Black & Decker Dustbuster ACV1205 User manual

1
ACV1205

2
B
D
E F
A
C

3
G
I
H

4
ENGLISH
Intended use
Your Black & Decker Dustbuster ®auto car vacuum cleaner has been designed for light
dry vacuum cleaning purposes. This appliance is powered from a car electrical system
and connected by the cigarette lighter socket. This appliance is intended for domestic
use only.
Safety instructions
@Warning! Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions listed below may result
in electric shock, re and/or serious injury.
u Read all of this manual carefully before using the
appliance.
u The intended use is described in this manual. The use
of any accessory or attachment or the performance of
any operation with this appliance other than those
recommended in this instruction manual may present a
risk of personal injury.
u Retain this manual for future reference.
Using your appliance
u Do not use the appliance to pick up liquids or any
materials that could catch re.
u Do not use the appliance near water.
u Do not immerse the appliance in water.
u Never pull the charger lead to disconnect the charger
from the socket. Keep the charger lead away from
heat, oil and sharp edges.
u This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.

5
ENGLISH
u The appliance is only to be used with the power supply
unit provided with the appliance.
u The appliance must only be supplied at safety extra
low voltage corresponding to the marking on the
appliance.
Inspection and repairs
u Before use, check the appliance for damaged or
defective parts. Check for breakage of parts, damage
to switches and any other conditions that may affect its
operation.
u Do not use the appliance if any part is damaged or
defective.
u Have any damaged or defective parts repaired or
replaced by an authorized repair agent.
u Regularly check the charger lead for damage. Replace
the charger if the lead is damaged or defective.
u Never attempt to remove or replace any parts other
than those specied in this manual.
Additional safety instructions
Residual risks.
Additional residual risks may arise when using
the tool which may not be included in the
enclosed safety warnings. These risks can arise
from misuse, prolonged use etc.
Even with the application of the relevant safety
regulations and the implementation of safety
devices, certain residual risks can not be
avoided. These include:
u Injuries caused by touching any moving parts.
u Injuries caused by touching any hot parts.
u Injuries caused when changing any parts or
accessories.
u Injuries caused by prolonged use of the appliance.
When using any appliance for prolonged periods
ensure you take regular breaks.

6
ENGLISH
Electrical safety
The appliance is designed for use with 12V
negative ground vehicle battery systems.
Warning! The cigarette lighter connector is tted with
a non-serviceable safety fuse. The fuse may operate in
the event of a fault. If this occurs the fuse must be
replaced together with the connector and cable by the
manufacturer or an authorised Black and Decker Service
Centre in order to avoid a hazard.
Warning! Do not operate the appliance with systems
which have positive ground or a different voltage.
Features
1. On/off switch
2. Release button
3. Dust bowl
4. Cigarette lighter connector
Fig. A
5. Crevice tool
6. Brush tool
Assembly
Fitting the accessories (g. A & C)
The appliance is supplied with the following accessories:
u a crevice tool (5) for conned spaces
ua hard brush (6) for upholstery
To t an accessory, proceed as follows:
uTake the accessories from the appliance.
uInsert the appropriate accessory into the front of the appliance.
Additional accessories
(g. C, D & E)
uan extension hose (7) and a hose connector (8)
ua brush (9) for carpets and upholstery
u an extended crevice tool (10) for the most difcult to reach areas
When not in use, the appliance and the accessories can be stored in the storage bag
(11).
To t an accessory, proceed as follows:
uFit the hose connector onto the nose of the appliance.
uAttach one end of the hose to the connector.
uAttach the appropriate accessory to the other end of the hose.

7
ENGLISH
Use
Connecting to the vehicle's power supply (g. B)
uMake sure that the appliance is switched off.
uRemove the cigarette lighter from the socket.
uPlug the connector (4) into the cigarette lighter socket.
Operating the appliance (g. F)
u To switch on, slide the on/off switch (1) forward.
u To switch off, slide the on/off switch back.
The appliance can be used for periods of up to 30 minutes without noticeably affecting
the power of a normally charged car battery in good condition.
Warning! Extended use will drain the battery power. Do not run the vehicle's engine
while cleaning. This can shorten the life of the appliance.
Cleaning and maintenance
Warning! Regularly clean the lters.
Cleaning the dust bowl and lters (g. G & H)
The lters are re-usable and should be cleaned regularly.
uPress the release button (2) and remove the dust bowl (3).
uEmpty the dust bowl.
u Remove the lters (12 & 13) by twisting them clockwise.
u Brush any loose dust off the lters.
u Wash the lters in warm, soapy water. The bowl can also be washed if necessary.
Do not immerse the appliance in water.
u Make sure the dust bowl and lters are dry.
u Ret the lters (12 & 13) onto the appliance, twisting them counterclockwise until
they lock into place.
u Ret the dust bowl onto the appliance. Make sure the dust bowl clicks into place.
Warning! Never use the appliance without the lters. Optimum dust collection will only
be achieved with clean lters and an empty dust bowl.
Cleaning the exhaust lter (g. I)
uOpen the lid (14).
u Remove the lter (15) from the recess.
u Wash the lter in warm, soapy water.
u Make sure the lter is dry.
u Ret the lter (15).
uClose the lid.
Replacing the lters
The lters should be replaced every 6 to 9 months and whenever worn or damaged.
Replacement lters are available from your Black & Decker dealer (cat. no. VF40).
u Remove the old lters as described above.
u Fit the new lters as described above.

8
ENGLISH
Protecting the environment
ZSeparate collection. This product must not be disposed of with normal household waste.
Should you nd one day that your Black & Decker product needs replacement, or if it is
of no further use to you, do not dispose of it with household waste. Make this product
available for separate collection.
zSeparate collection of used products and packaging allows materials to be recycled and used again. Re-use of recycled materials helps prevent
environmental pollution and reduces the demand for raw materials.
Local regulations may provide for separate collection of electrical products from the
household, at municipal waste sites or by the retailer when you purchase a new
product.
Black & Decker provides a facility for the collection and recycling of Black & Decker
products once they have reached the end of their working life. To take advantage of
this service please return your product to any authorised repair agent who will collect
them on our behalf.
You can check the location of your nearest authorised repair agent by contacting your
local Black & Decker ofce at the address indicated in this manual. Alternatively, a list
of authorised Black & Decker repair agents and full details of our after-sales service
and contacts are available on the Internet at: www.2helpU.com
Technical data
ACV1205
(H1)
Voltage Vdc
12
Weight kg 0.9

9
DEUTSCH
Guarantee
Black & Decker is condent of the quality of its products and offers an outstanding
guarantee. This guarantee statement is in addition to and in no way prejudices your
statutory rights. The guarantee is valid within the territories of the Member States of
the European Union and the European Free Trade Area.
If a Black & Decker product becomes defective due to faulty materials, workmanship or
lack of conformity, within 24 months from the date of purchase, Black & Decker
guarantees to replace defective parts, repair products subjected to fair wear and tear
or replace such products to ensure minimum inconvenience to the customer unless:
uThe product has been used for trade, professional or hire purposes;
uThe product has been subjected to misuse or neglect;
uThe product has sustained damage through foreign objects, substances or
accidents;
uRepairs have been attempted by persons other than authorised repair agents or
Black & Decker service staff.
To claim on the guarantee, you will need to submit proof of purchase to the seller or an
authorised repair agent. You can check the location of your nearest authorised repair
agent by contacting your local Black & Decker ofce at the address indicated in this
manual. Alternatively, a list of authorised Black & Decker repair agents and full details
of our after-sales service and contacts are available on the Internet at: www.2helpU.
com
Please visit our website www.blackanddecker.co.uk to register your new Black &
Decker product and to be kept up to date on new products and special offers. Further
information on the Black & Decker brand and our range of products is available at
www.blackanddecker.co.uk
