access to the Internet, call 1-888-338-6798 from 9:00 a.m. to 5:00 p.m.
EST Mon. - Fri. to speak with an agent.
Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.

IMPORTANT SAFETY
INSTRUCTIONS.
READ ALL INSTRUCTIONS
BEFORE USING.
DO NOT PLACE UNIT IN AN
AREA WHERE IT CAN FALL
INTO WATER OR NEAR
FLAMMABLE MATERIALS.
DO NOT CLEAN UNIT WITH
WATER OR LIQUID.
SAVE THIS MANUAL FOR
FUTURE REFERENCE.

CONTENTS
SAFETY INFORMATION
Important Safety Instructions ...........................................................................................................................2
ELECTRICAL REQUIREMENTS
Power Cord Supply ..............................................................................................................................................3
SET UP & USE
Proper Location ....................................................................................................................................................3
How to Use ............................................................................................................................................................4
MAINTENANCE
Cleaning and Removing Bottom Tray .............................................................................................................4
Cleaning Electric Grid .........................................................................................................................................5
How to Replace Bulb ...........................................................................................................................................6
CUSTOMER SERVICE
Troubleshooting ...................................................................................................................................................7
Contact us .............................................................................................................................................................7
Limited Warranty .................................................................................................................................................8
PRODUCT REGISTRATION
Remember to record the model number
of this device located on the base of this
unit
Staple your receipt to your manual. You
will need it to obtain warranty service.
Model number
Date of purchase
Page 1
PRODUCT SPECIFICATIONS
Model: BDPC971
Coverage: 2 ACRE
Bulb Wattage: 2x36W
Grid Voltage: 4,000V
Replacement Bulb: 2G11 36W
TO REGISTER YOUR PRODUCT VISIT: BLACKANDDECKERPESTCONTROL.COM

Page 2
PLEASE READ THESE INSTRUCTIONS BEFORE USING THE INSECT ZAPPER
1. Household use only.
2. Extension cords are available. Extension cord can be used, such as “Use
extension cord marked SJW-A, SJEW-A, or SJTW-A only”, or the equivalent.
3. Use only extension cords which have plugs and receptacles which accept the
product’s plug. Replace or repair damaged cords.
4. The electrical rating of the extension cord must be as great as the electrical
rating of the product.
5. Don’t Abuse Cord – Never carry product by cord or yank it to disconnect from
receptacle. Keep cord from heat, oil, and sharp edges.
6. Disconnect the product from the power supply when not in use, before
servicing, when changing bulbs, cleaning, and similar actions.
7. Do not insert foreign objects into this product.
8. Outdoor extension cords must be used with outdoor use products and are
surface marked with sux letters “W-A” and with a tag stating “Suitable for Use
with Outdoor Appliances”.
9. The connection to an extension cord should be kept dry and o the ground.
10. Store products indoors when not in use – out of reach of children.
11. Do not clean this product with a water spray or similar method.
12. The product should only be connected to a circuit that is protected by a
ground-fault circuit-interrupter (GFCI).
13. Any other servicing should be performed by a service representative.
14. If the unit is malfunctioning, unplug it and contact the manufacturer.
15. Do not place unit in an area where it can fall into water or near flammable
materials.
16. Avoid looking directly into the UV light. Skin or Eye damage may result from
directly viewing the light produced by the lamp in this apparatus.
17. Insects accumulating within base of the unit may contribute to fire. Clean dead
insects from unit frequently as noted in this manual.
18. Lamps are replaceable by user. See replacement bulb information located in
this manual.
SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS:
DANGER: Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING: Indicates an imminently hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates an imminently hazardous situation which, if not avoided, may
result in minor or moderate injury.
WARNING: When using electrical appliances, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and personal injury:
NOTICE: Indicates a practice not related to personal injury which, if not avoided,
may result in property damage.
WARNING: This product can expose you to certain chemicals, which are known to the
State of California to cause cancer or birth defects or other reproductive
harm. For more information go to: www.P65Warnings.ca.gov

Page 3
POWER SUPPLY CORD:
1. This device is equipped with a 2-prong plug to fit proper type receptacles.. To reduce
the risk of fire or injury, only plug into a properly installed outlet.
2. Extension cords if needed for this product must be marked with sux letters “W-A”
and with a tag stating “Suitable for use with outdoor appliances”.
3. Connections between power supply cord and extension cord if used should be kept
o the ground and dry.
NOTE: Neither BLACK+DECKER nor the dealer can accept any liability for damage to the product or
personal injury resulting from failure to observe the electrical connection procedures.
SET UP AND USE
PROPER LOCATION:
ELECTRICAL REQUIREMENTS
HOME
ZAPPER
AWG
Minumum Gauge for Extension Cord Sets
18 16 16 14
25 (7.6) 50 (15.2) 100 (30.5) 150 (45.7)
Length
Feet (Meters)
Flying insects will always be more attracted to humans than to lights, however they will
gravitate to the strongest light source in the area.
We suggest when flying insects are very aggressive in your area, try and stay away from
the bug zapper for a few days with only the light of the zapper on. This will help lure
them into its trap and kill off the majority of insects. Depending on the insect population,
two weeks or more may be necessary to significantly reduce the population.
When determining where to place the unit for best results, locate a spot away from human
activity. Select a location within the insect’s natural habitat including near bushes, low
trees and ground coverage such as Ivy. This will ensure the best possible results. Device
should also be placed between 6’-7’ above the ground using the included chain. Suitable
hanging locations include from a tree, mounting pole, or other free standing object.

Page 4
1. Unpack unit and save all packaging material for storage when season is over.
2. Select the proper location as noted in above instructions.
3. Plug the cord into a compatible extension cord if needed as noted in above
electrical instructions.
4. Once plugged into powered outlet, the device is active. UV lights should
illuminate and zapper is ready for use.
5. If using removable bottom tray, make sure to clean the tray often of dead insects.
6. If using over natural setting, remove tray permanently (see instructions below)
to allow zapped insects to fall freely through onto the ground. This will eliminate
the need to clear away dead insects that can build up inside the tray.
7. If zapping grid shows signs of accumulation of dead insects on the live electrified
grid, occasional cleaning of wire grid may be required (see further instructions
detailing this process).
8. It is recommended that this unit be placed into use from early Spring until late
Fall for best results.
9. The device is designed to withstand moderate rain. If severe weather is expected,
it is recommended to remove this device and store indoors until severe weather
has passed.
10. Unplug device when not in use.
REMOVING & CLEANING BOTTOM TRAY:
MAINTENANCE
Removal of bottom tray when unit is placed in yard eliminates the need to empty bottom
tray for insect removal.
If bottom tray is intended to contain dead insects from falling to ground, tray should be
emptied frequently. Use caution and use gloves when opening tray as some dead insects
potentially may fall out of tray upon removal.
HOW TO USE:
The BDPC971 Electronic Bug Zapper exterior housing does not require cleaning. Periodic
rainfall will clean the exterior. Do not attempt to clean the housing with water or spray or
any other liquids.
To remove tray:
Slide out as shown

Page 5
• In areas with large insect populations, electric
grid may begin to accumulate dead insects on
the grid that can aect the function of the device.
To ensure eective use of this device periodic
cleaning of electric grid with included brush may
be necessary.
• Rate of cleaning depends on insect population in
your area.
1. Unplug the device and remove unit from hanging position and allow it to sit for three
hours to allow all electricity in unit to disperse.
2. Access grid through the open slots in grill as shown using included cleaning brush and
gently brush away dead insects so they fall down into the lower tray for removal.
3. Never use water to clean the unit as this can cause damage to the electronics.
4. Use care and make sure not to move the metal electric grid.
5. Return unit to hanging position and plug back in
ELECTRIC GRID CLEANING:
WARNING:
Always unplug your Bug Zapper before cleaning to
avoid electric shock. When cleaning electric grid, only
use included cleaning brush to avoid any risk of shock
or injury. Ignoring this warning may result in death or
injury.

Page 6
1. To prepare for bulb replacement, unplug unit and allow it to sit for two hours to allow
the electrical charge within the unit to dissipate.
2. Remove the tray. (As indicated on Pg. 4)
3. Remove both screws securing grate panel. (Fig. 1)
4. Lift up grate to access bulb. (Fig. 2)
5. Wearing gloves, Gently tug on the bulb to remove. (Fig. 3)
6. Replace bulb only with proper Black and Decker replacement bulbs.
7. Wearing gloves, insert replacement bulbs making sure they are properly seated into
the sockets that they were removed from.
8. Gently apply pressure on bulbs until they snap into socket securely.
9. Place grate plate back into position and fasten with screws.
10. If using base tray, slide back into place on bottom of unit.
11. Plug in to test replaced bulb functions properly.
12. Replaceable lamp, type 2G11 36W,Rated 36W for model BDPC971
HOW TO REPLACE BULB:
NOTE: Bulb contains mercury, dispose of properly.
To order replacement bulbs email: [e-mail]
or call 1-888-338-6798
Fig. 1 Fig. 2 Fig. 3
NOTE: If device fails to light after bulb replacement, unplug device, and following the
instructions above ensure that the bulb was correctly installed, and re-assemble unit.

Device does not light but appears to have voltage through the electrical grid:
•Unplug unit and check if bulb is properly seated in socket.
•Unplug unit and replace bulb if necessary.
Device does not light and electrical grid does not appear to have voltage:
•Ensure device is plugged into a functioning outlet.
Device appears to be functioning (light and zapper work) but insect population does not
appear to have been reduced:
•Move unit to another area in yard for better results.
•Allow more time. It can take several weeks for device to aect the insect population
depending on the density of insects.
•Check surrounding area to ensure there are no features that may be drawing the insects
to your location. Examples include standing water, refuse and bright lights that may
compete with the light output of this unit.
Unit is sparking/arcing constantly:
•Unplug the unit and clean the electric grid of the device as instructed previously in
Electric Grid Cleaning (Pg. 5)
If troubleshooting does not solve the problems you are encountering,
or if you have further questions not answered by these instructions,
please call our customer service at 1-888-338-6798 or email [e-mail]
IMPORTANT! DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product
please contact Customer Service at 1-888-338-6798 or email: [e-mail]
DATED PROOF OF PURCHASE and MODEL# REQUIRED FOR WARRANTY SERVICE
CUSTOMER SERVICE
BEFORE YOU CALL CUSTOMER SERVICE:
1. Check to make sure that the zapper is plugged in securely. If it is not, remove the plug
from the outlet, wait 10 seconds and plug it in again securely.
2. Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to be
operating properly, test the outlet with another appliance.
CONTACT US:
Page 7
TROUBLESHOOTING:
Do not try to adjust or repair the zapper yourself. Component parts shall be replaced
with like components. Servicing shall be done by factory authorized service personnel
to minimize the risk of possible ignition due to incorrect parts or improper service.
WARNING:

Printed in P.R.C
BLACK & DECKER, BLACK+DECKER, the BLACK & DECKER and BLACK+DECKER logos and product
names and the orange and black color scheme are trademarks of The Black & Decker Corporation, used
under license. All rights reserved.
Product in this box may dier slightly from that pictured. Does not aect function. Not all accessories
shown in photography are included in this package.
Imported by Umba Group, 500 River Ave, Lakewood, NJ 08701
LIMITED WARRANTY:
Any repair, replacement, or warranty service,
and all questions about this product should be
directed to Umba Group at 1-888-338-6798
Umba Group. warrants to the original purchaser that
the product will be free from defects in material,
parts and workmanship for the period designated
for this product. The warranty commences the day
the product is purchased and covers up to a period
of 2 years (24 months) for labor 2 years (24 months)
(manufacturing defects only)/carry in service/ and
a total of 2 years (24 months). UV bulb carried 6
month warranty. Umba Group agrees that it will, at
its option, replace the defective product with either
a new or re-manufactured unit equivalent to your
original purchase during the warranty period.
1. This warranty does not apply to the below:
If the appearance or exterior of the product
has been damaged or defaced, altered or
modified in design or construction.
2. If the product original serial number has
been altered or removed or cannot be readily
determined.
3. If there is damaged due to power line cord
or connection to improper voltage source.
4. If damage is due to general misuse, accidents
or acts of God.
5. If repair attempts are done by unauthorized
service agents, use of parts other than
genuine parts or parts obtained from persons
other than authorized service companies.
6. On units that have been transferred from the
original owner.
7. On products that have been purchased as
refurbished, like new, second-hand, in a “As-
Is” or “Final Sale” terms.
8. To products used in a commercial or rental
setting.
9. To products used in settings other than
ordinary household use or used other than in
accordance with the provided instructions.
10. To damages for service calls for Improper
installations.
11. Transportation and shipping costs associated
with the replacement of the unit.
12. Service calls to instruct you how to use your
product.
13. Service calls to repair or replace the house
fuse, reset the circuit breaker or correct the
wiring in the house.
Exclusions:
REPAIR OR REPLACEMENT AS PROVIDED
UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CUSTOMER; Umba Group.
SHALL NOT BE LIABLE FOR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR
BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY ON THIS PRODUCT, EXCEPT TO
THE EXTENT PROHIBITED BY APPLICABLE
LAW. ANY IMPLIED WARRANTY OF
MERCHANTABILITY OF FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED TO THE DURATION OF THE
WARRANTY.
Some states do not allow the exclusion or
limitations of incidental or consequential
damages, or limitations on how long the
warranty lasts. In these cases the above
exclusions or limitations may not apply to you.
This warranty gives you specific legal rights
and you may also have other rights which vary
from state to state.
Obtaining Service: To obtain service, product
literature, supplies or accessories please call
888-338-6798 to create a ticket for exchange/
repair. Please make sure to provide the date
of purchase, model number and a brief
description of the problem. Our customer
service representative will contact you or send
detailed return instructions.
Umba Group does not warrant that the appliance
will work properly in all environmental conditions,
and makes no warranty and representation, either
implied or expressed, with respect to the quality,
performance, merchantability, or fitness for a
particular purpose or other than the purpose
identified within this user’s manual. Umba Group
has made every eort to ensure that this user’s
manual is accurate and disclaims liability for
any inaccuracies or omissions that may have
occurred. Information in this user’s manual is
subject to change without notice and does not
represent a commitment on the part of Umba
Group. Umba Group. reserves the right to make
improvements to this user’s manual and/or to
the products described in this user’s manual at
any time without notice. If you find information
in this manual that is incorrect, misleading, or
incomplete, please contact us at 888-338-6798
Umba Group
500 River Ave
Lakewood, NJ 08701
Page 8

Printed in P.R.C
