Black & Decker RC1050-B1 User manual

WWW.blackanddecker.com
Rice Cooker
Penanak nasi
RC650-B1
English 3
Bahasa Indoesia 8
RC1050-B1
RC1860-B1

2
Features
 。
＠
 
 ”
  叫N ”
  
 
  
 
 
 
 ” ””” 

Intended use
Your Black & Decker rice cooker has been
designed for cooking rice. This appliance is
intended for household use only.
Safety instructions
Warning! Read all safety
warnings and all instructions.
Failure to follow the warnings
and instructions listed below may result in
electric shock, fi e and/or serious injury.
• Read all of this manual carefully before
using the appliance.
• The intended use is described in this
manual. The use of any accessory or
attachment or the performance of any
operation with this appliance other than
those recommended in this instruction
manual may present a risk of personal
injury.
• Retain this manual for future reference.
Using your appliance
Warning! The temperature of accessible
surfaces may be high when the appliance is
operating.
• This appliance is not intended for use by
persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use
of the appliance by a person responsible
for their safety.
• Children should be supervised to ensure
that they do not play with the appliance.
• Do not allow children or any person
unfamiliar with these instructions to use
the appliance.
• Do not allow children or animals to come
near the work area or to touch the
appliance or power supply cord.
• Close supervision is necessary when the
appliance is used near children.
• Do not touch hot surfaces.
• Always take care when using the
appliance.
• Never pull the power supply cord to
disconnect the plug from the socket.
Keep the supply cord away from heat, oil
and sharp edges.
• Do not place the appliance on or near
heat sources or in a heated oven.
• Do not allow the power supply cord to
hang over the edge of your work top or
table.
• Always place the appliance on a level
surface with adequate free space on all
sides.
• Do not place the appliance below a
socket outlet.
• Do not place the appliance on a wet or
slippery surface.
• Do not use the appliance near flammable
or explosive materials.
• Do not use the appliance outdoors.
3

• Always protect the appliance from water
or excessive humidity.
• Do not move the appliance when in use.
• Operate the appliance only with dry
hands.
• Do not use the appliance if you have
bare feet.
• If the power supply cord is damaged
during use, disconnect the appliance
from the power supply immediately. Do
not touch the power supply cord before
disconnecting from the power supply.
• Disconnect the appliance from the
power supply cord before fitting o
removing parts and before cleaning.
• Allow the appliance to cool before
cleaning.
• Steam may escape from the lid during
use. Always position the lid so that any
steam vents away from the user.
• Always route the cord carefully so that it
does not cause a tripping hazard.
• Cook only in the bowl supplied.
After use
• Remove the plug from the socket and let
the appliance cool down before leaving
it unattended and before changing,
cleansing or inspecting any parts of the
appliance.
• When not in use, the appliance should be
stored in a dry place.
• Children should not have access to
stored appliances.
Inspection and repairs
• Before use, check the appliance for
damaged or defective parts. Check for
breakage of parts, damage to switches
and any other conditions that may a° ect
its operation.
• Do not use the appliance if any part is
damaged or defective.
• Have any damaged or defective parts
repaired or replaced by an authorised
repair agent.
• Before use, check the power supply cord
for signs of damage, ageing and wear.
• Do not use the appliance if the power
supply cord or mains plug is damaged or
defective.
• If the power supply cord or mains plug is
damaged or defective it must be repaired
by an authorised repair agent in order to
avoid a hazard. Do not cut the power
supply cored and do not attempt to
repair it yourself.
• Never attempt to remove or replace any
parts other than those specified in thi
manual.
Electrical safety
Before use, check that the mains voltage
corresponds to the voltage on the rating
plate.
Do not immerse the appliance,
power supply cord or plug in
water or other liquid.
4

ENGLISH
• This product must be earthed.
• If supply cord is damaged, it must be
replaced by the manufacturer or an
authorised Black & Decker Service
Centre in order to avoid a hazard.
Extension cables
• As the appliance is earthed and of class I
construction, only use a 3-core extension
cable.
• When using an extension cable make
sure it is correctly wired and rated for its
use.
Additional safety instructions for
rice cookers
• If water has entered the unit allow it to
dry thoroughly before using the
appliance again.
• Always ensure that the heating plate and
the bottom of the cooking bowl are free
from spilled particles before cooking.
• Keep the unit and heating plate clean
and free from any foreign particles.
• Always carry the appliance using the side
handles.
• Do not switch the appliance on without
having inserted the cooking bowl.
• Do not use the appliance for deep frying
food and do not let any part of the rice
cooker come into contact with hot oil.
• Do not obstruct the steam vent with any
article.
• To prevent damaging the non stick
coating on the appliance always use the
plastic rice spoon or other rubber or
wood utensils.
Residual risks
Additional residual risks may arise when
using the appliance which may not be
included in the enclosed safety warnings.
These risks can arise from misuse, prolonged
use etc.
Even with the application of the relevant
safety regulations and the implementation of
safety devices, certain residual risks can not
be avoided. These include:
• Injuries caused by touching any
rotating/moving parts.
• Injuries caused when changing any parts,
blades or accessories.
• Injuries caused by prolonged use of an
appliance. When using any appliance for
prolonged periods ensure you take
regular breaks.
• Impairment of hearing.
Unpacking
• Remove all packaging from the appliance.
• Wash the cooking bowl, lid, steaming tray,
measuring cup and serving spoon in
warm sudsy water before fir t use.
Use
Measuring the rice
The measuring cup (6) can be used to
measure the rice. Each cup of uncooked rice
normally gives two bowls of cooked rice. Do
not exceed the quantities indicated in the
following table.
5

• Measure the rice with the measuring cup
(6).
Determining the required water quantity
The amount of water required can be
determined in the following table.
• Measure the water quantity with the
measuring cup (6) according to the table
below.
Cooking rice
Warning! Do not interfere with the
automatic action of the control lever by
preventing it from switching to the warm
mode.
Warning! Exercise caution when handling
the appliance as the cooking bowl and
accessories get hot during use. These may
remain hot for some time after use.
Warning! Steam can escape from the unit
when the accessories or lid is removed.
• Measure the rice.
• Wash the rice thoroughly under cold
running water to remove excess starch.
Important: Do not use the cooking bowl to
wash the rice.
• Put the washed rice into the cooking
bowl (4).
• Add the required amount of water.
• Smooth the surface of the rice with the
rice spoon, ensuring all the rice is under
water.
• Put the cooking bowl into the appliance.
• Ensure the cooking bowl is correctly
fitted in good contact with the heating
plate.
• Fit the lid.
• Plug the supply cord into a suitable
electric supply. The keep warm indicator
(3) will light up.
• Press the control lever (1) to start the
cooking process. The cook indicator (2)
will light up.
The cook indicator will go out when the
cooking process is finished. After that the
keep-warm indicator (3) will light up
automatically.
Note: For the best results stir the rice just
after the keep-warm indicator comes on.
Stirring the rice with the rice spoon allows
the steam to escape. This will give fluffier
rice.
Rice quantity Water quantity
1 cups 2 cups
2 cups 3 cups
3 cups 3.5 cups
Rice quantity Water quantity
1 cups 2 cups
2 cups 3 cups
3 cups 3.5 cups
4 cups 5 cups
5 cups 6 cups
Rice quantity Water quantity
1 cups 2 cups
2 cups 3 cups
3 cups 3.5 cups
4 cups 5 cups
6 cups 7 cups
8 cups 9 cups
10 cups 11 cups
15 cups 16 cups
RC650-B1
RC1050-B1
RC1850
RC1860-B1
RC2850
6

Using the steamer tray
(Except RC650-B1)
Warning! Do not use the steamer tray for
cooking meat or poultry.
• Measure the rice.
• Wash the rice thoroughly under cold
running water to remove excess starch.
Important: Do not use the cooking bowl to
wash the rice.
• Put the washed rice into the cooking
bowl (4).
• Add the required amount of water.
• Smooth the surface of the rice with the
rice spoon, ensuring all the rice is under
water.
• Put the cooking bowl into the appliance.
• Place the vegetables or fish into the
steamer tray.
• Put the steamer tray into the appliance.
• Ensure the cooking bowl is correctly
fit ed in good contact with the heating
plate.
• Fit the lid.
• Plug the supply cord into a suitable
electric supply.
• The keep warm indicator (3) will light up.
• Press the control lever (1) to start the
cooking process.
• The cook indicator (2) will light up.
The cook indicator will go out when the
cooking process is finished. After that the
keep-warm indicator (3) will light up
automatically.
Note: For the best rice results stir the rice
just after the keep-warm indicator comes
on. Stirring the rice with the rice spoon
allows the steam to escape. This will give
fluffier rice.
Warning! Always ensure that the contents of
the steamer tray are thoroughly cooked
before serving.
Cleaning and Maintenance
Warning! Before cleaning and maintenance,
remove the plug from the socket and allow
the appliance to cool.
• Do not wash any part of the appliance in
a dishwasher.
• Wipe the exterior with a damp cloth.
• Do not use scouring pads.
• If necessary, use a mild detergent to
remove deposits. Do not use any abrasive
or solvent based cleaner.
Warning! Do not immerse the appliance in
water or any other liquid.
Technical data
RC650-B1 (Type 1) RC1050-B1(Type 1)
Frequency 220-240V, 50/60Hz 220-240V, 50/60Hz
Power W
350 400
input
Capacity l 0.65 1
Weight kg 1.55 1.675
RC1850 (Type 1)
RC1860-B1 (Type 1)
Frequency 220-240V, 50/60Hz 220-240V, 50/60Hz
Power W
700 700
input
Capacity l 1.8 1.8
Weight kg 2.48 2.48
RC2850 (Type 1)
Frequency
220-240V, 50/60Hz
Power W
1100
input
Capacity l 2.8
Weight kg 3.875
7

ENGLISH
Protecting the environment
Separate collection. This product must
not be disposed of with normal
household waste.
Should you find one d y that your Black &
Decker product needs replacement, or if it is
of no further use to you, do not dispose of it
with other household waste. Make this
product available for separate collection.
• Black & Decker provides a facility for
recycling Black & Decker products once
they have reached the end of their
working life. This service is provided free
of charge. To take advantage of this
service please return your product to any
authorised repair agent who will collect
them on our behalf.
• You can check the location of your
nearest authorised repair agent by
contacting your local Black & Decker
o˛c e at the address indicated in this
manual. Alternatively, a list of authorized
Black & Decker repair agents and full
details of our after-sales service and
contact are available on the Internet at:
www.2helpU.com.
8
Service Information
BLACK+DECKER offers a full network of
company-owned and authorized service
locations throughout Asia. All BLACK
++DECKER Service Centers are staffe with
trained personnel to provide customers
with efficient and reliable power tool
service.Whether you need technical advice,
repair, or genuine factory replacement
parts, contact the BLACK+DECKER location
nearest to you.
Notes
•BLACK+DECKER's policy is one of
continuous improvement to our
products and, as such, we reserve the
right to change product specifications
without prior notice.
•Standard equipment and accessories
may vary by country.
•Product specifications may differ by
country.
•Complete product range may not be
available in all countries.
•Contact your local BLACK+DECKER
dealers for range availability.


    

     
     
 
  


 






 




 

  



。 

   
      
   

  
    

 
 
9

10

11

12
RC1850
RC1860-B1
RC2850
RC1050-B1
RC650-B1

13

14

15
RC1860-B1 (Tipe 1)
RC1050-B1 (Tipe 1)
RC650-B1 (Tipe 1)
350 400
700
700
1100

16

17

  
   呻 
  
 
M



 
  
   
 
JAMI NAN

  

 

 
 
   
 
  

18
Diimpor oleh
Alamat
:PT.Stanley Black & Decker
:Menara Standard Chartered Lt 31
Jl. Prof. Dr. Satrio No.164 RT/RW 003/004
Kel.Karet, Kec.Setiabudi
Jakarta Selatan

1/2017
