Black Box ServShield RM470A-R2 User manual

1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax [phone]
© Copyright 2009. Black Box Corporation. All rights reserved.

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
CUSTOMER
SUPPORT
INFORMATION
JANUARY 2009
RM470A-R2
RM471
RF207
RM475
RM476
RM3055
ServShield

SERVSHIELD
1
TRADEMARKS USED IN THIS MANUAL
Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc.
Plexiglas®is a registered trademark of Rohm & Haas Company.
Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
Contents
Chapter Page
1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2. Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 What’s Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 Leveling the Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2 Removing the Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3 Fan Assembly (RF207) and Rear Door Fan Filter (RM475) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.4 Front Door Filter (RM476) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.5 Mounting Rails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1. Specifications
ServShield (RM470A-R2):
Capacity — Cabinet: 600 lb. (272 kg);
Vented Stationary Shelf: 200 lb. (90.8 kg)
Construction — Steel
19" EIA Rails — Mounting type: M6;
Mounting height: Top rails: 14U;
Bottom rails: 17U front, 23U rear;
Rail depth:
Top rails: 4.5" (11.4 cm) minimum, 33" (83.8 cm) maximum;
Bottom rails: 5.5" (13.9 cm) minimum, 33" (83.8 cm) maximum
Color — Black
Keyboard Tray — 20"W x 9.75"D (50.8 x 24.8 cm)
Writing Area — 20.7"W x 7.5"D (52.6 x 62.9 cm)
Size — 72"H x 30"W x 36"D (182.9 x 76.2 x 91.4 cm)
Weight — 330 lb. (150 kg)
Sliding, Adjustable Tower Shelf (RM471):
Capacity — 110 lb. (49.9 kg)
Size — 19"W x 22"D (48.3 x 55.9 cm)
Fan Unit (RF207):
Airflow Rate — 225 CFM
Approvals —UL®E191535
Power — 115 VAC, 50/60 Hz, 0.6 amps
2
SERVSHIELD

3
SERVSHIELD
19" EIA M6
mounting rails
30"
Front view
17.876" opening
18.312" centers
31"
opening
25.75"
opening
17.876"
opening
18.312"
centers
19" EIA M6
mounting rails
Figure 1-1. Front Dimensions.
NOTE
The front door has been removed for clarity.

SERVSHIELD
4
36"
72"
Side view
Figure 1-2. Side Dimensions.
NOTE
The side panel has been removed for clarity.

SERVSHIELD
5
2. Introduction
2.1 Description
The ServShield protects your computer hardware in manufacturing environments and other industrial areas
subject to harsh conditions.
The cabinet is constructed of steel and it holds 600 lb. (272 kg)of equipment. The cabinet is preassembled, so
it’s easy to set up and use. Cabinet components include: upper, clear Plexiglas®door; isolated, steel middle
keyboard drawer; steel, perforated lower front door with dust filter; steel rear door furnished with fan assembly
and dust filters; a gland plate (12"L x 2.5"W [30.5 x 6.4 cm]), which provides cable access on the bottom of the
enclosure; one vented stationary shelf for mounting the monitor (200-lb. [90.8-kg] weight capacity); rubber
feet; and leveling glides. All doors have compression latches and locks. Cabinet dimensions are 72"H x 30"W x
36"D (182.9 x 76.2 x 91.4 cm).
The top Plexiglas door, middle keyboard door, bottom front door, and rear door are keyed the same.
2.2 What’s Included
• ServShield unit (assembled)
• (4) sets of keys
• (30) M6 cage nuts
• (30) M6 screws
• This user’s manual
2.3 Options
You may also need the following:
• 19" (48.3 cm) Sliding, Adjustable Tower Shelf (RM471)—At 19" (48.3 cm) high and 22" (55.9 cm) deep,
this shelf holds network hardware weighing up to 110 lb. (49.9 kg).
• Fan assembly (RF207)
• Rear door fan filter (RM475)
• Front door filter (RM476)
• Power strip mounting brackets (RM3055)
SERVSHIELD

SERVSHIELD
6
3. Installation
3.1 Leveling the Cabinet
ServShield cabinets are shipped with both casters and leveling glides for your convenience. Two casters have
brakes that you can activate by turning the brake level on the side of the wheel. You can lower the leveling legs
by turning the leveling glide to the proper height using a 3⁄4" open-ended wrench.
3.2 Removing the Doors
The top and bottom front doors and the rear door are removable. To remove a door, open the door beyond 90
degrees. Then grasp the door with both hands, and carefully lift upward. When the door is free of the hinge
pins, pull the door away from the enclosure. To attach the door, align all of the hinges (two on the front doors
and three on the rear door) and slowly slide the door down until seated.
3.3 Fan Assembly (RF207) and Rear Door Fan Filter (RM475)
The fan assembly is already installed in the rear door. The part number for the rear fan filter is RM475. If you
need to replace a filter, follow these steps:
1. Replace one filter at a time. The 12 screws, which hold the filters in place, are the only thing holding on
the fan assembly. If you replace one filter at a time, you only have to remove four screws at a time so you
don’t have to remove the fan assembly.
2. Remove the fan filter cover—it snaps off.
3. Remove the four #8-32 x 3⁄4" screws holding the filter on the door.
4. Replace the filter, using the same four #8-32 x 3⁄4" screws.
5. Replace the fan filter cover.
6. Repeat steps 2 through 5 for the remaining two filters.
SERVSHIELD

SERVSHIELD
7
Figure 3-1. Replacing a Rear Door Fan Filter.
Rear Door
Fan Filter Cover
Fan Grill (3)
#8-32 x 3⁄4" self-drilling
and tapping screws (12)
Fan Assembly
(RF207)

SERVSHIELD
8
3.4 Front Door Filter
You can easily remove the filter on the front door to clean or replace it. The part number for the front door
filter is RM476. To remove the filter, remove the two wing nuts on the top of the filter, swing the filter bracket
down and remove the filter.
The life of the filter depends on the environment the ServShield is installed in. You can vacuum the filters or
wash them in warm water with mild detergent. We recommend vacuuming the filter to keep it in peak
condition. If you choose to wash the filter, do so only once and replace it with a new filter when it gets dirty
again.
Bottom
Front Door
Filter
Filter Bracket
Wing Nut
Figure 3-2. Replacing the Front Door Filter.
SERVSHIELD

SERVSHIELD
3.5 Mounting Rails
Two pairs of vertical M6 steel mounting rails are in the top and bottom of the ServShield enclosure. The upper
rails have 14U (24.5") of rack mounting space and the bottom rails have 17U (29.75") in the front and 23U
(40.25 cm) in the rear of rack mounting space.
M6 rails
M6 rails
Figure 3-3. Mounting Rails.
9
