Black & Decker BHSMP2008 User manual

www.blackanddecker.co.uk
®
BHSMP2008
BHSMP2314

2
12
2
5b
6
3
17
3
4
5a
7
8
9
10 11
11b
15 16
13
14
12
11a
1
1a 1b 1c
21
English (original instructions) 6
Deutsch (übersetzt von den originalanweisungen) 14
Français (traduction de la notice d’instructions originale) 23
Italiano (tradotto dalle istruzioni originali) 31
Nederlands (vertaald vanuit de originele instructies) 40
Español (traducido de las instrucciones originales) 49
Português (traduzido das instruções originais) 58
Svenska (översatt från de ursprungliga instruktionerna) 66
Norsk (oversatt fra de originale instruksjonene) 74
Dansk (oversat fra original brugsvejledning) 81
Suomi (käännetty alkuperäisestä käyttöohjeesta) 89
Ελληνικά (μετάφραση από τις πρωτότυπες οδηγίες) 96

3
12
2
5b
6
3
17
3
4
5a
7
8
9
10 11
11b
15 16
13
14
12
11a
1
1a 1b 1c
21

4
1
2
17
11
5a
5b
6
A
6
14
14a
B
3
2
3a
C
3
3a
DE

5
ENGLISH
(Original instructions)
11
9
13
9
7
8
11
15/16
F
G H
9
18 18
I
19
20 20
J

6
ENGLISH (Original instructions)
Intended use
Your BLACK+DECKER BHSMP2008, BHSMP2314 steam
mops have been designed for cleaning sealed hardwood,
sealed laminate, linoleum, vinyl, ceramic tile, stone and mar-
ble oors.These appliances are intended for indoor household
use only.
Safety Instructions
Warning! Read all safety
warnings and all instructions.
Failure to follow the warnings
and instructions listed below may
result in electric shock, re and/
or serious injury.
@Warning! When using
mains-powered appliances,
basic safety precautions,
including the following, should
always be followed to reduce
the risk of re, electric shock,
personal injury and material
damage.
uThe intended use is described in this
manual.
uThe use of any accessory or
attachment or the performance of any
operation with this appliance other
than those recommended in this
instruction manual may present a risk
of personal injury.
uRetain this manual for future refer-
ence.
uThe appliance can be used by persons
with reduced physical, sensory or
mental capabilities or lack of experi-
ence and knowledge, if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance.
uChildren should be supervised to
ensure that they do not play with the
appliance.
uThe plug must be removed from the
socket-outlet before cleaning or main-
taining the appliance.
uThe liquid or steam must not be
directed towards equipment contain-
ing electrical components, such as the
interior of ovens.
9 12
18
20
20
18
K
9 19 12
L

7
ENGLISH
(Original instructions)
uCare should be taken when using
the appliance due to the emission of
steam.
uKeep the appliance and its cord out
of reach of children less than 8 years
of age when it is energized or cooling
down.
uIf the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualied
persons in order to avoid a hazard.
uThe appliance shall not be left
unattended while it is connected to the
supply mains.
uThe appliance is not to be used if it
has been dropped, if there are visible
signs of damage or if it is leaking.
uKeep the appliance out of reach of
children when it is energized or cooling
down.
uThe lling aperture shall not be opened
during use.
Using your appliance
uDo not open the pressure relief valve
during use.
uDo not direct steam at people,
animals, electrical appliances or
electrical outlets.
uDo not expose to rain.
uDo not immerse the appliance in water.
uDo not leave the applianceunattended.
uDo not leave the appliance connected
to an electrical outlet when not in use.
uNever pull the power lead to discon-
nect the appliance from the socket.
uKeep the appliance lead away
from heat, oil and sharp edges.
uDo not handle steam cleaner with wet
hands.
uDo not pull or carry by cord, use cord
as a handle, close door on cord, pull
cord around sharp corners or expose
cord to heated surfaces.
uDo not use appliance in an enclosed
space lled with vapour given off by
oil-base paint thinner, some
mothproong substances, ammable
dust, or other explosive or toxic
vapours.
uCheck the type of oor with the
manufacturer.
uDo not use on leather, wax polished
furniture or oors, synthetic fabrics,
velvet or other delicate, steam
sensitive materials.
@Warning! Do not use on
unsealed wood or unsealed
laminate oors. On surfaces
that have been treated with
wax or some no wax oors,
the sheen may be removed by
the heat and steam action. It is
always recommended to test an
isolated area of the surface to
be cleaned before proceeding.
We also recommend that you
check the use and care
instructions from the oor
manufacturer.
uNever put descaling, aromatic,
alcoholic or detergent products into the
steam cleaner, as this may damage it
or make it unsafe for use.

8
ENGLISH (Original instructions)
uIf the home circuit breaker activates
while using the steam function,
discontinue product use immediately
and contact the customer support
centre. (Beware of the risk of electrical
shock.)
uThe appliance emits very hot steam to
clean the area of use. This means
that the steam head, cleaning pads
and attachments get very hot
during use.
Caution! Always wear suitable shoes
when using your steam mop and when
changing the accessories on your steam
mop.
Do not wear slippers or open toed
footwear.
uThe lid may become hot during use.
uThe surface of the nozzle may become
hot during use
uSteam may escape from the appliance
during use. Care should be taken
when using this appliance. DO NOT
touch any parts which may become
hot during use.
uIf steam is observed escaping from the
body of the steam mop, switch off and
disconnect the unit from the mains
supply, allow to cool.
Contact your nearest authorised repair
agent.
uIf steam is observed escaping from the
pressure relief valve (21), switch unit
off, disconnect the unit from the mains
supply, wait for one hour for the
appliance to cool, and then unscrew.
Check the condition of the seal on the
pressure relief valve.
If the seal is in good condition, screw
back on completely to a tight t.
If steam continues to escape from the
cap contact our nearest authorised
repair centre.
DO NOT CONTINUE TO USE THE
APPLIANCE.
After use
uUnplug the appliance and allow to cool
before cleaning.
uWhen not in use, the appliance should
be stored in a dry place.
uChildren should not have access to
stored appliances.
uResidual steam is under pressure in
the hose once the unit is switched off.
Please allow the unit to cool before
pressing the trigger
Inspection and repairs
uUnplug the appliance and allow to cool
before performing any maintenance or
repairs.
uunplug the appliance and allow to
cool, check that there is no steam in
the system by activating the steam
trigger on the steam handle (11)
before unscrewing the pressure
relief valve (21). The pressure relief
valve should never be unscrewed
until the appliance is cooled and
no steam left in the system. Screw
back on completely to a tight t after
maintenance.
uBefore use, check the appliance for
damaged or defective parts.

9
ENGLISH
(Original instructions)
Check for breakage of parts, damage
to switches and any other conditions
that may affect its operation.
uRegularly check the power lead for
damage.
uDo not use the appliance if any part is
damaged or defective.
uHave any damaged or defective parts
repaired or replaced by an authorized
repair agent.
uNever attempt to remove or replace
any parts other than those specied in
this manual.
Residual risks
Additional residual risks may arise when
using the tool which may not be included
in the enclosed safety warnings. These
risks can arise from misuse, prolonged
use etc. Even with the application of the
relevant safety regulations and the
implementation of safety devices, certain
residual risks can not be avoided. These
include:
uInjuries caused by touching any
moving parts.
uInjuries caused by touching any hot
parts.
uInjuries caused when changing any
parts or accessories.
uInjuries caused by prolonged use
of the appliance. When using any
appliance for prolonged periods
ensure you take regular breaks.
Electrical safety
@Warning! This product must be
earthed.
Always check that the power
supply corresponds to the volt-
age on the rating plate.
Power plugs must match the outlet.
Never modify the plug in any way.
Unmodied plugs and matching outlets
will reduce risk of electric shock.
uIf the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
Extension cables & Class 1
product
uA 3-core cable must be used as your
appliance is earthed and of Class 1
construction.
uAlways use an approved extension
cable suitable for the power input of
this appliance (see technical data). Up
to 30m of 1.50mm2extension cable
can be used without loss of product
performance.
Before use, inspect the extension
cable for signs of damage, wear and
ageing.
Replace the extension cable if
damaged or defective.
When using a cable reel, always
unwind the cable completely.
Labels on appliance
The following pictograms along with the
date code are shown on the appliance.

10
ENGLISH (Original instructions)
CAUTION! Hot Steam
Wash at 60°C. Do not
use bleach or fabric
softener
CAUTION! Hot Surface
Features
This appliance includes some or all of the following features.
1. On/off switch
1a. Red indicator light - Water empty warning light
1b. Green indicator light - Steam ready light
1c. White indicator light - Power on indicator
2. Main unit
3. Water tank
4. Accessory storage
5a. Extension pole A
5b. Extension pole B
6. Floorhead with storage hook
7. Wallpaper striper plate (Only supplied with unit
BHSMP2314)
8. Steam concentrator
9. Hand nozzle (2 supplied with unit BHSMP2314)
10. L-shaped nozzle
11. Steam handle
11a. Lock off slider
12. Squeegee
13. Hand nozzle sock (2 supplied with unit BHSMP2314)
14. Floorpad (2 supplied with unit BHSMP2314)
15. Round brush (2 supplied with unit BHSMP2314)
16. Copper brush (Only supplied with unit BHSMP2314)
17. Flexible hose
18. Handle nozzle’s latches
19. Squeegee peg
20. Squeegee rear hooks
21. Pressure relief valve
Assembly
@Warning! Before attempting any of the following
instructions, make sure that the appliance is
switched off and unplugged and the appliance is
cold and does not contain any water.
Attaching the oor extension to the oor
cleaning head (Fig. A)
uPush the extension pole B (5b) into the oorhead (6)
making sure it clicks securely into place, as shown in
gure A.
Attaching the hand held hose unit to the oor
extension (Fig. A)
uPush the steam handle (11) rmly onto extension pole A
(5a) making sure it clicks securely into place.
uConnect extension pole A (5a) to extension pole B (5b)
Warning! Inspect the seal between the connection point
on the steam handle (11) and the extension poles (5a and 5b)
before each use. If the seal malfunctions or is damaged,
please contact your nearest authorised repair agent. Do not
use the appliance.
Attaching a cleaning pad (Fig. B)
Replacement cleaning pads are available from your
BLACK+DECKER dealer :- (cat no. FSMP20-XJ).
uPlace a cleaning pad (14) on the oor with the velcro 'loop'
side facing up.
uLightly press the steam mop down onto the cleaning pad.
Caution! Never leave the steam mop in one spot on any
surface for any period of time. Always place the steam mop
supported in the upright position when stationary and make
sure the steam mop is turned off when not in use.
Removing a cleaning pad
Caution! Always wear suitable shoes when changing the
cleaning pad on your steam mop.
Do not wear slippers or open toed footwear.
uReturn the steam mop to the upright position and turn the
steam mop 'OFF'.
uWait until the steam mop cools down (approximately 5
minutes).
uLift the steam mop away from the cleaning pad (14)
freeing it from the velcro fastening by putting weight on the
cleaning pad removal tab (14a).
Attaching / Removing the water tank (Fig. C,
D)
Note! Fill the water tank (3) with clean tap water (Do not use
any additives or chemicals).
Note! In areas of hard water, the use of de-ionised water is
recommended.
uSlide the water tank (3) up and away from the steam mop
main unit (2).
uWater tank can be taken to the tap to be lled.
uLift cap (3a) to ll.
Warning! When lling, maintain the water tank (3) in vertical
position with the cap (3a) at the top.
Warning! Your water tank has a 1.2 litre capacity. Do not over
ll the tank.
uClose the cap (3a).
Note! Ensure the cap is rmly secured.
