Atlas Copco LUM12 SR Instruction sheet

LUM12 SR
Printed Matter No. 9836 9272 01 Screwdriver
Publication Date 2023-12-07
Valid from Serial No. B0440001 Product Instructions
LUM12 SR3LUM12 SR2LUM12
SR4LUM12 SR1
(0.40.50.40.6-3.52.54.51.8 Nm)
8431027833843
1027834843102
7832843102783
5
WARNING
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference

2© Atlas Copco Industrial Technique AB - 9836 9272 01
Table of Contents
Product Information................................................................................................4
General Information ..........................................................................................4
Safety Signal Words ..............................................................................4
Warranty ................................................................................................4
Website..................................................................................................4
ServAid ..................................................................................................5
Safety Data Sheets MSDS/SDS............................................................5
Country of Origin ...................................................................................5
Dimensional Drawings...........................................................................5
Overview...........................................................................................................5
Technical Product Data .........................................................................5
Installation ...............................................................................................................6
Installation Requirements .................................................................................6
Air Quality ..............................................................................................6
Air Lubrication Guide .............................................................................6
Compressed Air Connection..................................................................6
Operation .................................................................................................................7
Ergonomic Guidelines.......................................................................................7
Configuration Instructions .................................................................................7
Tightening torque ..................................................................................7
Service .....................................................................................................................9
Maintenance Instructions..................................................................................9
Service Recommendations....................................................................9
Service instructions ...............................................................................9
Tightening of Threaded Connections ....................................................9
Grease Guide Screwdrivers ..................................................................9
For Maximum Performance .................................................................10
Reporting, RE - Signal.........................................................................10
Lubrication Instructions...................................................................................10
Rust Protection and Cleaning..............................................................10
Grease Guide Screwdrivers ................................................................10
Lubrication of Motor Parts ...................................................................11
For Maximum Performance .................................................................11
Testing of Tightening Torque..........................................................................11
Torque and Angle Testing Instrument .................................................11
Testjoint and Transducer.....................................................................12
Test joints - High torque range ............................................................14
Air pressure monitoring, RE-signal S1............................................................14
Free speed / Air consumption.........................................................................15
Instructions for vane motor .............................................................................16
Testing of tightening torque ............................................................................16
Torque and angle testing instrument ...................................................16
Testjoint and Transducer.....................................................................17

© Atlas Copco Industrial Technique AB - 9836 9272 01 3
Recycling ...............................................................................................................19
Environmental Regulations.............................................................................19
Recycling information .....................................................................................19

Product Information EN LUM12 SR
4© Atlas Copco Industrial Technique AB - 9836 9272 01
Product Information
General Information
WARNING Risk of Property Damage or Severe Injury
Ensure that you read, understand and follow all instructions before operating the tool. Failure to follow
all the instructions may result in electric shock, fire, property damage and/or severe bodily injury.
►Read all Safety Information delivered together with the different parts of the system.
►Read all Product Instructions for installation, operation and maintenance of the different parts of
the system.
►Read all locally legislated safety regulations regarding the system and parts thereof.
►Save all Safety Information and instructions for future reference.
Safety Signal Words
The safety signal words Danger, Warning, Caution, and Notice have the following meanings:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or se-
rious injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if
not avoided, could result in minor or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
Warranty
■Product warranty will expire 12+1 months after dispatch from Atlas Copco's Distribution Center.
■Normal wear and tear on parts is not included within the warranty.
■Normal wear and tear is that which requires a part change or other adjustment/overhaul during
standard tools maintenance typical for that period (expressed in time, operation hours or other-
wise).
■The product warranty relies on the correct use, maintenance, and repair of the tool and its component
parts.
■Damage to parts that occurs as a result of inadequate maintenance or performed by parties other
than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the
warranty.
■To avoid damage or destruction of tool parts, service the tool according to the recommended mainte-
nance schedules and follow the correct instructions.
■Warranty repairs are only performed in Atlas Copco workshops or by Certified Service Partners.
Atlas Copco offers extended warranty and state of the art preventive maintenance through its ToolCover
contracts. For further information contact your local Service representative.
For electrical motors:
■Warranty will only apply when the electric motor has not been opened.
Website
Information concerning our Products, Accessories, Spare Parts and Published Matters can be found on
the Atlas Copco website.
Please visit: www.atlascopco.com.

LUM12 SR EN Product Information
© Atlas Copco Industrial Technique AB - 9836 9272 01 5
ServAid
ServAid is a portal that is continuously updated and contains Technical Information, such as:
■Regulatory and Safety Information
■Technical Data
■Installation, Operation and Service Instructions
■Spare Parts Lists
■Accessories
■Dimensional Drawings
Please visit: https://servaid.atlascopco.com.
For further Technical Information, please contact your local Atlas Copco representative.
Safety Data Sheets MSDS/SDS
The Safety Data Sheets describe the chemical products sold by Atlas Copco.
Please consult the Atlas Copco website for more information www.atlascopco.com/sds.
Country of Origin
For the Country of Origin, please refer to the information on the product label.
Dimensional Drawings
Dimensional Drawings can be found either in the Dimensional Drawings Archive, or on ServAid.
Please visit: http://webbox.atlascopco.com/webbox/dimdrw or https://servaid.atlascopco.com.
Overview
Technical Product Data
Technical Product Data can be found on either ServAid, or the Atlas Copco website.
Please visit: https://servaid.atlascopco.com or www.atlascopco.com.

Installation EN LUM12 SR
6© Atlas Copco Industrial Technique AB - 9836 9272 01
Installation
Installation Requirements
Air Quality
■For optimum performance and maximum product life we recommend the use of compressed air with
a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration
type air dryer.
■Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of
liquid water. Install the filter as close as possible to the product and prior to any other air preparation
units to avoid pressure drop.
For impulse/impact tools make sure to use lubricators adjusted for these tools. Regular lubricators will
add too much oil and therefore decrease the tool performance due to too much oil in the motor.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.
Both lubricated and lubrication free products will benefit from a small quantity of oil supplied from a lu-
bricator.
Air Lubrication Guide
Recommended air lubricators:
■Atlas Copco Optimizer (1 liter) 9090 0000 04
■Q8 Chopin 46
■Shell Air Tool Oil S2 A 320
Compressed Air Connection
WARNING Risk of severe injury
Air under pressure can cause injury.
►Always shut off the air supply when not in use or before any adjustments.
►Drain the hose of air pressure and disconnect the tool from air supply when not in use or before
any adjustments.
►Always use the correct hose size and air pressure for the tool.
WARNING Compressed Air
High air pressure can cause severe damage and bodily injury.
►Do not exceed maximum air pressure.
►Make sure that there are no damaged or loose hoses or fittings.
For correct air pressure and hose size, see the Technical Product Data on - https://
servaid.atlascopco.com or www.atlascopco.com.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.

LUM12 SR EN Operation
© Atlas Copco Industrial Technique AB - 9836 9272 01 7
Operation
Ergonomic Guidelines
Consider your workstation as you read through this list of general ergonomic guidelines to identify areas
for improvement in posture, component placement, or work environment.
■Take frequent breaks and change work positions frequently.
■Adapt the workstation area to your needs and the work task.
■Adjust for a convenient reach range by determining where parts and tools need to be located to
avoid static load.
■Use workstation equipment such as tables and chairs appropriate for the work task.
■Avoid work positions above shoulder level or with static holding during assembly operations.
■When working above shoulder level, reduce the load on the static muscles by lowering the weight
of the tool, using for example torque arms, hose reels or weight balancers. You can also reduce
the load on the static muscles by holding the tool close to the body.
■Take frequent breaks.
■Avoid extreme arm or wrist postures, particularly during operations requiring a degree of force.
■Adjust for a convenient field of vision that requires minimal eye and head movements.
■Use appropriate lighting for the work task.
■Select the appropriate tool for the work task.
■In noisy environments, use ear protection equipment.
■Use high-quality inserted tools and consumables to minimize exposure to excessive levels of vibra-
tion.
■Minimize exposure to reaction forces.
■When cutting:
A cut-off wheel can get stuck if the cut-off wheel is bent or not guided properly. Use the correct
flange for the cut-off wheel and avoid bending the cut-off wheel during operation.
■When drilling:
The drill might stall when the drill bit breaks through. Use support handles if the stall torque is high.
The safety standard ISO11148 part 3 recommends using a device to absorb a reaction torque
above 10 Nm for pistol grip tools and 4 Nm for straight tools.
■When using direct-driven screwdrivers or nutrunners:
Reaction forces depend on the tool settings and joint characteristics. Strength and posture deter-
mine the amount of reaction force that an operator can tolerate. Adapt the torque setting to the op-
erator's strength and posture and use a torque arm or reaction bar if the torque is too high.
■In dusty environments, use a dust extraction system or wear a mouth protection mask.
Configuration Instructions
Tightening torque
For accurate operation and safety, the tightening torque of the screwdriver must be adjuisted correctly in
relation to the screw joint. Check the torque specification for the actual joint.
The tightening torque is adjusted by altering the tension of the clutch spring. Turn the protection ring until
the hole in the clutch housing is free. Then turn the out going spindle until you can see the keyhole in the
adjustment washer. Turn the adjustment key clockwise to decrease and anticlockwise to increase the
torque. After the adjustment, turn the protective ring back again.
Verification of tightening torque
Recommended equipment for verification if tightening torque are an Atlas Copco Torque Analyser plus an
appropriately-sized transducer together with the available test joints.

Operation EN LUM12 SR
8© Atlas Copco Industrial Technique AB - 9836 9272 01
Torque range of the clutch springs
Each clutch spring gives a certain torque range. Do not adjust the torque over the maximum recom-
mendation as that might result in improper function and faster wear of the clutch.

LUM12 SR EN Service
© Atlas Copco Industrial Technique AB - 9836 9272 01 9
Service
Maintenance Instructions
Service Recommendations
Preventive maintenance is recommended at regular intervals. See the detailed information on preventive
maintenance. If the product is not working properly, take it out of service and inspect it.
If no detailed information about preventive maintenance is included, follow these general guide-
lines:
■Clean appropriate parts accurately
■Replace any defective or worn parts
Service instructions
Overhaul and preventive maintenance is recommended at regular intervals once per year or after maxi-
mum 250.000 tightening depending on which occurs sooner. More frequent overhaul may be needed if
used at high torque, high cycle rate or long tightening times. If the machine is not working properly, it
should immediately be taken away for inspection.
At the overhauls, all parts should be cleaned accurately and defective or worn parts (i.e. O-rings) should
be replaced.
Tightening of Threaded Connections
The tightening torques indicated in the exploded views list in ServAid (see Spare parts section in https://
servaid.atlascopco.com) are established to achieve the correct clamping force and prevent the parts from
coming loose.
When servicing these parts, they must be able to open up without being destroyed. In special circum-
stances (depending on application and usage) the parts may however come loose after some time of op-
eration. In such cases the torque can be increased by 10-20%. If necessary, a low or medium threadlock-
ing fluid can also be applied.
Example
Grease Guide Screwdrivers
Brand
General purpose
Bearings Air Lubrication
BP Energrease LS-EP2 Energol E46
Castrol Spheerol EP L2
Esso Beacon EP2 Arox EP46
Q8 Rembrandt EP2 Chopin 46
Mobil Mobilegrease XHP 222 Almo oil 525
Shell Alvania EP2 Tonna R32

Service EN LUM12 SR
10 © Atlas Copco Industrial Technique AB - 9836 9272 01
Brand
General purpose
Bearings Air Lubrication
Texaco / Preem Multifak EP2 Aries 32
Brand Clutch / Gears Angle gears
Molycote Longterm 2 Plus
Lub. engineers LE 3752*
* except, see Clutch in exploded views
For Maximum Performance
At tough working conditions – soft joints and max. setting – lubrication of the air is recommended.
With extreme dry air the service life of vanes and machine performance might be reduced. A daily supply
of 0.1 – 0.2 ml oil into the machine inlet will improve the machine performance. Alternatively consider an
automatic lubricator device, Atlas Copco oil lubricator LUB, or single point lubricator DOS, which will im-
prove the machine performance.
Reporting, RE - Signal
Reporting (RE) machines supply an air signal that can be connected to a monitoring instrument that
counts the number of approved tightening and detects premature shut-off and rehits and other irregulari-
ties.
Lubrication Instructions
Rust Protection and Cleaning
Water in the compressed air can cause rust. To prevent rust we strongly recommend to install an air dryer.
Water and particles can cause sticking of vanes and valves. This can be prevented by installing an air fil-
ter close to the product to avoid pressure drop.
Before longer stand stills always protect your tool by adding a few drops of oil into the air inlet. Run the
tool for 5–10 seconds and absorb any access oil at the air outlet in a cloth.
Grease Guide Screwdrivers
Brand
General purpose
Bearings Clutch Air Lubricacion
BP Energrease LS-EP2 Energol E46
Castrol Spheerol EP L2
Esso Beacon EP2 Arox EP46
Q8 Rembrandt EP2 Chopin 46
Mobil Mobilegrease XHP 222 Almo oil 525
Shell Alvania EP2 Tonna R32
Texaco/Preem Multifak EP2 Aries 32
Lubricating Engineers LE 3752

LUM12 SR EN Service
© Atlas Copco Industrial Technique AB - 9836 9272 01 11
Brand Gears Angle gear
Molycote BR2 Plus Longterm 2 Plus
Lubrication of Motor Parts
■No grease is needed for protected Ball bearings.
■Apply a thin layer of air tool oil where needed.
For Maximum Performance
At tough working conditions – soft joints and max. setting – lubrication of the air is recommended.
With extreme dry air the service life of vanes and machine performance might be reduced. A daily supply
of 0.1 – 0.2 ml oil into the machine inlet will improve the machine performance. Alternatively consider an
automatic lubricator device, Atlas Copco oil lubricator LUB, or single point lubricator DOS, which will im-
prove the machine performance.
Testing of Tightening Torque
For accurate operation and safety, the tightening torque of the screwdriver must be adjuisted correctly in
relation to the screw joint. Check the torque specification for the actual joint.
The tightening torque is adjusted by altering the tension of the clutch spring. Turn the protection ring until
the hole in the clutch housing is free. Then turn the out going spindle until you can see the keyhole in the
adjustment washer. Turn the adjustment key clockwise to decrease and anticlockwise to increase the
torque. After the adjustment, turn the protective ring back again.
Torque and Angle Testing Instrument
■In the workshop

Service EN LUM12 SR
12 © Atlas Copco Industrial Technique AB - 9836 9272 01
A Torque transducer
B Test joint
C Torque and angle testing instrument
■At the assembly line
A Torque transducer
B Actual joint
C Torque and angle testing instrument
For further information, please refer to Atlas Copco main catalogue or separate leaflet.
Testjoint and Transducer
Select testjoint and transducers according to minimum and maximum torque of your tool.

LUM12 SR EN Service
© Atlas Copco Industrial Technique AB - 9836 9272 01 13
Lubricate screw and elastic washers with Molykote BR2 Plus.
Soft joints
Torque range
(Nm)
Test joint
Ordering No.
Screw size Screw quality Spare screw
Ordering No.
0.2 - 0.6 4145 0958 78 M3x20 12.9 buy locally
0.6 - 2.0 4145 0959 80 M4x30 12.9 0211 1177 00
1.5 - 4.0 4145 0959 81 M6x35 12.9 0211 1251 00
3.0 - 7.0 4145 0959 82 M6x35 12.9 0211 1251 00
5.5 - 10.0 4145 0959 83 M6x35 12.9 0211 1251 00
10.0 - 25.0 4145 0959 84 M8x35 12.9 0211 1327 00
Hard joints
Torque range
(Nm)
Test joint
Ordering No.
Screw size Screw quality Spare screw
Ordering No.
0.25 - 0.6 4145 0958 87 M3x30 12.9 buy locally
0.5 - 1.5 4145 0958 80 M4x50 12.9 0211 1181 00
1.5 - 3.0 4145 0958 81 M4x30 12.9 0211 1177 00
3.0 - 6.0 4145 0958 82 M6x60 12.9 0211 1256 00
6.0 - 9.0 4145 0958 83 M6x35 12.9 0211 1251 00
9.0 - 25.0 4145 0958 84 M8x60 12.9 0211 1332 00
In-line torque transducers - Torque/angle models
Model Drive Hex
(inch)
Drive Square
(inch)
Rated capacity
(Nm) (ft lb)
Ordering No.
IRTT 1A-I06 ½ 1 0.8 8092 1130 96
IRTT 2A‑I06 ½ 2 1.5 8092 1182 01
IRTT 5A‑I06 ¼ 5 4 8092 1182 06
IRTT 5A‑06 ¼ 5 4 8092 1182 08
In-line torque transducers - Torque models
Model Drive Hex
(inch)
Drive Square
(inch)
Rated capacity
(Nm) .ft lb)
Ordering No.
IRTT 5-I06 ¼ 5 4 8092 1129 05
IRTT 20-I06 ¼ 20 15 8092 1129 10
IRTT 20-06 ¼ 20 15 8092 1129 15
IRTT 25-10 3/8 25 18 8092 1129 20

Service EN LUM12 SR
14 © Atlas Copco Industrial Technique AB - 9836 9272 01
Model Drive Hex
(inch)
Drive Square
(inch)
Rated capacity
(Nm) .ft lb)
Ordering No.
IRTT 75-10 3/8 75 55 8092 1129 25
IRTT 180-13 ½ 180 133 8092 1129 30
IRTT 500-20 ¾ 500 369 8092 1129 35
IRTT 750-25 1 750 553 8092 1129 40
IRTT 1400-25 1 1400 1033 8092 1129 45
In-line torque transducers - Torque/angle models
Model Drive Hex
(inch)
Drive Square
(inch)
Rated capacity
(Nm) (ft lb)
Ordering No.
IRTT 2A-I06 ½ 2 1.5 8092 1130 01
IRTT 5A-I06 ¼ 5 4 8092 1130 06
IRTT 20A-I06 ¼ 20 15 8092 1130 11
IRTT 20A-06 ¼ 20 15 8092 1130 16
IRTT 25A-10 3/8 25 18 8092 1130 21
IRTT 75A-10 3/8 75 55 8092 1130 26
IRTT 180A-13 ½ 180 133 8092 1130 31
IRTT 500A-20 ¾ 500 369 8092 1130 36
IRTT 750A-25 1 750 553 8092 1130 41
IRTT 1400A-25 1 1400 1033 8092 1130 46
IRTT 3000A-38 1½ 3000 3000 8092 1130 51
Test joints - High torque range
Soft joints
Bolt size
Torque range
Nm Ordering No.
Torque rate
Nm/rev.
Degrees at
rated
capacity Service kit*
M8 15 4080 0788 91 10 540 4080 0788 80
M10 30 4080 0789 91 24 450 4080 0789 80
M12 60 4080 0790 91 40 540 4080 0790 80
M14 90 4080 0791 91 60 540 4080 0791 80
M16 200 4080 0866 90 200 360 4080 0865 80
M20 400 4080 0868 90 400 360 4080 0867 80
M30 800 4080 0876 92 800 360 4080 0867 80
* Including 2x bolts, 2x nuts, 2x washers
Air pressure monitoring, RE-signal S1
Reporting pneumatic assembly tools provide a pneumatic signal that indicates which part of the tightening
cycle the tool has reached, by means of variations in air pressure.

LUM12 SR EN Service
© Atlas Copco Industrial Technique AB - 9836 9272 01 15
In the RE-Controller box timers are triggered when certain pressure levels are reached.
Pressure level 1 (P1) starts a timer that checks that the tightening cycle is not too short.
Pressure level 2 (P2) starts a timer that checks the time taken from when the clutch has been released to
when the operator releases the trigger to ensure that it is not too short.
The controller measures the differential pressure over the motor.
It should be noted that the system does not measure torque! Regular check of installed torque/torque out-
put of the tool must be done separately.
The RE-Controller checks the air-line pressure. One of the most common problems in air-line systems is
pressure variations. If the pressure drops too much the tool might stall and/or the torque will not be cor-
rect. The RE-Controller will give a signal if the pressure drops too much.
The RE-Controller alerts the operator when it detects:
■Missed fasteners
■Premature tool shut-off
■Stripped threads
■Cross-threading
■Rehits
■Drop in air supply
The air pressure inside the tool is measured through a small hose (see Optional accessories - RE-Signal
kit) and converted into a digital signal. This signal is processed in the RE-Controller. The RE-Controller
gives instant visual and audio feedback to the operator on whether the tightening was OK or not OK.
For further information, please see leaflet 9833 1358 01.
Free speed / Air consumption
Model r / min l / s
LUM12 SR1 1770 5.5
LUM12 SR2 1350 5.5
LUM12 SR3 930 5.5
LUM12 SR4 700 5.5
LUM12 SR8-K 500 6

Service EN LUM12 SR
16 © Atlas Copco Industrial Technique AB - 9836 9272 01
Instructions for vane motor
Testing of tightening torque
Torque and angle testing instrument
ACTA* 3000/ 4000. For further informatiom, please see our main catalogue or separate leaflet.

LUM12 SR EN Service
© Atlas Copco Industrial Technique AB - 9836 9272 01 17
Testjoint and Transducer
Select testjoint and transducers according to minimum and maximum torque of your tool.
Lubricate screw and elastic washers with Molykote BR2 Plus.
Soft joints
Torque range
(Nm)
Test joint
Ordering No.
Screw size Screw quality Spare screw
Ordering No.
0.2 - 0.6 4145 0958 78 M3x20 12.9 buy locally
0.6 - 2.0 4145 0959 80 M4x30 12.9 0211 1177 00
1.5 - 4.0 4145 0959 81 M6x35 12.9 0211 1251 00
3.0 - 7.0 4145 0959 82 M6x35 12.9 0211 1251 00
5.5 - 10.0 4145 0959 83 M6x35 12.9 0211 1251 00
10.0 - 25.0 4145 0959 84 M8x35 12.9 0211 1327 00
Hard joints
Torque range
(Nm)
Test joint
Ordering No.
Screw size Screw quality Spare screw
Ordering No.
0.25 - 0.6 4145 0958 87 M3x30 12.9 buy locally
0.5 - 1.5 4145 0958 80 M4x50 12.9 0211 1181 00
1.5 - 3.0 4145 0958 81 M4x30 12.9 0211 1177 00
3.0 - 6.0 4145 0958 82 M6x60 12.9 0211 1256 00
6.0 - 9.0 4145 0958 83 M6x35 12.9 0211 1251 00
9.0 - 25.0 4145 0958 84 M8x60 12.9 0211 1332 00
In-line torque transducers - Torque/angle models
Model Drive Hex
(inch)
Drive Square
(inch)
Rated capacity
(Nm) (ft lb)
Ordering No.
IRTT 1A-I06 ½ 1 0.8 8092 1130 96
IRTT 2A‑I06 ½ 2 1.5 8092 1182 01
IRTT 5A‑I06 ¼ 5 4 8092 1182 06
IRTT 5A‑06 ¼ 5 4 8092 1182 08
In-line torque transducers - Torque models
Model Drive Hex
(inch)
Drive Square
(inch)
Rated capacity
(Nm) .ft lb)
Ordering No.
IRTT 5-I06 ¼ 5 4 8092 1129 05
IRTT 20-I06 ¼ 20 15 8092 1129 10

Service EN LUM12 SR
18 © Atlas Copco Industrial Technique AB - 9836 9272 01
Model Drive Hex
(inch)
Drive Square
(inch)
Rated capacity
(Nm) .ft lb)
Ordering No.
IRTT 20-06 ¼ 20 15 8092 1129 15
IRTT 25-10 3/8 25 18 8092 1129 20
IRTT 75-10 3/8 75 55 8092 1129 25
IRTT 180-13 ½ 180 133 8092 1129 30
IRTT 500-20 ¾ 500 369 8092 1129 35
IRTT 750-25 1 750 553 8092 1129 40
IRTT 1400-25 1 1400 1033 8092 1129 45
In-line torque transducers - Torque/angle models
Model Drive Hex
(inch)
Drive Square
(inch)
Rated capacity
(Nm) (ft lb)
Ordering No.
IRTT 2A-I06 ½ 2 1.5 8092 1130 01
IRTT 5A-I06 ¼ 5 4 8092 1130 06
IRTT 20A-I06 ¼ 20 15 8092 1130 11
IRTT 20A-06 ¼ 20 15 8092 1130 16
IRTT 25A-10 3/8 25 18 8092 1130 21
IRTT 75A-10 3/8 75 55 8092 1130 26
IRTT 180A-13 ½ 180 133 8092 1130 31
IRTT 500A-20 ¾ 500 369 8092 1130 36
IRTT 750A-25 1 750 553 8092 1130 41
IRTT 1400A-25 1 1400 1033 8092 1130 46
IRTT 3000A-38 1½ 3000 3000 8092 1130 51

LUM12 SR EN Recycling
© Atlas Copco Industrial Technique AB - 9836 9272 01 19
Recycling
Environmental Regulations
When a product has served its purpose it has to be recycled properly. Dismantle the product and recycle
the components in accordance with local legislation.
Batteries shall be taken care of by your national battery recovery organization.
Recycling information
Part: Recycle as:
1 Protection ring Metal, Steel
2 Clutch housing Metal, Steel
3 Clutch Metal, Steel
4 Driver Metal, Steel
5 Planetary gear Metal, Steel
6 Planetary gear Metal, Steel
7 Gear rim Metal, Steel
Rubber
8 Vane motor Metal, Steel
9 Reversing valve Metal, Aluminum
10 Valve rod Metal, Steel
Plastics
11 Reversing ring Plastics
12 Motor casing Metal, Aluminum
13 Lever Metal, Steel
14 Valve Metal, Steel

Recycling EN LUM12 SR
20 © Atlas Copco Industrial Technique AB - 9836 9272 01
Part: Recycle as:
15 Filter Plastics
16 Distributor Metal, Aluminum
17 Adapter Metal, Steel
