Black & Decker Powerful Solutions AS36LN User manual

English 4
INDONESIA 16
AS36LN
This manual is applicable for A9, KR, B1 and JP
Black & Decker Copyright 2009
90581821

2
➇
➃
➃
➆
➄
➅
➅
➂
➂
➉
➈
➈
B
ED
CA
11
13
➁
➁
➀

3
G3
2F1F
G2
1G3F
➆
➆
➆
12
12

4
ENGLISH
3.6V Li-ion Screwdriver
AS36LN
Technical Data
Cordless Screwdriver AS36LN
Voltage VDC 3.6
No Load Speed RPM 180
Max. Torque Nm 4.8
Bit Holder mm (Hex) 6.35
Weight kg 0.5
Battery
Voltage V 3.6
Type Li-ion
Capacity Ah 1.1
Charger
Approx. Charging Time Hour 6 (fully charged)
Weight kg 0.4
Intended Use
Your Black & Decker compact screwdriver has been designed for screwdriving applications.
The tool is intended for consumer use only.
Your Black & Decker charger has been designed for charging Black & Decker batteries of
the type supplied with this tool.
Safety Instructions
When using power tools, always observe the safety regulations applicable in your
country to reduce the risk of fire, electric shock, personal injury and material damage.
Read the following safety instructions before attempting to operate this product. Keep
these instructions in a safe place!
The following symbols are used throughout this manual:
Denotes risk of personal injury, loss of life or damage to the tool in case of non-
observance of the instructions in this manual.

5
ENGLISH
Denotes risk of electric shock.
Fire hazard.
1. Keep work area clean. Cluttered areas and benches can cause accidents.
2. Consider work area environment. Do not expose power tool to humidity. Keep work
area well lit (250-300 Lux). Do not use power tools in the presence of inflammable liquids
or gases.
3. Keep children away. Do not let children come into contact with the tool or extension
cord. Keep all people away from the work area.
4. Dress properly. Do not wear loose clothing or jewelry. They can be caught in moving
parts. Preferably wear rubber gloves and non-slip footwear when working outdoors.
Wear protective hair covering to keep long hair out of the way. When working outdoors,
preferably wear suitable gloves and non-slip footwear.
5. Personal protection. Always use safety glasses. Everyday eyeglasses only have impact
resistant lenses, they are not safety glasses. Use a face or dust mask whenever the
operations may produce dust or flying particles. If these particles might be considerably
hot, also wear a heat-resistant apron. Wear ear protection whenever the sound level
seems uncomfortable, i.e. if the sound pressure stated in this manual exceeds 85 dB(A).
6. Do not overreach. Keep proper footing and balance at all times.
7. Stay alert. Watch what you are doing. Use common sense. Do not operate the tool
when you are tired.
8. Secure workpiece. Use clamps or a vice to hold the workpiece. It is safer and it frees
both hands to operate the tool.
9. Remove adjusting keys and wrenches. Always check that adjusting keys and
wrenches are removed from the tool before switching on.
10. Use appropriate tool. The intended use is laid down in this instruction manual. Do not
force small tools or attachments to do the job of a heavy-duty tool. The tool will do the
job better and safer at the rate for which it was intended. Do not force the tool.
Warning! The use of any accessory or attachment or performance of any operation
with this tool, other than those recommended in this instruction manual may present a
risk of personal injury.
11. Check for damaged parts. Before using the tool, carefully check it for damage
to ensure that it will operate properly and perform its intended function. Check for
misalignment and seizure of moving parts, breakage of parts and any other conditions
that may affect its operation. Have damaged guards or other defective parts repaired or
replaced as instructed. Do not use the tool if the switch is defective. Have any damaged
or defective parts replaced by an authorized repair agent. Never attempt any repairs
yourself.

6
ENGLISH
12. Avoid unintentional starting. Do not carry the plugged-in tool with a finger on the
switch. Be sure that the switch is released when plugging in.
13. Do not abuse cord. Never carry the tool by its cord or yank it to disconnect from the
socket. Keep the cord away from heat, oil and sharp edges.
14. Store idle tools. When not in use, power tools must be stored in a dry place and locked
up securely, out of reach of children.
15. Maintain tools with care. Keep the tools in good condition and clean for better and
safer performance. Follow the instructions for maintenance and changing accessories.
Inspect the tool cords at regular intervals and, if damaged, have them repaired by an
authorized repair agent. Inspect the extension cords periodically and replace them if
damaged. Keep all controls dry, clean and free from oil and grease.
16. Have your tool repaired by an authorized repair agent. This power tool is in
accordance with the relevant safety regulations. To avoid danger, electric appliances
must only be repaired by qualified technicians using original spare parts.
Additional Safety Instructions for Batteries and Chargers
Batteries
17. Never attempt to open for any reason.
18. Do not store in locations where the temperature may exceed 40ºC.
19. Charge only at ambient temperatures between 4ºC and 40ºC.
20. Charge only using the charger provided with the tool (see technical data).
21. When disposing of batteries, follow the instructions given in the section
“Protecting the environment”.
22. Leaks from battery cells can occur under extreme conditions. The battery fluid,
a 25-30% solution of potassium hydroxide, can be harmful. In case of skin contact:: (a)
wash quickly with soap and water; or (b) neutralize with a mild acid such as lemon juice
or vinegar. If the liquid gets into the eyes, flush them immediately with clean water for a
minimum of 10 minutes. Seek medical attention.
23. Fire hazard! Avoid short-circulating the contacts of a detached battery.
24. Do not incinerate the battery.
Chargers
25. Use your Black & Decker charger only to charge the battery in the tool with which it was
supplied. Other batteries could burst, causing personal injury and damage.
26. Never attempt to charge non-rechargeable batteries.

7
ENGLISH
27. Have defective cords replaced immediately.
28. Do not expose to water.
29. Do not open the charger.
30. Do not probe the charger.
31. The charger is intended for indoor use only.
Specific Safety Rules
32. When fitting and changing accessories, always use the instructions supplied with the
accessory.
33. Should your screwdriver develop a fault, do not try to fix it yourself, but take it to one of
our authorized repair agents.
34. Warning: Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth defects or other
reproductive harm. Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically-treated lumber (CCA).
Your risk from these exposures varies, depending on how often you do this type of work.
To reduce your exposure to these chemicals: work in a well ventilated area, and work
with approved safety equipment, such as those dust masks that are specially designed
to filter out microscopic particles.
Avoid prolonged contact with dust from power sanding, sawing, grinding, drilling,
and other construction activities. Wear protective clothing and wash exposed
areas with soap and water. Allowing dust to get into your mouth, eyes, or lay on the
skin may promote absorption of harmful chemicals.

8
ENGLISH
Labels on your tool
They may include the following symbols.
V ............. volts
A ............. Amperes
Hz ............. Hertz
W ............. Watts
Min. ............. Minutes
............. Alternating current
............. Direct current
no............. No load speed
............. Class II Construction
............. Earthing terminal
............. Safety alert symbol
.../min ............. Revolutions or reciprocation per minute
.../bpm ............. Beats per minute
Save these instructions!
Electrical safety
Your charger is double insulated; therefore no earth wire is required. Always check
that the mains voltage corresponds to the voltage on the rating plate. Never attempt to
replace the charger unit with a regular mains plug.
Using an Extension Cable
An extension cable should not be used unless absolutely necessary. Use of an improper
extension cable could result in a risk of fire and electric shock. If an extension cable must be
used, use only those that are approved by the country’s Electrical Authority. Make sure that
extension cord is in good condition before using. Always use the cord that is suitable for the
power input of your charger (see technical data on name plate).
When using a cable reel, always unwind the cable completely.

9
ENGLISH
Fig. A
1. On/off switch
2. Forward/reverse slider
3. Forward/reverse window
4. Bit holder
5. LED light
6. Mode selector / torque adjustment collar
7. Screw holder
8. Charger
9. Charging base
10. Charging indicator
11. Bit storage
Assembly
Fitting the charging base to the wall (fig. A & B)
The charging base (9) can be placed on a worktop or fitted to the wall to provide a
convenient storage and charging point for the tool. Screws and wall anchors are not
included.
Drive screws in the wall with the same distance apart as the slots (13) on the back of the
charging base (9).
The distance between the slots must be 75 mm.
Slide the charging base over the screws to fit the base to the wall.
Plug in the charger (8).
Place the tool on the charging base making sure the charging indicator (10) lights up.
Warning! Avoid damaging the power cord when mounting the charging base to the wall.
Fitting and removing a drill bit or a screwdriver bit (fig. C)
This tool uses screwdriver bits and drill bits with a 6.35 mm (1/4”) hexagonal shank.
To fit a bit, insert the bit shaft into the bit holder (4).
To remove a bit, pull the bit shaft out of the bit holder (4).
◆
◆
◆
◆
◆
◆

10
ENGLISH
Use
Warning! Let the tool work at its own pace. Do not overload.
Before first use, the battery must be charged for at least 9 hours.
Charging the battery (fig. A)
Place the tool on the charging base (9).
Plug in the charger (8).
Leave the tool connected to the charger for 6 hours.
The red light illuminates when the unit is on charge and will stay red as long as there is
power to the charger. The red light will not go off to indicate a full charge.
The charger may hum and become warm while charging; this is normal and does not
indicate a problem.
Warning! Do not charge the battery at ambient temperatures below 4 °C or above 40 °C.
Selecting the direction of rotation (fig. D)
For drilling and for tightening screws, use forward (clockwise) rotation. For loosening screws
or removing a jammed drill bit, use reverse (counterclockwise) rotation.
The forward/reverse window (3) displays the rotation direction with an arrow.
To select forward rotation, push the forward/reverse slider (2) to the forward position.
To select reverse rotation, push the forward/reverse slider (2) to the rearward position.
To lock the tool, set the forward/reverse slider into the centre position.
Selecting the torque (fig. E)
This tool is fitted with a collar to set the torque for various screwdriving and drilling
applications. Large screws and hard workpiece materials require a higher torque setting than
small screws and soft workpiece materials. The collar has a range of 6 settings to suit your
application.
To set the torque, rotate the torque adjustment collar (6) clockwise or counterclockwise.
For screwdriving, set the collar to the desired setting.
If you do not yet know the appropriate setting, proceed as follows:
- Set the collar (6) to the lowest torque setting.
- Tighten the first screw.
◆
◆
◆
◆
◆
◆
◆
◆
◆
