10
ENGLISH (Original instructions)
uThe blue LEDs (4) will illuminate in segments, displaying
the state of charge in the battery.
uThe completion of charge is indicated by the blue LEDs
(4) will turn off. The pack is fully charged and may be used
at this time or left on the charger.
Assembly (Fig. D)
uAlign the top of the extension tube (8) with the vacuum
inlet (6) as shown in gure D.
uPush the extension tube (8) onto the vacuum inlet (6) so it
locks into position.
uAlign the bottom of the extension tube (8) with the
oorhead (12) as shown in gure D.
uPush the bottom of the extension tube (8) onto the
oorhead (12) so it locks into position.
uTo remove the tube, press the extension pole release
button (9) located on the vacuum inlet or the bottom of the
extension tube and gently pull the connected accessory
off.
Using an accessory tool (Fig. E)
Your vacuum may come with some of the following tools.
1. 2-in-1 brush (13)
2. Crevice tool (14)
3. Pet head (Only available with BHFEA640WP unit) (15)
4. Powered pet head (Only available with BHFEA640WP
unit) (16)
uThe accessories 13, 14, 15 and 16 can be tted either
directly to the extension tube (8) or to the vacuum inlet (6)
as shown in gure E.
uAlign the top of the accessories 13, 14, 15 and 16 with the
vacuum inlet (6) or extension tube (8) and push into place
so it locks into position as shown in gure E.
Use (Fig. E1)
This vacuum can be used in one of four ways.
1. With the extension tube (8) and the oorhead (12).
2. With the oorhead (12).
3. With the extension tube (8) and an accesssory tool
4. With an accesssory tool.
Switching ON and OFF (Fig. F)
uTo switch ON, push the ON/OFF button (1) .
uTo change speed setting press hard oor mode (2) or
carpet mode (3) depending on oor type.
Note: The state of charge indicator LEDs will illuminate
while the vacuum is ON.
uTo switch OFF, press the ON/OFF button (1) a second
time.
uReturn the product to the charger immediately after use so
that it will be fully charged and ready for the next use.
Note: Ensure that the product is fully contacting the magnetic
charger plug.
Accessory storage on pole
uAccessory (13, 14, 15) can be stored on the pole of the
unit using the on pole storage attachment (20).
uAlign the pole storage clip feature (20) onto the rear of the
pole.
uPush rmly so that the pole storage is held rmly on
position on the pole.
uThe accessories (13, 14, 15) can be tted directly to the
on pole storage attachment.
uAlign the top of the accessories (13, 14, 15) with the pole
storage attachment (20) and push into place so it locks.
Note: A maximum of two accessories can be stored on the
pole storage.
Accessory storage on charge dock
uThe accessories 13, 14, 15 and 16) can be tted directly
to the wall hanging charge dock (18) as shown in Fig. C.
uAlign the top of the accessories (13, 14, 15 and 16) with
the wall hanging charge dock arms (18b) and push into
place so it locks into position as shown in Fig. C.
Note: The storage side arms (18b) can be removed from the
wall hook. This is possible for the user to do if they don’t have
enough space or only want to utilize one side arm.
To remove storage side arms from the charge dock, pull the
arm rmly upwards. To reconnect, align the arm with the
locking holes and press down.
Cleaning and emptying the vacuum
Warning! Projectile/Respiratory Hazard: never use the vac
without its lter.
IMPORTANT: Maximum dust collection will only be obtained
with clean lters and an empty dust canister.
If dust begins to fall back out of the product after it is switched
off, this indicates that the dust canister is full and requires
emptying.
Note: There is a MAX line on the dust cannister. Do not allow
the dust cannister to ll beyond this point.
Note: The foam/felt lter (23) is re‑usable do not throw it away
when the product is emptied. We recommend that you replace
the lters every 6–9 months depending on frequency of use.
Note: Replacement lters can be purchased from your
BLACK+DECKER Service Centre. Visit www.2helpu.com to
locate a service centre.
To empty the dust canister (Fig. G, H, I)
uPress button (11a) to release the dust canister (11) from
the chassis as shown in gure G.
uPlace the dust canister over a trash can and press the
dust canistor door release button (11b) to empty the dust
canister as shown in gure I.
uEmpty the contents of the dust canister (11) .
uClose the dust canister door (11c), until it clicks rmly
into position.
