Black Box LPJ001A-T-R2 User manual

24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM
802.3AT POE
GIGABIT
INJECTOR,
1-PORT
LPJ 001A-T-R2
USER MANUAL

2
TABLE OF CONTENTS
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
1. SPECIFICATIONS........................................................................................................................................................................... 3
2. OVERVIEW...................................................................................................................................................................................... 4
2.1 Introduction...............................................................................................................................................................................................4
2.2 Features ....................................................................................................................................................................................................4
2.3 Hardware Description..............................................................................................................................................................................5
3. SETTING UP YOUR POWER INJECTOR ....................................................................................................................................... 6
4. DESCRIPTION OF LED FUNCTIONS............................................................................................................................................. 7
APPENDIX A: REGULATORY INFORMATION .................................................................................................................................. 8
A.1 FCC Statement .........................................................................................................................................................................................8
A.2 NOM Statement .......................................................................................................................................................................................9
APPENDIX B: DISCLAIMER/TRADEMARKS ................................................................................................................................. 10
B.1 Disclaimer ...............................................................................................................................................................................................10
B.2 Trademarks Used in this Manual ..........................................................................................................................................................10

3
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
CHAPTER 1: SPECIFICATIONS
TABLE 1-1. SPECIFICATIONS
SPECIFICATION DESCRIPTION
Compliance cUL/UL®; RoHS, CE
Load (Maximum) 0.60 A
Regulation Line and load: 54–57 VDC under all conditions
Efficiency Minimum 85% at max. load
Environmental
Operating Temperature: +14 to +104° F (-10 to +40° C);
Storage Temperature: -4 to +158° F (-20 to +70° C);
Relative Humidity: 5 to 90%
EMI EN55032 Class B, FCC part 15 Class B
EMC
ESD: IEC61000-4-2 , Level 3
RS: IEC61000-4-3, Level 3
EFT/Burst: IEC61000-4-4, Level 2
Surge: IEC61000-4-5, Level 3
CS: IEC61000-4-6 , Level 3
Voltage Dips: IEC61000-4-11, Class 3
Harmonic: IEC61000-3-2, Class A
Isolation 42 VDC for one minute, 10 mA
Insulation Resistance Primary to secondary: > 10 M-Ohm, 500 VDC
Overvoltage Conforms to UL60950-1. Voltage between 2 SELV conductors shall not exceed 42.4 Vpk or 60 VDC for longer than
0.2 seconds. A limit of 71 VPK or 120 VDC shall not be exceeded. – Latching
Overcurrent 750 mA max
Short Circuit Protection Non-Latching Auto recovery. Output can be shorted permanently without damage
Connectors
Data in: (1) RJ-45 (10/100/1000);
Data/PoE out: (1) RJ-45 (10/100/1000);
Power: (1) IEC 320 (3-pin);
AC input: IEC320 C14 - three-wire
Indicators
(1) LED:
Blue – Valid 802.3at load connected
Blue and Red blink 3 times – Incorrect signature
Red LED lights solid for 2 seconds – Overload indication
Power
AC input voltage: 100–240 VAC, 50–60 Hz; 0.8 A;
Output: 56 V, 0.536 A;
Pin 3, 6: +56 V;
Pin 1, 2: Return
Size 1.18"H x 1.79"W x 5.52"D (3 x 4.5 x 14 cm)
Weight 7.04 oz. (200 g)

41. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
CHAPTER 2: OVERVIEW
2.1 INTRODUCTION
The LPJ001A-T-R2 is a high-powered Gigabit power injector that conforms to the IEEE 802.3at power standard.
As defined in 2009, this standard allows for a minimum of 25 W of power to operate with PoE equipment over a single Ethernet cable.
Use the LPJ001A-T with IP telephones, wireless access points, IP print servers, IP cameras, and Bluetooth access points.
2.2 FEATURES
IEEE 802.3at Compliant
DOE VI Efficiency
EU CoC Version 5 Tier 2 Efficiency
Compact Size
Limited Power Source
Three Wire Input Models
Full Over-Voltage and Over-Current Protection
Non-Vented Case

5
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
CHAPTER 2: OVERVIEW
2.3 HARDWARE DESCRIPTION
Figure 2-1 shows the side panels of the injector. Table 2-1 describes its components.
2 3
1
4
FIGURE 2-1. SIDE PANELS OF THE INJECTOR
TABLE 2-1. LPJ001A-T-R2 COMPONENTS
NUMBER IN FIGURE 2-1 COMPONENT DESCRIPTION
1 (1) Connect LED Indicates load connected or overload
2(1) RJ-45 connector Data in: (1) RJ-45 (10/100/1000)
3(1) RJ-45 connector Data/PoE out: (1) RJ-45 (10/100/1000)
4(1) IEC-320 C14 - three-pin connector AC input for power

61. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
CHAPTER 3: SETTING UP YOUR POWER INJECTOR
NOTE: Use CAT5e or higher Ethernet cables (not included).
1. Using screws, affix the metal feet on the front and/or rear to a flat surface such as a table or wall. See Figure 3-1.
NOTE: The power injector should not use the weight of the Ethernet cables for support.
insert a screw
to secure the unit
to a surface
insert a screw
to secure the unit
to a surface
FIGURE 3-1. LOCATION OF METAL FEET ON THE POWER INJECTOR
Power and data out Data in
IEC-320 power connector
FIGURE 3-2. PORTS ON THE POWER INJECTOR
2. Connect the 3-pin IEC-320 AC input connector to a power source. Power on the injector.
3. Using CAT5e or higher cable, connect the RJ-45 port on the injector labeled “IN” to your network switch. See Figures 3-2 and 3-3.
4. Connect the RJ-45 port labeled “OUT” on the injector over Ethernet cable to the powered device. See Figures 3-2 and 3-3.
5. The LEDs will light to diagnose the connection. See Tables 4-1 and 4-2.
Power and data to
powered device
Data input from
network switch
AC input
FIGURE 3-3. CABLE CONNECTIONS TO THE POWER INJECTOR

7
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
CHAPTER 4: DESCRIPTION OF LED FUNCTIONS
TABLE 4-1. LEDS AND THEIR FUNCTIONS
LED STATE FUNCTION DESCRIPTION
LED
Lights blue Valid 802.3at load connected This blue LED lights when a 802.3at compliant load is attached
to the output RJ-45 connector.
Blue and Red LED
blink 3 times Incorrect signature
After the LED blinks three times, the power injector will continue to try to
detect a valid load. Until the correct load is applied, the LEDs will continue to
blink.
Lights red for 2
seconds Overload Indication LED will light red for two seconds, and then go off as the power supply tries
to re-detect a valid load.

81. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
APPENDIX A: REGULATORY INFORMATION
A.1 FCC STATEMENT
This equipment has been found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
Shielded cables must be used with this equipment to maintain compliance with radio frequency energy emission regulations and
ensure a suitably high level of immunity to electromagnetic disturbances.
All power supplies are certified to the relevant major international safety standards.

9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
APPENDIX A: REGULATORY INFORMATION
A.2 NOM STATEMENT
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca
de una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo descrito en las instrucciones de operación.
Todo otro servicio deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su uso. La colocación del aparato eléctrico
sobre una cama, sofá, alfombra o superficie similar puede bloquea la ventilación, no se debe colocar en libreros o gabinetes que
impidan el flujo de aire por los orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor, estufas u otros
aparatos (incluyendo amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como
se indique en el aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados
sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato;o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

10 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
APPENDIX B: DISCLAIMER/TRADEMARKS
B.1 DISCLAIMER
Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of
cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box
Corporation may revise this document at any time without notice.
B.2 TRADEMARKS USED IN THIS MANUAL
Black Box and the Black Box logo type and mark are registered trademarks of Black Box Corporation.
Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

11
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
NOTES
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
_
_________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________\
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
__________________________________________________________________________________________________
_________________________________________________________________________________________________
__________________________________________________________________________________________________
___________________

NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
© COPYRIGHT 2018. BLACK BOX CORPORATION. ALL RIGHTS RESERVED.
LPJ001A-T-R2_USER_REV1.PDF
Table of contents
Other Black Box Laboratory Equipment manuals
Popular Laboratory Equipment manuals by other brands

Panasonic
Panasonic MIR-H163 Series operating instructions

Goobay
Goobay 20319 user manual

Qiagen
Qiagen Hybrid Capture System Multi-Specimen Tube Vortexer... user manual

Andersen Sterilizers
Andersen Sterilizers Anprolene AN74i Installation guidelines

Ratek
Ratek VM1 user manual

GE
GE SEMIPHOR TRANSPHOR Series operating instructions

Axygen
Axygen AXYPET Series instruction manual

AB Sciex
AB Sciex QTRAP 4500 LC/MS/MS system System user's guide

Amos
Amos AWB 210 Operation manual

Thermo Scientific
Thermo Scientific Arctic Express CY50900 Operation manual and parts list

Agilent Technologies
Agilent Technologies 1260 Infinity user manual

Westlab
Westlab 665-084 product manual
