Black & Decker NVB115W User manual

www.blackanddecker.co.uk
NVB115W
NVB115WA
NVB215W
NVB215WA
WDB115W
WDB115WA
WDB215W
WDB215WA

23
C
E
B
A
D
F

23
I
H
G

4
ENGLISH (Original instructions)
Intended use
Your BLACK + DECKER Dustbuster® handheld vacuum
cleaner has been designed for light dry vacuum cleaning
purposes (NVB115W, NVB115WA, NVB215W, NVB215WA).
This appliance is intended for household use only.
Your BLACK + DECKER Dustbuster® handheld vacuum
cleaner has been designed for light wet and dry vacuum
cleaning purposes (WDB115W, WDB115WA, WDB215W,
WDB215WA). This appliance is intended for household use
only.
Safety instructions
@Warning! Read all safety
warnings and all instructions.
Failure to follow the warnings
and instructions listed below
may result in electric shock, re
and/or serious injury.
@Warning! When using battery-
powered appliances, basic
safety precautions, including the
following, should always be fol-
lowed to reduce the risk of re,
leaking batteries, personal injury
and material damage.
uRead all of this manual carefully be-
fore using the appliance.
uThe intended use is described in this
manual. The use of any accessory
or attachment or the performance
of any operation with this appliance
other than those recommended in this
instruction manual may present a risk
of personal injury.
uRetain this manual for future refer-
ence.
Using your appliance
uDo not use the appliance to pick up
liquids or any materials that could
catch re.
uDo not use the appliance near water.
uDo not immerse the appliance in water.
uNever pull the charger lead to discon-
nect the charger from the socket. Keep
the charger lead away from heat, oil
and sharp edges.
uThis appliance can be used by chil-
dren aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge if
they have been given supervision or
instruction concerning use of the appli-
ance in a safe way and understand the
hazards involved. Children shall not
play with the appliance. Cleaning and
user maintenance shall not be made
by children without supervision.
Inspection and repairs
uBefore use, check the appliance for
damaged or defective parts. Check for
breakage of parts, damage to switches
and any other conditions that may af-
fect its operation.
uDo not use the appliance if any part is
damaged or defective.
uHave any damaged or defective parts
repaired or replaced by an authorized
repair agent.
uRegularly check the charger lead for
damage. Replace the charger if the
lead is damaged or defective.
uNever attempt to remove or replace
any parts other than those specied in
this manual.
Additional safety instructions
Residual risks.
Additional residual risks may arise when
using the tool which may not be included
in the enclosed safety warnings. These
risks can arise from misuse, prolonged
use etc.

5
ENGLISH
(Original instructions)
Even with the application of the relevant
safety regulations and the implementa-
tion of safety devices, certain residual
risks can not be avoided. These include:
uInjuries caused by touching any mov-
ing parts.
uInjuries caused by touching any hot
parts.
uInjuries caused when changing any
parts or accessories.
uInjuries caused by prolonged use of
the appliance. When using any appli-
ance for prolonged periods ensure you
take regular breaks.
Batteries and chargers
Batteries
uNever attempt to open for any reason.
uDo not expose the battery to water.
uDo not expose the battery to heat.
uDo not store in locations where the
temperature may exceed 40°C.
uCharge only at ambient temperatures
between 10°C and 40°C.
uCharge only using the charger pro-
vided with the appliance/tool. Using
the wrong charger could result in an
electric shock or overheating of the
battery.
uWhen disposing of batteries, follow
the instructions given in the section
"Protecting the environment".
uDo not damage/deform the battery
pack either by puncture or impact, as
this may create a risk of injury and re.
uDo not charge damaged batteries.
uUnder extreme conditions, battery
leakage may occur. When you notice
liquid on the batteries carefully wipe
the liquid off using a cloth. Avoid skin
contact.
uIn case of skin or eye contact, follow
the instructions below.
Warning! The battery uid may cause
personal injury or damage to property. In
case of skin contact, immediately rinse
with water. If redness, pain or irritation
occurs seek medical attention. In case of
eye contact, rinse immediately with clean
water and seek medical attention.
Chargers
Your charger has been designed for a
specic voltage. Always check that the
mains voltage corresponds to the voltage
on the rating plate and the information in
the technical data table.
Warning! Never attempt to replace the
charger unit with a regular mains plug.
uUse your BLACK+DECKER charger
only to charge the battery in the appli-
ance/tool with which it was supplied.
Other batteries could burst, causing
personal injury and damage.
uNever attempt to charge nonrecharge-
able batteries.
uIf the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
uDo not expose the charger to water.
uDo not open the charger.
uDo not probe the charger.
uThe appliance/tool/battery must be
placed in a well ventilated area when
charging.
Electrical safety
Your charger has been designed for a
specic voltage. Always check that the
mains voltage corresponds to the volt-
age on the rating plate. Never attempt
to replace the charger unit with a regular
mains plug.

6
ENGLISH (Original instructions)
Symbols on the charger
Read all of this manual carefully
before using the appliance.
#This tool is double insulated;
therefore no earth wire is
required. Always check that the
power supply corresponds to
the voltage on the rating plate.
$The charging base is intended
for indoor use only.
Labels on appliance
The following symbols appear on this appliance along with the
date code:
S003AQ 15
Only use with charger S003AQ 15
Features
This tool includes some or all of the following features.
1. On/off switch (press and hold)
2. Bowl release button
3. Dust bowl
4. Charger
5. Charging bracket
Fig. A
6. Dry pick up cloth lter (NVB units Only)
7. Pre-lter (NVB units Only)
8. Wet/Dry foam insert (WDB units Only)
9. Wet/Dry deector (WDB units Only)
Fig. B
10. Squeegee (WDB___WA units Only)
11. Brush tool (WDB___WA and NVB___WA units Only)
12. Crevice tool (WDB___WA and NVB___WA units Only)
Installation
Wall Mounting (g. C)
The product can be attached to a wall to provide a convenient
storage and charging point for the appliance.
When xing to a wall, make sure that the xing method is
suitable for the wall type and is appropriate to the weight of
the appliance.
uMark the location of the screw holes (within reach of an
electrical outlet for charging the vac while it is on the wall
bracket).
uFix the mounting bracket to the wall using appropriate
screws and plugs for the type of wall and weight of the
appliance.
uHang the appliance on the wall by placing the opening
on the base of the vac over the hooks in the wall mount
charging bracket.
Assembly
Accessories (g .B)
These models may be supplied with some of the following
accessories:
uA squeege tool (10) for wet use on hard surfaces.
uA brush tool (11) for furniture and stairs.
uA crevice tool (12) for conned spaces.
Fitting (Fig. D)
uInsert the appropriate accessory into the front of the appli-
ance. Make sure that the accessory is pushed fully in.
Use
uBefore rst use, the battery must be charged for at least
24 hours.
uPlace the appliance on the charging bracket whenever it is
not in use.
Warning! Before charging, be sure to empty all liquid contents
and dry thoroughly, to avoid damage to your appliance.
Charging the battery (Fig. C)
uMake sure that the appliance is switched off. The battery
will not be charged with the on/off switch (1) pressed.
uPlace the appliance on the charging bracket (5).
uPlug in the charger. Switch on at the mains.
uLeave the appliance to charge for at least 21 hours.
While charging, the charger may become warm. This is
normal and does not indicate a problem. The appliance can
be left connected to the charger indenitely.
Warning! Do not charge the battery at ambient temperatures
below 10 °C or above 40 °C.
Switching on and off (g. E)
uTo switch the appliance on, press and hold the on/off
switch (1).
uTo switch the appliance off, release on/off switch (1).
Dry pick up (NVB units Only)
uFor everyday spills of dry material.
Warning! Never pick up wet applications with these units.
Wet and dry pick up (WDB units Only)
uFor everyday spills of dry material, use your appliance
without the squeegee accessory.

7
ENGLISH
(Original instructions)
Warning! Your product is designed for light spills only.
uThis appliance can also be used to pick up everyday liquid
spills. Use the squeegee accessory on non-absorbent,
hard surfaces. On absorbent surfaces, such as carpet,
your appliance will pick up wet spills better without the
accessory.
uFor best performance on hard surface wet pickups, insert
squeegee into the bowl nozzle opening.
uFor best results when using this accessory, hold the appli-
ance at an angle of 45° and pull it slowly towards you.
uDo not ll the bowl beyond the end of the intake chute. If
there is any liquid in the bowl, do not turn the unit upside
down, sideways, point the nozzle upward, or shake the
vac excessively.
uAfter picking up liquid substances clean the appliance and
lter immediately. Mold and mildew may form if the unit is
not properly cleaned after wet pickups.
uBefore charging, be sure to empty all liquid contents and
dry thoroughly, to avoid damage to your appliance.
Optimising the suction force
In order to keep the suction force optimised, the lters must be
cleared regularly during use.
Emptying and cleaning the product.
Removing the dust bowl and lters (g. F & G).
Warning! The lters are re-usable and should be cleaned
regularly.
uPress the bowl release button (2) and pull the dust bowl
(3) straight off.
uWhile holding the dust bowl over a bin or sink, pull out the
lter to empty the contents of the bowl.
uTo replace the dust bowl, place it back onto the handle
until it “clicks” rmly into position.
Warning! Never use the appliance without the lters. Opti-
mum dust collection will only be achieved with clean lters.
Foam insert (g. H) (WDB units Only)
uPlace the foam insert (8) into the centre of the wet/dry
deector (9).
Warning! Never use the appliance for wet applications without
the water deector and foam insert tted.
Pre-lter (g. I) (NVB units Only)
The Filter and pre-lter can be separated to allow better
cleaning.
uTwist the pre-lter (7) in an anti-clockwise direction and lift
from the lter (6).
Warning! Never pick up wet applications with these units.
Cleaning the dust bowls and lters
uThe dust bowls and lters can be washed in warm soapy
water.
uMake sure that the lters and the dust bowl are dry before
re-tting.
Replacing the lters
The lters should be replaced every 6 to 9 months and when-
ever worn or damaged.
Replacement lters are available from your BLACK+DECKER
dealer:
For models: NVB115W, NVB115WA, NVB215W, NVB215WA
use lter part number FLVD10-XJ
For models: WDB115W, WDB115WA, WDB215W,
WDB215WA use lter part number FLWD10-XJ
Maintenance
Your BLACK+DECKER corded/cordless appliance/tool has
been designed to operate over a long period of time with a
minimum of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance on corded/
cordless power tools:
uSwitch off and unplug the appliance/tool.
uOr switch off and remove the battery from the appliance/
tool if the appliance/tool has a separate battery pack.
uOr run the battery down completely if it is integral and then
switch off.
uUnplug the charger before cleaning it. Your charger does
not require any maintenance apart from regular cleaning.
uRegularly clean the ventilation slots in your appliance/tool/
charger using a soft brush or dry cloth.
uRegularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
Protecting the environment
ZSeparate collection. Products and batteries marked
with this symbol must not be disposed of with normal
household waste.

8
ENGLISH (Original instructions)
Products and batteries contain materials that can be recov-
ered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions. Further information is available at
www.2helpU.com
Technical data
NBV115W, NBV115WA,
WDB115W, WDB115WA
NBV215W, NBV215WA
WDB215W, WDB215WA
Voltage (Vdc)3.6 7.2
Battery Li-Ion Li-Ion
Weight (Kg)
0.61 0.65
Charger 9062787 9062787
Input Voltage
(Vac)
100 - 240 100 - 240
Output
Voltage (V)
15 15
Current (mA) 150 150
Approx
charge time
(h)
10 10
Guarantee
Black & Decker is condent of the quality of its products and
offers consumers a 24 month guarantee from the date
of purchase. This guarantee is in addition to and in no way
prejudices your statutory rights. The guarantee is valid within
the territories of the Member States of the European Union
and the European Free Trade Area.
To claim on the guarantee, the claim must be in accordance
with Black&Decker Terms and Conditions and you will need to
submit proof of purchase to the seller or an authorised repair
agent. Terms and conditions of the Black&Decker 2 year guar-
antee and the location of your nearest authorised repair agent
can be obtained on the Internet at www.2helpU.com, or
by contacting your local Black & Decker ofce at the address
indicated in this manual.
Please visit our website www.blackanddecker.co.uk to register
your new Black & Decker product and receive updates on new
products and special offers.

9
ENGLISH
(Original instructions)

10 11

10 11

90633926 REV-0
12/2015
Australia Black & Decker (Australia) Pty. Ltd. Tel. [phone]
20 Fletcher Road, Mooroolbark, Fax [phone]
Victoria, 3138
New Zealand Black & Decker Tel. [phone]
5 Te Apunga Place Fax [phone]
Mt Wellington
Aukland 1060
United Kingdom & Black & Decker Tel. [phone]
Republic Of Ireland 210 Bath Road Fax [phone]
www.blackanddecker.co.uk Slough, Berkshire SL1 3YD
[email protected]
